Emerson Designer Remote CF759AB03 User manual

Part No. F40BP73180000 Form No. BP7318
U.L. Model No.: CF759
READ AND SAVE THESE INSTRUCTIONS
Model No.
CF759AB03
CF759AW03
CF759BS03
CF759OB03
CF759ORB03
CF759WB03
CF759WW03
DESIGNER REMOTE
Net Weight: 21.1 Lbs.
Series Ceiling Fan
Owner's Manual
LIMITED WARRANTY
What The Warranty Covers:
This warranty covers the motor and the other components and accessories of your Emerson ceiling fan against all defects in workmanship and materials.
You must be the original purchaser or user of the product to be covered.
What The Period Of Coverage Is:
As it applies to the motor, this warranty will last for the lifetime of your ceiling fan. All other components and accessories are covered by this warranty for
one year from the date you purchased your ceiling fan. ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
MADE WITH RESPECT TO COMPONENTS AND ACCESSORIES IS ALSO LIMITED TO ONE YEAR.
What Will Emerson Electric Co. Do To Correct Problems:
Emerson Electric Co. will replace a defective Emerson Air Comfort Ceiling Fan motor, blade, component or other accessory at no charge to you. If repair of
the motor or blades is not practical or possible within a reasonable time and no replacement can be provided, Emerson will refund the actual purchase price
of your fan. WE WILL SHIP THE REPAIRED PRODUCT OR REPLACEMENT TO YOU AT NO CHARGE, BUT YOU ARE RESPONSIBLE FOR ALL COSTS OR
REMOVAL, REINSTALLATION AND SHIPPING OF THE PRODUCT TO EMERSON ELECTRIC CO.
How Can You Get Service:
YOU MUST HAVE PROOF OF YOUR PURCHASE OF THE CEILING FAN TO OBTAIN LIMITED WARRANTY SERVICE. KEEP YOUR RECEIPT OR OTHER PROOF
OF PURCHASE. You can return the product to our factory or to your nearest authorized service center.
• To return the product to the factory, obtain a return authorization and service identification tag by writing to Air Comfort Products, Division of Emerson
Electric Co., 8100 W. Florissant Ave., St. Louis, MO 63136. Include all model numbers shown on the product with your request.
• To return the product to an authorized service center, call 1-800-654-3545 for the address of the nearest authorized service center.
You will be responsible for all insurance, freight or other transportation charges to our factory or authorized service
center. Your Emerson Air Comfort Ceiling Fan should be properly packed to avoid damage in transit since we will not be responsible for any such damage.
What Is Not Covered:
The glass globes and light bulbs of your ceiling fan are not covered by this warranty. This warranty also does not cover any defects, malfunctions or failures
caused by:
• Repairs by persons not authorized by Emerson Electric Co.,
• Use of parts or accessories not authorized by Emerson Electric Co.,
• Mishandling, improper installation, modifications or damage to your ceiling fan while in your possession, or
• Unreasonable use, misuse, abuse, including failing to do reasonable and necessary maintenance, and normal wear and tear.
Additionally, this warranty and any implied warranty of merchantability or fitness for a particular purpose are voided when:
• The original purchaser or user ceases to own the product, or
• The fan is moved from its original point of installation.
This warranty is only valid within the 50 states of the United States and the District of Columbia. No other written or oral warranties apply, and no employee,
agent, dealer or other person is authorized to give any warranties on behalf of Emerson Electric Co.
REPAIR, REPLACEMENT OR A REFUND ARE THE EXCLUSIVE REMEDIES AVAILABLE UNDER THIS WARRANTY AND EMERSON IS NOT RESPONSIBLE
FOR DAMAGES OF ANY KIND, INCLUDING INCIDENTAL AND CONSEQUENTIAL DAMAGES. Incidental damages include but are not limited to such damages
as loss of time and loss of use. Consequential damages include but are not limited to the cost of repairing or replacing other property which was damaged if
this product does not work properly.
How State Law Relates To The Warranty:
Some states do not allow the exclusion or limitation of incidental or consequential damages so the above exclusion or limitation may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

2
WARNING
!
WARNING: To avoid fire, shock, and serious personal injury, follow these instructions.
Safety Instructions
1. Read your owner’s manual carefully and keep it for future reference.
2. Before servicing or cleaning unit, switch power off at service panel and lock service panel
disconnecting means to prevent power from being switched on accidentally. When the service
disconnecting means cannot be locked, securely fasten a warning device, such as a tag, to the
service panel.
3. Be careful of the fan and blades when cleaning, painting, or working near the fan. Always turn off
the power to the ceiling fan before servicing.
4. Do not put anything into the fan blades while they are turning.
5. Do not operate reversing switch until fan blades have come to a complete stop.
Additional Safety Instructions for Installation
1. To avoid possible shock, be sure electricity is turned off at the fuse box before wiring, and do not
operate fan without blades.
2. All wiring must be in accordance with the National Electrical Codes “ANSI/NFPA 70-1999” and
Local Electrical Codes. Use the National Electrical Code if Local Codes do not exist. The ceiling
fan must be grounded as a precaution against possible electrical shock. Electrical installation
should be made or approved by a licensed electrician.
3. The outlet box and joist must be securely mounted and capable of reliably supporting at least
50 pounds. Use only U.L. outlet boxes listed as acceptable for fan support, and use the mounting
screws provided with the outlet box. Most outlet boxes commonly used for support of light
fixtures are not acceptable for fan support and may need to be replaced. Consult a qualified
electrician if in doubt.
4. The downrod furnished with the fan provides the minimum recommended floor to fan blade
clearance for an 8 foot ceiling.
5. The fan must be mounted with the fan blades at least 7 feet from the floor to prevent accidental
contact with the fan blades.
6. The fan must be installed on a level ceiling. Do NOT install the fan on a sloped or cathedral
ceiling, unless the outlet box is installed so that the mounting surface (the bottom of the outlet
box) is level. The receiver will be damaged, resulting in an inoperable fan and a possible electrical
fire.
7. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do
not know enough about electrical wiring, have your fan installed by a licensed electrician.
WARNING: To avoid fire, shock or injury, do not use an Emerson or any other brand of control not
specifically approved for this fan.
WARNING: This product is designed to use only those parts supplied with this product and/or any
accessories designated specifically for use with this product by Emerson. Substitution of parts or
accessories not designated for use with this product by Emerson could result in personal injury or
property damage.
WARNING: To reduce the risk of personal injury, do not bend the blade flange when installing the
blade flanges, balancing the blades or cleaning the fan. Do not insert foreign objects in between
rotating fan blades.
WARNING: To reduce the risk of electric shock, this fan must be installed with an isolating wall
control/switch.
DATE CODE:
The date code of this fan may be found on the box, stamped in ink on a white label.
You should record this data above and keep it in a safe place for future use.

1. Check to see that you have received the following
parts:
NOTE: If you are uncertain of part description,
refer to exploded view illustration.
a. Fan motor assembly
b. One switch housing assembly
c. Five fan blades
d. One ceiling cover
e. Five blade flanges
f. One remote control (transmitter and receiver)
g. Four 25-watt candelabra bulbs
h. One hanger ball/downrod assembly
i. One hanger bracket
j. One coupling cover
k. One loose parts bag containing:
1. Sixteen M5 x 6 washer head blade
screws
2. Sixteen blade washers
3. One M6 x 14 captive screw with
lockwasher
4. Three wire connectors
5. Two threaded studs
6. Two knurled knobs
7. Two lockwashers
8. One clevis pin
9. One hairpin clip
This Manual Is Designed to Make it as Easy as Possible for You to Assemble,
Install, Operate and Maintain Your Ceiling Fan
Tools Needed for Assembly
One Phillips head screwdriver One stepladder
One 1/4” blade screwdriver One wire stripper
Three wire connectors (supplied).
MATERIALS
1. Wiring outlet box and box connectors must be of
type required by the local code. The minimum wire
would be a 3-conductor (2-wire with ground) of the
following size:
3
Installed Wire Length Wire Size A.W.G.
Up to 50 ft. 14
50-100 ft. 12
2. A 9-volt alkaline battery is required for operating
the remote control.
Unpacking Instructions
For your convenience, check-off boxes are provided next to each step. As each step is completed, place a
check mark in the box. This will insure that all steps have been completed and will be helpful in finding
your place should you be interrupted.
Before assembly your ceiling fan, refer to section on
proper method of wiring your fan (page 7). If you feel
you do not have enough wiring knowledge or experi-
ence, have your fan installed by a licensed electrician.
Do not install or use fan if any part is damaged or
missing. Call Toll-Free:
1-800-654-3545
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product by
Emerson Electric Co. Substitution of parts or acces-
sories not designated for use with this product by
Emerson Electric Co. could result in personal injury
or property damage.
NOTE: Place the parts from the loose parts bags
in a small container to keep them from being lost.
If any parts are missing, contact your local retail-
er or catalog outlet for replacement before
proceeding.
2. Remove the fan motor assembly from the
protective plastic bag and place it into the lower
foam pad with the top of the fan motor assembly
facing up.
The lower foam pad serves as a holder for the fan
during assembly.
LOOSE
PARTS
BAG
HANGER
BRACKET
FAN
BLADES
FAN MOTOR
ASSEMBLY
CEILING
COVER
BLADE
FLANGES
SWITCH
HOUSING
ASSEMBLY
COUPLING
COVER
HANGER BALL/
DOWNROD
ASSEMBLY
REMOTE CONTROL
RECEIVER
REMOTE CONTROL
TRANSMITTER 25-WATT
CANDELABRA
BASE BULBS
WARNING
!
WARNING
!
WARNING
!

ON
1234
ON
SWITCH
LEVERS
CODE
SWITCH
BATTERY
CONNECTOR
BATTERY REMOTE
CONTROL
TRANSMITTER BATTERY
COVER
CODE SWITCH
CODE
SWITCH RECEIVER
Figure 1
IMPORTANT
This Owner’s Manual is divided into two sections.
The first section, REMOTE CONTROL
PROCEDURES, describes how to install the 9-Volt
alkaline battery (not supplied) in the remote
control transmitter, and how to set the operating
frequency of the transmitter and receiver. These
instructions must be performed prior to
installation of the ceiling fan as described in the
second section, CEILING FAN PROCEDURES.
REMOTE CONTROL
PROCEDURES
General
The remote control supplied with your Emerson
ceiling fan consists of a hand-held transmitter and a
receiver which is mounted under the fan ceiling cover.
The remote control is designed to separately control
your ceiling fan and light intensities. There are four
push buttons (HI, MED, LOW, OFF) to set the fan
speed and turn the fan off. The REV push button
changes the airflow direction of the fan blades. The
U/L (uplight) and D/L (downlight) pushbuttons turn the
lights on and off and control the light intensities. The
red indicator light will illuminate while any button is
pressed, indicating that the battery is good.
The remote control transmitter is powered by a 9-Volt
alkaline battery (not supplied). To prevent possible
damage if the battery should leak, be sure to remove
the battery when the control is not to be used for an
extended period of time.
Code switches in the transmitter and receiver may be
set in 16 different positions. If your fan and light go on
and off without using your control, you may be getting
interference from other remote units such as garage
door openers, car alarms or security systems. To
remedy this situation, simply change the combination
code in your transmitter and receiver.
Preset Memory Feature
Your Emerson remote control receiver is equipped
with a preset memory feature. If the electrical supply
to the receiver is controlled through a wall switch,
when the switch is turned off, the control will
remember the light intensities and fan speed. When
the switch is turned back on, the lights and fan will
resume operation as they were prior to the switch
being turned off.
Installation of Battery
1. Remove the battery cover and install a 9-Volt
alkaline battery (not supplied), oriented as shown in
the battery compartment (Figure 1).
Setting Operating
Frequency of Transmitter
and Receiver
Your remote control transmitter and receiver have
code switches which must be set on one of 16
possible code combinations. The four levers
(numbered 1, 2, 3, and 4) on the switches are factory-
set in the ON (up) position. Do not use this setting.
Change the switch settings as follows:
1. Slide the four switch levers (Figure 1) in the remote
control transmitter to your choice of ON (up) or
down positions. Use a ball-point pen or small
screwdriver and slide the levers firmly up or down.
2. In the receiver, slide the four switch levers in the
same positions as set in the transmitter. Make sure
the levers on both switches are in the same
positions; otherwise the fan will not operate.
3. Position the battery in the transmitter battery
compartment and replace the battery cover.
CEILING FAN
PROCEDURES
How to Put Your Ceiling
Fan Together
1. Remove the hanger ball by loosening the setscrew
in the hanger ball until the ball falls freely down the
downrod (Figure 2). Remove the pin from the
downrod, then remove the hanger ball. Retain the
pin and hanger ball for reinstallation in step 6.
4
DOWNROD
PIN
SETSCREW
HANGER
BALL
Figure 2

4. Reinstall the hanger ball (Figure 5) on the downrod
as follows. Route the four 80” motor leads through
the hanger ball. Position the pin through the two
holes in the downrod and align the hanger ball so
the pin is captured in the groove in the top of the
hanger ball. Pull the hanger ball up tight against
the pin and securely tighten the setscrew in the
hanger ball. A loose setscrew could create fan
wobble.
5.Screw the four 25-watt candelabra bulbs into the
uplight sockets on top of the fan motor
assembly (Figure 4).
6.The fan comes with blue, black, orange and white
leads that are 80” long. Before installing fan,
measure up approximately 6 to 9-inches above top
of hanger ball/downrod assembly. Cut off excess
leads and strip back insulation 1/2-inch from end of
leads.
7. Turn the fan assembly upside down in preparation
for mounting the switch housing assembly and fan
blades.
8. Engage the connector of the switch housing
assembly with the motor connector (Figure 6). The
two connectors are keyed and color-coded and
must be mated correctly (color-to-color) before
they can be engaged. Make sure the connector
latch closes properly.
2. Separate, untwist and unkink the four 80” motor
leads. Route the motor lead wires through the
downrod. Remove the setscrews from the motor
coupling. Align the clevis pin holes in the downrod
with the holes in the motor coupling. Install the cle-
vis pin and secure with the hairpin clip (Figure 3).
The clevis pin must go through the holes in the
motor coupling and the holes in the downrod. Be
sure to push the straight leg of the hairpin clip
through the hole near the end of the clevis pin until
the curved portion of the hairpin clip snaps around
the clevis pin. The hairpin clip must be properly
installed to prevent the clevis pin from working
loose. Pull on the downrod to make sure the clevis
pin is properly installed. Reinstall the setscrews in
the motor coupling. Check that the setscrews are
tightened securely (Figure 3).
NOTE: The setscrew must be properly installed as
described above, or fan wobble could result.
3. Make sure the grommet is properly installed in the
coupling cover, then slide the coupling cover on the
downrod until it rests on the motor housing. Place
the ceiling cover over the downrod. Be sure that
the ceiling cover and the coupling cover are both
oriented correctly (Figure 4).
5
It is critical that the clevis pin in the motor coupling
is properly installed and the setscrew securely
tightened. Failure to verify that the pin and setscrew
are properly installed could result in the fan falling.
WARNING
!
SETSCREWS
HAIRPIN CLIP
DOWNROD
CLEVIS PIN
MOTOR
COUPLING
Figure 3
CEILING
COVER
COUPLING
COVER
UPLIGHT
SOCKET (4)
SETSCREW
DOWNROD
PIN
HANGER BALL
CEILING
COVER
Figure 5
It is critical that the pin in the hanger ball is properly
installed and the setscrew securely tightened.
Failure to verify that the pin and setscrew are proper-
ly installed could result in the fan falling.
WARNING
!
Figure 4
SWITCH HOUSING
CONNECTOR
MOTOR CONNECTOR
SWITCH HOUSING
MOUNTING SCREW (3)
SWITCH
HOUSING
PLATE
Figure 6

10. Mount blade flanges to fan blades using three
M5 x 6 washer head blade screws and three
blade washers (Figure 8).
NOTE: Take care not to scratch fan housing when
installing blades.
SWITCH
HOUSING
ASSEMBLY
MOUNTING
SCREWS (3)
FAN BLADE
BLADE FLANGE
M5 x 6 WASHER HEAD
BLADE SCREW (3)
BLADE WASHER (3)
6
Figure 7 Electrical Requirements
If your fan is to replace an existing ceiling light fixture,
turn electricity off at the main fuse box at this time and
remove the existing light fixture.
Your new ceiling fan will require a grounded electrical
supply line of 120 volts AC, 60 Hz, 15 amp circuit.
The outlet box must be securely anchored and capa-
ble of withstanding a load of at least 50 pounds.
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked acceptable for
fan support, and use screws supplied with outlet
box. Most outlet boxes commonly used for support
of light fixtures are not acceptable for fan support
and may need to be replaced. Consult a qualified
electrician if in doubt.
To avoid fire or shock, follow all wiring instructions
carefully. Any electrical work not described in these
instructions should be done or approved by a
licensed electrician.
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is
turned off at the main fuse box before wiring. All
wiring must be in accordance with National and
Local codes and the ceiling fan must be properly
grounded as a precaution against possible electrical
shock.
WARNING
!
WARNING
!
WARNING
!
NOTE: Remove and discard the five shipping
spacers and screws from the motor hub.
11. Loosely attach one blade assembly to the motor
hub using two M6 x 14 captive screws with lock-
washers (Figure 9). Make sure the screws are
NOT tightened. Repeat this procedure for other
four blade assemblies.
12. The blade flanges have an interlocking feature
that must be fully engaged before tightening the
screws. Make sure all the flanges are properly
engaged and then tighten the flange screws. If
one of the flanges does not seat properly on the
motor hub, loosen the adjacent flange screws, re-
engage and reseat the flanges, then tighten the
screws again.
13. You have now completed the assembly of your
new ceiling fan. You can now proceed with
hanging and wiring your fan.
To reduce the risk of personal injury, do not bend the
blade flange when installing the blade flanges,
balancing the blades or cleaning the fan. Do not
insert foreign objects in between rotating fan blades.
WARNING
!
BLADE
ASSEMBLY
M6 x 14 CAPTIVE SCREWS
WITH LOCKWASHERS
Figure 9
Figure 8
To avoid possible fire or shock, do not pinch wires
between the switch housing assembly and the
housing plate.
WARNING
!
9. Remove the three switch housing mounting screws
(Figure 6) from the switch housing plate. Position
the switch housing assembly on the switch
housing plate and align the holes in the switch
housing assembly with the holes in the plate.
Secure the switch housing assembly by installing
the three screws (Figure 7).

If you feel that you do not have enough electrical
wiring knowledge or experience, have your fan
installed by a licensed electrician.
1. Pull the wire leads, coming from the end of the
downrod, and the supply wires through the open
side of the hanger bracket. (Figure 13).
2. Position the SW105 Receiver in the ceiling cover
so that the flat side of the receiver faces up and the
open portion of the receiver is to the right, as
shown (Figure 13).
7
How to Wire the Ceiling Fan
and Install the Receiver
To avoid possible electrical shock, be sure electricity
is turned off at the main fuse box before wiring.
NOTE: If you are not sure if the outlet box is ground-
ed, contact a licensed electrician for advice, as it
must be grounded for safe operation.
OUTLET
BOX
HANGER
BRACKET
HANGER BALL/
DOWNROD ASSEMBLY
NOTE: CEILING COVER,
SUPPLY WIRES AND
FAN WIRES OMITTED
FOR CLARITY.
Figure 12
To avoid possible fire or shock, do not pinch wires
between the hanger ball/downrod assembly and
hanger bracket.
WARNING
!
WARNING
!
How to Hang Your
Ceiling Fan
The fan must be hung with at least 7' of clearance
from floor to blades (Figure 10).
The fan must be installed on a level ceiling. Do NOT
install the fan on a sloped or cathedral ceiling,
unless the outlet box is installed so that the
mounting surface (the bottom of the outlet box) is
level. The receiver will be damaged, resulting in an
inoperable fan and a possible electrical fire.
Hanger bracket must seat firmly against outlet box. If
the outlet box is recessed, remove wall board until
bracket contacts box. If bracket and/or outlet box are
not securely attached, the fan could wobble or fall.
Failure to seat tab in groove could cause damage to
electrical wires and possible shock or fire hazard.
TWO SCREWS
SUPPLIED WITH
OUTLET BOX HANGER
BRACKET
TAB
OUTLET
BOX
AT LEAST
7'
CEILING
FLOOR
Figure 10
Figure 11
To reduce the risk of fire, electric shock, or personal
injury, mount fan to outlet box marked acceptable for
fan support, and use screws supplied with outlet
box. Most outlet boxes commonly used for support
of light fixtures are not acceptable for fan support
and may need to be replaced. Consult a qualified
electrician in in doubt.
The outlet box must be securely anchored and capable
of withstanding a load of at least 50 lbs.
2. Carefully lift the fan and seat the hanger ball/down-
rod assembly on the hanger bracket that was just
attached to the outlet box (Figure 12). Be sure the
groove in the ball is lined up with tab on the hanger
bracket (Figure 11).
WARNING
!
WARNING
!
WARNING
!
WARNING
!
WARNING
!
1.Securely attach the hanger bracket to the outlet box
using the two screws supplied with the outlet box.
(Figure 11.)

NOTE: If you are using an Emerson Light Fixture
with your fan, refer to the Light Fixture Owner’s
Manual for installation instructions.
8
To avoid possible fire or shock, make sure that the
electrical wires are completely inside the outlet box
and not pinched between the ceiling cover and the
ceiling.
WARNING
!
GROUND
BLACK
TO AC
ELECTRICAL
SUPPLY
WHITE
GREEN
REMOTE CONTROL
RECEIVER
BLACK/WHITE
WHITE
BLUE
WHITE
BLACK
YELLOW
BLUE
WHITE
BLACK
ORANGE
Figure 14
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not
operate fan until blades are in place. Noise and fan
damage could result.
WARNING
!
1-1/4"
THREADED
STUD
LOCKWASHERS (2)
CEILING COVER
KNURLED KNOB
Figure 16
3. Using wire connectors (supplied), make wiring
connections as follows (Figure 13 and 14):
a. Connect the green ground wires from the
hanger bracket and the hanger ball to the supply
ground wire (bare or green).
b. Connect the white fan wire and the white
supply wire to the white receiver wire (AC
IN/MOTOR N).
c. Connect the black fan wire to the black
receiver wire (TO MOTOR L).
d. Connect the black supply wire to the
black/white receiver wire (AC IN L).
e. Connect the blue fan wire to the blue receiver
wire (BOTTOM LIGHT).
f. Connect the orange fan wire to the yellow
receiver wire (UPPER LIGHT).
g. After connecting the wires, spread them apart
so that the green and white wires are on one side
of the outlet box and the black wire is on the
other side. Make sure that black antenna wire sits
on top of the receiver unit.
OUTLET BOX
BLACK SUPPLY WIRE
BLACK/WHITE RECEIVER WIRE
BLACK FAN WIRE
BLUE FAN WIRE
BLUE RECEIVER
WIRE
ORANGE FAN WIRE
YELLOW RECEIVER WIRE
CEILING COVER
WHITE RECEIVER WIRE
WHITE FAN WIRE
WIRE CONNECTOR
RECEIVER
WHITE SUPPLY
WIRE
SUPPLY
GROUND
WIRE (GREEN
OR BARE)
HANGER BALL
GROUND WIRE
(GREEN)
HANGER BRACKET
GROUND WIRE
(GREEN)
HANGER BRACKET
BLACK RECEIVER WIRE
OPEN
PORTION OF
RECEIVER
HERE
Figure 13
4. Insert the connected ends of the wires
up through the open side of the hanger
bracket and into the outlet box as
shown in Figure 15.
5. Screw two 1-1/4” threaded studs (sup-
plied with the ceiling fan) into the tapped
holes in the hanger bracket (Figure 15).
OUTLET BOX
RECEIVER
CEILING COVER
HANGER
BRACKET
1-1/4"
THREADED
STUDS (2)
Figure 15
6. Slide the receiver up and over the hanger bracket.
Press the receiver against the ceiling, holding it in
place while installing the ceiling cover. Lift the
ceiling cover up to the threaded studs and turn until
studs protrude through the holes in the ceiling
cover (Figure 16).
7. Secure the ceiling cover in place by sliding lock-
washers over the threaded studs and installing the two
knurled knobs (supplied) (Figure 16). Tighten the
knurled knobs securely until the ceiling cover fits
snugly against the ceiling. Your fan is now wired to be
controlled using the remote control transmitter.

9
IMPORTANT CARE INSTRUCTIONS
for your Ceiling Fan
Periodic cleaning of your new ceiling fan is the only
maintenance that is needed.
When cleaning, use only a soft brush or lint free cloth
to avoid scratching the finish.
Abrasive cleaning agents are not required and should
be avoided to prevent damage to finish.
Maintenance
Accessories
Do not use water when cleaning your ceiling fan. It
could damage the motor or the blades and create the
possibility of an electrical shock.
This product is designed to use only those parts
supplied with this product and/or any accessories
designated specifically for use with this product by
Emerson Electric Co. Substitution of parts or acces-
sories not designated for use with this product by
Emerson Electric Co. could result in personal injury
or property damage.
The use of any other control not specifically
approved for this fan could result in fire, shock and
personal injury.
1. Ceiling Fan Light Kits (see store or catalog).
2. Downrod Extension Kits (see store or catalog).
WARNING
!
WARNING
!
WARNING
!
REV
MED
OFF
HI
LOW
ULDL
®
NOTE: To prevent damage to the receiver, turn
“off” the electricity at the wall switch before
installing or removing light bulbs on the ceiling
fan or light fixture.
Figure 17
Operation
IMPORTANT
Fan installation must be completed, including the
installation of the fan blades, before testing of the
remote control.
Your remote control has full control of your fan and
lights (Figure 17).
NOTE: Prior to operation of the down light from
the remote control, make sure the switch on the
light is ON.
1. To set the desired fan speed, press the HI, MED,
or LOW button to operate your fan on high,
medium, or low speed.
2. To turn your fan off, press the OFF button.
3. To change the airflow direction of the fan blades,
press the REV button.
4. To turn the downlight on, press and release the D/L
button. The light will turn on at the light intensity
previously selected.
5. To turn the uplight on, press and release the U/L
button. The light will turn on at the light intensity
previously selected.
6. To vary the intensity of the light, hold the U/L or D/L
button down until the desired light intensity is
reached, then release the button.
Installation of
Storage Bracket
A storage bracket is supplied with the remote control
for holding the control unit when not in use. If you
desire to use the bracket, use the two screws
(supplied) and install it on a wall that is away from
excess heat or humidity.

10
WARNING: For your own safety, turn off power at fuse box or circuit breaker before trouble shooting your fan.
Trouble Shooting
TROUBLE PROBABLE CAUSE SUGGESTED REMEDY
1. Fan will not start. 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit
breakers.
2. Loose power line connections to the fan, 2. Check line wire connections to fan and receiver
or loose receiver wire connections in the wire connections in the ceiling cover.
ceiling cover. WARNING: Make sure main power is turned
OFF.
3. Dead battery in Remote Control 3. Replace battery (red indicator light on
transmitter. transmitter should light when any button is
pressed).
4. Code switches in Remote Control 4. Check that code switches are in same positions.
receiver and transmitter are not in Reset if necessary.
same positions.
2. Fan sounds noisy. 1. Blades not attached to fan. 1. Attach blades to fan before operating.
2. Loose screws in motor housing. 2. Check to make sure all screws in motor housing
are snug (not over-tight).
3. Screws securing fan blade flanges to 3. Check to make sure the screws which attach
motor hub are loose. the fan flanges to the motor hub are tight.
4. Wire connectors inside cup assembly 4. Check to make sure wire connectors in cup
rattling. assembly are not rattling against each other or
against the interior wall of the cup assembly.
WARNING: Make sure main power is turned
OFF.
5. Screws holding blades to flanges 5. Tighten screws securely.
are loose.
3. Fan wobbles 1. Setscrew in motor coupling is loose. 1. Tighten setscrew securely in the motor
excessively. coupling.
2. Setscrew in hanger ball/downrod 2. Tighten the setscrew in the hanger ball/
assembly is loose. downrod assembly.
3. Screws securing fan blade flanges to 3. Check to be sure screws which attach the fan
motor are loose. blade flanges to the motor are tight.
4. Fan blade flanges not seated properly. 4. Check to be sure the fan blade flanges seat
firmly and uniformly to the surface of the motor.
If flanges are seated incorrectly, loosen the
flange screws and retighten according to the
procedure in the section on "How to Put
Your Ceiling Fan Together".
5. Hanger bracket and/or ceiling outlet 5. Tighten the hanger bracket screws to the outlet
box is not securely fastened. box, and/or secure outlet box.
6. Fan blades out of balance. 6. Interchanging an adjacent (side-by-side) blade
pair can redistribute the weight and result in
smoother operation.
!
!
!

11
21
65
20
8
9
16
13
4
12
3
12
11
18 10
15
14
17
7
19
Repair Parts

Before discarding packaging material, be certain all
parts have been removed.
HOW TO ORDER REPAIR PARTS
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE
FOLLOWING INFORMATION:
• PART NUMBER • PART DESCRIPTION
• NAME OF ITEM • MODEL NUMBER
For repair parts, phone [phone].
Part No. F40BP73180000 Printed in China 03/06 Form No. BP7318
Repair Parts Listing
Model No.
Key
No. Description CF759WW03 CF759ORB03 CF759AB03 CF759OB03 CF759BS03 CF759WB03 CF759AW03
* Hanger Ball Assembly, 761655 761655-32 761655-3 761655-9 761655-17 761655-20 761655-21
Consisting of:
1 Hanger Bracket — — — — — — —
2 Hanger Ball — — — — — — —
3 Downrod — — — — — — —
* Parts Bag Containing: 763160-1 763160 763160 763160 763160-1 763160 763160-1
4 Wire Connector (3) — — — — — — —
5 Pin, Clevis — — — — — — —
6 Clip, Hairpin — — — — — — —
7 Screw, M6 x 14 (1) — — — — — — —
8 Screw, M5 x 6 (16) — — — — — — —
9 Washer, Blade (16) — — — — — — —
10 Threaded Stud (2) — — — — — — —
11 Lockwasher (2) — — — — — — —
12 Knurled Knob (2) — — — — — — —
13 Canopy, Ceiling 761620 761620-33 761620-3 761620-9 761620-25 761620-26 761620-29
14 Harness, Reversing 763159 763159 763159 763159 763159 763159 763159
15 Switch Housing Assembly 763158-WW 763158-ORB 763158-AB 763158-OB 763158-BS 763158-WB 763158-AW
16 Cover, Coupling 762463-15 762463-16 762463-4 762463 762463-8 762463-1 762463-5
17 Transmitter, Remote Control 762281 762281 762281 762281 762281 762281 762281
18 Receiver, Remote Control 762401 762401 762401 762401 762401 762401 762401
19 Bulb, 25-W Candelabra — — — — — — —
20 Blade (set of 5) 761859-22 761859-32 761859-8 761859-5 761859-30 761859-24 761859-23
21 Flange (set of 5) 763154-WW 763154-ORB 763154-AB 763154-OB 763154-BS 763154-WB 763154-AW
—Owner's Manual BP7318 BP7318 BP7318 BP7318 BP7318 BP7318 BP7318
Air Comfort Products
DIVISION OF EMERSON ELECTRIC CO.
8100 W. Florissant ¥ St. Louis, MO 63136
