D+H RZN 43-E Series User manual

Gebrauchsanleitung
99.821.70 3.5/01/12
housing
transformer
rail
cable duct
cable ducts
motherboard with rectifier card
and power supply plug-in unit
keys
Smoke Vent Control Panel RZN 43xx-E
Installation
Safety system protects human life and material assets!
A specialist company authorised by the manufacturer should carry out connection, installation and annual
service.
Green control diodes in the buttons must be alight all the time, otherwise see "Trouble shooting".
Repair power failure immediately. Emergency power supply available for 72 hours.
Instruction for use
instruction for use
Smoke vent control book
Fig.: RZN 43xx-E6
D+H service and sales partners
Installation and operation
Safety in the building not only comes from the product. Above all, safety
results from competence. All D+H service and sales partners are certified
and regularly trained specialist SHEV businesses. Working closely with
D+H Mechatronic AG as the manufacturer, they develop comprehensive
system solutions for SHEVs and natural building ventilation. With integral
customer support and continuous quality assurance in all phases of the
project: from sales advice, planning and project management through to
installation, commissioning, repair and service. The highest national and
international quality standards are therefore reliably fulfilled.
The comprehensive network of D+H service and sales partners is at your
disposal to professionally install your system and commission it. Our partner
system guarantees that D+H products are installed exclusively by trained
and experienced fitters, in compliance with the technical guidelines and
specifications. Personal handover and training for users is included.
Maintenance and repair
Quality with guarantee
Always nearby
www.dh-partner.com
Every building operator is responsible for ensuring that its safety equipment
works reliably. Regular and professional maintenance ensures that your
system is always operational. As specialist SHEV businesses, the D+H
service and sales partners are best qualified to carry out maintenance. By
taking out a maintenance contract, operators can prove at all times that they
have fulfilled their obligations.
For all D+H SHEV systems, which have been installed by a D+H service and
sales partner and are regularly serviced, you will receive extended warranty
services.Ask your local D+H service and sales partner about this.
With the network of our own subsidiaries and exclusive partners, we are
represented nearly all over the world.
Are you looking for your local D+H partner?
Simply visit our website:
Introduction

min
15
2
45 30
sec
20
2
60 40
OK
AUTO
M
2/16
RZN 43xx-E
99.821.70 3.5/01/12
Weather automatic switched on
Technical Data
Type of control panel RZN 4308-E RZN 4316-E RZN 4332-E RZN 4364-E
Protection class I
Ingress protection IP54
Class of rating
- Monitoring Continous duty
- Alarm / ventilation short-time duty
Output voltage 24VDC / residual ripple 48%
Safe output
- running current of drives
- rated current of drives
Housing sheet steel
colour of housing RAL 7035; light grey
Rated voltage 230 VAC, 50Hz 230 VAC, 50Hz 230 VAC, 50Hz 230 VAC, 50Hz
Rated power 240 VA 500 VA 1000 VA 2000 VA
Stand-by operating ca. 10,4 W ca. 11 W ca. 16,2 W ca. 26 W
Interfering emission DIN EN 55011; DIN EN 50081-2
Resistance to jamming DIN EN 61000-4 -2, -3, -4
Temperature range -5 bis +40 °C
6,4 A 12,8 A 25,6 A 51,2 A
8 A 16 A 32 A 64 A
Housing dimensions ...-E6 500 x 500 x 210 ...-E6 500 x 500 x 210 ...-E6 600 x 600 x 210 ...-E12 800 x 1000 x 300
...-E9 600 x 600 x 210 ...-E9 600 x 600 x 210 ...-E9 600 x 600 x 210 ...-E15 800 x 1000 x 300
...-E14 600 x 600 x 210 ...-E14 600 x 600 x 210 ...-E14 600 x 800 x 250 ...-E20 800 x 1000 x 300
≈
Automatic temperature control
Signal "rain"
Signal "wind-force switchpoint"
Guarantee
You will get guarantee for all D+H products from date of verified
handing over of the system up to maximal 3 years after date of delivery,
when mounting and starting has been carried out by a D+H authorized
.
D+H guarantee is expired, with connection of D+H components with
external systems or with mixing of D+H products with parts of other
manufacturers.
2 years
distributor
Maintenance
Once a year by a specialist company authorised by the equipment
manufacturer.
- Renew test badge.
- Update logbook.
The respective current D+H maintenance instructions should be followed.
A D+H authorised company has been specially trained by D+H for carrying
out this maintenance competently and will be automatically provided with
the latest maintenance instructions.
Following tests must be carried out during maintenance:
- External examination and inspection of system components
- Measuring of insulation resistances
- Checking of all relevant power supply units.
- Functional testing of connected system components.
- Logging the competent execution of maintenance and identification
thereof in accordance with directions.
Important Regulations
Regulations for Hazard detection systems VDE 0833, Guidelines for
electrical systems VdS 2221, VDE 0100, DIN 18232 for smoke and heat
ventilation systems, regulations from the local fire-authorities and from
energy supply company, for mains supply connection must be observed.
Pictograph Explanation
Smoke and heat vent alarm
Control panel O.K.
Fuse drive
Power supply
Vent button function “OPEN”
Vent/ smoke vent function “CLOSE”
Fault
Battery fault
Charging voltage controller
Check pins ground fault
Regulator for wind-force switchpoint
Regulator for signal storage time
Ground fault
Smoke detector / fuse
Smoke-vent button / fuse
Window-lock group / fuse
Stroke-instantaneous value in per cent
Hysteresis
Regulator for Ventilation time
Regulator for OPEN running time
Automatic weather control activated
24 V - Emergency Supply
Emergency power supply for 72 hours.
Use only VdS approved accumulators.
: 2 x accumulator type 3 (12V, 7,0Ah ± 15%)
: 2 x accumulator type 4 (12V, 12Ah ± 15%)
: 2 x accumulator type 5 (12V, 18Ah ± 15%)
: 2 x accumulator type 6 (12V, 26Ah ± 15%)
RZN 4308-E
RZN 4316-E
RZN 4332-E
RZN 4364-E
Content
Maintenance/ Guarantee/ Pictograph / Technical Data / Emergency Supply . . . 2
Motherboard / General Plug-in ..................................3
Optional Functional Extension / Wiring plan / 230V Connection ..........4
Supply plug-in card VE 520 / VE 530 ...............................5
Line plug-in card LE 513 ......................................6-7
Group plug-in card GE 628 (-L) V2 ...............................8-9
Servo plug-in card SE 622 ...................................10-11
Weather plug-in card WE 516...................................12
Window-lock plug-in cardAE 525-AandAE 526-DG...................13
Trouble shooting............................................14
Examination...............................................15

OK
RZN 43xx-E
3/16
99.821.70 3.5/01/12
GKS
567
566
NBE
N+
24V=
VE
530
Service
USB/PC
F3,15A
F1,25A
F0,125A
Motherboard
1234567
N
-N
+
S
S
t-
S
A
L+
KZ Z
E1
1234567
N
-N
+
S
S
t-
S
A
L+
KZ Z
E2
1234567 1234567 1234567 1234567 1234567 1234567
8 9 10 11 8 9 10 11 8 9 10 11 8 9 10 11 8 9 10 11 8 9 10 11
Bez.:
Bez.:
Bez.:
Bez.:
Bez.:
Bez.:
Bez.:
Bez.:
Bez.:
Bez.:
Bez.:
Bez.:
GK VE
Trafo
Trafo
+
+B
-
ERDA
E3
E4
optional functional extension by modules
slots E1 and E2
earthing
optional functional extension by modules
for extension of control panel
(ribbon cable required)
fire recognition
element
(thermal maximum
detector) *
free slots for LE/ GE/ WE/ AE/ SE 622
battery
connection
rectifier card GK
power supply
plug-in unit VE
* Monitoring the inner temperature of the controller.An emergency opening of the complete smoke and heat
ventilation system, under alarm conditions, will occur if the inner temperature exceeds 72°C, caused by the radiant
heat from a fire in the immediate vicinity of the installation location.
VE
530
Service
USB/PC
F3,15A
F1,25A
F0,125A
Rectifier card GK
1 x per control panel
2 x per control panel
up to an overall power of 32A
or
up to an total current of 64A
(2 motherboards).
Supply plug-in card
VE 520 / VE 530
1 x per control panel
Monitoring of
- grid
- battery voltage
- battery charging voltage
- earth leakage protection.
Stabilization GKS 567 *
to stabilize the output voltage when
connecting an external drive.
Output current : 16A
Output voltage : 24VDC ±10%
Residual ripple : 10%≤
Mains-battery-plug-in unit NBE 566
Stabilization GPS 566/32 *
to stabilize the output voltage when
connecting an external drive.
Output current : 32A
Output voltage : 24VDC ±10%
Residual ripple : 10%≤
Stabilization GPS 566/64 *
to stabilize the output voltage when
connecting an external drive.
Output current : 64A
Output voltage : 24VDC ±10%
Residual ripple : 10%≤
General plug-in

* RZN 4308-E = T 2 A
RZN 4316-E = T 2,5 A
RZN 4332-E = T 6,3 A
RZN 4364-E = T 10 A
*
4/16
RZN 43xx-E
99.821.70 3.5/01/12
230 V, 50 Hz
Seperate electric circuit.
Mark fuses.
to further ones
see line lenghts and cross sections
Drive at smoke
vent opening SHEV control panel
vent button
ca. 1,2 m above
upper edge
firm flooring
smoke vent button
ca. 1,5 m above
upper edge
firm flooring
external control
fire detector
FO 1362 or FT 1262
4x 0,8 Ø
8x 0,8 Ø (RT 45)
10x 0,8 Ø (RT 45-LT)
8x 0,8 Ø (RT 45)
10x 0,8 Ø (RT 45-LT)
2x 0,8 Ø
2x 0,8 Ø
OK
OK
rain sensor
4x 0,8 Ø
3x 1,5 mm²
Wiring plan (Paragon)
System voltage 24 V!
Do not run cables with together power lines!
In case of a cable with (green / yellow)
this must !
Cable and terminal boxes have to be labeled.
ground wire
not be used
Slot E1 / E2
AM 44-Z Alarm-cutoff module
TR 42 Cutoff relay module
WFR 41 Weather-stepping-relay
Slot LE
IM 44-E Impulse module
UM 41-Z Transmission module
for sirens, fire bells and flashing lights
for remote indication of fault or alarm
for connecting of several D+H smoke
vent control panels on a wind/ rain
detector
Triggering of alarm and reset from BMS
or series connected smoke vent system
for RT 42-Z
Slot GE
AT 41 Drive starting time-lag module
in conjunction with shading systems
Optional Functional Extensions
Connection 230 V
Plan separate electric circuit.
Mark fuses.
Connecting cable: NYM-I 3x1.5
Connected load: RZN 4308E = 240 VA,
RZN 4316E = 500 VA,
RZN 4332E=1kVA,
RZN 4364E=2kVA.

RZN 43xx-E
5/16
99.821.70 3.5/01/12
VE
530
Service
USB/PC
F3,15A
F1,25A
F0,125A
123456
X5
12
RM RT
LE
345678
-
RT 45
RT 45
10kW
-
n.c.
275 83164
n.c.
-
23164
8
75
X5/VE
123456
LT Out 1
LT In 1
LT Out 2
LT In 2
LT 43 (-SD)
–N
–N
5671234
LT MOT
LP
GE
LT 43
LP
X5/VE
123456
LT Out 1
LT In 1
LT Out 2
LT In 2
alarm
Supply plug-in card VE 520 / VE 530
Servicetimer:
An overdue maintenance of the system will be indicated by the control
panel after about ca. 14 to 16 months. If connected to "Malfunction 1" or
"Malfunction 2" the yellow LED in the RT 45 will start flashing.
A malfunction of the smoke vent system will be still indicated by the
extinction of the green LED in the RT 45.
The ventilation function OPEN can be interrupted for up to 2 groups via
the connections "LT In" and "LT Out" after the maintenance time is
expired. This function can be deactivated via the servicetool.
Attention: Reset of the service timer can be carried out by a
specialist company only, who has been authorized by the appliance
manufacturer.
close
red
green
yellow
line
control
close
control
line
line
malfunction
close
malfunction
line
control
close
Malfunction 1
Malfunction 2
Smoke vent button
Connecting the
RT 45 malfunction LED
for displaying the
servicetimer
close
open
close
open
open signal (only -SD)
Malfunction 1
Malfunction 2
Vent button
Interruption of the
vent button function
OPEN after the
servicetimer
elapsed
Supply plug-in card
VE 520 / VE 530
1 x per control panel
VE 520 : Control panels up to 16 A
VE 530 : 32 AControl panels from
Monitoring of
- Grid
- Battery voltage
- Battery charging voltage
- Earth leakage protection.
Integrated Servicetimer
- Programmable interval
- 2 Malfunction outputs (e.g. for RT 45)
- 2 floating outputs for disconnecting the ventilation function
- Reset via PDA-Servicetool or BI-BT 2
Functions:
Malfunction 1
Malfunction 2
LT Out 1
LT In 1
LT Out 2
LT In 2
alarm alarm
alarm

12345
ON
513
LE
0
I
F1,25A
TEST
F0,125A
F0,125A
6/16
RZN 43xx-E
99.821.70 3.5/01/12
Detector Cables (Line):
The detector cables are monitored for short
circuit and break.
The opening device is automatically triggered
and opens up in the case of a fault, if DIP-switch
1+2 are set to ON.
Smoke vent button cable and cable from
automatic detectors:
- Weak current sheathed flexible cable YR 6 x
0.8
or
- Domestic wiring cable IY(ST)Y 4 x 2 x 0.6
Encoding LE 513
Following functions can be encoded on the plug-in board using the DIP-switch.
In the case of a group fault (e.g. with broken motor line or missing end module) the control panel will be
switched to alarm i.e. the smoke vent opens.
In the case of a line fault (e.g. with interrupted button line or missing terminal resistor) the control panel will be
switched to alarm, i.e. the smoke vent opens.
Smoke detector alarm cannot be reset pressing the button in the smoke vent button once. DIP-switch 3 must be
switched to OFF if you want to carry out a remote reset of smoke detectors via the smoke vent button. Should only be
used if DIP-switch 4 and 5 = OFF.
Groups and lines connected in series will be released in the case of an alarm.
Every previous plug-in slot for the triggering line and group must be occupied. Both the lines must be
switched OFF/ON for “Smoke Detector Reset” at the control panel.
This line is released by a line connected in series.
Every previous plug-in slot after the releasing line must be occupied! Both the lines must be
switched OFF/ON for “Smoke Detector Reset” at the control panel.
DIP-switch 1 on ON =
DIP- 4 on ON =
Dip- 5 on ON =
DIP-switch 2 on ON =
DIP-switch 3 on ON =
switch
Important:
switch
Important:
- line plug-in card for connecting of
maximum 14 fire detectors and 8
smoke vent buttons each
-
- line On/ Off
- alarm/ fault
Functions:
DIP-switch
factory setting
Connection RT 45 on LE 513 and connection GE 628 (-L) V2
1122
RM RM RT
LE
3
145678
X5
external
control fire
detector
type***
operating
contact
alarm resistor
10k *W
10kW
1kW
out
out
in
in
last
first to
penultimate
line
line
–
–
line
Malfunction 1
-
control
alarm
close
smoke vent button
RT 45
RT 45
10kW
alarm
control
-
line
line
malfunction
n.c.
close
275 83164
alarm
zu
red
green yellow
malfunction
n.c.
line
-
control
alarm
close
23164
8
75
10k *W
< optional >
Line plug-in card LE 513
Vent button drives*
LT 43 (-SD)
EM 47 K
terminal module
lenght of line and cross
sections, see page 9
close
–N
OPEN signal
open
close
OPEN signal (only -SD)
–N
open
monitoring
Mot.a
Mot.b
5671234
LT MOT
LP
GE
black
black
orange
2x47kW
branch
box by customer
first to
penultimate
drive
LT 43
LP Mot. b
-HS*
Mot. a
* For detailed information concerning the connection,
please refer to the instruction for use of respective drive.
last
drive
Mot. b
-HS*
Mot. a
VE

RZN 43xx-E
7/16
99.821.70 3.5/01/12
12345678 1
RM
LE
RT X5
line
line
–
–
control
alarm
close
Smoke vent button
1st line
Smoke vent button
2nd line
RT 45 RT 45
RT 45
RT 45
10kW
10kW
alarm
alarm
control
control
-
-
line
line
line
line
malfunction
n.c.
malfunction
n.c.
close
close
22
7575
8833116644
alarm
alarm
close
close
red
red
green green yellow yellow
malfunction
n.c.
malfunction
n.c.
line
line
-
-
control
control
alarm
alarm
close
close
2233116644
88
7575
last smoke
vent button
each
first to
penultimate
smoke vent
button each
Malfunc-
tion 1
shunt connection
by customer
Line plug-in card LE 513 (continuation)
Parallel connection of RT 45 on LE 513
* Terminal resistor for line monitoring:
** Maximum total cut-off current
of connected drives:
*** Fire detectors
**** Thermal fire recognition element,
They are secured in the control panel for transport.
Take them out and connect them in accordance with the plan.
The must remain in terminal clamp L 1,2 if no fire
detector or external control is present.
RZN 4308-E = 8A
RZN 4316-E = 16A
RZN 4332-E = 32A
RZN 4364-E = 64A
No more than 10A on one group plug-in card.
Only D+H - approved detectors permissible.
optional, is required by some fire authorities.
Terminal resistor
VE

min
15
2
45 30
sec
20
2
60 40
628 V2
GE
M
F8,0A
min
15
2
45 30
sec
20
2
60 40
12345678910
ON
8/16
RZN 43xx-E
Encoding GE 628 (-L) V2
Attention:
When group-DIP-switch 8 is ON, the smoke vent is re-triggered during a period of 30 minutes at intervals of 2 minutes in accordance with VdS
2581, based on the set alarm direction (see DIP-switch 6). Therefor, the drive must be safeguarded against blockage in accordance with VdS 2580
Part 4.7. . All D+H drives meet this precondition. Otherwise DIP-switch 8 must be switched on OFF.
Group plug-in card GE 628 (-L) V2
GE 628-L V2
- drives up to max. 10A can be connected to
a group plug-in card
- possibility of combination with further
groups
- adjustable ventilation time limitation and
OPEN-running time limitation
- for control of ventilation drives
DIP-switch
factory setting
Group plug-in card GE 628 (-L) V2
Only possible if DIP-switch 4 = ON (memory mode in CLOSED-direction). Ventilation time can be
set by using a potentiometer.
The drives / NSHEVs will automatically close again, after the set time has expired.
Only possible if DIP-switch 1 = ON (OPEN-running time limitation).
If DIP-switch 1 is switched to ON, the OPEN-running time limitation can be re-triggered again.
Press vent button once briefly. > The drives / NSHEVs will close to their final position.
The drives / NSHEVs will close as long as the vent button is pressed.
Press vent button once briefly. > The drives / NSHEVs will open to their final position.
The drives / NSHEVs will open as long as the vent button is pressed.
The drives/ NSHEVs will close in the case of alarm.
Only possible if DIP-switch 4 = ON.
In the case of power failure, the drives/ NSHEVs.
.
During a period of 30 minutes, the smoke vent is triggered
at intervals of 2 minutes in accordance with VdS 2581.
The group plug-in card can be triggered in OPEN-direction viaAz signals.
The group plug-in card can be triggered in CLOSED-direction via Zz signals.
GE 628 V2 GE 628-L V2
DIP-switch 1 on ON OPEN-running time limitation in ventilation operation
DIP-switch 2 on ON Ventilation time limitation
DIP-switch 3 on ON OPEN-retriggering
DIP-switch 4 on ON Storage operation in CLOSED-direction
DIP-switch 4 on OFF Tip operation in CLOSED-direction
DIP-switch 5 on ON Storage operation in OPEN-direction
DIP-switch 5 on OFF Tip operation in OPEN-direction
DIP-switch 6 on ON Group CLOSE in case of alarm - no function -
DIP-switch 7 on ON Power failure-CLOSE - only function, if control panel
has emergency
power supply -
DIP-switch 8 on ON Alarm re-triggering - no function -
DIP-switch 9 on ON
DIP-switch 10 on ON
If the vent button is actuated in OPEN-direction, the drives/ NSHEVs run for
the duration of the running time.
will close
(If for example a rain detector is connected,
the switch must be ON, otherwise no closing will take place.)
Only possible if DIP-switch 5 = ON (Storage operation in OPEN-direction).
Running time in OPEN-direction can be limited by using the potentiometer.
GE 628 V2
High-Speed function:
- for control of smoke and heat ventilation
drives in conjunction with the line plug-in
card LE 513
- Smoke and heat ventilation re-triggering
function
- group-fault display
- power failure-CLOSE function
All D+H drives with SHEV high-speed function
are supported. In daily ventilation operation, a
considerable noise reduction is achieved
through the reduced drive speed. In case of
SHEV the drives run - triggered through the
orange monitoring line - with a very high speed
to reach the OPEN position defined within 60
seconds at the most.

RZN 43xx-E
9/16
Connection GE 628 (-L) V2
- Supply wires
and branch off parallel
- is looped through
all the cables up to the group end.
Mot. a Mot. b
Monitoring
Connection in case of line branch (GE 628 (-L) V2)
The smoke vent control panel is designed for opening smoke vent devices,
which operate by thermal lifting and through automatic fire recognition
devices (thermal detector, smoke detector). They are triggered either
automatically or manually by smoke detectors at an early stage of a fire and
remain in an opened position without further power consumption. In such a
case, the functional retention of the electrical system is only required at the
early stage of fire. Secured wiring with protection against mechanical
damage is required in accordance with DIN 18232 Part 2.7.2.4.
Cable from the Smoke and heat vent control panel to connect the drive.
Drive lines have a monitoring wire in which fire recognition devices (thermal
maximal detector e.g. THE) can be looped-in:
- standard guidelines for line systems MLAR or safety line with function
retention ... E30, installed in accordance with DIN 4102*.
An increased cable function retention time may be required when drive lines
are installed through areas of the building which are not monitored.
- standard guidelines for line systems MLAR or safety line with function
retention ... E90 installed in accordance with DIN 4102*.
Control cable (Group):
Cables through non-monitored areas:
* Please note: No type designation is given for these cables because of a
large variety on the market. Please consult your D+H distributor about
these.
! The earth conductor must not be wired !
cross section (mm²) =
80
* Connect in parallel 2 wires for each drive line.
** Connect in parallel 3 wires for each drive line.
simple cable length (m) x total current
total
consumption 12345678910A
3x1,5 mm² 120 60 40 30 24 20 17 15 13 12 m
3x2,5 mm² 2001006550403328252220m
*5x2,5 mm² 400200130100806556504440m
**7x 2,5 mm² 600 300 200 150 120 100 85 75 67 60 m
Cable for GE 628 (-L) V2
Connection examples (GE 628 (-L) V2)
control
panel M
25m
3 x 2,5²
MMMMMMM
Example 1:
1 line
Simple wiring, however unfavourable for voltage drop:
All drives on one cable.
Example 2:
2 lines
Control panel in the centre, one side wired as branch, the other one as
terminal line. 4 wires are required for each branch!
Example 3:
2 lines on one side
Branch and terminal line in same direction.
Number of drives varies in accordance with lengths of lines. 4 wires are
required for each branch!
Example 4:
3 lines
Three cable runs are provided because of the very long distances:
2 cable runs with 3 drives each over 65 m line as branch and 1 cable run with
2 drives over 200 m line. 4 wires are required for each branch.
Group plug-in card GE 628 (-L) V2 ( )continuation
M
50m
3 x 2,5²
4 x 2,5²
branch box
50m
MMM MMMM
control
panel
M
control
panel
65m
40m
4 x 2,5²
3 x 2,5²
MMMM MMM
branch box
M
65m 65m
200m
4 x 2,5² 4 x 2,5²
5 x 2,5²
MMMMMMM
control
panel
branch box
 
control panel
Mot. b
765
Mot. a
monitored


Mot. a
Mot. b
Mot. a
Mot. b
branch box
on motor
branch boxbranch box
branch box
on motor
switch further
branchings
alike
Vent button drives*
LT 43 (-SD)
EM 47 K
terminal module
lenght of line and cross
sections, see page 9
close
–N
OPEN signal
open
close
OPEN signal (only -SD)
–N
open
monitoring
Mot.a
Mot.b
5671234
LT MOT
LP
GE
black
black
orange
2x47kW
branch
box by customer
first to
penultimate
drive
LT 43
LP Mot. b
-HS*
Mot. a
* For detailed information concerning the connection,
please refer to the instruction for use of respective drive.
last
drive
Mot. b
-HS*
Mot. a

622
12345678
ON
10/16
RZN 43xx-E
99.821.70 3.5/01/12
The servo plug-in unit SE 622 is used as interface
module between Building Management System
(BMS) or Central air conditioning plant (ZLT) and
D+H Smoke extraction and vent system RZN
43xx-E. The unit is to convert an analogue preset
value from the BMS into a drive stroke between 0-
100% in conjunction with D+H drive with option
"-SGI". Opening width can be steplessly
controlled, depending on the BMS input value.
For the function of the SE 622, are
additionally required to the drive with position
indicator for actual value feedback.
Cable connection BMS - servo plug-in unit:
- provide 2 wires Ø 0,8 mm per servo plug-in
unit.
- one group plug-in unit is required per servo
plug-in unit.
- all connected drives must have the same
stroke.
- Safe closing of all drives when the setpoint
value from the BMS < 5 %.
two wires
Servo plug-in card SE 622
Technical Data:
System requirements : RZN 43xx-E /
GVL 83xx-E
in conjunction with
D+H drive with
option "-SGI"
or ZA...-SG
Input (BMS) : selectable 0 -10V
or 0-20mA
or 4-20mA
Input impedance : voltage = 50 k
current = 50
Hysteresis : adjustable 2-10%
Output :- 0 or 24VDC, only in
conjunction with
GE 628 (-L) V2
- 0-10 V current position
- max. 5 SE 622 per
control panel
Ω
Ω
Functional description
Factory settings
(0-10V)
SG SGI
ON
123456781 2 3 4 5 6 7 8
Function:
Power failure-synchronisation
Triggering is effected as analogue setpoint value
via a 2-wire circuit. Either current-controlled with
values 0 - 20 mA, 4 - 20 mA or voltage-controlled
with values 0 - 10V. This corresponds to an
opening width of 0 - 100%. BMS input is
electrically isolated from the D+H-system
voltage.
The servo plug-in unit compares the setpoint
value from BMS with the actual value of the drive
and operates the drive to the desired position,
using the group plug-in unit. The servo function
can be switched off at the plug-in unit or by
remote control. Then the drive group can be
manually opened or closed by built-in vent
buttons or external vent buttons LT. The actual
value can be checked on a digital display on the
plug-in unit. The feedback to the BMS is provided
as analogue signal with values 0 - 10 V.
The servo function is overridden in the case of an
alarm from the Smoke and heat vent system. The
function “Master CLOSE“, e.g. in the case of rain
or a timer, has a higher priority than the servo
function and can be activated by DIP-switch (5).
The drives are automatically closed in the case of
wire break or short circuit on the setpoint value
wire.
After a power failure with the DIP switch No. 6
switched to ON, the drive will go to its position
CLOSED in order to be able to open again up to
the given value (e.g. 50% from the BMS) in the
Attention!
Encode only, if unit is not plugged-in.
OPEN direction, after the power failure has been
resolved.
The drive is controlled
automatically, so there is a potential source of
danger of pinch or shear points in the area of the
drive. With the factory-setting “OFF“, the drive
must run to position „CLOSED“ after a power
failure, via a vent button with visual contact to the
drive. For this, the automatic operation of the
servo plug-in unit SE 622 must be switched OFF
beforehand.
are
equipped with a digital pulse generator. The
servo plug-in unit must know the total pulse
number of the drive so that the setpoint value
from the BMS can be equally distributed over the
opening width. For this purpose, there is an
operating mode “Measure opening width“.
The clamps 8 + 9 (-N + Auto I/O) must be bridged
on the plug-in slot of the servo plug-in unit for the
activation of this operating mode.
Please note:
D+H Drives with the option "-SGI"
This operating mode is activated with reset button
(S4). The button (S4) must be activated for at
least for 7 seconds.
Auto I/O
-N
SE 622
RZN 43xx-E / GVL 83xx-E
10 11 34 5 7689
0
min. 7 sec.
Please note:
The drives of type ZA...-SG
Attention!
In this mode, the drive will run over
the entire stroke length in the OPEN and in the
CLOSE direction. A stop is not possible at this
time.
The measured stroke will be saved in the SE 622.
are equipped with
an analogue position indicator. The servo
plug-in unit compares the set value of BMS
with the actual value of the drive, and directs
the drive to the desired position using the
group plug-in unit.
The SE 622 is not compatible with the
SE 621! (Observe connection diagram!)
Encoding SE 622
S2
S6
S4
Master CLOSE funct.
ZA...-SG
Drive with "-SGI"
Input 4-20 mA
Input 0-20 mA
Input 0-10 V
1
OFF
ON
ON
ON
ON
ON
2
ON
OFF
OFF
OFF
345678
Power failure sync.
OFF
OFF
ON
S2 S6
SGI
SG
no function

RZN 43xx-E
11/16
99.821.70 3.5/01/12
Servo plug-in card SE 622 continuation()
Connection SE 622
Optional with manual control
SG SGI
ON
12345678
LT43U-W
PPS
0-10V
0-20mA
4-20mA
BMS
Mot.b
Mot.a
monitoring
open
close
-N
open signal
Auto I/O
+SG(I)
-SG(I)
-N
IN+N
-BMS (in)
+BMS (in)
open
-BMS (out)
close
+BMS (out)
Zz
K
SA1
-
SSt
+N
-N
1
GE 628 (-L) V2
SE 622
RZN 43xx-E / GVL 83xx-E
E 1/2
234 567
1233
1
442 55 67 76891011
+SG(I)
monitoring
Mot.a
Mot.b
drive with -SGI
or ZA-SG
-SG(I)
black
black
orange
2x47kW
branch box
by customer
terminal module
EM 47 K
LT
MOT
Mot.a
Mot.b
-HS
-SG(I)
+SG(I)
SGI
0-10V
0-10V
SG
0-10V
0-20mA
4-20mA
BMS
Mot.b
Mot.a
monitoring
open
close
-N
open signal
Auto I/O
+SG(I)
-SG(I)
-N
IN+N
-BMS (in)
+BMS (in)
open
-BMS (out)
close
+BMS (out)
Zz
K
SA1
-
SSt
+N
-N
1
GE 628 (-L) V2
SE 622
RZN 43xx-E / GVL 83xx-E
E 1/2
234 567
1233
1
442 55 67 76891011
+SG(I)
monitoring
Mot.a
Mot.b
drive with -SGI
or ZA-SG
-SG(I)
black
black
orange
2x47kW
branch box
by customer
terminal module
EM 47 K
LT
MOT
Mot.a
Mot.b
-HS
-SG(I)
+SG(I)
SGI
0-10V
0-10V
SG

F0.125A
F0.125A
F1.25A
F6.3A
TEST
516
12/16
RZN 43xx-E
99.821.70 3.5/01/12
- weather plug-in card for
- wind-/ rain transmitter
- central vent button
- temperature control
- weather automatic On/ Off
- operational control central
Open/ Close
- wind force sensitivity adjustable
- signal retention time adjustable
- wind/ rain indication Closed
- Functions:
You can select an infinitely variable wind-force setting between 2 and 8 on
the Beaufort scale using the regulator on the plug-in unit. As soon as the
wind force reaches the set value (time lag of a few seconds), the signal is
displayed on the plug-in card and, if available, on the control panel.
If the automatic weather control is ON, the system closes automatically. This
is given priority, even over an attempted opening by temperature control.
The wind signal remains active for an adjustable length of time to prevent
continuous actuator operation during gusty wind conditions. The regulator
on the plug-in unit can be used to select the infinitely adjustable signal
storage time between 1 and 15 minutes.
Encoding WE 516Weather plug-in card WE 516
Connection WE 516
LT 43-W
close
–N
open
P PS
ZZ2
–N
ZMP1
ZMP2
1234567891011
WE 516
rain
wind
wind
–
+
124357689
R
W
WRG 82
S 1/1
S 1/2
P3 P4
rain
+
wind
–N
AZ
ZZ1
–T
ITR 79
1
6
2
7
4
35
230VAC
5
13
RTR 230 *
open
close
-
potential free
wind/rain indication to
further control panels
max. 60V / 1A
Function WE 516
Automatic rain control:
Automatic temperature control:
Manual Control:
If the automatic weather control is on, the system will close automatically when it starts to rain. A signal, if available, will be indicated on module/ plug-in unit
and on the control panel.
To test, place a moist finger on the surface. Clean rain detector electrodes and insulator with mild soap water in the case of dirt accumulation and rinseoff
thoroughly.
Ventilation control is carried out by a room temperature controller, if available, and if the Automatic temperature control is switched on and if no wind / or rain
signal is indicated.
If a wind / or rain signal is present, this has priority and it will close the system.
The system fully opens or closes fully by pressing the or button once briefly .
Pressing both buttons at the same time or pressing the “Stop” button on the operator panel stops the system at any intermediate position.
Manual control is only enabled if no wind, rain or temperature signal is being processed or if the automatic control has been deactivated.

12
ON
F0.125A
F0.125A
F1.25A
F6.3A
TEST
AE
526-DG
12
ON
RZN 43xx-E
13/16
99.821.70 3.5/01/12
AE
525-A
0
I
F6,3A
F1,25A
TEST
F0,125A
- window-lock plug-in card for triggering of
max. 8 pressure-gas generators
- release via smoke vent buttons and/ or fire
detectors
- LE 513 is not required
Releases 1 2 4 8 16 24 30
cable 4 x 0,6 100 50 25 / / / / m
cable 4 x 1,5² 600 300 150 75 30 / / m
cable 4 x 2,5² 1000 500 250 125 60 45 30 m
Releases 1 2 4 6 8
cable 2 x 0,8 (2 x 2 x 0,6) 150 130 90 50 10 m
cable 2 x 1,5² 450 400 270 140 20 m
cable 2 x 2,5² 750 650 450 240 35 m
Pressure gas generators:
cross section (mm²) =
400
simple cable lenght (m) x no. of releases
Tripping devices:
Window-lock plug-in card AE 526-DG
- window-lock plug-in card for triggering of
max. 30 window-lock units of type ABF 12
- release via smoke vent buttons and/ or fire
detectors
- LE 513 is not required
Window-lock plug-in card AE 525-A
Function of DIP- switches:
S1-1 on ON failure = alarm
S1-2 -no function-
DIP-switch
factory setting
DIP-switch
factory setting
Function of DIP- switches:
S1-1 on ON failure = alarm
S1-2 -no function-
56712 3 4
10 11 89
AE 525-A
RZN 43xx-E
fire
detector
Smoke vent
button
type* RT 45
10k *W
10k *W
10k *W
out
out
in
in
line
line
+control
+alarm
closed
2
2
8
8
3
3
1
1
6
6
4
4
last or
single
first or
penultimate
RT 45
line
line
–
–
+control
+alarm
close
StL
A+
monitored
A-
OK
1
2
4
5
1
2
4
5
-
+
branch
box
M
M
ABF 12
ABF 12
-
+
Tripping devices
YR 0,8
YR 0,8 according to D+H table
for layout of cables
insert
bridge!
* fire detector
Only D+H approved
detector permissible
fire
detector
smoke vent
button
type* RT 45
10k *W
10k *W
10k *W
out
out
in
in
line
line
+control
+alarm
close
2
2
8
8
3
3
1
1
6
6
4
4
RT 45
line
line
–
–
+control
+alarm
n.c.
StL
+DG
monitored
-DG
56712 3 4
10 11 89
AE 526-DG
OK
branch
box
RZN 43xx-E
DG
DG
YR 0,8
YR 0,8
according to
D+H table for
layout of cables
last or
single
first or
penultimate
pressure gas generator
(max. 8 pce.)

14/16
RZN 43xx-E
99.821.70 3.5/01/12
Please check following points, if the smoke vent system fails to function satisfactorily or the green control LED in the button fails to lighten. Diagnosis must be
carried out in following order: 1st supply plug-in card VE, 2nd line plug-in card LE, 3rd group plug-in card GE, 4th window lock plug-in card AE, 5th smoke
detector and external control. Detected faults must be eliminated at once before the diagnosis is continued!
Trouble shooting
To test the function of the earth fault checkup, the diagnosis pins on the VE must be bridgeover.
If the LED does not light, it might be necessary to check the grounding and connect it correctly.
Symptoms
Supply plug-in card VE
Line plug-in card LE
Group plug-in card
Window-lock plug-in card
Smoke detector
External control
LED diode lightens.
LED diode lightens
LED diode fails to lighten
LED diode lightens
LED diode lightens.
LED diode lightens.
LED diode fails to lighten.
LED diode lightens.
LED diode lightens.
Pilot light extinguishes during closing
operation of drive, red LED diode
lightens, flap can't be closed.
Pilot light extinguishes during opening
operation of drive after approx. 20 seconds,
red LED diode lightens.
LED diode lightens.
LED diode lightens.
LED diode fails to lighten.
LED diode lightens.
LED diode fails to lighten.
Detector cannot be reset, though
there is no smoke existing.
Detector fails to respond, when
checked with smoke.
Smoke vent is opens without external alarm;
smoke vent can be reset again.
Smoke vent opens without external alarm.
Smoke vent cannot be reset again.
Smoke vent is not opening, though external
system gives alarm.
.
.
.
GE
AE
Remedy
Eliminate earth fault.
Check accumulator, connection and fuse.
Call in-house electrician immediately for eliminating
power failure.
Connect line.
.
1. Bridge diagnostic pin against middle pin on line
plug-in card.
Check fuse, connections, cables, t ,
clamps, smoke detectors and external control.
2. Bridge diagnostic pin against middle pin on line
plug-in card.
Check fuses, connections, cables, terminal resistors,
terminals and smoke vent buttons.
Check fuses, connections, cables, and t
on drive.
Check t or terminal module between
terminal and .
Check t or terminal module between
terminal and .
.
1. Bridge diagnostic pin against middle pin
on plug-in card
Check fuses, connections, cables, t ,
terminals, smoke detectors and external control.
2. Bridge diagnostic pin against middle pin
on plug-in card.
Check fuses, connections, cables, t ,
terminals and smoke vent buttons.
Check fuse, terminals and loop resistance.
Exchange detector.
Exchange detector.
In case of repetition, disconnect contact.
Search for fault in external system.
Disconnect temporary perhaps, so that the
smoke vent remains operative.
Search for interruption; check whether
contact in external system is really closing.
For exact diagnosis proceed as follows
57
56
For diagnosis proceed as follows
erminal resistor
erminal resistor
erminal resistor
erminal resistor
erminal resistor
erminal resistor
Causes
Earth fault.
Malfunction in accumulator
No 230V power supply available.
Line is disconnected
Malfunction in smoke detector or
smoke vent button line.
Malfunction in smoke detector line.
Malfunction in smoke vent button line.
Malfunction in group
Malfunction in group
Malfunction in group
Malfunction in plug-in card.
Malfunction in smoke detector line .
Malfunction in smoke vent button line
Malfunction in line to magnetic valve.
Detector is dirty or faulty.
Defector is faulty or wrong type.
External system gives possibly only short
contact by malfunction or has given alarm or
false alarm and has been unknown reset
again.
Ensure, that contact in external system is
opened. If external alarm is not resettable by
malfunction, search there for malfunction.
Main contact is not closing
.
.
.
.
.
RM
RT.
OK
OK

RZN 43xx-E
15/16
99.821.70 3.5/01/12
Every six months and after maintenance carried out by a specialist
engineer or trained staff.
Visual inspection:
Clamps and fastenings
Drives and smoke vent
Attention
Automatic fire detectors
Procedure in the case of alarm:
Do not carry out functional testing if
trigger plug-in card AE 526-DG is
installed for the control of 8 pressure
gas generators.
Closing after automatic release by smoke detector:
Procedure in the case of alarm with external control:
- Eliminate any errors immediately
- Fill out the logbook
- Advise that the system is going to be taken out of operation before starting
the inspection
- Inform the operating company that the alarm is going to be triggered for
equipment testing purposes
- Interrupt or turn off remote alarm reporting or remote control
Check all appliances and cable connections for outer damage and dirt
accumulation.
Fire detectors, smoke vent buttons, smoke vents and so on must not be
impaired in their function by goods in storage or structural changes.
-
Check connection terminals and fastenings of appliances that they are
securely seated.
-
In the case of excessive dirt accumulation and load, clean and re-grease
outer mechanically moved parts.
: Use only colourless fat-free Lusin A spray. Do not use any
grease so that dirt cannot stick.
-
In the case of severe externally visible dirt accumulation or false alarms,
send them in for maintenance and install an exchange detector. Check
detectors individually with D+H-smoke detector tester.
No possibility of functional testing. Triggering will lead to the destruction of
the pressure gas generators and sprinkler bottles as well as the emptying of
the CO cartouches. This will generate costs for exchange parts and the time
to install them. Shutdown of the system by a specialist company or trained
staff.
1. Open smoke vent button.
2. Open the system first with vent button and then close it again.
3. Trigger smoke detector with D+H-smoke detector tester.
4. Response delay approx. 20 seconds
5. Red display LED in the smoke vent button must light up.
6. Smoke vent opening must open.
1. Wait until there is no more smoke in detector. Switch the line on / off at the
control panel with reset button.
2. Press concealed button in smoke vent button; smoke vent closes.
3. Red display LED in button and on line plug-in unit goes out.
1. Trigger external control, if available.
2. Smoke vent opening must open.
2
Please note: Always activate another smoke vent button or smoke detector
for each line with every new test.
Closing after automatic triggering by external control:
Check alarm display and balanced running of all drives up to final
position.
Emergency supply:
Accumulator:
If the voltage of one
of the accumulators is less than 11V, both the accumulators must be
replaced.
1. Open contact in external system, e.g. by resetting the fire alarm system.
2. Press concealed button in smoke vent button; smoke vent closes.
3. Red display LED in button and on line plug-in unit goes out.
- Switch off main fuse at distribution box.
- Green control diode in smoke vent buttons should not light up.
Repeat functional testing.
- Green mains indication diode on control panel should not light up.
- Ventilation is out of service.
Yellow display LED on the central unit circuit board must light up.
- Check accumulator type.
- Contacts and housings must be clean and tight.
- Check fully charged accumulators that have not yet been used for correct
open-circuit and on-load voltage using D+H accumulator tester, in
accordance with the testing table:
- Measure the open-circuit voltage (alternatively using a digital
voltmeter); every accumulator must have between 13.5 and 13.9 V.
- Measure the on-load voltage. For this, open the system completely
twice via vent button. On the third time, measure the voltage during the
process.
The voltage of each accumulator must be at least 11 V.
Charging voltage:
Charging voltage is factory-set!
- Disconnect accumulator for checking.
- Substituded
- Compare voltage with table, using a calibrated 3½-digit digital
voltmeter and a calibrated thermometer.
, connect 10 kΩ resistors to accumulator
output.
Surrounding temperature in
battery height Charging voltage
15°C 27,52 - 27,92 V
16°C 27,49 - 27,89 V
17°C 27,46 - 27,86 V
18°C 27,42 - 27,82 V
19°C 27,39 - 27,79 V
20°C 27,36 - 27,76 V
21°C 27,33 - 27,73 V
22°C 27,30 - 27,70 V
23°C 27,26 - 27,66 V
24°C 27,23 - 27,63 V
25°C 27,20 - 27,60 V
26°C 27,17 - 27,57 V
27°C 27,14 - 27,54 V
28°C 27,20 - 27,50 V
29°C 27,07 - 27,47 V
30°C 27,04 - 27,44 V
31°C 27,01 - 27,41 V
32°C 26,98 - 27,38 V
33°C 26,44 - 27,34 V
34°C 26,91 - 27,31 V
35°C 26,88 - 27,28 V
Examination
OK
OK

99.821.70 3.5/01/12
D+H MechatronicAG
Georg-Sasse-Str. 28-32
22949Ammersbek
Tel. [phone]
Fax [phone]
, Germany
: +49 239
: +49
E-Mail: [e-mail]
www.dh-partner.com
© 2010 D+H Mechatronic AG, Ammersbek
Technische Änderungen vorbehalten. /
Rights to technical modifications reserved.
