emerio SID-122305.1 User manual

- 1 -
Content –Innehåll –Innhold
Instruction manual –English........................................................................................- 2 -
Bruksanvisning –Swedish ............................................................................................- 9 -
Brukermanual –Norwegian .......................................................................................- 16 -

- 2 -
Instruction manual –English
SAFETY INSTRUCTIONS
Before use make sure to read all of the below instructions in
order to avoid injury or damage, and to get the best results
from the appliance. Make sure to keep this manual in a safe
place. If you give or transfer this appliance to someone else
make sure to also include this manual.
In case of damage caused by user failing to follow the
instructions in this manual the warranty will be void. The
manufacturer/importer accepts no liability for damages
caused by failure to follow the manual, a negligent use or use
not in accordance with the requirements of this manual.
1. Read and save these instructions. Attention: pictures in the
IM are for reference only.
2. This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
3. Children shall not play with the appliance.
4. Cleaning and user maintenance shall not be made by
children without supervision.
5. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
6. Keep the appliance and its cord out of reach of children
less than 8 years.
7. WARNING: This appliance is intended only for drying
textiles washed in water.
8. This appliance is intended to be used in household and
similar applications.
9. Before inserting the plug into the mains socket, please
check that the voltage and frequency comply with the

- 3 -
specifications on the rating label.
10. The appliance must always be switched off and
disconnected from the mains power when it is not being
used and before assembling, disassembling or cleaning.
11. The appliance must not be moved during use.
12. Do not use any extension cables.
13. Ensure that the mains cable is not hung over sharp edges
and keep it away from hot objects and open flames.
14. Do not immerse the appliance or the mains plug in water
or other liquids. There is danger to life due to electric
shock!
15. To remove the plug from the plug socket, pull the plug. Do
not pull the power cord.
16. Do not touch the appliance if it falls into water. Remove
the plug from its socket, turn off the appliance and send it
to an authorized service center for repair.
17. Do not plug or unplug the appliance from the electrical
outlet with a wet hand.
18. Never attempt to open the housing of the appliance, or to
repair the appliance yourself. This could cause electric
shock.
19. Never leave the appliance unattended during use.
20. This appliance is not designed for commercial use.
21. Do not use the appliance for other than intended use.
22. Do not wind the cord around the appliance and do not
bend it.
23. Exit of warm air must not be blocked.
24. Caution: do not use the appliance in the immediate vicinity
of bath tubes, showers, wash basins or swimming pools.
25. The appliance is for indoor use only.
26. Do not insert or allow foreign objects to enter any
ventilation or exhaust opening, as this may cause an
electric shock or fire, or damage the appliance.
27. Be sure that no other appliances are plugged into the same
circuit with your appliance, as circuit overload could occur.

- 4 -
28. Protect the appliance from heat, naked flame, extreme
temperatures, persistent moisture, wet conditions and
collisions.
29. Always place the appliance with clear space above it and
on all sides on a dry, flat, solid and heat-resistant surface.
30. Do not place the appliance under other electronic devices.
31. Means “DO NOT COVER”.
32. The machine should not be operated by means of an
external timer-switch or by means of a separate system
with remote control.
33. WARNING!!
Please do not touch surface while in use. The
temperature of accessible surfaces may be
high when the appliance is operating.

- 5 -
SID-122305.1 EN
PARTS DESCRIPTION
1. Hanger
2. Telescopic rod
3. Main rod
4. Air outlet
5. Motor unit
6. Ventilation slots
7. ON/OFF switch with timer (30-180
minutes)
8. Mounting flange
9. Fastener
10. Water fender
11. Collar section
12. Nylon balloon
ASSEMBLY
1. Remove all packaging materials.
2. Install the water fender onto the main rod in the range of 5cm from the black line sticked at the main rod. (It
will affect the use or even damage the appliance to install the water fender too high or too low.) Tighten the
screw to fix the water fender there. Make sure the hollowed side of the water fender face downwards.
3. Plug the main rod into the recess on the top of the motor unit.
4. Assemble the hanger as below drawing shows. Insert the two halves onto the collar section. Note the left
and right side by connecting the logo “L” at one side and logo “R” at the other side. Insert the two halves
firmly until a click sound is sent out. Tighten the provided screws (a) into the small holes at two sides to fix
the assembly of the hanger.
5. Place the hanger onto the telescopic rod by the middle socket. Make sure the slight bend of hanger faces
forwards (the same side of “ON/OFF switch and timer”).
6. Attach the nylon balloon:
1) Hang the nylon balloon onto the hanger and collar section.
2) Make the main rod and telescopic rod stand in the nylon balloon.
3) There is elastic cord the bottom of the nylon balloon. Press the elastic cord below the mounting flange
to fix the nylon balloon.
USE
1. Place the appliance on a stable, flat, moisture-resistant and heat-resistant surface.
2. Loosen the fastener to adjust the height of the telescopic rod to your desired level.
Tighten the fastener after the adjustment.
3. Attach the nylon balloon by following the instructions in “Assembly”.
4. Put on the clothes outside the nylon balloon and button up if there are buttons. Make
the collar fit the collar collection. Do not twist or scrunch up the two sleeves.
5. Put the plug into an appropriate power outlet.
6. Turn on the appliance by rotating the ON/OFF switch with timer to position “ON”, or turn the timer

- 6 -
clockwise to select the length of time you want. When the appliance is running, the indicator light besides
position “ON” turns on.
7. If you use the timer and the select time elapses, the appliance will switches off automatically. The
drying/pressing can be interrupted at any time by turning the ON/OFF switch with timer to the position
“OFF”.
8. Remove the dried/pressed clothes from the nylon balloon.
9. Take out the mains plug from power outlet and allow the appliance to cool down completely.
Notes:
This appliance is intended to be used for drying and pressing textiles, for example blouses and shirts.
Delicate textiles such as wool or similar fabrics must not be dried/pressed on the appliance. Always follow
the care labels for the textiles!
This appliance is intended primarily for machine-spun laundry. If hand-washed or non-machine-spun
laundry is to be pressed, dry it until there is no water dropping when the laundry is hanging.
The drying/pressing process takes around 10 minutes for a spin-dried shirt. However, the length of time
varies depending on the material and thickness. We recommend that you start with a shorter time and
extend it if necessary.
The nylon balloon can be enlarged or reduced in size by opening or closing the zip fasteners at two sides.
REFERENCE TABLE
This table is tested on the spin-dried clothes and only for your reference.
The actual time for drying/pressing clothes depend on the material and thickness of clothes, as well as how dry
the clothes originally are.
Clothes type
T-shirt
Shirt/blouse in
short sleeves
Shirt/blouse in
long sleeves
Suit
Drying/pressing time
(minutes)
10
9
15
17
CLEANING AND MAINTENANCE
1. Remove the mains plug from power outlet and allow the appliance to cool down completely before any
cleaning or storage.
2. Clean the outside of the appliance with a slightly damp cloth and a little mild detergent if needed, then dry
it completely with a soft dry cloth.
3. Clean the hanger, rod, water fender and nylon balloon with a damp cloth, or wash them in warm soapy
water and then rinse them fully. Dry all these parts completely before use.
4. Never immerse the appliance, its mains cable or mains plug in water or any other liquids.
5. Do not use any corrosive or abrasive cleaning agents or cleaning pads to clean the appliance.
TROUBLE SHOOTING
Problem
Possible cause
Solution
The appliance does not work.
The indicator light does not
light up.
The mains plug is not inserted
into the plug socket correctly.
Connect the mains plug correctly.
The plug socket is defective.
Try another plug socket.
The appliance is not switched
on.
Switch on the appliance and set the
timer.

- 7 -
Unusual noises
The ventilation slots are
covered up or blocked
Free up the ventilation slots.
The appliance switches off
suddenly.
The ventilation slots are
covered up or blocked.
Free up the ventilation slots.
The appliance has an
automatic safety switch-off
function. It switches off
automatically when it
overheats.
Allow the appliance to cool down and
switch it on again.
The appliance has fallen over.
The appliance has a protective
switch that is activated if the
appliance falls over.
Set the appliance up again and switch
it back on.
The set time has elapsed.
Set the time as you want again.
Odour produced
You may notice a slight odour
caused by production residues
the first time you use the
appliance.
This is harmless and will cease as you
use the appliance.
TECHNICAL DATA
Operating voltage: 220-240V ~ 50/60Hz
Power consumption: 1200W
IPX2
GUARANTEE AND CUSTOMER SERVICE
Before delivery our devices are subjected to rigorous quality control. If, despite all care, damage has occurred
during production or transportation, please return the device to your dealer. In addition to statutory legal rights,
the purchaser has an option to claim under the terms of the following guarantee:
For the purchased device we provide 2 years guarantee, commencing from the day of sale. If you have a
defective product, you can directly go back to the point of purchase.
Defects which arise due to improper handling of the device and malfunctions due to interventions and repairs
by third parties or the fitting of non-original parts are not covered by this guarantee. Always keep your receipt,
without the receipt you can’t claim any form of warranty. Damage caused by not following the instruction
manual, will lead to a void of warranty, if this results in consequential damages then we will not be liable.
Neither can we hold responsible for material damage or personal injury caused by improper use or if the
instruction manual are not properly executed. Damage to accessories does not mean free replacement of the
whole appliance. In such case please contact our service department. Broken glass or breakage of plastic parts is
always subject to a charge. Defects to consumables or parts subjected to wearing, as well as cleaning,
maintenance or the replacement of said parts are not covered by the warranty and are to be paid.

- 8 -
ENVIRONMENT FRIENDLY DISPOSAL
Recycling –European Directive 2012/19/EU
This marking indicates that this product should not be disposed with other household wastes. To
prevent possible harm to the environment or human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable reuse of material resources. To return your used
device, please use the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.

- 9 -
Bruksanvisning –Swedish
SÄKERHETSANVISNINGAR
Före användning och för att att erhålla bästa resultat från
apparaten, var noga med att läsa igenom alla instruktioner
nedan för att undvika skada på person eller egendom. Se till
att förvara denna bruksanvisning på en säker plats. Om du ger
bort eller överlåter denna apparat till någon, se till att även
inkludera denna bruksanvisning.
Vid skador som orsakats av att användaren inte följer
instruktionerna i denna bruksanvisning ogiltighetsförklaras
garantin. Tillverkaren/importören tar inget ansvar för skador
som orsakats av underlåtenhet att följa bruksanvisningen, vid
en vårdslös användning eller användning som inte är i
enlighet med kraven i denna bruksanvisning.
1. Läs igenom och spara dessa instruktioner. Obs! Bilderna
häri är endast för referens.
2. Denna apparat får användas av barn från 8 års ålder,
personer med nedsatt fysisk, sensorisk eller mental
förmåga eller personer med brist på erfarenhet och
kunskap om de övervakas eller fått instruktioner angående
användningen av apparaten på ett säkert sätt och förstår
riskerna.
3. Barn får inte leka med apparaten.
4. Rengöring och underhåll av apparaten får inte göras av
barn utan vuxens tillsyn.
5. Om sladden är skadad måste den bytas ut av tillverkaren,
en av tillverkaren godkänd reparatör eller liknande
kvalificerad person för att undvika faror.
6. Apparaten och dess sladd ska hållas utom räckhåll för barn
under 8 år.
7. VARNING! Produkten är endast avsedd att användas för att
torka textilier som tvättats i vatten.
8. Denna apparat är avsedd för användning i hushåll och
liknande tillämpningar.
9. Innan du ansluter strömkontakten till eluttaget, kontrollera
