Reference Manual
00809-0100-4130, Rev DC
January 2019
Rosemount™2130 Level Switch
Vibrating Fork

ii
Section Title
January 2019
Reference Manual
00809-0100-4130, Rev DC

i
Reference Manual
00809-0100-4130, Rev DC
Title Page
January 2019
Title Page
Rosemount™2130 Level Switch
Vibrating Fork
NOTICE
Read this manual before working with the product. For personal and system safety, and for optimum
product performance, make sure you thoroughly understand the contents before installing, using, or
maintaining this product.
For technical assistance, contacts are listed below:
Customer Central
Technical support, quoting, and order-related questions.
Americas 1 800 999 9307
Europe [phone]
Middle east [phone]
Asia [phone]
North American Response Center
Equipment service needs.
1-800-654-7768 (24 hours — includes Canada)
Outside of these areas, contact your local Emerson™representative.
The products described in this document are NOT designed for nuclear-qualified applications.
Using non-nuclear qualified products in applications that require nuclear-qualified hardware or
products may cause inaccurate readings.
For information on Rosemount nuclear-qualified products, contact your local Emerson sales
representative.

ii
Reference Manual
00809-0100-4130, Rev DC
Title Page
January 2019
Title Page
Failure to follow these installation guidelines could result in death or serious injury.
Make sure only qualified personnel perform the installation.
Use the Rosemount 2130 Level Switch (“level switch”) only as specified in this manual.
Failure to do so may impair the protection provided by the equipment.
The weight of the level switch with a heavy flange and extended fork length may exceed
37 lb. (18 kg). A risk assessment is required to be done before carrying, lifting, and installing
the level switch.
Explosions could result in death or serious injury.
Do not remove the level switch cover in explosive atmospheres when the circuit is alive.
The level switch cover must be fully engaged and locked to meet explosion-proof
requirements.
Verify the operating environment of the level switch is consistent with the appropriate
hazardous locations certifications.
Review Appendix B: Product Certifications for special conditions and safety instructions
associated with a hazardous location installation.
Electrical shock can result in death or serious injury.
If the level switch is installed in a high-voltage environment and a fault or installation error
occurs, high voltage may be present on the sensor leads and terminals.
Use extreme caution when making contact with the leads and terminals.
Make sure the main power to the level switch is off and the lines to any other external power
source are disconnected or not powered while wiring the level switch.
Ensure the wiring is suitable for the electrical current and the insulation is suitable for the
voltage, temperature, and environment.
External surfaces may be hot.
Care must be taken to avoid possible burns. The flange and process seal may also be hot at
high process temperatures. Allow to cool before servicing.
Process leaks could result in death or serious injury.
Install and tighten process connection before applying pressure.
Do not attempt to loosen the process connection while the level switch is in service.
Make sure that the level switch is handled carefully. If the process seal is damaged, gas might
escape from the tank.
Any substitution of non-recognized parts may jeopardize safety and is under no
circumstances allowed.
Unauthorized changes to the product are strictly prohibited as they may unintentionally and
unpredictably alter performance and jeopardize safety.
Unauthorized changes that interfere with the integrity of the welds or flanges, such as
making additional perforations, compromise product integrity and safety. Equipment
ratings and certifications are no longer valid on any products that have been damaged or
modified without the prior written permission of Emerson. Any continued use of product
that has been damaged or modified without the written authorization is at the customer’s
sole risk and expense.

i
Reference Manual
00809-0100-4130, Rev DC
Contents
January 2019
Contents
Contents
1Section 1: Introduction
1.1 Using this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1.1 The sections in this manual. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1.2 Definitions and abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.2 Models covered . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3 Level switch overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3.1 Features list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.3.2 Measurement principle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3.3 Short fork technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.3.4 Special features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
1.4 Product recycling and disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2Section 2: Installation
2.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Considerations before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2.1 Safety considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2.2 Environmental considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.2.3 Application considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.2.4 Installation considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.2.5 Installation recommendations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.2.6 Installation examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.3 Installation procedures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3.1 Mechanical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3.2 Correct fork alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.3.3 Tightening the threaded level switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.3.4 Insulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.4 Setting the mode switch and switching time delay. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.5 LED indication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.6 Operating mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.7 Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.7.1 Direct load switching electronics cassette. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
2.7.2 PNP/PLC electronics cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
2.7.3 DPCO relay electronics cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
2.7.4 Fault and alarm relays (2 x SPCO) electronics cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
2.7.5 NAMUR electronics cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

ii
Reference Manual
00809-0100-4130, Rev DC
Contents
January 2019
Contents
2.7.6 8/16 mA electronics cassette. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.7.7 Fault condition detected (self-check mode only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3Section 3: Service and Troubleshooting
3.1 Safety messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
3.2 Magnetic test point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.3 Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.4 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.5 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
3.6 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.7 Service support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.8 Replacement and calibration of electronic cassettes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.8.1 Replacement sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
3.8.2 Calibration sequence. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4Section A: Reference Data
A.1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
A.1.1 General. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
A.1.2 Mechanical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
A.1.3 Functional . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
A.1.4 Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
A.1.5 Electrical. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
A.2 Dimensional drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
A.3 Ordering information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
A.3.1 Spare parts and accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
5Section B: Product Certifications
B.1 European directive information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B.2 NAMUR approval. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B.3 Overfill approval. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B.4 Marine approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B.5 Drinking water approval. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B.6 Ordinary location certifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
B.7 Safety Integrity Level (SIL) certification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
B.8 Canadian Registration Number. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

iii
Reference Manual
00809-0100-4130, Rev DC
Contents
January 2019
Contents
B.9 Hazardous locations certifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
B.9.1 American and Canadian approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
B.9.2 European approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
B.9.3 International approvals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

iv
Reference Manual
00809-0100-4130, Rev DC
Contents
January 2019
Contents

1
Reference Manual
00809-0100-4130, Rev DC
Introduction
January 2019
Introduction
Section 1 Introduction
1.1 Using this manual
1.1.1 The sections in this manual
The sections in this manual provide information on installing, operating, and maintaining the
Rosemount™2130 Level Switch – Vibrating Fork. The sections are organized as follows:
Section 2: Installation contains mechanical and electrical installation instructions.
Section 3: Service and Troubleshooting covers basic maintenance guidelines and troubleshooting
techniques for the most common operating problems.
Section A: Specifications and Reference Data supplies reference and specification data as well as
ordering information.
Section B: Product Certifications contains safety approval information and approval drawings.
1.1.2 Definitions and abbreviations
The following definitions are used in this manual:
1.2 Models covered
All models of the Rosemount 2130 Level Switch -- Vibrating Fork are covered in this manual.
1.3 Level switch overview
1.3.1 Features list
The Rosemount 2130, version with 2130***E in the model number, is designed for operating in high
process temperatures of –94 to 500 °F (–70 to 260 °C).
The Rosemount 2130, version with 2130***M in the model number, is designed for operating in
mid-range process temperatures of –40 to 356 °F (–40 to 180 °C).
Based on vibrating short fork technology, the level switch is suitable for many liquid applications.
It is virtually unaffected by flow, bubbles, turbulence, foam, vibration, solids content, coating
products, liquid properties, and product variations.
Dry(1)
1. The switching point does vary with different liquid densities (see Figure 2-3 on page 30).
The Rosemount 2130 fork (sensor) is submerged to a depth of less than 0.5 in. (13 mm).
Wet(1) The Rosemount2130 fork (sensor) is submerged to a depth of greater than 0.5 in. (13 mm).
Fault The fork frequency is outside the normal frequency band.
Normal mode The operating mode in which the Rosemount 2130 considers a 0 Hz fork frequency to
represent a wet condition (and not a fault).
Enhanced mode The operating mode in which the Rosemount 2130 considers a 0 Hz fork frequency to
represent a fault condition.

2
Reference Manual
00809-0100-4130, Rev DC
Introduction
January 2019
Introduction
Electronic self-checking and condition monitoring.
A ‘heartbeat’ LED indicates its operating state.
The LED also flashes when the switch output is ‘off’ and is constantly lit when 'on'.
‘Fast-drip’ fork design gives quicker response time, especially with viscous liquids. Rapid wet-to-dry
and dry-to-wet time setting for highly responsive switching
Adjustable switching delay prevents false switching in turbulent or splashing applications.
Magnetic test-point for easy functional test
No moving parts or crevices for virtually no maintenance
No need for calibration and requires minimum installation procedures
Easy terminal access and electrical protections (see “Electrical” on page 42)
Short fork length with extensions up to 157.5 in. (4 m)
General area, explosion-proof/flameproof and intrinsically safe options
SIL 2 suitable (see “Ordering information” on page 47)
This combination of features makes the Rosemount 2130 Level Switch an ideal choice for a wide variety
of challenging applications in the chemical, power generation, and oil and gas industries.
See Figure 1-2 on page 3 for application examples.
Figure 1-1. Rosemount 2130 Features
A. Electronics cassettes: Direct Load, DPCO Relay, Fault + Alarm (2 x SPCO) Relays, PLC/PNP, NAMUR, or 8/16 mA
B. NEMA®Type 4X (IP66/67) housings in aluminum or 316 stainless steel
C. Short fork length with extensions up to 157.5 in. (4 m)
D. Wetted material in 316/316L stainless steel, solid Alloy C and Alloy C-276,
or ECTFE co-polymer coated 316/316L stainless steel
E. ‘Fast drip’ fork design
F. Threaded, flanged, or Tri Clamp connections
G. Thermal tube in 316/316L stainless steel (2130***E version only)
H. Two cable/conduit entries
I. Magnetic test point
BH
F
I
G
C, D, E
A

3
Reference Manual
00809-0100-4130, Rev DC
Introduction
January 2019
Introduction
Figure 1-2. Rosemount 2130 Application Examples
Overfill protection
Spillage caused by overfilling can be hazardous to people and the environment,
resulting in lost product and potentially high clean-up costs.
High- and low-level alarm
Maximum and minimum level detection in tanks containing different types of
liquids are ideal applications. The Rosemount 2130 is robust and operates
continuously across the process temperature range of –94 to 500 °F (–70 to 260 °C)
and operating pressures of up to 1450 psig (100 barg), making it perfect for use as a
high- or low-level alarm. It is common practice to have an independent high-level
alarm switch as a backup to an installed level device in case of primary failure.
Pump control (limit detection)
Batch processing tanks often contain stirrers and agitators to ensure mixing and
product ‘fluidity’.
The standard user selectable time delay, from 0.3 to 30 seconds, virtually eliminates
the risk of false switching from splashing.
Pump protection or empty pipe detection
With the fork projecting only 2 in. (50 mm) (dependent on connection type), the
Rosemount 2130 can be installed in small diameter pipes. Short forks mean
minimum intrusion on the wetside and allow for simple, low cost installation at any
angle into pipes or tanks. By selecting the option of direct load switching or relay
electronics, the Rosemount 2130 is ideal for reliable pump control and can be used
to protect against pumps running dry.
High-temperature applications
The 2130***E version is designed for high temperatures and is suitable for
continuous operation within the process temperature range of –94 to 500 °F (–70
to 260 °C).
Wireless applications
The advent of wireless communications allows process plant managers to save up
to 90% on installation cost compared with wired technologies. More data can be
collected at central locations than has ever been possible before. The Rosemount
2130 can be used with a Rosemount 702 Wireless Discrete Transmitter to enable
these benefits for your applications.
Hygienic applications
With the highly polished forks option providing a surface finish (Ra) better than
0.4 μm, the Rosemount 2130 meets the most stringent hygienic requirements used
in food and beverage, and pharmaceutical applications. It is robust enough to easily
withstand CIP (Clean In Place) and SIP (Steam In Place) cleaning routines.

4
Reference Manual
00809-0100-4130, Rev DC
Introduction
January 2019
Introduction
1.3.2 Measurement principle
The level switch is designed using the principle of a tuning fork. A piezo-electric crystal oscillates the
forks at their natural frequency. Changes to this frequency are continuously monitored. The frequency of
the vibrating fork sensor changes depending on the medium in which it is immersed. The denser the
liquid, the lower the frequency.
When used as a low-level alarm, the liquid in the tank or pipe drains down past the fork, causing a
change of natural frequency that is detected by the electronics and switches the output state.
When the level switch is used as a high-level alarm, the liquid rises in the tank or pipe making contact
with the fork and causing the output state to switch.
1.3.3 Short fork technology
The natural frequency (~1400 Hz) of the fork avoids interference from plant vibration that may cause
false switching. This allows for minimum intrusion into the tank or pipe through the use of a short fork.
Using short fork technology, the Rosemount 2130 Level Switch can be used in almost all liquid
applications. Extensive research has maximized the operational effectiveness of the fork design, making
it suitable for most liquids including coating liquids, aerated liquids, and slurries.
1.3.4 Special features
Instrument health monitor and continuous self-check
The Rosemount 2130 Level Switch continuously performs instrument health diagnostics to self-check
the condition of the fork and sensor. These diagnostics can detect damage to the forks including
corrosion, internal or external damage to the forks, and breakages to the internal wiring. Any of these
conditions trigger the 'heartbeat' LED to pulse intermittently, followed by safe handling of the electrical
load.
Heartbeat LED
The Rosemount 2130 has a ‘heartbeat’ LED that indicates its operating state. The LED flashes when the
switch output is ‘off’ and is constantly lit when 'on'.
Fork design
The “fast drip” fork design draws liquid away from the fork tips when mounted horizontally, and together
with a short switching delay, allows the Rosemount 2130 to react quickly and with greater sensitivity to
density variations.
Mode switch and adjustable time delay
A mode switch allows the Rosemount 2130 to be set to switch from wet to dry (typically for low-level
alarm) or from dry to wet (typically for high-level alarm). There is also a user-selectable time delay (0.3,
1, 3, 10, or 30 s) to virtually eliminate the risk of false switching in turbulent or splashing applications.
Magnetic test point
A magnetic test point is located on the side of the housing, allowing the user to perform a functional test
of the Rosemount 2130 and the system connected to it. Holding a magnet to the test point causes the
output to change state.
Electrical hook-up
The terminal blocks extend above the housing and give easy terminal access. Electrical protections
make electrical hook-up safe and easy (see “Electrical” on page 42).

5
Reference Manual
00809-0100-4130, Rev DC
Introduction
January 2019
Introduction
1.4 Product recycling and disposal
Recycling of equipment and packaging should be taken into consideration. The product and packaging
should be disposed of in accordance with local and national legislation.

6
Reference Manual
00809-0100-4130, Rev DC
Introduction
January 2019
Introduction

7
Reference Manual
00809-0100-4130, Rev DC
Installation
January 2019
Installation
Section 2 Installation
Safety messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 7
Considerations before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 8
Installation procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 16
Setting the mode switch and switching time delay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page20
LED indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 21
Operating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 22
Electrical installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 23
2.1 Safety messages
Procedures and instructions in this manual may require special precautions to ensure the safety of the
personnel performing the operations. Information that raises potential safety issues is indicated by a
caution symbol ( ). The external hot surface symbol ( ) is used when a surface is hot and care must be
taken to avoid possible burns. If there is a risk of an electrical shock, the ( ) symbol is used. Refer to the
safety messages listed at the beginning of each section before performing an operation preceded by this
symbol.
Failure to follow these installation guidelines could result in death or serious injury.
Make sure only qualified personnel perform the installation.
Use the Rosemount 2130 Level Switch (“level switch”) only as specified in this manual.
Failure to do so may impair the protection provided by the equipment.
The weight of the level switch with a heavy flange and extended fork length may exceed
37 lb. (18 kg). A risk assessment is required to be done before carrying, lifting, and installing the
level switch.
Explosions could result in death or serious injury.
Do not remove the level switch cover in explosive atmospheres when the circuit is alive.
The level switch cover must be fully engaged and locked to meet explosion-proof requirements.
Verify the operating environment of the level switch is consistent with the appropriate hazardous
locations certifications.
Review Appendix B: Product Certifications for special conditions and safety instructions
associated with a hazardous location installation.
Electrical shock can result in death or serious injury.
If the level switch is installed in a high-voltage environment and a fault or installation error occurs,
high voltage may be present on the sensor leads and terminals.
Use extreme caution when making contact with the leads and terminals.
Make sure the main power to the level switch is off and the lines to any other external power
source are disconnected or not powered while wiring the level switch.
Ensure the wiring is suitable for the electrical current and the insulation is suitable for the voltage,
temperature, and environment.

8
Reference Manual
00809-0100-4130, Rev DC
Installation
January 2019
Installation
2.2 Considerations before installation
Important
Emerson is not in a position to evaluate or guarantee the compatibility of the process fluid or other
process parameters with the product, options, configuration or materials of construction selected.
2.2.1 Safety considerations
Safety instructions and control drawings specific to hazardous area installations are in
Appendix B: Product Certifications, and there are safety instructions in the Rosemount 2120 Quick Start
Guide (see Emerson.com/Rosemount). The safety instructions also include general safety information.
2.2.2 Environmental considerations
The Rosemount 2130 Level Switch (“level switch”) is available as Intrinsically Safe (IS) or explo-
sion-proof/flameproof versions for hazardous area installations. There are also ordinary location versions
for unclassified, safe areas. Approvals are listed in Appendix B: Product Certifications.
This level switch is designed for detecting liquids in open or closed tank, and pipe installations.
It is weatherproof and protected against the ingress of dust, but must be protected from flooding.
Avoid installing the level switch near heat sources.
Figure 2-1. Environmental Considerations
External surfaces may be hot.
Care must be taken to avoid possible burns. The flange and process seal may also be hot at high
process temperatures. Allow to cool before servicing.
Process leaks could result in death or serious injury.
Install and tighten process connection before applying pressure.
Do not attempt to loosen the process connection while the level switch is in service.
Make sure that the level switch is handled carefully. If the process seal is damaged, gas might escape
from the tank.
OKOK

9
Reference Manual
00809-0100-4130, Rev DC
Installation
January 2019
Installation
2.2.3 Application considerations
For most liquids, including coating, aerated liquids and slurries, the function is virtually unaffected by
flow, turbulence, bubbles, foam, vibration, solid particles, build-up, or properties of the liquid.
The 2130***E version of the level switch operates in high process temperatures of –94 to 500 °F
(–70 to 260 °C).
The 2130***M version of the level switch operates in mid-range process temperatures of –40 to 356 °F
(–40 to 180 °C).
The level switch can be mounted in an open or closed tank, or pipe. There is a wide range of threaded,
flanged, and Tri Clamp process connections.
Important
There should be no risk of ‘bridging’ the forks (see Figure 2-2). Examples of media that can create
‘bridging’ of forks are dense paper slurries and bitumen.
Figure 2-2. Avoid Product Build-up
Application guidelines
Ensure the process is operating within the level switch operating temperature and pressure ranges
(see “Specifications” on page 39).
Ensure the liquid viscosity is within the recommended viscosity range
(see “Specifications” on page 39).
Check that the liquid density is higher than 37.5 lb/ft3(600 kg/m3), or above 31.2 lb/ft3(500 kg/m3)
when ordered with the Low Density Range option (see “Specifications” on page 39).
Liquid density affects the switching point e.g. dry-to-wet (see Figure 2-3 on page 10).
Check for risk of build-up on the forks.
Avoid situations where drying and coating products may create excessive build-up. Problems may
occur if the product coats and then dries, causing caking.
Check the solids content in the liquid.
OK

10
Reference Manual
00809-0100-4130, Rev DC
Installation
January 2019
Installation
As a guideline, the maximum solid particle diameter in the liquid is 0.2 in. (5 mm).
Extra consideration is needed when dealing with particles bigger than 0.2 in. (5 mm).
Consult the factory for advice.
In almost all cases, the level switch is insensitive to foams (i.e. does not see the foam).
However, on rare occasions, some very dense foams may be seen as liquid. Known examples of this are
found in ice-cream and orange juice manufacturing.
Figure 2-3. Switching Points
SP. Switchpoint (H20)
HY. Switching Hysteresis
Note
When mounted vertically, a low density media has a switching point closer to the process connection.
A high density media has a switching point closer to fork tip.
SP
HYSP
0.1 in.
(2.5 mm)
0.5 in.
(13 mm)
0.5 in.
(13 mm)

11
Reference Manual
00809-0100-4130, Rev DC
Installation
January 2019
Installation
2.2.4 Installation considerations
For dimensional drawings, see “Dimensional drawings” on page 43.
Device identification
To identify the Rosemount 2130 Level Switch version, look at the labels on the housing and on the
electronics cassette inside the housing. See “Product Certifications” on page 53 for approval
information.
Allow adequate space outside tank or pipe
Mount the level switch so that it is removable. Clearance of 1.2 in. (30 mm) is required for cover removal.
Ensure there is sufficient room for electrical connections.
The housing cannot be rotated. Ensure there is sufficient room for electrical connections.
Fit the cover correctly
Ensure that the housing O-ring is sitting evenly and then tighten the housing cover to form a good seal.
Always use Emerson O-rings.
Grounding
Always ground the housing in accordance with national and local electrical codes.
The most effective grounding method for the housing is a direct connection to earth ground with
minimal impedance. Housings with NPT conduit entries do not have an earth ground point and must use
the fork earth.
Do not modify the level switch
Do not change the level switch fork in any way (Figure 2-4 on page 11).
Figure 2-4. Do Not Modify the Rosemount 2130

12
Reference Manual
00809-0100-4130, Rev DC
Installation
January 2019
Installation
How to handle the level switch
Handle the level switch with great care (Figure 2-5 on page 12).
The weight of a level switch with a heavy flange and extended fork length may exceed 37 lb. (18 kg).
A risk assessment is required to be done before carrying, lifting, and installing the level switch.
Use both hands to carry the high-temperature versions (2130***E) and extended length versions
(2130***M) of the level switch. Do not hold using the forks.
For hygienic applications, the level switch must be hygienically cleaned before installation and handled in
strict accordance with hygienic standards.
Figure 2-5. Handling the Rosemount 2130
2.2.5 Installation recommendations
Test the system by using the magnetic test point (see “Magnetic test point” on page 32).
Avoid installing near the liquid entering the tank at the fill point.
Avoid heavy splashing on the forks. Increasing the time delay reduces accidental switching.
Ensure that the forks do not come into contact with the tank wall, any internal fittings, or obstructions.
Allow for a sufficient distance between product build-up and fork (see Figure 2-2 on page 9).
Ensure the installation does not create tank crevices around the forks where liquid may collect.
This can happen with high-viscosity and high-density liquids.
Extra consideration is needed if the plant vibration is close to the 1400 Hz operating frequency
of the level switch.
Supporting the extended fork avoids long fork length vibration
(see Figure 2-6 on page 13 or Figure 2-7 on page 14, depending on the installation).
OK OK
