EMPERO EMP.BST.001 User manual

1
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
CONTENTS
A GENERAL INFORMATION Page 2
A1 PRODUCT DESCRIPTION Page 3
A2 TECHNICAL INFORMATION Page 3
A3 TRANSPORTATION Page 4
A4 UNPACKING Page 4
B INSTALLATION Page 4
C SAFETY INSTRUCTIONS Page 5
D OPERATION Page 6
E CLEANING & MAINTENANCE Page 7
F TROUBLESHOOTING Page 8
G SPARE PART LIST- EXPLODING DRAWING Page 9
H ELECTRIC CIRCUIT SCHEMA Page 13

2
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
A GENERAL INFORMATION
Before installing the appliance, read operation and maintenance instructions
carefully.Wrong installation and part changing may damage the product or may cause
injury on people.These are not in our company’s responsibility to damage the
appliance intentionally,negligence,detriments because of disobeying instructions and
regulations,wrong connections.Unauthorized intervention to appliance invalidates the
warranty.
1. This instruction manual should be kept in a safe place for future reference.
2. Installation should be made in accordance with ordinances and security rules of
that country by a qualified service personnel.
3. This appliance has to be used by trained person.
4. Please turn off the appliance immediately in the event of malfunction or failure.The
appliance should be repaired only by authorized service personnel.Please demand
original spare part.

3
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
A1 PRODUCT DESCRIPTION
*The Professional Knife Sterilizer ,that provides high efficiency has been designed to be used
in industrial kitchens.
Product Code
Dimensions (mm)
Weight (kg)
Packaging
Dimensions (mm)
EMP.BST.001
552x131x620
9
610x170x670
EMP.BST.002
1022x131x620
13
1070x170x670
A2 TECHNICAL INFORMATION
Product
Code
Model
Capacity
(piece)
Power
(W)
Operating
Voltage
(V)
Cable
(mm²)
Lighting
Armature
(A)
EMP.BST.001
One Lid
10
15
220
3x1,5
0,1
EMP.BST.002
Double Lid
20
30
220
3x1,5
0,15

4
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
A3 TRANSPORTATION
*This appliance can be moved by hand from area to area.Do not crash and drop the appliance
while transporting.
A4 UNPACKING
*Please unpack the package according to the security codes and ordinances of current
country and get rid from the pack.Parts which contacts with food are produced by stainless
steel.All plastic parts are marked by material’s symbol.
*Please check that all the parts of appliance had come completely and if they are damaged or
not during the shipping.
B INSTALLATION
*Please place the product to straight and sturdy ground,please take necessary steps against
possibility of overturn.
*Technician who will serve for installation and service for the appliance must be professional
on this subject and must have installation and service licenses by the company.
*Connection to Electric Power Supply must be done by authorized person.
*Please be sure that the voltage connected to appliance must be equal with the voltage which
is on appliance’s label.
This appliance must be connected to an earthed outlet in accordance with safety rules
and standards.
*Appliance’s earthing must be connected to earthing line on panel which is nearest to
electric installation.
*Connection to the main fuse and leak current fuse must be done in accordance with the
current regulations.
!

5
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
C SAFETY INSTRUCTIONS
*Do not use the appliance in insufficient lighted place.
*Do not touch the moving attachments while the appliance operates.
*Do not install the appliance in the presence of flammable or explosive materials.
*Do not operate the appliance when the machine is empty.
*Do not load so less or more than appliance’s capacity.
*Do not attempt to use the appliance without suitable protective equipments.
*Because of any reason if there is a fire or flame flare where the appliance is
used,turn off all gas valves and electric contactor switch quickly and use fire
extinguisher .Never use water to extinguish the fire.
*All the damages because of not having earthing connection will not be on
warranty.

!
!
!
!
!
!


6
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
D OPERATION
*Control Panel;
A: Timer
*Operating;
The appliance is generally used assembled to the wall.
Plug in the appliance.
Open the appliance’s lid.
Place the knives and choppers that need to be sterilized into the appliance smoothly.
Close the appliance’s lid.
Set the timer (0-120 min).
When the time expires after the appliance starts to operate,the timer indicator will be
zero and the appliance stops.
Open the lid and take off the sterilized knives and choppers.
After the operation completed,switch off the appliance.
The ultraviolet lamp in it can work till it explodes.

7
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
E CLEANING & MAINTENANCE
CLEANING AND MAINTENANCE AFTER EVERY USE
Clean the knife and chopper places after every use.
Always turn off the appliance and disconnect from the power supply before cleaning.
Clean outer surface of appliance ,lid with moist cloth and then dry.
Do not use abrasive cleaning chemicals as these can leave harmful residues.
Do not clean the appliance by spraying water directly,otherwise electric motor may
get damaged.
PERIODIC CLEANING AND MAINTENANCE
Maintenance should be done by qualified person.
Get the periodic maintenance of the appliance once in every 15 days.
Check the appliance’s lid in periodic time.Scar,crevice and broken lids must be
changed.Otherwise it may get damaged because of UV light.

8
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
F TROUBLESHOOTING
THE APPLIANCE DOESN’T OPERATE
1. Check if the appliance is plugged in.
2. Check the electrical connections and
voltage.
STERILIZATION IS NOT DONE
1. Check if the timer is set or not.
2. If the appliance is operated without
closing the lid,sterilization will not be
enough.
THE APPLIANCE STOPPED
1. The appliance can stop due to low
voltage.In this situation check the
voltage.
If sterilization is not done at suitable quality
If any function of security doesn’t work
Do not use the appliance.
*If these problems are still going on,contact with our authorized services.

9
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
G SPARE PART LIST-EXPLODING DRAWING
EMP.BST.001

10
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
G SPARE PART LIST-EXPLODING DRAWING
PRODUCT CODE:EMP.BST.001
NO
PRODUCT NAME
P.CODE
1
TOP LID
Y.EMP.BST.001.001
2
ARMATURE
Y.EMP.BST.001.002
3
UV LAMP
Y.EMP.BST.001.003
4
BASE FRAME
Y.EMP.BST.001.004
5
TIMER
Y.EMP.BST.001.005
6
BUTTON
Y.EMP.BST.001.006
7
LID LOCK
Y.EMP.BST.001.007
8
MICA LID
Y.EMP.BST.001.008
9
HINGE
Y.EMP.BST.001.009

11
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
G SPARE PART LIST-EXPLODING DRAWING
EMP.BST.002

12
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
G SPARE PART LIST-EXPLODING DRAWING
PRODUCT CODE:EMP.BST.002
NO
PRODUCT NAME
P.CODE
1
TOP LID
Y.EMP.BST.002.001
2
ARMATURE
Y.EMP.BST.002.002
3
UV LAMP
Y.EMP.BST.002.003
4
BASE FRAME
Y.EMP.BST.002.004
5
LOCK SHEETMETAL
Y.EMP.BST.002.005
6
HINGE
Y.EMP.BST.002.006
7
MICA LID
Y.EMP.BST.002.007
8
LID LOCK
Y.EMP.BST.002.008
9
MICA LID
Y.EMP.BST.002.009
10
BUTTON
Y.EMP.BST.002.010
11
TIMER
Y.EMP.BST.002.011

13
KNIFE STERILIZER
Kasap Tip Dik Buzdolapları
H ELECTRIC CIRCUIT SCHEMA
I
ZS
L1
Terminal
Timer Switch (1-120 min.)
Electronic Balanced
Ultraviolet Lamp
