Elumen8 ELUM121 User manual

!
!
!
!
!
Order!Code:!ELUM121!
! !
!
!!!!!!!!!!!!!!!!!!!!!!!!User Manual
www.prolight.co.uk
!

1
CONTENTS!
!
1.!Safety!Introduction!.................................................................................................!2!
2.!Technical!Specifications!..........................................................................................!3!
3.!How!To!Set!The!Fixture!...........................................................................................!4!
3.1!Control!Panel!.....................................................................................................!4!
3.2!Barn!Door!Installation!.......................................................................................!5!
3.3!Main!Functions!..................................................................................................!6!
4.!How!To!Control!The!Unit!......................................................................................!12!
4.1!DMX!Control!....................................................................................................!12!
4.2.!DMX!512!Configuration!..................................................................................!13!
4.3.!DMX!512!Connections!....................................................................................!15!
5.!Troubleshooting!....................................................................................................!16!
6.!Fixture!Cleaning!....................................................................................................!16!
!
!
!
!
!
!
!
!
!
!
!

2
!1.!Safety!Introduction! !
!
!
WARNING!
!
!Please!keep!this!User!Guide!for!future!consultation.!If!you!sell!the!unit!to!another!user,!be!sure!
that!they!also!receive!this!instruction!booklet.!
!Please!unpack!and!check!carefully!there!is!no!transportation!damage!before!using!the!unit.!
!Before! operating,! ensure! that! the! voltage! and! frequency! of! power! supply! match! the! power!
requirements!of!the!unit.! !
!You!must!ground!the!yellow/green!conductor!to!earth!in!order!to!avoid!electric!shock.!
!The!unit!is!for!indoor!use!only.!Use!only!in!a!dry!location.!
!The!unit!must!be!installed!in!a!location!with!adequate!ventilation,!at!least!50cm!from!adjacent!
surfaces.!Be!sure!that!no!ventilation!slots!are!blocked.! !
!Please!disconnect!mains!power!before!replacement!or!servicing.! !
!Please! make! sure! there! are! no! flammable! materials! close! to! the! unit! while! operating! as! they!
may!be!a!fire!hazard.! !
!Use!a!safety!cable!when!installing!this!unit.! !
!Maximum!ambient!temperature!is!Ta:!40.!DO!NOT!operate!it!where!the!temperature!is!higher!
than!this.!
!Unit! surface! temperature! may! reach! up! to! 55.! DO! NOT! touch! the! housing! with! bare-hands!
during! operation.! Turn! off! the! power! and! allow! 15! minutes! for! the! unit! to! cool! down! before!
replacing!or!servicing.!
!In!the!event!of!a!serious!operating!problem,!stop!using!the!unit!immediately.!Never!try!to!repair!
the!unit!by!yourself.!Repairs!carried!out!by!unskilled!people!can!lead!to!damage!or!malfunction.!
Please! contact! the! nearest! authorized! technical! assistance! center.! Always! use! the! same! type!
Please!read!carefully!the!instructions!which!include!important!
information!about!installation,!usage!and!maintenance.

3
spare!parts.!
!DO!NOT!touch!any!cables!during!operation!as!the!high!voltage!may!cause!electric!shock.!
!
Warning:!
!To! prevent! or! reduce! the! risk! of! electrical! shock! or! fire,! do! not! expose! the! unit! to! rain! or!
moisture.!
!The!housing!or!front!lens!must!be!replaced!if!they!are!visibly!damaged.!
Installation:!
The!unit!should!be!mounted!via!its!screw!holes!to!a!bracket.!Always!ensure!that!the!unit!is!firmly!
fixed!to!avoid!vibration!and!slipping!while!operating.!Make!sure!that!the!structure!to!which!you!
are!attaching!the!unit!is!secure!and!is!able!to!support!a!weight!of!10!times!of!the!unit’s!weight.!
Also!always!use!a!safety!cable!that!can!hold!12!times!of!the!weight!of!the!unit!when!installing!the!
fixture.! !
The!equipment!must!be!installed!by!professionals.!It!must!be!installed!in!a!place!where!is!out!of!
the!reach!of!people!and!no!one!can!pass!by!or!under!it.!
!2.!Technical!Specifications! !
◆Powerful!cyclorama!projector,with!innovative!optics,featuring!a!high!power!quad!colour!LED!
and!90°x!113°beam!angle,!delivering!excellent!colour!mixing!with!an!even!and!wide-field!
projection.!
◆Control!Mode:!DMX,!Master/Slave!
◆DMX!Channels:!4!/!9.! !
◆0~100%!smooth!dimming!with!2!speed!options.!
◆Frame!for!the!use!of!colour!filters!and!barn!doors.!
◆Variable!strobe!speed.!
◆LCD!display!for!easy!navigation.!
¸Power!Voltage:! ! !!!!!!!!!!!!AC!100!~!240V,!50/60Hz!
¸!Power!Consumption:! !!!!!!!!155W!
¸!Light!Sources:! ! ! ! ! ! ! ! ! ! ! ! ! ! ! 1!x!150W!RGBW!LED!
¸!Beam!angle:! !!!!!!!!!!!!!!!90°x!113°!
¸!Weight:! ! ! !!!!!!!!!!!!!!!!!6.2!Kgs!
¸!Dimension:! ! !!!!!!!!!!!!!! ! 425!x!364!x!419mm!

4
!
!
! 3.!How!To!Set!The!Fixture! !
3.1!Control!Panel! !
4
1. Display: Used!to!show!the!various!menus!and!selected!functions;!
2. DMX!IN!:!For!DMX!512!linking,!use!5-pin!XLR!cables.!
3. POWER!IN:!Used!to!connect!mains!supply!power;!
4. POWER!OUT:!Used!to!connect!to!supply!power;!

5
5. DMX!OUT:!For!DMX!512!linking,!use!5-pin!XLR!cables!to!link!to!the!next!unit.!
6. Power!Switch:!Turns!the!power!On/Off.!
7.!Buttons:!
MENU!
! To!select!the!programming!functions!
DOWN!
! To!go!backward!in!the!selected!functions!
UP!
! To!go!forward!in!the!selected!functions!
ENTER!
! To!confirm!the!selected!functions!
8.!Fuse!(T3.15A):!Protects!the!unit!from!over-voltage!or!short!circuit.!
!
3.!2!Frame!for!Barn!Door!Installation! !
Please!insert!the!Barn!Door!into!the!outer!most!slot,!from!the!topside!of!the!fixture!as!per!arrow!
○
1 .!To!secure!in!place,!fasten!the!lock!(Note:!Please!take!care!to!ensure!the!Barn!Door!is!securely!
located!inside!the!left,!right!and!lower!barn!door!rails);!
Finally,!as!per!the!arrow! ○ 2,!(Note:!the!lock!must!slide!to!the!right!in!order!to!open/close)!flip!
down!the!lock!cap!again!as!arrow○ 3 ,!in!order!to!fasten!the!Barn!Door.!For!best!practice,!secure!
the!barn! door!using! a!suitable! safety!bond! fastened!to! the!eye! located!on! the!barn! door!frame!
(safety!bond!not!supplied).!
!

6
3.3!Main!Functions! !
Press!the!MENU!button!into!menu!mode,!press!the!UP!and!DOWN!buttons!until!the!required!
function!is!shown!on!the!display.!Select!the!function!by!pressing!the!ENTER!button.!Use!the!UP!
and!DOWN!buttons!to!choose!the!submenu,!press!the!ENTER!button!to!store!and!automatically!
return!to!the!last!menu.!Press!the!MENU!button!or!leave!the!unit!idle!for!one!minute!to!exit!the!
menu!mode.! !

7
Mode1(4ch)
Linear Curve
Inverse Square Law
S curve
Square Law
Colour Dimming Mode
Colour Macro
Static Colour Mode
StandAlone
Red
Green
Blue
White
Color 1
Color 32
Macro 1
Macro 7
LEE Colour
Colour Temp
Strobe
Dimmer
Dimmer Fine
!

8
DMX!Settings!
To!select!DMX!Settings,!press!the!ENTER!button!to!confirm,!use!the!UP/DOWN!buttons!to!select!
DMX!Address!or!Channel!Mode! !
DMX!Address! !
To!select!DMX!Address,!press!the!ENTER!button!to!confirm.!Use!the!UP/DOWN!buttons!to!
adjust!the!address!from!1!to!512,!press!the!ENTER!button!to!setup.!To!go!back!to!the!
functions!without!any!changes!press!the!MENU!button!again.!Press!and!hold!the!MENU!
button!for!about!one!second!or!wait!for!one!minute!to!exit!the!menu!mode.!
Channel!Mode! !
To!select!Channel!Mode,!press!the!ENTER!button!to!confirm.!Use!the!UP/DOWN!buttons!to!
select!Mode!1!(4!ch)!or!Mode!2!(9!ch)!To!go!back!to!the!functions!without!any!changes!press!
the!MENU!button!again.!Press!and!hold!the!MENU!button!for!about!one!second!or!wait!for!
one!minute!to!exit!the!menu!mode.!
!
Stand!Alone!
To!select!Stand!Alone,!press!the!ENTER!button!to!confirm,!use!the!UP/DOWN!buttons!to!select!
Colour!Dimming!Mode,!Static!Colour!Mode!or!Colour!Macro.!
Colour!Dimming!Mode! !
To!select!Colour!Dimming!Mode,!press!the!ENTER!button!to!confirm.!When!you!select!Mode!
1!(4!ch),!use!the!UP/DOWN!buttons!to!select!Red,!Green,!Blue!or!White.!If!you!choose!Mode!
2!(9!ch),use!the!UP/DOWN!buttons!to!select!Red,!Green,!Blue,!White,!Lee!compatible!colour,!
Colour-Temp,!Strobe,!Dimmer!or!Dimmer!fine!mode,!press!enter,!use!the!UP/DOWN!button!
to!select!desired!value!000-255,!press!ENTER!button!to!save,!when!using!this!mode!please!
make!sure!Strobe!is!set!to!value!255,!do!not!press!MENU!as!this!action!will!exit!the!
stand-alone!mode,!press!ENTER!to!save.!The!fixture!will!remember!the!stand-alone!mode!set!
even!after!a!power!off!and!back!on!cycle.!
!
!

9
Static!Colour!Mode! !
To!select!Static!Colour!Mode,!press!the!ENTER!button!to!confirm.!Use!the!UP/DOWN!button!
to!select!Color!1~Color!32!mode,!do!not!press!MENU!as!this!action!will!exit!stand-alone!mode!
selected,!press!ENTER!to!save.!The!fixture!will!remember!the!stand-alone!mode!set!even!after!
a!power!off!and!back!on!cycle.!
Colour!Macro!Mode!
To!select!Colour!Macro,!press!the!ENTER!button!to!confirm.!Use!the!UP/DOWN!button!to!
select!Macro!1~Macro!7!mode,!the!seven!Macro’s!are!all!a!colour!scrolling!fade!with!macro!1!
the!fastest!and!macro!7!the!slowest,!do!not!press!MENU!as!this!action!will!exit!stand-alone!
mode!selected,!press!ENTER!to!save.!The!fixture!will!remember!the!stand-alone!mode!set!
even!after!a!power!off!and!back!on!cycle.!
!
Dimmer!Curve!
To!select!Dimmer!Curve,!press!the!ENTER!button!to!show!the!DIMMER!CURVE!on!the!display,!the!
current!setting!will!be!highlighted!on!the!display,!use!the!UP/DOWN!button!to!select!Linear,!
Square!Law!,Inverse!Square!Law!or!S!cure.!To!go!back!to!the!functions!without!any!changes!press!
the!MENU!button!again.!Press!and!hold!the!MENU!button!for!about!one!second!or!wait!for!one!
minute!to!exit!the!menu!mode.!
!
Square!Law:!Light!intensity!control!is!finer!at!low!levels!and!coarser!at!high!levels.!
Inverse!Square!Law:!Light!intensity!control!is!coarser!at!low!levels!and!finer!at!high!levels.!
Linear:!The!increase!in!light!intensity!appears!to!be!linear!as!DMX!value!is!increased.!
S-curve:!Light!intensity!control!is!finer!at!low!and!high!levels!and!coarser!at!medium!levels.!
!
