elsner elektronik Suntracer KNX basic Guide

Installation and Adjustment
EN
Elsner Elektronik GmbH Control and AutomationTechnology
Herdweg 7
D – 75391 Gechingen Phone [phone] / 93 97-0 [e-mail]
Germany Fax [phone] / 93 97-20 www.elsner-elektronik.de
Suntracer KNX
Weather Station

1 Content
Elsner Elektronik GmbH • Herdweg 7 • D-75391 Gechingen • Germany
Weather Station Suntracer KNX • from software version 1.17, ETS programme version 1.4
Version: 27.06.2013 • Errors excepted. Subject to technical changes.
1. Description ........................................................................................... 3
1.1. Technical specifications ........................................................................................... 4
2. Installation and commissioning ........................................................... 5
2.1. Installation notes ...................................................................................................... 5
2.1.1. Location ......................................................................................................... 6
2.2. Mounting the weather station ................................................................................. 7
2.2.1. Attaching the mount ..................................................................................... 7
2.2.2. Rear view and drill sketch ............................................................................ 8
2.2.3. Preparing the weather station ..................................................................... 9
2.2.4. PCB layout ................................................................................................... 10
2.2.5. Aligning the DCF77 antenna ...................................................................... 11
2.2.6. Mounting the sensor .................................................................................. 11
2.3. Notes on mounting and commissioning .............................................................. 12
3. Addressing of the device at the bus .................................................. 13
4. Maintenance ....................................................................................... 13
5. Transmission protocol ....................................................................... 14
5.1. List of all communication objects ......................................................................... 14
6. Setting of parameters ........................................................................ 21
6.1. General settings ..................................................................................................... 21
6.2. Location ................................................................................................................... 22
6.3. Position of the sun ................................................................................................. 22
6.3.1. Position of the sun in sector 1 / 2 / 3 / 4 / 5 ............................................... 23
6.4. Temperature ........................................................................................................... 24
6.4.1. Temperature threshold value 1 / 2 / 3 / 4 .................................................. 24
6.5. Wind force ............................................................................................................... 25
6.5.1. Wind threshold value 1 / 2 / 3 .................................................................... 25
6.6. Brightness ............................................................................................................... 27
6.6.1. Brightness threshold value 1 / 2 / 3 ........................................................... 27
6.7. Dawn ....................................................................................................................... 27
6.7.1. Dawn threshold value 1 / 2 / 3 .................................................................... 27
6.8. Calendar time switch ............................................................................................. 28
6.8.1. Calendar time switch period 1 / 2 / 3 ......................................................... 28
6.8.2. Calendar time switch period 1 / 2 / 3, Sequence 1 / 2 .............................. 28
6.9. Week time switch ................................................................................................... 28
6.9.1. Weekly watch Mon, Tue, Wed, Thu, Fri, Sat, Sun 1 … 4 ......................... 28
6.10.AND Logic ............................................................................................................... 29
6.10.1. AND Logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 .............................................................. 29
6.10.2. Linkage inputs of AND logic ...................................................................... 31
6.11.OR Logic ................................................................................................................. 34
6.11.1. OR Logic 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 ................................................................ 34
6.11.2. Linkage inputs of OR logic ......................................................................... 34

2 Clarification of signs
This manual is amended periodically and will be brought into line with new software
releases. The change status (software version and date) can be found in the contents footer.
If you have a device with a later software version, please check
www.elsner-elektronik.de in the menu area "Service" to find out whether a more up-to-
date version of the manual is available.
Clarification of signs used in this manual
Installation, inspection, commissioning and troubleshooting of the device
must only be carried out by a competent electrician.
Safety advice.
Safety advice for working on electrical connections, components,
etc.
DANGER! ... indicates an immediately hazardous situation which will lead to
death or severe injuries if it is not avoided.
WARNING! ... indicates a potentially hazardous situation which may lead to
death or severe injuries if it is not avoided.
CAUTION! ... indicates a potentially hazardous situation which may lead to
trivial or minor injuries if it is not avoided.
ATTENTION! ... indicates a situation which may lead to damage to property if it is
not avoided.
ETS In the ETS tables, the parameter default settings are marked by
underlining.

3 Description
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
1. Description
The Weather Station Suntracer KNX measures temperature, wind speed and
brightness. It perceives precipitation and receives the DCF77 signal for date and time.
Furthermore, the exact position of the sun (azimuth and elevation) is calculated on the
basis of location coordinates and time.
ATTENTION!
The calculation of the position of the sun is optimised for UTC
-1...+3. The device therefore may only be applied within Europe.
For other time zones, please use Suntracer KNX-GPS Weather
Station.
All data may be used for the control of switching outputs which depend on threshold
values. The states may be linked by means of AND and OR logic gates. The compact
housing of Suntracer KNX stores the sensor system, the evaluation electronics and
the electronics of the bus connection.
Functions:
•Brightness and position of the sun: The current light intensity is measured
by means of a sensor. At the same time, Suntracer KNX calculates the position
of the sun (azimuth and elevation) on the basis of time and location. The
necessary position coordinates (degree of longitude and latitude) are entered
into the ETS software
•Wind measurement: The measurement of wind speed is accomplished
electronically and thus noiseless and reliable even in case of hail, snow and
minus temperature. Air swirls and up-draught in the radius of the weather
station are collected, too
•Precipitation perception: The surface of the sensor is heated so that only
drops and flakes are recognised as precipitation but not fog or dew. If it stops
raining or snowing, the sensor dries quickly and the precipitation message
ends
•Temperature measurement
•Week and calendar time switch: The weather station receives time and date
from the integrated DCF77 receiver. The week time switch operates up to 4
different periods each day. With the calendar time switch, you may determine
3 additional periods where the time switch accomplishes up to 2 activations
and deactivations each day. The Switching outputs can be used as
communication objects. The switching times are set by parameter or via
communication objects
•Switching outputs for all measured and calculated values (Threshold values
can be set by parameter or via communication objects)
•8 AND and 8 OR logic gates with each 4 inputs. Every switching incident as
well as 8 logic inputs (in the form of communication objects) may be used as
inputs for the logic gates. The output of each gate may optionally be configured
as 1 bit or 2 x 8 bits

4 Description
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
Configuration is made using the KNX software ETS. The programme file (format VD),
the data sheet and the manual can be downloaded from the Elsner Elektronik
homepage on www.elsner-elektronik.de in the “Service” menu.
1.1. Technical specifications
Housing Plastic material
Colour White / translucent
Mounting On-wall
Protection category IP 44
Dimensions approx. 96 × 77 × 118 (W × H × D, mm)
Weight 230 V AC version: approx. 240 g
24 V DC version: approx. 170 g
Ambient temperature Operation -30…+50°C, Storage -30…+70°C
Operating voltage Available for 230 V AC or for 24 V DC (20 V AC)
Cable cross-section Massive conductors of up to 1.5 mm² or
conductors with fine wires
Current 230 V AC version: max. 20 mA
24 V DC version: max. 100 mA
Residual ripple 10%
If switching power supply units are applied, the quality of the radio clock reception
may be influenced.
Data output KNX +/- bus terminal plug
BCU type Own micro controller
PEI type 0
Group addresses max. 254
Allocations max. 255
Communication objects 222
Heating rain sensor approx. 1.2 W (230 V and 24 V)
Measurement range
temperature
-40…+80°C
Resolution (temperature) 0.1°C
Accuracy (temperature) ±1°C at -10…+85°C
±1.5°C at -25…+150°C
Measurement range wind 0…70 m/s
Resolution (wind) <10% of the measured value
Accuracy (wind) ±25% at 0…15 m/s
at an angle of attack of 45°, pole mounting
Measurement range
brightness
0…150 000 lux

5 Installation and commissioning
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
The product conforms with the provisions of EC guidelines
• EMC Directive 2004/108/EC
• Low Voltage Directive 2006/95/EC
The following standards and/or technical specifications have been applied:
• EN 50491-5-1 :2010
• EN 50491-5-2 :2011
• EN 61000-6-1 :2007
• EN 61000-6-3 :2007
2. Installation and commissioning
2.1. Installation notes
Installation, testing, operational start-up and troubleshooting should
only be performed by an electrician.
DANGER!
Risk to life from live voltage (mains voltage)!
There are unprotected live components within the device.
• National legal regulations are to be followed.
• Ensure that all lines to be assembled are free of voltage and take
precautions against accidental switching on.
• Do not use the device if it is damaged.
• Take the device or system out of service and secure it against
unintentional use, if it can be assumed, that risk-free operation is no
longer guaranteed.
The device is only to be used for its intended purpose. Any improper modification or
failure to follow the operating instructions voids any and all warranty and guarantee
claims.
After unpacking the device, check it immediately for possible mechanical damage. If it
has been damaged in transport, inform the supplier immediately.
The device may only be used as a fixed-site installation; that means only when assem-
bled and after conclusion of all installation and operational start-up tasks and only in
the surroundings designated for it.
Elsner Elektronik is not liable for any changes in norms and standards which may occur
after publication of these operating instructions.
Resolution (brightness) 1 lux at 0…120 lux
2 lux at 121…1 046 lux
63 lux at 1 047…52 363 lux
423 lux at 52 364…150 000 lux
Accuracy (brightness) ±35%

6 Installation and commissioning
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
2.1.1. Location
Select an assembly location at the building where wind, rain and sun may be collected
by the sensors unobstructedly. Do not assemble any construction components above
the weather station from where water may drop on to the rain sensor after it has
stopped raining or snowing.
The weather station may not be shaded by the building or for example by trees. Leave
at least 60 cm of free space beneath the weather station in order to enable a correct
wind measurement and in order to avoid that the weather station is snowed in if there
is heavy snowfall. The distance also protects the unit against damage by birds.
Please ensure that the extended awning does not cast shade on the unit, and that this
is not protected from the wind.
Temperature measurements can also be affected by external influences such as by
warming or cooling of the building structure on which the sensor is mounted, (sun-
light, heating or cold water pipes).
Temperature variations from such sources of interference must be corrected in the ETS
in order to ensure the specified accuracy of the sensor (temperature offset, see Chapter
"Temperature").
Iron constructions or huge metal sheets directly behind or in the vicinity of the weather
station reduce the reception quality of the assembled radio clock receiver. Please take
this into consideration when selecting the assembly location. The reception of the DCF
signal may also be disturbed or made impossible by magnetic fields, emitters and in-
terfering fields of electrical consumers (e.g. fluorescent tubes, illuminated advertising,
switching power supply units, etc.).
Fig. 1
The wind sensor must be mounted onto a
vertical wall (or pole).
Wall
or
pole
Fig. 2
The wind sensor must be mounted horizon-
tally in the lateral direction.
Horizontal

7 Installation and commissioning
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
2.2. Mounting the weather station
2.2.1. Attaching the mount
The weather station comes with a combination wall/pole mount. The mount comes ad-
hered by adhesive strips to the rear side of the housing.
Fasten the holder vertically to the wall or pole.
Fig. 3
For wall mounting: Flat side to the wall, crescent
moon-shaped crosspiece facing up.
Collar
Fig. 4
For pole mounting: curved side to the pole,
crosspiece facing down.
Collar
Fig. 5
Different mounting arms are available from El-
sner Elektronik as additional, optional accesso-
ries for flexible installation of the weather station
on a wall, pole or beam.
Example of the use of a mounting arm: Due to
flexible ball joints, the sensor can be brought
into ideal position.

8 Installation and commissioning
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
2.2.2. Rear view and drill sketch
Fig. 6
Example use of the hinge arm mounting:
With the hinge arm mounting, the weather sta-
tion projects from beneath the roof overhang.
Sun, wind and precipitation can act upon the
sensors without hindrance.
Fig. 7
Example use of the hinge arm mounting:
Fitting to a pole with worm drive hose clips
Oblong hole 7,5 x 5 mm
Fig. 8 a+b
Drill sketch.
Dimensions of the rear side
of the housing with holder,
dimensions in mm. Diver-
gences are possible for
technical reasons.

9 Installation and commissioning
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
2.2.3. Preparing the weather station
The weather station cover with the rain sensor snaps in on the left and right along the
bottom edge (see Fig.). The cover of the 230V model is also screwed on top. Remove
the weather station cover. Proceed carefully, so as not to pull off the wire connecting
the PCB in the bottom part with the rain sensor in the cover (soldered cable connection
in case of 230 V AC version, cable with plug in case of 24 V DC version).
Push the power supply and bus connection cable through the rubber seal on the bot-
tom of the weather station and connect voltage LN and bus +/- to the provided clamps.
Fig. 9
1 Screw-on cover (230V
device)
2 Cover with rain sensor
3 Cover snaps
4 Bottom part of housing
3
4
Unsnap cover
and remove upwards
2
1

10 Installation and commissioning
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
For 24V devices the connection cable must be plugged in between the cover and circuit
board.
2.2.4. PCB layout
230 V AC version
Fig. 10
Remove the cable shielding under the circuit
board and only feed the connector cables up-
wards through the openings in the circuit
board.
Fig. 11
1 Cable connection to the rain
sensor in the housing cover
2 Opening for the cable for the
voltage supply
3 Tension clamp for voltage
supply (230 V AC),
suitable for massive conduc-
tors of up to 1.5 mm² or con-
ductors with fine wires
4SlotforKNXclamp+/-
5 Opening for bus cable
6 Programming pushbutton for
the teach-in of the device
7 Programming LED
8 Adjusting screw DCF77
antenna
9 Control LED DCF77 reception
23
8
5
1
6
7
4
9

11 Installation and commissioning
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
24 V DC version
2.2.5. Aligning the DCF77 antenna
The antenna for DCF77 reception of date and time is located under the PCB in the hous-
ing. Using the set screw (see chapter “PCB layout”, No. 8), you can turn the antenna
by up to 180° in order to achieve the best alignment. You know you are getting recep-
tion when the control LED (No. 9) flashes regularly once every second (in second 59,
the flashing interrupts once) The flashing may be displayed in the ETS programme file
(also see chapter “Setting of parameters: general settings“).
2.2.6. Mounting the sensor
Close the housing by putting the cover back over the bottom part. The cover must snap
in on the left and right with a definite “click”.
Fig. 12
1 Slot for cable connection to
the rain sensor in the housing
cover
2 Tension clamp for voltage
supply (24 V DC/20 V AC).
For massive conductors of up
to 1.5 mm² or conductors with
fine wires. Terminal configu-
ration independent from po-
larity (+/- or -/+).
3 Opening for the cable for the
voltage supply
4SlotforKNXclamp+/-
5 Opening for bus cable
6 Programming pushbutton for
the teach-in of the device
7 Programming LED
8 Adjusting screw DCF77
antenna
9 Control LED DCF77 reception
23
8
9
5
1
6
7
4
Fig. 13
Make sure the cover and bottom part are
properly snapped together! This picture is
looking at the closed sensor from under-
neath.
Fastening

12 Installation and commissioning
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
DANGER!
There is a risk to life from the live voltage on a 230 V device!
• The cover must be screwed on in operation.
To remove it, the sensor can be simply pulled upwards out of the mount, against the
resistance of the fastening.
2.3. Notes on mounting and commissioning
Do not open weather station if water (rain) might ingress: even some drops might
damage the electronic system.
Observe the correct connections. Incorrect connections may destroy the weather sta-
tion or connected electronic devices.
Please take care not to damage the temperature sensor (small blank at the bottom part
of the housing.) when mounting the weather station. Please also take care not to break
away or bend the cable connection between the blank and the rain sensor when con-
necting the weather station.
Remove all existing protection labels after installation.
The measured wind value and thus all other wind switching outputs may only be sup-
plied 60 seconds after the supply voltage has been connected.
After the auxiliary voltage has been applied, the device will enter an initialisation phase
lasting a few seconds. During this phase no information can be received via the bus.
Fig. 14
With the 230V model, screw the cover on to
the underpart, to prevent unauthorised or ac-
cidental opening.
Fig. 15
Push the housing from above into the fas-
tened mount. The bumps on the mount must
snap into the rails in the housing.

13 Addressing of the device at the bus
Weather Station Suntracer KNX • Version: 27.06.2013 • Technical changes reserved. Errors reserved.
3. Addressing of the device at the bus
The device is supplied with the bus address 15.15.250. You can program another ad-
dress into the ETS by overwriting the 15.15.250 address or by teaching via the pro-
gramming key on the circuit board inside the housing.
DANGER!
Risk to life from live voltage (mains voltage)!
• With the 230V model, bus addressing via the programming key
should only be done by an accredited electrician.
• Do not touch any components on the circuit board while pressing
the key.
4. Maintenance
DANGER!
There is a risk to life from the live voltage (mains voltage)!
If you come into contact with live components in the device, (e.g. caused
also by a jet of water) there is the risk of an electric shock with
230 V devices.
Risk of injury caused by components moved automatically!
The automatic control can start system components and place people in
danger (e.g. moving windows/awnings if a rain/wind alarm has been
triggered while cleaning).
• Always isolate the device from the mains for servicing and cleaning
(e. g. switch off or remove the fuse).
The device must regularly be checked for dirt twice a year and cleaned if necessary. In
case of severe dirt, the sensor may not work properly anymore.
ATTENTION
The device can be damaged if significant volumes of water penetrate the
housing.
• Do not clean with high pressure cleaners or steam jets.

14 Transmission protocol
Weather Station Suntracer KNX • Version: 27.06.2013 • Errors excepted. Subject to technical changes.
5. Transmission protocol
Units:
Temperatures in degree Celsius
Light in Lux
Wind in meters per second
The DCF signal may be slightly disturbed. It is possible that there is no radio clock re-
ception for a longer period of time. Therefore only use the indicated time for synchro-
nisation purposes of a clock which is operated parallel in your system. For this purpose
it is advisable to use second 0.
5.1. List of all communication objects
Abbreviations EIS types:
1 Switching1/0
3Time
4Date
5 Floating decimal value
6 8 bit value
Abbreviations Flags:
C Communication
R Read
WWrite
T Transmit
No. Name Function EIS
type
Flags
0 DCF date 4 C R T W
1 DCF time 3 C R T W
2 Date and time requirement 1 C R W
3 Switching output dawn 1 C R T
4 Switching output rain 1 C R T
5 Logic input 1 1 C R W
6 Logic input 2 1 C R W
7 Logic input 3 1 C R W
8 Logic input 4 1 C R W
9 Logic input 5 1 C R W
10 Logic input 6 1 C R W
11 Logic input 7 1 C R W
12 Logic input 8 1 C R W
13 Sun position azimuth 5 C R T
14 Sun position elevation 5 C R T
15 Switching output sun in sector 1 1 C R T

15 Transmission protocol
Weather Station Suntracer KNX • Version: 27.06.2013 • Errors excepted. Subject to technical changes.
16 Switching output sun in sector 2 1 C R T
17 Switching output sun in sector 3 1 C R T
18 Switching output sun in sector 4 1 C R T
19 Switching output sun in sector 5 1 C R T
20 Measured temperature value 5 C R T
21 Requirement min/max temperature Requirement 1 C R W
22 Lowest measured temperature value Sends min.
temperature
5CRT
23 Highest measured temperature value Sends max.
temperature
5CRT
24 Min/max temperature reset Reset of
temperature
1CRW
25 Temperature threshold value 1 Target value 5 C R W
26 Temperature threshold value 1 Actual value 5 C R T
27 Temperature threshold value 2 Target value 5 C R W
28 Temperature threshold value 2 Actual value 5 C R T
29 Temperature threshold value 3 Target value 5 C R W
30 Temperature threshold value 3 Actual value 5 C R T
31 Temperature threshold value 4 Target value 5 C R W
32 Temperature threshold value 4 Actual value 5 C R T
33 Switching output temperature threshold
value 1
1CRT
34 Switching output temperature threshold
value 2
1CRT
35 Switching output temperature threshold
value 3
1CRT
36 Switching output temperature threshold
value 4
1CRT
37 Measured value of wind force 5 C R T
38 Requirement max. wind force Requirement 1 C R W
39 Highest measured value of wind force Sends max. wind
force
5CRT
40 Max. wind force reset Reset of wind force 1 C R W
41 Wind force threshold value 1 Target value 5 C R W
42 Wind force threshold value 1 Actual value 5 C R T
43 Wind force threshold value 2 Target value 5 C R W
44 Wind force threshold value 2 Actual value 5 C R T
45 Wind force threshold value 3 Target value 5 C R W
46 Wind force threshold value 3 Actual value 5 C R T
No. Name Function EIS
type
Flags

16 Transmission protocol
Weather Station Suntracer KNX • Version: 27.06.2013 • Errors excepted. Subject to technical changes.
47 Switching output wind force threshold
value 1
1CRT
48 Switching output wind force threshold
value 2
1CRT
49 Switching output wind force threshold
value 3
1CRT
50 Measured light value 5 C R T
51 Brightness threshold value 1 Target value 5 C R W
52 Brightness threshold value 1 Actual value 5 C R T
53 Brightness threshold value 2 Target value 5 C R W
54 Brightness threshold value 2 Actual value 5 C R T
55 Brightness threshold value 3 Target value 5 C R W
56 Brightness threshold value 3 Actual value 5 C R T
57 Switching output light threshold value 1 1 C R T
58 Switching output light threshold value 2 1 C R T
59 Switching output light threshold value 3 1 C R T
60 Activation time period 1, sequence 1 Calendar time switch 3 C R W
61 Switch off time period 1, sequence 1 Calendar time switch 3 C R W
62 Switching output calendar time switch Period 1, sequence 1 1 C R T
63 Activation time period 1, sequence 2 Calendar time switch 3 C R W
64 Switch off time period 1, sequence 2 Calendar time switch 3 C R W
65 Switching output calendar time switch Period 1, sequence 2 1 C R T
66 Activation time period 2, sequence 1 Calendar time switch 3 C R W
67 Switch off time period 2, sequence 1 Calendar time switch 3 C R W
68 Switching output calendar time switch Period 2, sequence 1 1 C R T
69 Activation time period 2, sequence 2 Calendar time switch 3 C R W
70 Switch off time period 2, sequence 2 Calendar time switch 3 C R W
71 Switching output calendar time switch Period 2, sequence 2 1 C R T
72 Activation time period 3, sequence 1 Calendar time switch 3 C R W
73 Switch off time period 3, sequence 1 Calendar time switch 3 C R W
74 Switching output calendar time switch Period 3, sequence 1 1 C R T
75 Activation time period 3, sequence 2 Calendar time switch 3 C R W
76 Switch off time period 3, sequence 2 Calendar time switch 3 C R W
77 Switching output calendar time switch Period 3, sequence 2 1 C R T
78 Activation time Monday 1 Week time switch 3 C R W
79 Switch off time Monday 1 Week time switch 3 C R W
80 Activation time Monday 2 Week time switch 3 C R W
81 Switch off time Monday 2 Week time switch 3 C R W
No. Name Function EIS
type
Flags

17 Transmission protocol
Weather Station Suntracer KNX • Version: 27.06.2013 • Errors excepted. Subject to technical changes.
82 Activation time Monday 3 Week time switch 3 C R W
83 Switch off time Monday 3 Week time switch 3 C R W
84 Activation time Monday 4 Week time switch 3 C R W
85 Switch off time Monday 4 Week time switch 3 C R W
86 Switching output week time switch Monday 1 1 C R T
87 Switching output week time switch Monday 2 1 C R T
88 Switching output week time switch Monday 3 1 C R T
89 Switching output week time switch Monday 4 1 C R T
90 Activation time Tuesday 1 Week time switch 3 C R W
91 Switch off time Tuesday 1 Week time switch 3 C R W
92 Activation time Tuesday 2 Week time switch 3 C R W
93 Switch off time Tuesday 2 Week time switch 3 C R W
94 Activation time Tuesday 3 Week time switch 3 C R W
95 Switch off time Tuesday 3 Week time switch 3 C R W
96 Activation time Tuesday 4 Week time switch 3 C R W
97 Switch off time Tuesday 4 Week time switch 3 C R W
98 Switching output week time switch Tuesday 1 1 C R T
99 Switching output week time switch Tuesday 2 1 C R T
100 Switching output week time switch Tuesday 3 1 C R T
101 Switching output week time switch Tuesday 4 1 C R T
102 Activation time Wednesday 1 Week time switch 3 C R W
103 Switch off time Wednesday 1 Week time switch 3 C R W
104 Activation time Wednesday 2 Week time switch 3 C R W
105 Switch off time Wednesday 2 Week time switch 3 C R W
106 Activation time Wednesday 3 Week time switch 3 C R W
107 Switch off time Wednesday 3 Week time switch 3 C R W
108 Activation time Wednesday 4 Week time switch 3 C R W
109 Switch off time Wednesday 4 Week time switch 3 C R W
110 Switching output week time switch Wednesday 1 1 C R T
111 Switching output week time switch Wednesday 2 1 C R T
112 Switching output week time switch Wednesday 3 1 C R T
113 Switching output week time switch Wednesday 4 1 C R T
114 Activation time Thursday 1 Week time switch 3 C R W
115 Switch off time Thursday 1 Week time switch 3 C R W
116 Activation time Thursday 2 Week time switch 3 C R W
117 Switch off time Thursday 2 Week time switch 3 C R W
118 Activation time Thursday 3 Week time switch 3 C R W
119 Switch off time Thursday 3 Week time switch 3 C R W
120 Activation time Thursday 4 Week time switch 3 C R W
121 Switch off time Thursday 4 Week time switch 3 C R W
No. Name Function EIS
type
Flags

18 Transmission protocol
Weather Station Suntracer KNX • Version: 27.06.2013 • Errors excepted. Subject to technical changes.
122 Switching output week time switch Thursday 1 1 C R T
123 Switching output week time switch Thursday 2 1 C R T
124 Switching output week time switch Thursday 3 1 C R T
125 Switching output week time switch Thursday 4 1 C R T
126 Activation time Friday 1 Week time switch 3 C R W
127 Switch off time Friday 1 Week time switch 3 C R W
128 Activation time Friday 2 Week time switch 3 C R W
129 Switch off time Friday 2 Week time switch 3 C R W
130 Activation time Friday 3 Week time switch 3 C R W
131 Switch off time Friday 3 Week time switch 3 C R W
132 Activation time Friday 4 Week time switch 3 C R W
133 Switch off time Friday 4 Week time switch 3 C R W
134 Switching output week time switch Friday 1 1 C R T
135 Switching output week time switch Friday 2 1 C R T
136 Switching output week time switch Friday 3 1 C R T
137 Switching output week time switch Friday 4 1 C R T
138 Activation time Saturday 1 Week time switch 3 C R W
139 Switch off time Saturday 1 Week time switch 3 C R W
140 Activation time Saturday 2 Week time switch 3 C R W
141 Switch off time Saturday 2 Week time switch 3 C R W
142 Activation time Saturday 3 Week time switch 3 C R W
143 Switch off time Saturday 3 Week time switch 3 C R W
144 Activation time Saturday 4 Week time switch 3 C R W
145 Switch off time Saturday 4 Week time switch 3 C R W
146 Switching output week time switch Saturday 1 1 C R T
147 Switching output week time switch Saturday 2 1 C R T
148 Switching output week time switch Saturday 3 1 C R T
149 Switching output week time switch Saturday 4 1 C R T
150 Activation time Sunday 1 Week time switch 3 C R W
151 Switch off time Sunday 1 Week time switch 3 C R W
152 Activation time Sunday 2 Week time switch 3 C R W
153 Switch off time Sunday 2 Week time switch 3 C R W
154 Activation time Sunday 3 Week time switch 3 C R W
155 Switch off time Sunday 3 Week time switch 3 C R W
156 Activation time Sunday 4 Week time switch 3 C R W
157 Switch off time Sunday 4 Week time switch 3 C R W
158 Switching output week time switch Sunday 1 1 C R T
159 Switching output week time switch Sunday 2 1 C R T
160 Switching output week time switch Sunday 3 1 C R T
No. Name Function EIS
type
Flags

19 Transmission protocol
Weather Station Suntracer KNX • Version: 27.06.2013 • Errors excepted. Subject to technical changes.
161 Switching output week time switch Sunday 4 1 C R T
162 AND logic 1 Switching output 1 C R T
163 AND logic 1 8 Bit output A 6 C R T
164 AND logic 1 8 Bit output B 6 C R T
165 AND logic 2 Switching output 1 C R T
166 AND logic 2 8 Bit output A 6 C R T
167 AND logic 2 8 Bit output B 6 C R T
168 AND logic 3 Switching output 1 C R T
169 AND logic 3 8 Bit output A 6 C R T
170 AND logic 3 8 Bit output B 6 C R T
171 AND logic 4 Switching output 1 C R T
172 AND logic 4 8 Bit output A 6 C R T
173 AND logic 4 8 Bit output B 6 C R T
174 AND logic 5 Switching output 1 C R T
175 AND logic 5 8 Bit output A 6 C R T
176 AND logic 5 8 Bit output B 6 C R T
177 AND logic 6 Switching output 1 C R T
178 AND logic 6 8 Bit output A 6 C R T
179 AND logic 6 8 Bit output B 6 C R T
180 AND logic 7 Switching output 1 C R T
181 AND logic 7 8 Bit output A 6 C R T
182 AND logic 7 8 Bit output B 6 C R T
183 AND logic 8 Switching output 1 C R T
184 AND logic 8 8 Bit output A 6 C R T
185 AND logic 8 8 Bit output B 6 C R T
186 OR logic 1 Switching output 1 C R T
187 OR logic 1 8 Bit output A 6 C R T
188 OR logic 1 8 Bit output B 6 C R T
189 OR logic 2 Switching output 1 C R T
190 OR logic 2 8 Bit output A 6 C R T
191 OR logic 2 8 Bit output B 6 C R T
192 OR logic 3 Switching output 1 C R T
193 OR logic 3 8 Bit output A 6 C R T
194 OR logic 3 8 Bit output B 6 C R T
195 OR logic 4 Switching output 1 C R T
196 OR logic 4 8 Bit output A 6 C R T
197 OR logic 4 8 Bit output B 6 C R T
198 OR logic 5 Switching output 1 C R T
199 OR logic 5 8 Bit output A 6 C R T
No. Name Function EIS
type
Flags
