EMX NIR-50 User manual

O P E R A T I N G I N S T R U C T I O N S
Operating Instructions
4564 Johnston Parkway, Cleveland, Ohio 44128
P. 800 426 9912 F. 216 518 9884
Sales Inquiries: [email protected]
Technical Support: [email protected]
www.emxinc.com
NIR-50™
U L 3 2 5 N O N - C O M P L I A N T
RETROREFLECTIVE PHOTOEYE

NIR-50 Operating Instructions 1
Document no. NIR-50 Instructions.doc
Contents
Cautions and Warnings
2
Product Overview
2
Specifications
2
Controls and Indicators
3
Connections
3
Troubleshooting
4
Installation
4
Ordering Information
4

NIR-50 Operating Instructions 2
Document no. NIR-50 Instructions.doc
Cautions and Warnings
WARNING … Not to be used for Personnel Protection
Never use product as sensing devices for personnel protection. Doing so could cause
serious injury or death. These sensors do NOT include the self-checking redundant
circuitry necessary to allow their use in personnel safety applications. A sensor failure
or malfunction can cause either an energized or de-energized sensor output condition.
UL 325 Non-compliant.
Retroreflective photoeyes rely on a reflective surface (a reflector) for proper operation. In some cases
a vehicle with reflective surface at a given distance can act as a reflector and allow the gate to close on
a car.
EMX Industries Inc. assumes no responsibility in this case and all risk is on the installer, designer and
user of the gate system with a retroreflective photoeye. In case such risk is not acceptable, EMX
Industries Inc. strongly recommends the use of a through beam type of photoeye.
Product Overview
Product may be used for activation of gates or doors when the beam is interrupted. The NIR-50 fail-
safe reflective sensor uses an infrared signal that is returned from a reflector mounted on the
opposite side of the opening to be monitored.
Specifications
Specifications
Power Supply
12 –240VDC / 24 –240VAC
Power Supply Tolerance
+ / - 10%
Current Draw
28mA standby 15mA detected @ 12 VDC
Housing Material
ABS and Acrylate on lenses
Relay Type
SPDT 2A @ 24 VDC 0.6A @ 220 VAC
Temperature Range
-20º - +60ºC
Connector
Cable 2 Meters (6feet)
Environmental Protection
IP 66 IEC
Size
1.6” x 2.6” x 0.8”
Response time
10ms maximum
Range
0.3 –30 feet
Certifications
CE

NIR-50 Operating Instructions 3
Document no. NIR-50 Instructions.doc
Controls and Indicators
Sensitivity
Clockwise increases sensitivity
Normally set to maximum (single turn)
Yellow LED
LED is on when unit is energized and signal is stable
Red LED
Is on when is energized and alignment is correct
LED is off when unit is energized and object is detected or not aligned
Connections
Wire Color
Connection
Brown
Power Positive (+)
Blue
Power Negative (-)
Black
Internal Relay Contact Normally Closed (NC)
Gray
Internal Relay Contact Normally Open (NO)
White
Internal Relay Contact Common (COM)

NIR-50 Operating Instructions 4
Document no. NIR-50 Instructions.doc
Troubleshooting
Symptom
Possible cause
Solution
Units stays in detect
Unit out of alignment
Reflector covered with dirt,
dust, snow, or water
Water inside of reflector
Verify alignment
Clean reflector surface of
contaminants
Replace reflector
Add Reflector 0-HD
No Output
No power
Bad Connection, wires broken
Mis-wired
Check wiring as per chart on page 2
Check connections
Verify wired to correct inputs on
operator
No Detection
Unit not powered
Other reflective surface
causing signal return
Check Power
Check surrounding area for reflective
surface
Installation
Recommended alignment technique is to mount the NIR-50 at the desired location and hold reflector
about 2 or 3 feet in front of the unit and while watching the lights to assure that both remain lit, move
backward to the desired mounting location for the reflector. You may have to move the reflector up,
down, left or right to keep the reflector in the middle of the signal path. This assures the least
troublesome set up by keeping the reflector off the edges of the signal where any movement may take
it out of alignment. Note: the signal pattern is only 2 feet diameter.
Ordering Information
NIR-50 Retroreflective photoeye, includes mounting bracket with hardware
NIR-HD Steel protective hood
Reflector -O Plastic reflector, 3" dia.
Reflector-O-HD Plastic hood for reflector

NIR-50 Operating Instructions 5
Document no. NIR-50 Instructions.doc
Accessories
NIR-HD Reflector-O Reflector-O-HD
Warranty
EMX Industries Incorporated warrants all products to be free of defects in
materials and workmanship for a period of two years under normal use and
service from the date of sale to our customer. This warranty does not cover
normal wear and tear, abuse, misuse, overloading, altered products, damage
caused by incorrect connections, lightning damage, or use other than intended
design.
There is no warranty of merchantability. There are no warranties expressed or
implied or any affirmation of fact or representation except as set forth herein.
EMX Industries Inc. sole responsibility and liability, and the purchaser’s
exclusive remedy shall be limited to the repair or replacement at EMX
Industries option of a part or parts found not conforming to the warranty. In
no event shall EMX Industries Inc. be liable for damages, including but not
limited to damages resulting from non-conformity, defect in material or
workmanship.
Effective date: January 1st, 2002
