Emerson AS1-ACC Series Installation instructions

1(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as1-acc-1_v02.docx
CAD Re-assembly instructions
for our neutral CAD file formats
Product: Air preparation unit, 2-part, Series AS1-ACC
Parts assembled: 2 (5)
Consists of following part: 9 pcs
Parts assembled: 2 (5)

2(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as1-acc-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 1(3): Insert
Constraint 2(3): Align
Constraint 3(3): Mate
1 - Assemble Shut-off valve & Block assembly kit 1 Parts assembled: 2(9)
Constraint 1(3): Align
Constraint 2(3): Align
Constraint 3(3): Mate
2- Assemble Shut-off valver & Block assembly kit 2 Parts assembled: 3(9)

3(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as1-acc-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 1(2): Insert
Constraint 2(2): Mate
3- Assemble Filter pressure regulator & Shut-off valve Parts assembled: 4(9)
Constraint 1(3): Insert
Constraint 2(3): Align
Constraint 3(3): Mate
4- Assemble Filter pressure regulator & Block assembly kit 3 Parts assembled: 5(9)

4(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as1-acc-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 1(2): Insert
Constraint 2(2): Mate
5- Assemble Filter pressure regulator & Reservoir Parts assembled: 6(9)
Constraint 1(2): Insert
Constraint 2(2): Mate
6- Assemble Reservoir & Drain knob Parts assembled: 7(9)

5(5)
Emerson Automation Solutions | AVENTICS
cad_re-ass_as1-acc-1_v02.docx
Mate instructions, step by step for easy handling
Constraint 1(3): Align(0.25mm)
Constraint 2(3): Align(0.25mm)
Constraint 2(3): Align(2.5mm)
7- Assemble Filter pressure regulator & Pressure gauge Parts assembled: 8(9)
Constraint 1(2): Insert
Constraint 2(2): Mate
8- Assemble Shut-off valve & Silencer Parts assembled: 9(9)
