Emerson DESIGNER REMOTE CF759AB00 User manual

Part No. F40BP72400001 Form No. BP7240-1
READ AND SAVE THESE INSTRUCTIONS
Model No.
CF759OB00 CF759PB00
CF759TG00 CF759HTW00
CF759BS00 CF759AB00
CF759WW00
DESIGNER REMOTE
Series
®
Ceiling Fan
Owner's Manual
LIMITED WARRANTY
What The Warranty Covers:
This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials.
You must be the original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
As it applies to the motor, this warranty will last for thirty years from the date you purchased your ceiling fan. All other components and accessories are
covered by this warranty for one year from the date you purchased your ceiling fan. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Company Do To Correct Problems:
Emerson Company will replace a defective Emerson Air Comfort Ceiling Fan motor, blade, component or other accessory at no charge to you. If repair of the
motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson Company will refund the actual purchase
price of your fan. We will ship the repaired product or replacement to you at no charge, but you are responsible for all costs or removal, reinstallation and
shipping of the product to Emerson Electric.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE CEILING FAN TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR RECEIPT OR OTHER PROOF
OF PURCHASE. You can return the product to our factory or to your nearest authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort Products, Division of Emerson
Company, 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service center. Your Emerson Air Comfort
Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
What Is Not Covered:
The glass globes and light bulbs of your ceiling fan are not covered by this warranty. This warranty also does not cover any defects, malfunctions or failures
caused by:
• Repairs by persons not authorized by Emerson Company,
• Use of parts or accessories not authorized by Emerson Company,
• Mishandling, improper installation, modifications or damage to your ceiling fan while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• The original purchaser or user ceases to own the product, or
• The fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral warranties apply, and no employee,
agent, dealer or other person is authorized to give any warranties on behalf of Emerson Company.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND EMERSON IS NOT RESPONSIBLE
FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGES. Incidental damages include but are not limited to such damages
as loss of time and loss of use. Consequential damages include but are not limited to the cost of repairing or replacing other property which was damaged if
this product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Net Weight: 17.3 Lbs.

2
WARNING
!
WARNING: To avoid fire, shock, and serious personal injury, follow these instructions.
Safety Instructions
1. Read your owner’s manual carefully and keep it for future reference.
2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting
means to prevent power from being switched on accidentally. When the service disconnecting means cannot
be locked, securely fasten a warning device, such as a tag, to the service panel.
3. Be careful of the fan and blades when cleaning, painting, or working near the fan. Always turn off the power to
the ceiling fan before servicing.
4. Do not put anything into the fan blades while they are turning.
5. Do not operate reversing switch until fan blades have come to a complete stop.
Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned off at the fuse box before wiring, and do not operate fan
without blades.
2. All wiring must satisfy National and Local Electrical Codes. Use the National Electrical Code if Local Codes do
not exist. The ceiling fan must be grounded as a precaution against possible electrical shock. Electrical
installation should be made or approved by a licensed electrician.
3. The outlet box and joist must be securely mounted and capable of reliably supporting at least 50 pounds. Use
only U.L. outlet boxes listed as acceptable for fan support, and use the mounting screws provided with the
outlet box. Most outlet boxes commonly used for support of light fixtures are not acceptable for fan support
and may need to be replaced. Consult a qualified electrician if in doubt.
4. The downrod furnished with the fan proves the minimum recommended floor to fan blade clearance for an
8 foot ceiling.
5. The fan must be mounted with the fan blades at least 7 feet from the floor to prevent accidental contact with the
fan blades.
6. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not know
enough about electrical wiring, have your fan installed by a licensed electrician.
WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not specifically
approved for this fan.
WARNING: This product is designed to use only those parts supplied with this product and/or any accessories
designated specifically for use this product by Emerson. Substitution of parts or accessories not
designated for use with this product by Emerson could result in personal injury or property damage.
WARNING: To Reduce the risk of personal injury, do not bend the blade flange when installing the blade flanges,
balancing the blades or cleaning the fan. Do not insert foreign objects in between rotating fan blades.
DATE CODE:
The date code of this fan may be found on
the box, stamped in ink on a white label.
You should record this data above and
keep it in a safe place for future use.

This Manual Is Designed to Make it as Easy as Possible
for You to Assemble, Install,
Operate and Maintain Your Ceiling Fan
Tools Needed for Assembly
One Phillips head screwdriver One stepladder
One 1/4” blade screwdriver One wire stripper
Three wire connectors (supplied).
Unpacking Instructions
For your convenience, check-off boxes are provided next to each step. As each step is completed,
place a check mark in the box. This will insure that all steps have been completed and will be helpful in
finding your place should you be interrupted.
1. Check to see that you have received the following parts:
NOTE: If you are uncertain of part description,
refer to exploded view illustration.
a. Fan motor assembly
b. One switch housing assembly with receiver
c. One hand held transmitter
d. Five fan blades
e. One ceiling cover
f. Five blade flanges
g. One hanger ball/downrod assembly
h. One hanger bracket
i. One coupling cover
j. One loose parts bag containing:
1. Sixteen 3/16-24 x 5/16” slotted Phillips
blade screws
2. Sixteen blade washers
3. Eleven 1/4-20 x 1/2” Phillips oval head
flange screws
4. Three wire connectors
5. Two threaded studs
6. Two knurled knobs
7. Two lockwashers
8. One clevis pin
9. One hairpin clip 3
NOTE: Place the parts from the loose parts bags
in a small container to keep them from being lost.
If any parts are missing, contact your local retail-
er or catalog outlet for replacement before
proceeding.
2. Remove the fan assembly from the protective plas-
tic bag. Place the fan assembly into the upper
foam pad with the bottom of the motor facing up.
The upper foam pad serves as a holder for the fan
during the first stages of assembly.
LOOSE
PARTS
BAG
HANGER BALL/
DOWNROD
ASSEMBLY
HANGER
BRACKET
FAN
BLADES
FAN MOTOR
ASSEMBLY
CEILING
COVER
BLADE
FLANGES
SWITCH CUP
ASSEMBLY WITH
RECEIVER
TRANSMITTER
®
COUPLING
COVER
MATERIALS
Wiring outlet box and box connectors must be of type
required by the local code. The minimum would be a
3-conductor (2-wire with ground) of size shown to the
right:
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
Before assembly your ceiling fan, refer to section on
proper method of wiring your fan (page 6). If you feel
you do not have enough wiring knowledge or experi-
ence, have your fan installed by a licensed electrician.
WARNING
!
Do not install or use fan if any part is damaged or
missing. Call Toll-Free:
1-800-654-3545
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product by
Emerson Company. Substitution of parts or acces-
sories not designated for use with this product by
Emerson Company could result in personal injury or
property damage.
WARNING
!
WARNING
!

4
How to Put Your Ceiling
Fan Together
1. Remove the hanger ball by loosening the setscrew
in the hanger ball until the ball falls freely down the
downrod (Figure 1). Remove the pin from the
downrod, then remove the hanger ball. Retain the
pin and hanger ball for reinstallation in step 5.
2. Separate, untwist and unkink the three 80” motor
leads. Route the motor lead wires through the
downrod. Remove the upper setscrew from the
motor coupling. Align the clevis pin holes in the
downrod with the holes in the motor coupling.
Install the clevis pin and secure with the hairpin
clip (Figure 2). The clevis pin must go through the
holes in the motor coupling and the holes in the
downrod. Be sure to push the straight leg of the
hairpin clip through the hole near the end of the
clevis pin until the curved portion of the hairpin clip
snaps around the clevis pin. The hairpin clip must
be properly installed to prevent the clevis pin from
working loose. Pull on the downrod to make sure
the clevis pin is properly installed. Reinstall the
upper setscrew in the motor coupling. Check that
the lower setscrew is tightened securely (Figure 2).
NOTE: The setscrews must be properly installed
as described above, or fan wobble could result.
3. Make sure the grommet is properly installed in the
coupling cover, then slide the coupling cover on
the downrod until it rests on the motor housing.
Place the ceiling cover over the downrod. Be sure
that the ceiling cover and the coupling cover are
both oriented correctly (Figure 3).
4. Reinstall the hanger ball (Figure 4) on the downrod
as follows. Route the three 80” motor leads through
the hanger ball. Position the pin through the two
holes in the downrod and align the hanger ball so the
pin is captured in the groove in the top of the hanger
ball. Pull the hanger ball up tight against the pin and
securely tighten the setscrew in the hanger ball.
A loose setscrew could create fan wobble.
5.The fan comes with blue, black and white leads that
are 80” long. Before installing fan, measure up
approximately 6 to 9-inches above top of hanger
ball/downrod assembly. Cut off excess leads and
strip back insulation 1/2-inch from end of leads.
6. Engage the connector of the switch housing
assembly with the motor connector (Figure 5). The
two connectors are keyed and color-coded and
must be mated correctly (color-to-color) before
they can be engaged. Make sure the connector
latch closes properly.
It is critical that the clevis pin in the motor coupling
is properly installed and the setscrews securely
tightened. Failure to verify that the pin and setscrews
are properly installed could result in the fan falling.
WARNING
!
PIN
SETSCREW
HANGER
BALL
DOWNROD
Figure 1
MOTOR COUPLING
HAIRPIN
CLIP
CLEVIS
PIN
UPPER
SETSCREW
CLEVIS
PIN
SETSCREW
HAIRPIN
CLIP
MOTOR
COUPLING
SETSCREW
CLEVIS PIN
DOWNROD
Figure 2
CEILING
COVER
COUPLING COVER
PIN
SETSCREW
HANGER
BALL
DOWNROD
Figure 4
It is critical that the pin in the hanger ball is properly
installed and the setscrew securely tightened.
Failure to verify that the pin and setscrew are
properly installed could result in the fan falling.
WARNING
!
Figure 3

7. Remove the three switch housing mounting screws
(Figure 5) from the switch housing plate. Position
the switch housing assembly on the switch hous-
ing plate and align the holes in the switch housing
assembly with the holes in the plate. Secure the
switch housing assembly by installing the three
screws (Figure 6).
8. Turn fan assembly upside down in preparation for
mounting fan blade assemblies.
9. Mount blade flanges to fan blades using three
3/16-24 x 5/16” slotted Phillips blade screws and
three blade washers (Figure 7).
NOTE: Take care not to scratch fan housing when
installing blades.
The outlet box must be securely anchored and
capable of withstanding a load of at least 50 pounds.
If your fan is to replace an existing ceiling light fixture,
turn electricity off at the main fuse box at this time and
remove the existing light fixture.
NOTE: Remove and discard the four shipping
spacers and screws from the motor hub.
10. Loosely attach one blade assembly to the motor
hub using two 1/4-20 x 1/2” Phillips oval head
flange screws. Make sure the screws are NOT
tightened. (Figure 8.) Repeat this procedure for
other four blade assemblies.
11. The blade flanges have an interlocking feature that
must be fully engaged before tightening the screw.
Make sure all the flanges are properly engaged and
then tighten the flange screws. If one of the flanges
does not seat properly on the motor hub, loosen the
adjacent flange screws, re-engage and reseat the
flanges, then tighten the screws again.
12. You have now completed the assembly of your
new ceiling fan. You can now proceed with
hanging and wiring your fan.
To reduce the risk of personal injury, do not bend the
blade flange when installing the blade flanges,
balancing the blades or cleaning the fan. Do not
insert foreign objects in between rotating fan blades.
BLADE
ASSEMBLY
BLADE FLANGE SCREWS
Figure 8
WARNING
!
5
Electrical Requirements
Your new ceiling fan will require a grounded electrical
supply line of 120 volts AC, 60 Hz, 15 amp circuit.
FAN BLADE
BLADE FLANGE
3/16-24 x 5/16" SLOTTED PHILLIPS
BLADE SCREW (3)
BLADE WASHER (3)
Figure 7
SWITCH
HOUSING
ASSEMBLY
MOUNTING
SCREWS (3)
Figure 6 To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked acceptable for
fan support, and use screws supplied with outlet
box. Most outlet boxes commonly used for support
of light fixtures are not acceptable for fan support
and may need to be replaced. Consult a qualified
electrician if in doubt.
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is
turned off at the main fuse box before wiring. All
wiring must be in accordance with National and
Local codes and the ceiling fan must be properly
grounded as a precaution against possible
electrical shock.
WARNING
!
WARNING
!
To avoid possible fire or shock, do not pinch wires
between the switch cup assembly and the switch
cup plate.
WARNING
!
SWITCH HOUSING
MOUNTING SCREW (3)
SWITCH HOUSING
CONNECTOR
MOTOR CONNECTOR
SWITCH CUP
CONNECTOR
MOTOR
CONNECTOR
Figure 5

If you feel that you do not have enough electrical
wiring knowledge or experience, have your fan
installed by a licensed electrician.
1. Connect the green grounding lead from the hanger
ball and the green grounding lead from the hanger
bracket to the grounding conductor of supply (this
may be a bare wire or wire with green colored
insulation). Securely connect wires with wire
connector supplied (Figure 12).
NOTE: If you are using an Emerson Light Fixture
with your fan, refer to Light Fixture Owner’s
Manual for wiring.
2. Securely connect the fan motor white wire to the
supply white (neutral) wire using wire connector
supplied (Figure 12). Securely connect the fan
motor black wire and blue wire to the supply black
(hot) wire using wire connector supplied (Figure
12). After connections have been made, turn leads
upward and carefully push leads into the outlet box,
with the white and green leads on one side of the
outlet box and the black and blue leads on the
other side of the outlet box.
6
How to Wire
Your Ceiling Fan
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD ASSEMBLY
NOTE: CEILING COVER,
SUPPLY WIRES AND
FAN WIRES OMITTED
FOR CLARITY.
Figure 11
To avoid possible fire or shock, do not pinch wires
between the hanger ball/downrod assembly and
hanger bracket.
WARNING
!
To avoid possible electrical shock, be sure electricity
is turned off at the main fuse box before wiring.
NOTE: If you are not sure if the outlet box is ground-
ed, contact a licensed electrician for advice, as it
must be grounded for safe operation.
WARNING
!
How to Hang Your
Ceiling Fan
The fan must be hung with at least 7' of clearance
from floor to blades (Figure 9).
Hanger bracket must seat firmly against outlet box. If
the outlet box is recessed, remove wall board until
bracket contacts box. If bracket and/or outlet box are
not securely attached, the fan could wobble or fall.
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
TWO SCREWS
SUPPLIED WITH
OUTLET BOX HANGER
BRACKET
TAB
OUTLET
BOX
Figure 2
AT LEAST
7'
CEILING
FLOOR
Figure 9
Figure 10
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked acceptable for
fan support, and use screws supplied with outlet
box. Most outlet boxes commonly used for support
of light fixtures are not acceptable for fan support
and may need to be replaced. Consult a qualified
electrician in in doubt.
To avoid fire or shock, follow all wiring instructions
carefully.
Any electrical work not described in these
instructions should be done or approved by a
licensed electrician.
The outlet box must be securely anchored and
capable of withstanding a load of at least 50 lbs.
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
1.Securely attach the hanger bracket to the outlet box
using the two screws supplied with the outlet box.
(Figure 10.)
2. Carefully lift the fan and seat the hanger ball/down-
rod assembly on the hanger bracket that was just
attached to the outlet box (Figure 11). Be sure the
groove in the ball is lined up with tab on the hanger
bracket (Figure 10).

7
3. Screw the two threaded studs (supplied) into the
tapped holes in the hanger bracket.
4. Lift the ceiling cover up to the threaded studs and
turn until studs protrude through the holes in the
ceiling cover (Figure 13).
5. Secure the ceiling cover in place by sliding
lockwashers over the threaded studs and installing the
two knurled knobs (supplied). (Figure 13). Tighten the
knurled knobs securely until the ceiling cover fits
snugly against the ceiling and the hole in the ceiling
cover is clear of the downrod. Your fan is now wired to
be turned on and off from the fan switch.
NOTE: CEILING COVER
OMITTED FOR CLARITY.
GROUND
WIRE
LISTED
WIRE
CONNECTOR (3)
GREEN WIRE
(GROUND) FROM
HANGER BRACKET
GREEN WIRE
(GROUND) FROM
HANGER BALL
WHITE SUPPLY
(NEUTRAL)
WHITE FAN
WIRE
BLACK SUPPLY
(HOT)
BLACK AND BLUE
FAN WIRES
Fi
g
ure 4
CEILING COVER
THREADED STUD
KNURLED KNOB
LOCKWASHERS (2)
Figure 12
Figure 13
Setting Remote Control
Operating Frequency
Your Emerson Remote Control Fan receiver and
transmitter can be set to operate at one of 16
different frequencies. In most cases you will not need
to change the factory set frequency. The frequency
should only need to be changed for one of the
following reasons:
a. Multiple fans in one location that you wish to
operate from one transmitter. (ALL fans should be
set at the same frequency.)
NOTE: Your Emerson Remote Control is designed
to operate from a distance up to 20 feet from the
fan. If you are operating multiple fans with one
transmitter you should be no more than 20 feet
from any of the fans to ensure that all fans will
respond at the same time.
b. Multiple fans in one location that you wish to
operate from different transmitters. (ALL fans set
to different frequencies.)
c. Interference with other household systems such as
your garage door opener.
NOTE: If you change the operating frequency,
you must change both the transmitter and
receiver to the same frequency. The remote
control will not operate unless both the transmit-
ter and receiver are set at the same frequency.
Setting Transmitter Frequency
1. Remove battery cover and the battery from the
transmitter. Locate the switch with four levers
numbered 1, 2, 3, 4, just above the battery
compartment (See Figure 14).
2. With a narrow blade screwdriver, change the
position of one or more of the four levers on the
switch. Note the positions of each of the four
levers by number; down is ON, up is OFF.
Setting Receiver Frequency
1. After electricity has been turned off at the main fuse
box, remove the switch housing assembly by
removing the three mounting screws (See Figure 6).
2. Disconnect the switch housing connector form the
motor connector by squeezing the latch and pulling
the connectors apart.
3. Remove the receiver from the switch housing and
locate the switch with four numbered levers (same
as transmitter). (See Figures 14 and 15).
4. Set the position of all four levers, ON or OFF to the
same position as those on the transmitter.
5. Install the receiver in the switch housing, push the
motor connector into the switch housing connector
and assemble the switch housing assembly to the
housing plate (See Figures 5 and 6).
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not
operate fan until blades are in place. Noise and fan
damage could result.
WARNING
!
To avoid possible fire or shock, make sure that the
electrical wires are completely inside the outlet box
and not pinched between the ceiling cover and the
ceiling.
WARNING
!
SUPPLY
GROUND
WIRE

8
FAN/OFF
FOR/REV
LIGHT
DIMMER
HIGH
MED
LOW
®
Figure 17
Operation of Your
Remote Control
1. To set the desired fan speed, push the HI, MED or
LOW buttons to set your fan on high, medium or
low speed. (See Figure 17).
2. To reverse the direction the fan is turning, press
the FOR/REV button. The direction the fan turns
will change each time the FOR/REV button is
pressed.
3. To turn the fan OFF press the FAN/OFF button.
4. To set the level of light brightness, press and hold
the LIGHT DIMMER button. The light brightness
will continue to increase then decrease while the
button is held down. When the light is at the
desired brightness, release the button.
5. To turn the light ON or OFF, press and release the
LIGHT DIMMER button. The light will turn ON at
the light level previously set (See Step 4).
Red light turns on when any button is pressed.
If the light does not come on, replace your
battery.
1. Restore electrical power to the outlet box by turning
the electricity on at the main fuse box.
2. Remove the battery cover by pressing firmly on the
arrow and sliding the cover off the control
transmitter.
3. Engage the connector in the transmitter with the
terminals of a 9-volt alkaline battery (not supplied)
(Figure 16).
4. Position the battery in the transmitter and replace
the battery cover.
5. Operate ceiling fan using the Remote Control
transmitter.
Using Your Ceiling Fan
9-VOLT ALKALINE
BATTERY (NOT
SUPPLIED)
REMOTE CONTROL
TRANSMITTER
BATTERY COVER
Figure 16
SWITCH
LEVERS
SWITCH
LEVERS
Figure 14. TRANSMITTER Figure 15. RECEIVER

9
Trouble Shooting
TROUBLE PROBABLE CAUSE SUGGESTED REMEDY
1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit
breakers.
2. Loose power line connections to the fan, or loose 2. Check line wire connections to fan and switch
switch wire connections in the switch housing. wire connections in the switch housing.
WARNING: Make sure main power is turned off.
3. Reversing switch in neutral position. 3. Make sure reversing switch position is all the way
to one side.
2. Fan sounds noisy. 1. Blades not attached to fan. 1. Attach blades to fan before operating.
2. Loose screws in motor housing. 2. Check to make sure all screws in motor housing
are snug (not over-tight).
3. Screws securing fan blade flanges to motor hub 3. Check to make sure the screws which attach
are loose. the fan flanges to the motor hub are tight.
4. Switch housing binding against blade hub. 4. Check to make sure that the switch housing
does not bind against the blade hub.
5. Wire connectors inside switch housing rattling. 5. Check to make sure wire connectors in
switch housing are not rattling against each
other or against the interior wall of the switch
housing.
WARNING: Make sure main power is turned off.
6. Motor noise caused by solid-state variable 6. Some fan motors are sensitive to signals from
speed control. Solid-State variable speed controls. If Solid-
State Control is used and motor noise results
choose an alternative control method.
7. Screws holding blades to flanges are loose. 7. Tighten screws securely.
3. Fan wobbles 1. Screws securing fan blade flanges to motor hub 1. Check to be sure screws which attach the fan
excessively. are loose. blade flanges to the motor hub are tight.
2. Fan blade flanges not seated properly. 2. Check to be sure the fan blade flanges seat
firmly and uniformly to the surface of the motor
hub. If flanges are seated incorrectly, loosen the
flange screws and retighten according to the
procedure in the section on "How to Put Your
Ceiling Fan Together".
3. Hanger bracket and/or ceiling outlet box is not 3. Tighten the hanger bracket screws to the outlet
securely fastened. box, and/or secure outlet box.
4. Fan blades out of balance. 4. Interchanging an adjacent (side-by-side) blade
pair can redistribute the weight and result in
smoother operation.
WARNING: FOR YOUR OWN SAFETY TURN OFF POWER AT FUSE BOX OR CIRCUIT BREAKER
BEFORE TROUBLE SHOOTING YOUR FAN.
IMPORTANT CARE INSTRUCTIONS
for your Ceiling Fan
Periodic cleaning of your new ceiling fan is the only
maintenance that is needed.
When cleaning, use only a soft brush or lint free cloth
to avoid scratching the finish.
Abrasive cleaning agents are not required and should
be avoided to prevent damage to finish.
Maintenance Accessories
1. Ceiling Fan Light Kits (see store or catalog).
2. Downrod Kits (see store or catalog).
Do not use water when cleaning your ceiling fan. It
could damage the motor or the blades and create the
possibility of an electrical shock.
WARNING
!This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product by
Emerson Company. Substitution of parts or
accessories not designated for use with this product
by Emerson Company could result in personal injury
or property damage.
The use of any other control not specifically
approved for this fan could result in fire, shock and
personal injury.
WARNING
!
WARNING
!
!
!
!

Repair Parts Listing
Part Numbers
Key Model No. Model No. Model No. Model No. Model No. Model No. Model No.
No. Description CF759AB00 CF759PB00 CF759OB00 CF759TG00 CF759BS00 CF759HTW00 CF759WW00
* Hanger Ball Assembly, 760750 760750-1 760750-36 760750-37 760750-24 760750-34 760750-3
Consisting of:
1 Hanger Bracket — — — — — — —
2 Hanger Ball — — — — — — —
3 Downrod — — — — — — —
* Parts Bag Containing: 761538-6 761538-5 761538-8 761538-8 761538-7 761538-5 761538-5
4 Wire Connector (3) — — — — — — —
5 Pin, Clevis — — — — — — —
6 Clip, Hairpin — — — — — — —
7 Screw, 1/4-20 x 1/2” (11) — — — — — — —
8 Screw, 3/16-24 x 5/16”(16) — — — — — — —
9 Threaded Stud (2) — — — — — — —
10 Lockwasher (2) — — — — — — —
11 Knurled Knob (2) — — — — — — —
12 Blade Washer (16) — — — — — — —
13 Canopy, Ceiling 760169-2 760169-1 760169-24 760169-25 760169-15 760169-20 760169
14 Coupling Cover 761860-7 761860-10 761860-4 761860-1 761860-3 761860-5 761860
15 Control Transmitter 762023 762023 762023 762023 762023 762023 762023
16 Control Receiver 762036 762036 762036 762036 762036 762036 762036
17 Switch Housing 762024-3 762024-1 762024-4 762024-6 762024-5 762024-2 762024
18 Blade (set of 5) 761859-8 761859-8 761859-5 761859-16 761859-17 761859-6 761859-22
19 Flange (set of 5) 761901 761901-1 761901-4 761901-11 761901-9 761901-8 761901-5
—Owner's Manual BP7240-1 BP7240-1 BP7240-1 BP7240-1 BP7240-1 BP7240-1 BP7240-1
Before discarding packaging material, be certain
all parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE
THE FOLLOWING INFORMATION:
• PART NUMBER • PART DESCRIPTION
• NAME OF ITEM • MODEL NUMBER
For repair parts, phone [phone].
Part No. F40BP72400001 Printed in Taiwan 11/00 Form No. BP7240-1
19
65
18
8
16
12
17
14
13
4
9
12
3
15
FAN/OFF
FOR/REV
LIGHT
DIMMER
HIGH
MED
LOW
®
10
11
7
EMERSON
Air Comfort Products
DIVISION OF EMERSON COMPANY
8100 W. Florissant, St. Louis, MO 63136
