Enabling Devices 3140 User manual

Sound Pillow #3140
USER’S GUI E

Sound and vibration!
We’ve switch adapted the sound machine in this vibrating pillow.
Sound machine has four sound choices: music, water, white noise and
a heartbeat. Simply remove the sound machine from the interior of the
pillow, select a sound choice and attach your switch. Replace the
machine and now the user can turn the sound on and off. Pillow has
two-speed vibration and is covered with a soft, comfortable corduroy
fabric. Sound machine has a 5 minute auto timer shut off. Pillow size:
4"L x 9½"W x 3½"H. Pillow requires 2 D Batteries; Sound machine
requires 3 AAA Batteries. Weight: lb.
Operation:
. To install the two D batteries and the 3 AAA batteries in the
Sound Machine, you must locate the zipper on the back of the
Pillow. Next unzip the opening and separate the opening in the
foam pillow to reveal the battery holder. Install the two D batteries
paying close attention to proper (+) and (-) polarity. Please Note:
Alkaline batteries are recommended (e.g. Duracell or Energizer
brand) Do not use rechargeable or heavy duty batteries as they will
not work as well with this device. Never mix old and new batteries
together.
2. To install the Sound Machine batteries use a Dime, or flathead
screwdriver to open the battery compartment and install 3 AAA
batteries.
2. Vibration Speed control switch has three positions, Low, Off and
High. The center position, this is the OFF position.
3. Connect the Sound Pillow to any external capability switch (not
included) via the cord jack located at the back side of the pillow.
Sound Pillow is equipped with a /8" female mono jack for use
with external capability switches that have a /8" mono plug.
Make sure you plug your switch in all the way. There should be
no gaps.
4. The Sound machine has four sound choices: music, water, white
noise and a heartbeat. Simply remove the sound machine from the
interior of the pillow, select a sound choice and attach your switch.
Replace the machine and now the user can turn the sound on and
off. Actuate your capability switch to turn the selected sound on
and activate it a second time to turn it off. Sound machine has a 5
minute auto timer shut off.
Troubleshooting:
Problem: The Sound/Vibrating Pillow does not activate.
Action #1: Make sure that all batteries are installed following proper
(+) and (-) polarity.
Action #2: Replace the batteries with new alkaline batteries (E.G
Duracell or Energizer Brand).
Action #3: Do not use rechargeable or heavy duty batteries.
Care of Unit:
The Sound Pillow is surface washable only.
o not submerge the unit, as it will damage the contents and the
electrical components.
Rev 9/24/13
