USER MANUAL
GFK-2746C
Sep 2019
PACSystemsTM RSTi
PROFIBUS & PROFINET NETWORK ADAPTER
USER MANUAL

User Manual Contents
GFK-2746C Sep 2019
Contents i
Contents
Chapter 1: Introduction ..........................................................1
1.1 I/O Station Capacity............................................................................................. 2
1.2 Network Topology............................................................................................... 2
1.3 Installation .......................................................................................................... 2
1.4 I/O GuidePro Tool for Configuration & Monitoring ............................................... 3
1.5 Features .............................................................................................................. 3
1.6 List of RSTi Network adapters .............................................................................. 3
1.7 List of RSTi Network adapters .............................................................................. 4
Chapter 2: Installation ............................................................5
2.1 Module Mounting................................................................................................ 6
2.1.1 How to Mount on DIN Rail ......................................................................... 6
2.1.2 How to dismount from DIN Rail ................................................................. 7
2.1.3 How to mount and dismount Network adapter with Integrated I/O ........... 8
2.2 Installing and Removing Components ................................................................. 9
2.3 Internal Bus/Field Power Contacts........................................................................ 9
2.3.1 RSTi Bus Data Pin & Field Power Pin Description ....................................... 10
2.3.2 RSTi Data Bus System .............................................................................. 10
Chapter 3: PROFIBUS Network Adapters ...............................12
3.1 STXPBS001........................................................................................................ 13
3.1.1 Interface ................................................................................................. 13
3.1.2 Specifications.......................................................................................... 14
3.2 STXPBS*............................................................................................................ 16
3.2.1 Interface ................................................................................................. 16
3.2.2 STXPBS* Specifications ........................................................................... 28
3.2.3 LED Indicators ......................................................................................... 31
3.2.4 Dimensions ............................................................................................. 32
3.2.5 PROFIBUS Communication Interface ....................................................... 33
3.2.6 Choice of PROFIBUS data transfer cable type ........................................... 34
3.2.7 PROFIBUS Module Configuration ............................................................. 36
3.2.8 Configuring an I/O Station for PROFIBUS Communication ....................... 39
3.2.9 I/O Process Image Map............................................................................ 46

User Manual Contents
GFK-2746C Sep 2019
Contents ii
3.3 STXPBS001: DPV1 Service Specification............................................................. 50
3.3.1 Supported Service ................................................................................... 50
3.3.2 MSAC1 Read (PROFIBUS-DP Extensions to EN 50170) .............................. 50
3.3.3 MSAC1 Write (PROFIBUS-DP Extensions to EN 50170) ............................. 51
3.3.4 MSAC2 Initiate (PROFIBUS-DP Extensions to EN 50170)........................... 52
3.3.5 MSAC2 Abort (PROFIBUS-DP Extensions to EN 50170)............................. 52
3.3.6 MSAC2 Read (PROFIBUS-DP Extensions to EN 50170).............................. 53
3.3.7 MSAC2 Write (PROFIBUS-DP Extensions to EN 50170) ............................. 54
3.3.8 Error Decode (PROFIBUS-DP Extensions to EN 50170) ............................. 55
3.3.9 Error Code_1 (PROFIBUS-DP Extensions to EN 50170) ............................. 55
3.3.10Diagnostics ............................................................................................. 56
Chapter 4: PROFINET NetworkAdapter .................................59
4.1 STXPNS001 ....................................................................................................... 59
4.1.1 Interface.................................................................................................. 59
4.1.2 STXPNS001 Specifications....................................................................... 60
4.1.3 STXPNS001 LED Indicators ...................................................................... 61
4.1.4 STXPNS001 Dimension ........................................................................... 63
4.1.5 PROFINET Communication Interface ....................................................... 63
4.1.6 PROFINET Module Configuration ............................................................. 64
4.1.7 Configuring an I/O Station for PROFINET Communication........................ 67
Appendix A: Diagnostics...........................................................71
A-1 How to Diagnose when Device Cannot Communicate with the Network............ 71
Appendix B: Product List...........................................................72
Appendix C: Product Certifications and Installation Guidelines for
Conformance............................................................................75
C-1 Important Notes................................................................................................ 75
C-2 Safety Notes ...................................................................................................... 75
C-3 Certifications..................................................................................................... 75
C-4 Government Regulations................................................................................... 76
C-5 Environmental Specifications............................................................................. 76
C-5.1 PROFIBUS STXPBS001 & STXPBS*............................................................ 76
C-5.2 PROFINET STXPNS001............................................................................. 77
C-5.3 Abbreviations.......................................................................................... 77

GFK-2746C Sep 2019
Warnings, Caution Notes as Used in this Publication
Warning
Warning notices are used in this publication to emphasize that hazardous voltages,
currents, temperatures, or other conditions that could cause personal injury to exist
in this equipment or may be associated with its use.
In situations where inattention could cause either personal injury or damage to
equipment, a Warning notice is used.
Caution
Caution notices are used where equipment might be damaged if care is not taken.
Notes: Notes merely call attention to information that is especially significant to understanding and operating
the equipment.
These instructions do not purport to cover all details or variations in equipment, nor to provide for every
possible contingency to be met during installation, operation, and maintenance. The information is supplied
for informational purposes only, and Emerson makes no warranty as to the accuracy of the information
included herein. Changes, modifications, and/or improvements to equipment and specifications are made
periodically and these changes may or may not be reflected herein. It is understood that Emerson may make
changes, modifications, or improvements to the equipment referenced herein or to the document itself at any
time. This document is intended for trained personnel familiar with the Emerson products referenced herein.
Emerson may have patents or pending patent applications covering subject matter in this document. The
furnishing of this document does not provide any license whatsoever to any of these patents.
Emerson provides the following document and the information included therein as-is and without warranty of
any kind, expressed or implied, including but not limited to any implied statutory warranty of merchantability
or fitness for particular purpose.

User Manual Chapter 1
GFK-2746C Sep 2019
Introduction 1
Chapter 1: Introduction
The PACSystems RSTi Network Interface and I/O family provides a cost effective, modular
distributed I/O system. The RSTi network is ideally suited for distributed applications such
as water/wastewater, process control, packaging and assembly. You can easily add RSTi
modules to the system to build functional remote I/O stations to meet your application
requirements.
Figure 1
Sr. Number
Label
Removable Switch of Terminal Block
Tester Pin Hole
Screw less Connection System
I/O Status Display LED
System-Data Pin (6 Pins)
Module Number Marking (Header Type)
Header Type Module (16 points)
Field Power Pin (2 pins)
RTB (Removable Terminal Block)
Reserved communication Port (Useful to only manufacturer)
PUSH Lock for DIN rail
Fieldbus Connector (actual connector depends upon the type network
adapter)
Module Number Marking (on the Removable terminal Block
Node ID or station address setting (either rotary or dip switches
depends upon the type of network adapter)

User Manual Chapter 1
GFK-2746C Sep 2019
Introduction 2
A set of interconnected RSTi modules can be chosen to suit the application and connected
as a slave on a PROFIBUS or a PROFINET network. An RSTi Network Adapter provides the
interface between the network and the RSTi modules. The Network Adapter and I/O
modules selected for an application constitute an I/O station.
1.1 I/O Station Capacity
•Up to 32 IO devices can be connected to a Network Adapter (STXPBS001,
STXPNS001) whereas. PROFIBUS network adapters with integrated IO support only
up to 8 IO modules. The power consumption of all the modules in the node should
be calculated and ensured that it does not exceed the capacity of Network Adapter
and power modules.
•The sum of all input and output data can be up to:
—504 bytes per station for a PROFINET network
—256 bytes / 72 bytes per station for a PROFIBUS network (for STXPBS001, 256
bytes and for STXPBS with Integrated IO, 72 bytes)
•The maximum number of I/O stations per RX3i PPROFINET controller is 128 and for
Rx3i PROFIBUS Controller is 125
1.2 Network Topology
For PROFIBUS networks, I/O stations can be connected via linear bus architecture with active
bus termination at both ends. Devices in a PROFIBUS network connect directly to the bus
cable or indirectly via stub lines.
For PROFINET networks, I/O stations can be connected using either linear or star
architecture.
1.3 Installation
The Network Adapter must be connected to the left of the other RSTi modules in the I/O
station.
Within the RSTi station the bus connection, power supply, and power distribution are
completed by connecting modules together on the DIN rail. Sensors and actuators are wired
to the RSTi modules using spring clamp terminals on the module’s removable terminal
strips. These terminal strips can be keyed so that they cannot be accidentally swapped. If a
module must be replaced, the wiring does not need to be removed; just remove the
terminal strip from the module.
RSTi PROFIBUS Network Adapter with Integrated digital I/O is available. It combines the
advantages of slice-type and block-type construction and offers reduced system design and
maintenance costs.

User Manual Chapter 1
GFK-2746C Sep 2019
Introduction 3
1.4 I/O Guide Pro Tool for Configuration &
Monitoring
PACSystems RSTi Network adapters can be configured & monitored using I/O GuidePro tool.
You can use the I/O GuidePro Tool to monitor & configure the following data:
•Online monitoring & configuration of MODBUS serial & TCP Network adapters.
•Offline configuration of PROFIBUS, DeviceNet & Ethernet/IP Network adapters.
•RSTi Network adapter & IO node over view.
•Power consumption details.
•O module configuration parameters & memory map.
•RSTi Network adapter & IO module technical help.
For more information refer the help section of I/O GuidePro tool.
1.5 Features
•Modules can be easily installed and connected without tools.
•Flexible and modular structure allows I/O stations to be easily expanded.
•A comprehensive selection of I/O modules supports a wide range of applications.
•Small removable terminal blocks conserve panel space and save time making
system connections.
•Module-based diagnostic functions
•The amount of costly parallel wiring is reduced. Within a station, voltage and data
routing can be carried out without additional wiring, reducing the cabinet space
needed.
•Different parts of the system can be operated independent of one another. This
means that pretests can be carried out when the system is set up and that the whole
system can be adapted and expanded.
1.6 List of RSTi Network adapters
RSTi PROFIBUS Network Adapters:
•STXPBS001 PROFIBUS DP/V1 network adapter
•STXPBS032 32-point Positive Logic Input
•STXPBS132 32-point Negative Logic Input
•STXPBS232 32-point Negative Logic Output
•STXPBS332 32-point Positive Logic Output
•STXPBS016 16 relay output
•STXPBS116 16 relay output isolated
•STXPBS432 16 Positive Logic in/16 Negative Logic out

User Manual Chapter 1
GFK-2746C Sep 2019
Introduction 4
•STXPBS532 16 Negative Logic in/16 Negative Logic out
•STXPBS824 16 Positive Logic in/8 relay out
•STXPBS924 16 Negative Logic in/8 relay out
•STXPBS825 16 Positive Logic in/8 relay out isolated
•STXPBS925 16 Negative Logic in/8 relay out isolated
RSTi PROFINET Network Adapter
•STXPNS001 PROFINET network adapter
1.7 List of RSTi Network adapters
•PACSystems RSTi I/O Manual –GFK 2745

User Manual Chapter 2
GFK-2746C Sep 2019
Installation 5
Chapter 2: Installation
WARNING
•Installing or removing modules or wiring with power applied to the system or field
wiring can cause an electrical arc. This can result in unexpected and potentially
dangerous action by field devices. Arcing is an explosion risk in hazardous locations.
Be sure that the area is non-hazardous or remove power appropriately before
installing or removing modules or wiring.
•Potentially dangerous voltages are present on a module’s terminals, even when
system power is turned off. Field power must be turned off when installing or
removing a terminal block assembly.
•Personnel, who install, operate and maintain automation systems that contain these
products must be trained and qualified to perform those functions.
•Overloading power modules or Network adapter can result into electric arc and
damage to modules.
CAUTION
•Check the rated voltage and terminal array before wiring.
•Ensure that specified environmental conditions are not exceeded. Avoid placing the
module in direct sunlight.
•Review module specifications carefully and ensure that input and output
connections are made in accordance with the specifications.
•Use specified cables for wiring.
•Field power isolators must be used according to the requirements of the
5VDC/24VDC/48VDC or AC voltage modules used in the system.
•If system power consumption exceeds the power limits, use system power
expansion modules.
•Power supplies for system power and field power must be supplied from separate
sources.

User Manual Chapter 2
GFK-2746C Sep 2019
Installation 6
2.1 Module Mounting
2.1.1 How to Mount on DIN Rail
1. Press down the module lightly on the DIN Rail until it clicks & locks.
Figure 2: Pressing down the module lightly
2. You can use the PUSH lock for DIN rail up as a second locking mechanism.
Figure 3: PUSH lock as a second locking mechanism

User Manual Chapter 2
GFK-2746C Sep 2019
Installation 7
2.1.2 How to dismount from DIN Rail
1. Pull down the locking mechanism by using small flat screw driver as in the
following figures.
Figure 4: Pulling down the lock
2. Pull up the module to remove from the DIN rail.
Figure 5: Pulling up the module

User Manual Chapter 2
GFK-2746C Sep 2019
Installation 8
2.1.3 How to mount and dismount Network adapter with
Integrated I/O
Figure 6: module mounting/dismounting instructions
Release the DIN rail locking clip by pulling clip downward with a small-bladed screwdriver.
The clip will click and lock into the open position. Install the module on the DIN rail firmly.
Once module is in place on the DIN rail, push the clip upward to secure the module on the
DIN rail. To remove, pull clip downward until the locking clip clicks and locks, the module
can now be removed from the DIN rail.
Note: Make sure that the locking clip is in the upward position to ensure the module is properly
grounded and secured to the DIN rail.

User Manual Chapter 2
GFK-2746C Sep 2019
Installation 9
2.2 Installing and Removing Components
To plug in the module, use a small-bladed screwdriver and push down the locking lever
located at bottom of the module. Install the module on DIN rail firmly; push up the locking
lever to lock. To pull out the RSTi module, push down the locking lever rail.
Figure 7: Removing RSTi module from DIN rail
2.3 Internal Bus/Field Power Contacts
Communication between the Network adapters and the IO module as well as system / field
power supply of the bus modules is carried out via the internal bus. It is comprised of 6 data
pins and 2 field power pins.
Figure 8: Internal bus with 6 data pins and 2 field power pins

User Manual Chapter 2
GFK-2746C Sep 2019
Installation 10
WARNING
Do not touch data and field power pins, in order to avoid damage by ESD noise.
2.3.1 RSTi Bus Data Pin & Field Power Pin Description
Table 1: RSTi Bus Pin Name and Description
No.
Name
Description
1
Vcc
System supply voltage (5V dc)
2
GND
System Ground
3
Token Output
Token output port of Processor module
4
Serial Output
Transmitter output port of Processor module
5
Serial Input
Receiver input port of Processor module
6
Reserved
Reserved for bypass Token
7
Field GND
Field Ground
8
Field Vcc
Field supply voltage (24Vdc)
2.3.2 RSTi Data Bus System
Figure 9: Interface between different modules
•Network Adapter Module: The Network Adapter Module forms the link between
the field bus and the field devices through IO Modules. The connection to different
field bus systems can be established by each of the corresponding Network

User Manual Chapter 2
GFK-2746C Sep 2019
Installation 11
Adapter Modules: PROFIBUS, CANopen, DeviceNet, Ethernet/IP, CC-Link,
MODBUS/Serial, MODBUS/TCP, PROFINET etc.
•IO Module: The IO Modules are supported by a variety of input and output field
devices. There are digital and analog input/output modules and special function
modules.
•Two types of Bus Message
Service Messaging
I/O Messaging

User Manual Chapter 3
GFK-2746C Sep 2019
PROFIBUS Network Adapters 12
Chapter 3: PROFIBUS Network Adapters
PROFIBUS Network Adapters include STXPBS001 and STXPBS* modules.
•STXPBS001
The following are the features of STXPBS001:
—STXPBS001 is connected with the PROFIBUS-DP by means of 9 Pin D-sub
Connector.
—It works as a slave in the Master/Slave environment.
—The node size can extend up to 32 IO modules units.
—Each STXPBS001 can control maximum 1024 digital input/1024 digital output,
or 64 analog input/64 analog output channels.
—LED indicators for diagnostic functions (the status of Module, network
expansion units, and field power)
—It has got the PNO conformance certificate. This means it has interoperability
with other PROFIBUS products.
—It supports the communication speed from 9.6Kbps to 12Mbps and the auto
baud rate detection.
—The station number is assigned by rotary switches.
•STXPBS
*
The following are the features of STXPBS*:
—STXPBS* supports PROFIBUS communication protocol and is connected with
PROFIBUS by means of 9 Pin open Connector.
—These modules work as a slave under Master/Slave circumstances.
—They allow I/O Data communications with Master by means of polling process.
—They support the transmission rate from 9.6Kbps to 12Mbps and Auto
Baudrate detection.
—The station number is assigned by dip switches.
*
indicates STXPBS032/132/232/332/016/116/432/532/824/924/825/925.

User Manual Chapter 3
GFK-2746C Sep 2019
PROFIBUS Network Adapters 13
3.1 STXPBS001
3.1.1 Interface
The following figure shows the interface diagram for STXPBS001.
Figure 10: PROFIBUS Network Adaptor Module: STXPBS001
The following table lists the pin numbers and their description for STXPBS001.
Table 2: STXPBS001: Pin Description
Pin Number
Description
Pin Number
Description
0
System power 24v
1
System power 0 v
2
Ground
3
Ground
4
Field power 0v
5
Field power 0v
6
Field power 24v
7
Field power 24v

User Manual Chapter 3
GFK-2746C Sep 2019
PROFIBUS Network Adapters 14
3.1.2 Specifications
The following table describes the specifications of STXPBS001.
Table 3: STXPBS001: Interface Specifications
Item
Specification
Network Type
PROFIBUS-DP
Network Cable
PROFIBUS-DP Special Cable
Cable Length
1.2Km ~ 100m
Maximum Station No.
99 Station (Include Master Scanner)
Station Type
PROFIBUS-DP Slave
Expansion No.
Maximum 32 Module
Baud rate Setting
Support Auto-baud rate
Station No. Setting
Rotary S/W #1, #2 (x10, x1)
I/O Data Size
Total: Input 128bytes/Output 128bytes
—Maximum Discrete I/O: Input 1024points/Output
1024points
—Maximum Analog I/O: Input 64channels/Output
64channels
Indicators
1 green/red Module Status Indicator
1 green Network Status Indicator
1 green/red IO Module Status indicator
1 green Field Power Status indicator
Baud Rate
9.6K~12M (1.2Km~100m) (Auto baud rate Selection)
Module Location
First module of RSTi system
Station type
Slave
Repeater Control Signal
TTL
Freeze mode
Supported
Sync mode
Supported
Auto baud rate
Supported
Fail safe mode
Supported
FMS support
Not supported
Redundancy
Not supported

User Manual Chapter 3
GFK-2746C Sep 2019
PROFIBUS Network Adapters 15
Table 4: STXPBS001: General Specifications
Item
Specification
System Power
Supply voltage: 24Vdc nominal
Supply voltage range: 11~28.8Vdc
Protection: Output current limit (1.5A)
Reverse polarity protection
Power Dissipation
60mA typical @24Vdc
Current for I/O Module
1.5A @5Vdc
Isolation
DeviceNet to internal logic: Non-isolation
Internal logic to I/O driver: Isolation
Field Power
Supply voltage: 24Vdc nominal
Supply voltage range: 11~28.8Vdc
Field Power detection
About 11Vdc
Max. Current Field Power Contact
DC 10A Max.
Weight
155g
Module Size
42mm x 99mm x 70mm
Vibration/shock resistance
IEC 60068-2-6:1995
EMC resistance burst/ESD
EMC Directive
Installation Pos. / Protect. Class
Variable/IP20
Product Certifications
cULus, CE, PROFIBUS (PNO), ATEX, UL Hazloc
Atmosphere
No excessive dust, No corrosive gases
Mount
DIN-Rail
Environment Condition
See “Environmental Specifications" in Appendix A:.

User Manual Chapter 3
GFK-2746C Sep 2019
PROFIBUS Network Adapters 16
3.2 STXPBS
3.2.1 Interface
STXPBS032 –Adapter with 32 pt Positive Logic Input
The following figure shows the interface diagram for STXPBS032.
Figure 11: PROFIBUS Network Adaptor Module: STXPBS032
Table 5: STXPBS032: Pin Description
Pin Number
Description
Pin Number
Description
01-0
Input Channel 0
03- 0
Input Channel 16
01-1
Input Channel 1
03-1
Input Channel 17
01-2
Input Channel 2
03-2
Input Channel 18
01-3
Input Channel 3
03-3
Input Channel 19
01-4
Input Channel 4
03-4
Input Channel 20
01-5
Input Channel 5
03-5
Input Channel 21
01-6
Input Channel 6
03-6
Input Channel 22
01-7
Input Channel 7
03-7
Input Channel 23
02-0
Input Channel 8
04-0
Input Channel 24
02-1
Input Channel 9
04-1
Input Channel 25
02-2
Input Channel 10
04-2
Input Channel 26
02-3
Input Channel 11
04-3
Input Channel 27
02-4
Input Channel 12
04-4
Input Channel 28
02-5
Input Channel 13
04-5
Input Channel 29
02-6
Input Channel 14
04-6
Input Channel 30
02-7
Input Channel 15
04-7
Input Channel 31
