EMU 2012 Mini User manual

BEING GREEN HAS NEVER LOOKED SO COOL!
American Scooter Company,L.L.C.
Please note that due to continuing improvements to our products and services, pictures
and/or descriptions may differ from the model and/or parts depicted in this manual.
READ THIS MANUAL COMPLETELY BEFORE ASSEMBLING
AND RIDING
EMU Trike
Electric Multi Use Trike
Owners
Manual
2012-2013
Models –EMU-Mini & EMU-Max

Page 2
Table of Contents
Front Cover-----------------------------------1
Table of Contents---------------------------2
Technical Information----------------------3
Warning Statement-------------------------4
Safety Warning------------------------------5
EMU Parts List-------------------------------6
Tool Kit & Assembly------------------------7
Installing the Handlebar-------------------9
Connecting Electric Plugs----------------10
Removal of Battery Cover---------------11
Battery Connection------------------------12
Folding the Handlebar--------------------13
Installing Basket----------------------------14
Charging Batteries-------------------------15
Riding your EMU---------------------------16
Adjusting Brakes---------------------------17
Remote Key Fob---------------------------18
Maintenance--------------------------------19
Trouble Shooting---------------------------21
Warranty--------------------------------------22-23

Page 3
Technical Information
Type of Motor 48V Permanent Magnet Brushless DC Motor
Motor Power 350W (Mini) 500W (Max)
Battery Type Sealed Lead Acid Batteries (Mini) x 4
Lithium Batteries (Max)
Battery 14AH 48V
Charger UL Approved 110v
Charging Time 4-8 hours
Rated Speed (2 speed) Mini 0-5mph & 0-15mph*
Max 0-8mph & 0-20mph *
Single Charge distance Mini Up to 15 miles*
Max up to 20 miles*
Maximum Capacity 285 lbs
EMU. Net Weight Mini around 90 lbs
Max around 70 lbs
*Note: Speed and distance may vary depending upon the terrain and weight
load.

Page 4
Warning Statement
STOP ----- IMPORTANT!
Before you ride your EMU please read this carefully:
Your existing insurance policy may not provide coverage for your
EMU trike of electric vehicles. You should contact your insurance
company to confirm if coverage is provided.
Please do not ride your EMU until you have read this owners manual
completely and you fully understand all its contents. This manual
contains critical information for your safety. If you have any questions
about the safe operation of your EMU, you should contact your
authorized EMU dealer.
It is very important that you follow all the safety instruction within this
manual in order to ensure maximum safety.
Failure to comply with all the standards outlined in this manual could
result in fire/ or serious injury.
American Scooter Company or authorized dealers will not be liable
for any damage or injuries caused by unsafe or faulty assembly or
unauthorized repairs. Any repairs carried out by unauthorized service
technicians are the sole responsibility of the owner and the Warranty
becomes void. Always follow local laws to where you can ride your
EMU.
Our EMU range of products are designed to be ecologically
conscious, please dispose of used batteries in compliance with local
laws.

Page 5
Safety Warning
(Please read before riding your EMU)
Before riding your EMU please read and be sure you understand this manual
completely. The EMU is not a toy and should always be operated in a safe
manner. American Scooter Company will not be liable for any damages or
injuries to any person. Any questions you may have about the safe operation of
your EMU should be directed to your authorized dealer.
Failure to comply with the safety warnings and operating instructions included in
this manual could result in serious injury to the operator and to others.
The EMU is not designed for all user repairs. An authorized EMU repair
technician should carry out repairs. American Scooter Company will not be liable
for any damage or injuries due to repairs by unauthorized individuals.
The EMU should only be operated by individuals 16 years of age or older.
The EMU is not a toy and should always be used responsibly.
Safety Instructions
Always wear approved safety equipment when operating the EMU.
Observe the maximum weight capacity of 265 lbs.
No more than one person should ride the EMU at a time.
The EMU should always be operated in a safe manner under safe
conditions. Observe local laws.
Before riding, inspect the EMU to insure all quick releases and pivot points
are secured properly. Make sure handlebars are secured and hand brake
is in operating condition.
Check the battery to insure it is properly charged.
The power ignition must be off when charging.
Remove your EMU from charge once it is charged. Do not leave charger
plugged in any longer that 8 hours.
Charge the battery after when required.
Do not expose the EMU, batteries or charger to wet conditions.
Always drive on paved surfaces.
Be careful when riding on wet or uneven surfaces.

Page 6
12
EMU Parts List
!" #$%&'()*++,(
-" .$/0(1$23+(
4" 5,+6'$76(0%'%$(
8" 9+2:,7;*'(<=%:>(
?" #$%&'(@%$3(
A" 12B3+'(<%='7%&2,>(
C" #%,:7&;(92&:,+D2$(E%&&+6'7%&(
F" G;&7'7%&(H+I(<=%:>(
J" K*$%'',+(
!L" (9+2:,7;*'(MN7'6*(
!!" O$++&(1/''%&(@%$(9%$&(
!-" 92&:,+D2$(*+7;*'(2:P/B'0+&'(
!4" Q%N+$(G&:762'%$(<=%:>(
!8" M+2'(Q%B'(<R='7%&2,>(
!?" M+2'(9+7;*'(S:P/B'0+&'(
!A" 92&:D$23+(
!C" M2@+'I()*++,B(
!F" T+2$()*++,B(
!J" 12''+$I(E%U+$(
-L" 5,+6'$762,(E%&&+6'%$B(
1
2
3
4
5
6
7
8
9
10/ 8
11
16
14
15
17
18
19
20
12

Page 7
Tool Kit
Charger
Tool Kit
Assembling the EMU
1/ Unpack the E.M.U. and
inspect all the parts to insure
all are included. Please
contact your E.M.U. dealer
immediately if any parts are
missing or damaged when
shipped.
Place your E.M.U. on a flat,
clean surface. Place a block
3.5” under the front, by the
battery. This will make it
easier for the next step.

Page 8
2/ Remove the bolts and nuts
from the connecting tube
clamp (B). place the
connecting tube into the top
opening (A). Align the bolt
holes.
3/ Slide the two bolts
(1) through the holes
connecting tube and
neck. Twist the bolts,
do not hammer them
through.
4/ Tighten the bolts and nuts
(2) using the 2 allen wrenches
in the tool kit. Also tighten the
small bolts on the outside of
the tube clamp securely (B).
Note some models may have
hex bolts instead.
B

Page 9
Installing the Handlebar
Extend the handlebar tube
to full upright position and
insert it into the
connection hole on the
front forks.
6/ Ensure the handlebars
are facing front with the
brake on the left and the
throttle on the right, then
tighten the handle bar hex
bolt securely. Fold
handlebar down to the left
hand side and tighten hex
bolt
Hex Bolt

Page 10
Connecting the Electrical power plugs
6/ Make sure you connect
the 4 the connectors to the
right outlets. You will damage
your emu electrics if you
connect them wrong. All
connectors are color-coded.
7/ Match the pins of the
plugs to the holes of the
sockets, align the notches
and secure.
8/ The height of the
handlebars can be
adjusted by opening
the quick clip release
the raise the
handlebars by pulling
or pushing on the
crossbar, then firmly
closing the quick
release clip.

Page 11
Removal of Battery Cover
(service only)
Undo the 4 screws (one
on each side of the cover
and 2 on the back).
Gently pull the cover
upwards to remove.
Reverse operation 1 & 2
to re-install cover. Be
careful not to trap wires
when putting the cover
back on.

Page 12

Page 13
Folding the Handlebar
Turn off the ignition key
Release the silver
quick clip
Lift the silver clip bar from the
bottom, at the same time pull
upwards on the handlebar
tube. Note the handlebar
remain attached to pole. Fold
down handlebars. Carefully
place the handlebar tube on
the footrest frame. Reverse
this procedure to re-attach
handlebar.
Picture of EMU handlebar
folded. Note arrow show
the direction they fold.

Page 14
Installing the Basket
Position the basket as shown.
The “U” Bracket attaches to both
sides of the forks, in the middle
of the three holes.
Attach the basket to the “U”
bracket using the included
hardware.
Attach the back of the basket
to the mounting bracket using
the included hardware.

Page 15
Charging the Batteries
Before riding your EMU for the first time, the unit should be fully charged. Ride
your EMU until the battery is fully discharged before recharging it. Doing this 3-5
times will insure maximum battery efficiency and scooter performance. Once this
has been done, for best results.
The lead acid batteries in the MINI should be recharged frequently, at least once
every 30 days for longest battery life. Leaving the battery uncharged for more
than 3 months will significantly decrease the battery lifespan. If you are not going
to use your EMU-MINI remove the fuse from the blue connecter under the battery
cover.
To charge the batteries, plug the charger into the socket located at the rear of the
battery compartment, then plug the charger into the wall outlet. The light on the
charge will be red when the unit is charging the batteries. When the light turns
green, the charge is complete. Always plug the charger into the trike before
the outlet.
Be sure the charger is properly connected to the EMU. The connector is
indented so that it will fit only one way. Do not force the connection. It should
slide easily into the unit when correctly aligned.
WARNING
Never leave the charger plugged into either the
EMU or electric outlet for longer than 8 hours.
Leaving your charger connected for a long
period can cause a fire.

Page 16
Riding your EMU
Always wear a helmet when riding the EMU
If you are using your EMU outdoors please be aware of all state and
local laws governing the use of such vehicles. State and local
ordinances may vary and it is your responsibility to make sure you
comply with all applicable laws.
First, put the key in the ignition
switch located onthe right side of
the light pod. Turn the key to the first
“On” position. The first ON position
is ignition/ power .The second ON
position is for the additional
headlight.
The battery gauge on the pod and will
illuminate, indicating the battery is
engaged. At full power the entire
gauge will be illuminated. As the
power decreases,the lights go out
starting with the right side moving to
the left. When there is no illumination,
the battery is completely drained and
your EMU must be recharged. The
single red light shows when headlight
is on.
The speed switch is just below the
throttle, located on the right side of
the handlebar to the (-) position is
slow speed. Position (o) is high
speed.The throttle is a twist grip.
Twist down slowly to increase
speed. The throttle is very sensitive
so be very careful until you get used
to the speed and sensitivity.

Page 17
To stop your E.M.U., disengage
the throttle and apply pressure to
the handbrake. Beware the brake
is very sensitive. When the brake is
applied this kills the power to the
throttle
If you are parking your scooter on
an incline, engage the handy
parking brake by tightly holding the
hand brake and pushing the black
parking brake paddle towards you.
Pull the handbrake lever towards
you to release.
When parking the scooter, always
remove the key for additional
security.
The red switch is the horn.
To adjust the seat, undo the quick
release then push in brass button
and adjust as required.
To remove the seat pole undo the
two bolts and then lift seat pole up.
When installing the seat make sure
these bolts are tight.

Page 18

Page 19
Adjusting Brakes
In order to adjust the sensitivity
of the hand brake, either tighten
or loosen the wire shown on the
left. First loosen the nut and
then push the wire back toward
the brake to lessen sensitivity,
or pull the wire to increase
sensitivity.
Front Facing

Page 20
Maintenance
Your EMU requires minimum maintenance to give you years of service. Always
follow these simple procedures before your ride.
•Make sure battery is fully charged.
•Never leave battery uncharged for more than 30 days, as this will
negatively impact performance and battery lifespan.
•Inspect all connections each time you ride to insure nothing is loose and
wires are not frayed or damaged.
•Make sure tires are inflated to their proper pressure as indicated on the
tires.
•Test brakes to insure they are operating before increasing speed.
•Properly adjust helmet to each rider for maximum protection.
•Oil bearings in rear wheels every 90 days.
•Never leave your EMU in the rain.
Battery Replacement
Battery replacement should be done by an EMU authorized service dealer or
anyone with simple technical skills. The batteries are located in the battery
compartment on the footboard. To access the batteries, remove the screws that
hold on the battery cover and carefully disconnect the wires from the battery
terminal, marking each wire to ensure that it will be reconnected to the correct
connector. Replace the batteries and reconnect the wires to the correct
connectors. Replace and secure the cover. Fully charge the batteries before
attempting to use.
