Installation Manual
20002158, Rev DO
October 2021
Micro Motion™ ELITE™ Coriolis Flow and
Density Sensors

Safety messages
Safety messages are provided throughout this manual to protect personnel and equipment. Read each safety message carefully
before proceeding to the next step.
Safety and approval information
This Micro Motion product complies with all applicable European directives when properly installed in accordance with the
instructions in this manual. Refer to the EU declaration of conformity for directives that apply to this product. The following are
available: the EU declaration of conformity, with all applicable European directives, and the complete ATEX Installation Drawings
and Instructions. In addition the IECEx Installation Instructions for installations outside of the European Union and the CSA
Installation Instructions for installations in North America are available on the internet at www.emerson.com or through your local
Micro Motion support center.
Information affixed to equipment that complies with the Pressure Equipment Directive, can be found on the internet at
www.emerson.com. For hazardous installations in Europe, refer to standard EN 60079-14 if national standards do not apply.
Other information
Full product specifications can be found in the product data sheet. Troubleshooting information can be found in the configuration
manual. Product data sheets and manuals are available from the Micro Motion web site at www.emerson.com.
Return policy
Follow Micro Motion procedures when returning equipment. These procedures ensure legal compliance with government
transportation agencies and help provide a safe working environment for Micro Motion employees. Micro Motion will not accept
your returned equipment if you fail to follow Micro Motion procedures.
Return procedures and forms are available on our web support site at www.emerson.com, or by phoning the Micro Motion
Customer Service department.
Emerson Flow customer service
Email:
•Worldwide: [email protected]
•Asia-Pacific: [email protected]
Telephone:
North and South America Europe and Middle East Asia Pacific
United States 800-522-6277 U.K. and Ireland 0870 240 1978 Australia 800 158 727
Canada [phone] The Netherlands [phone]
6666
New Zealand 099 128 804
Mexico [phone] France [phone]
901
India 800 440 1468
Argentina [phone] Germany 0800 182 5347 Pakistan 888 550 2682
Brazil [phone] Italy [phone] China [phone]
Chile [phone] Central & Eastern [phone]
111
Japan [phone]
Peru [phone] Russia/CIS [phone] South Korea [phone]
Egypt 0800 000 0015 Singapore [phone]
Oman 800 70101 Thailand 001 800 441 6426
Qatar 431 0044 Malaysia 800 814 008
Kuwait 663 299 01
South Africa 800 991 390
Saudi Arabia 800 844 9564
UAE 800 0444 0684
2

Contents
Chapter 1 Before you begin........................................................................................................5
1.1 About this document...................................................................................................................5
1.2 Hazard messages.........................................................................................................................5
1.3 Related documentation............................................................................................................... 6
Chapter 2 Planning.................................................................................................................... 7
2.1 Installation checklist.................................................................................................................... 7
2.2 Best practices.............................................................................................................................. 8
2.3 Temperature limits...................................................................................................................... 9
2.4 Recommendations for hygienic and self-draining applications...................................................12
Chapter 3 Mounting.................................................................................................................15
3.1 Recommendations for lifting heavy meters............................................................................... 15
3.2 Mount the sensor.......................................................................................................................17
3.3 Rotate junction box or 800 core processor (optional).................................................................18
3.4 Mount electronics of high-temperature sensors........................................................................ 19
3.5 Mount a CMF010 sensor to a wall or pole................................................................................... 23
3.6 Mount a CMFS007, CMFS010 or CMFS015 sensor in a bracket................................................... 24
3.7 Mount a CMFS025, CMFS040 or CMFS050 sensor in a wall mount bracket................................. 25
3.8 Secure wafer-style process connections.....................................................................................26
3.9 Attach extended electronics...................................................................................................... 27
Chapter 4 Transmitter power and I/O wiring............................................................................ 29
4.1 Options for wiring......................................................................................................................29
4.2 Connect 4-wire cable................................................................................................................. 30
4.3 Connect the 9-wire cable .......................................................................................................... 34
Chapter 5 Grounding................................................................................................................35
Chapter 6 Supplementary information.....................................................................................37
6.1 Purge the sensor case ................................................................................................................37
6.2 Pressure relief............................................................................................................................ 39
Installation Manual Contents
20002158 October 2021
Installation Manual 3

Contents Installation Manual
October 2021 20002158
4 Micro Motion ELITE

1 Before you begin
1.1 About this document
This document provides information on planning, mounting, wiring, and grounding the
ELITE sensor.
The information in this document assumes that users understand basic transmitter and
sensor installation, configuration, and maintenance concepts and procedures.
1.2 Hazard messages
This document uses the following criteria for hazard messages based on ANSI standards
Z535.6-2011 (R2017).
DANGER
Serious injury or death will occur if a hazardous situation is not avoided.
WARNING
Serious injury or death could occur if a hazardous situation is not avoided.
CAUTION
Minor or moderate injury will or could occur if a hazardous situation is not avoided.
NOTICE
Data loss, property damage, hardware damage, or software damage can occur if a
situation is not avoided. There is no credible risk of physical injury.
Physical access
NOTICE
Unauthorized personnel can potentially cause significant damage and/or misconfiguration
of end users' equipment. Protect against all intentional or unintentional unauthorized use.
Physical security is an important part of any security program and fundamental to
protecting your system. Restrict physical access to protect users' assets. This is true for all
systems used within the facility.
Installation Manual Before you begin
20002158 October 2021
Installation Manual 5

1.3 Related documentation
You can find all product documentation on the product documentation DVD shipped with
the product or at www.emerson.com.
See any of the following documents for more information:
•The hazardous area approvals documentation shipped with the sensor or available at
www.emerson.com/flowmeasurement.
•Micro Motion ELITE Coriolis Flow and Density Meters Product Data Sheet
•Micro Motion 9-Wire Flow Meter Cable Preparation and Installation Guide
•The transmitter installation and configuration and use guides
Before you begin Installation Manual
October 2021 20002158
6 Micro Motion ELITE

2 Planning
2.1 Installation checklist
□If you plan to mount the transmitter in a hazardous area:
WARNING
Make sure that the hazardous area specified on the approval tag is suitable for the
environment in which the meter will be installed.
□Verify that the local ambient and process temperatures are within the limits of the
meter.
□If your sensor has an integral transmitter, no wiring is required between the sensor and
transmitter. Follow the wiring instructions in the transmitter installation manual for
signal and power wiring.
□If your transmitter has remote-mounted electronics, follow the instructions in this
manual for wiring between the sensor and the transmitter, and then follow the
instructions in the transmitter installation manual for power and signal wiring.
Table 2-1: Maximum lengths for Micro Motion cable
Cable type To transmitter Maximum length
Micro Motion 9-wire 9739 MVD transmitter 1,000 ft (305 m)
All other MVD transmitters 60 ft (18 m)
Micro Motion 4-wire All 4-wire MVD transmitters —1,000 ft (305 m) without
Ex-approval
—500 ft (152 m) with IIC
rated sensors
—1,000 ft (305 m) with IIB
rated sensors
Table 2-2: Maximum lengths for user-supplied 4-wire cable
Wire function Wire size Maximum length
Power (VDC) 22 AWG (0.326 mm²) 300 ft (91 m)
20 AWG (0.518 mm²) 500 ft (152 m)
18 AWG (0.823 mm²) 1,000 ft (305 m)
Signal (RS-485) 22 AWG (0.326 mm²) or larger 1,000 ft (305 m)
□For optimal performance, install the sensor in the preferred orientation. The sensor will
work in any orientation as long as the flow tubes remain full of process fluid.
Installation Manual Planning
20002158 October 2021
Installation Manual 7

Table 2-3: Preferred sensor orientation
Process Primary preferred
orientation
Secondary preferred
orientation
Alternate suitable
orientation
Liquids & slurries
Gases
Liquid with bubbles Wet gas
Two-phase
□Install the meter so that the flow direction arrow on the sensor case matches the actual
forward flow of the process. (Flow direction is also software-selectable.)
2.2 Best practices
The following information can help you get the most from your sensor.
•There are no pipe run requirements for Micro Motion sensors. Straight runs of pipe
upstream or downstream are unnecessary.
•If the sensor is installed in a vertical pipeline, liquids and slurries should flow upward
through the sensor. Gases should flow downward.
•Keep the sensor tubes full of process fluid.
•For halting flow through the sensor with a single valve, install the valve downstream
from the sensor.
Planning Installation Manual
October 2021 20002158
8 Micro Motion ELITE

•The sensor does not require external supports. The flanges will support the sensor in
any orientation. (Some sensor models installed in very small, flexible pipeline have
optional installation instructions that allow for external supports.)
2.3 Temperature limits
Sensors can be used in the process and ambient temperature ranges shown in the
temperature limit graphs. For the purposes of selecting electronics options, temperature
limit graphs should be used only as a general guide. If your process conditions are close to
the gray area, consult with your Micro Motion representative.
WARNING
Temperature limits may be further restricted by hazardous area approvals that are
necessary to avoid potential injury to personnel and damage to equipment. Refer to the
hazardous area approvals documentation shipped with the sensor or available at
www.emerson.com/flowmeasurement for specific temperature ratings for each model
and configuration.
Note
•In all cases, the electronics cannot be operated where the ambient temperature is
below -40 °F (-40.0 °C) or above 140 °F (60.0 °C). If a sensor is to be used where the
ambient temperature is outside of the range permissible for the electronics, the
electronics must be remotely located where the ambient temperature is within the
permissible range, as indicated by the shaded areas of the temperature limit graphs.
•The extended-mount electronics option allows the sensor case to be insulated without
covering the transmitter, core processor, or junction box, but does not affect
temperature ratings. When insulating the sensor case at elevated process
temperatures above 140 °F (60.0 °C), ensure electronics are not enclosed in insulation
as this may lead to electronics failure.
•For the CMFS007 sensor, the difference between the process fluid temperature and the
average temperature of the case must be less than 210 °F (99 °C)
Installation Manual Planning
20002158 October 2021
Installation Manual 9

Ambient and process temperature limits for CMFS007, CMFS025–CMFS150
140 (60)
–40 (–40)
113
(45)
–148 (–100)
–58 (–50) 400 (204)
140 (60)
A
B
B
Tamb
Tproc
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Ambient and process temperature limits for CMF***M/L/H/P (excludes special order
cryogenic modifications) and CMFS010-015
140 (60)
–40 (–40)
113
(45)
–148 (–100)
–400
(–240)
400
(204)
140
(60)
T amb
T proc
A
B
B
C
-148
(-100)
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B = Remote mount electronics only
C = Recommend special order cryogenic sensor options when operating at a process
temperature below -148 °F (-100 °C)
Planning Installation Manual
October 2021 20002158
10 Micro Motion ELITE

Ambient and process temperature limits for special order cryogenic ELITE meters
140 (60)
–40 (–40)
–148 (–100)
–400
(–240)
176
(80)
A
B
Tamb
Tproc
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Ambient and process temperature limits for high temperature ELITE meters
140 (60)
–40 (–40)
–148 (–100)
–58
(–50)
662
(350)
A
B
Tamb
Tproc
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Installation Manual Planning
20002158 October 2021
Installation Manual 11

Ambient and process temperature limits for super duplex ELITE meters
140 (60) 140 (60)
–40 (–40)
–148 (–100)
–40 (–40) 400 (204)
113
(45)
A
B
B
Tamb
Tproc
Tamb = Ambient temperature °F (°C)
Tproc = Process temperature °F (°C)
A = All available electronic options
B= Remote mount electronics only
Note
For super duplex models operating above 351 °F (177.2 °C), consult the factory before
purchase.
2.4 Recommendations for hygienic and self-
draining applications
CMFS sensors are certified EHEDG TYPE EL CLASS I for hygienic applications when installed
vertically with the process fitting and gasket combinations listed in the Position Paper of
the EHEDG Test Methods Subgroup (available at https://www.ehedg.org). Other process
connections/gasket combinations may be used provided they have been evaluated and
successfully tested for in-place cleanability according to the latest edition of EHEDG
Document 2. Refer to the ELITE Product Data Sheet for further information about fitting
options.
For optimal cleanability and drainability:
•If possible, install the sensor in a vertical pipeline with the process fluid flowing upward
through the sensor.
•If the sensor must be installed in a horizontal pipeline, drainage is accomplished by air
purge evacuation of the pipeline circuit.
•For clean-in-place (CIP) applications, Micro Motion recommends using the generally-
accepted flow velocity of at least 1.5 m/s for cleaning the sensor.
•The gap between the electronics housing and sensor body should be inspected
periodically. Manually clean this gap when necessary.
Planning Installation Manual
October 2021 20002158
12 Micro Motion ELITE

Figure 2-1: Installation for self-draining applications
A
B
C
A. Process pipeline
B. Direction of normal process flow
C. Direction of drainage
Installation Manual Planning
20002158 October 2021
Installation Manual 13

Planning Installation Manual
October 2021 20002158
14 Micro Motion ELITE

3 Mounting
3.1 Recommendations for lifting heavy meters
Heavy meters (those over 50 lb (23 kg), and even lighter meters that must be installed in
elevated or difficult-to-reach places, usually require additional consideration when
transporting or lifting them into their installation location.
•Safe handling during transportation and installation is the responsibility of the installer
CAUTION
Know and follow all safety practices and regulations for your facility and for any
lifting/rigging equipment being used in order to prevent injury.
•A professional rigging crew with proper equipment should be used
•Typical equipment for handling heavy meters includes the following:
—Fixed hoist boom trucks or cranes
—Continuous web belt slings
—Eye to eye web belt slings
—Two leg wire rope slings
•Lift a meter by its case.
•Do not lift a meter by its electronics (junction box, transmitter, or any electrical fittings)
or by its purge fittings
•It may be useful to identify the meter center of gravity
•Protect the sealing surfaces on the process fittings with factory-installed flange
protectors or comparable field-installed protection
Installation Manual Mounting
20002158 October 2021
Installation Manual 15

Figure 3-1: Acceptable lifting points
Figure 3-2: Center of gravity for large meters
A
A. Typical center of gravity
Note
Complete and detailed dimensional drawings, including the location of the center of
gravity, can be found through the product drawings link in our online store at
www.emerson.com.
Mounting Installation Manual
October 2021 20002158
16 Micro Motion ELITE

3.2 Mount the sensor
NOTICE
•Lifting the sensor by the electronics or purge connections can damage the device.
•To reduce the risk of collecting liquid in the electronics housing, do not orient
transmitters or sensor junction boxes with their conduit openings pointing upward.
Procedure
Mount the sensor.
Notes
•Do not use the sensor to support the piping.
•The sensor does not require external supports. The flanges will support the sensor in
any orientation.Some sensor models installed in small, flexible pipelines have optional
installation instructions that allow for external supports.
Installation Manual Mounting
20002158 October 2021
Installation Manual 17

3.3 Rotate junction box or 800 core processor
(optional)
An integrally mounted junction box or 800 core processor can be rotated to one of eight
possible positions in 45 degree increments.
Figure 3-3: Parts for rotating the junction box or 800 core processor on the sensor
A
B
C
DE
A. Housing
B. Clamping ring
C. Clamping ring screw
D. Feedthrough
E. Alignment notches
Note
The 800 core processor is shown in this figure. The junction box has a somewhat different
appearance.
Procedure
1. Loosen the clamping ring screw and remove the clamping ring.
2. Gently separate the housing from the feedthrough, but only until there is sufficient
clearance from the alignment notches to rotate the housing.
3. Rotate the housing to the desired position and in line with the alignment notches.
4. Seat the housing onto the feedthrough.
5. Replace the clamping ring and tighten the clamping ring screw.
Mounting Installation Manual
October 2021 20002158
18 Micro Motion ELITE

3.4 Mount electronics of high-temperature sensors
The electronics of high-temperature sensors are attached to the end of a 32 in (813 mm)
pre-installed flexible conduit. The electronics must be separately mounted on a wall or
instrument pole.
Figure 3-4: Components of a high-temperature sensor
B
A
C
D
A. Sensor
B. Electronics
C. Mounting bracket
D. Flexible conduit with minimum bend radius 6 in (152 mm)
With some large meter sizes, the meter may ship with the electronics attached to the
sensor case. The meter cannot be operated in this configuration. Detach the electronics
bracket from the sensor case and then proceed to mount the electronics to a wall or
instrument pole as described below.
Important
Do not operate the meter while the electronics are attached to the sensor case.
Installation Manual Mounting
20002158 October 2021
Installation Manual 19

Figure 3-5: Removing electronics from the sensor case
A
A. Detach electronics from sensor case and mount to a wall or instrument pole
Procedure
•For wall mounting, use four 0.3 in (8 mm) bolts to secure the mounting bracket.
Mounting Installation Manual
October 2021 20002158
20 Micro Motion ELITE
