ENCLO EC18030 User manual

www.encloscreens.com
Tiaga Wood
Freestanding
Screen
73 ½"H X 36"W
30 min
Screen Assembly
Approximate time
Assembly Video
Scan the QR Code below
ASSEMBLY
INSTRUCTIONS
EC18030
VER. 080323
60 min
Surface Mounting
Approximate time

2
DETAILED PRODUCT DIMENSIONS &SPECIFICATIONS
GENERAL
INFORMATION
MISSING OR
DAMAGED PARTS?
NEED ASSEMBLY
HELP?
NEED TO RETURN?
IMPORTANT
jCheck the inside of the larger pieces in your box for other materials
packed inside.
jWe recommend an area approximately 5’x 8’for unobstructed
assembling.
jYou should not need to use excessive force when assembling
components.
jNo free replacement parts will be provided for wind related
damage.
VISIT OUR WEBSITE FIRST,
SO WE CAN HELP YOU RIGHT AWAY!
Although great care has been taken to ensure proper packaging and
handling of this product, occasionally problems occur. If you discover
any missing, damaged, or defective parts, please visit our website to
order replacement parts. If you experience any further trouble with your
product, please contact our customer service department.
parts.nychbrands.com ()
[e-mail]
704-892-5222 /877-234-6196
Customer service agents are available to take calls weekdays from 9am-5pm EST. If
you call outside of business hours, please leave a voicemail.
To help you quickly and accurately, please have reference item number
EC18030 and the specic part name which can be found on page 5. It is
helpful if you can provide the batch lot which is a stamped number on
the end of the box.
If you are having problems with the assembly or installation of this
product, we are happy to assist you with the process, so please give us
a call at 704-892-5222 / 877-234-6169
If for some reason you need to return this product, please allow us to
help resolve your issues rst. If you still decide to return the product,
you will need to initiate the return from the company you originally
purchased from.
(Only availible in the
continental US and
Canada)

in
in
in
in
in
in
in
3
DETAILED PRODUCT DIMENSIONS &SPECIFICATIONS
Tipping may occur if left freestanding in areas with wind exposure

4
LAY OUT MATERIALS
M5*50mm Wood Screw (10)
Nut (4)
BOX CONTENTS
C
Rail (2)
1¼" x 2" x 34¼"
B
Slat (25)
A
Post (2)
I
Nut (4)
FH
M6*80mm Bolt (4)
G
M6*30mm Bolt (4)
J
Washer (12)
K
Lock Washer (8)
L
Wrench (2)
D
Feet (2)
1" x 2" x 25"
E
Joiner Bracket (2)
NOT INCLUDED
TOOLS AND OPTIONAL HARDW ARE
is only recommended for
environments with low
wind exposure.
¼" Lag Screws 3"
Length (4)
Matching
Driver Bit
Wood
Drill Bit Concrete
Drill Bit
Matching
Wrench
¼" Concrete Wedge
Anchor 2¼" Length (4)
Hammer Drill
Hammer
Phillips Bit
Power Drill
Power Drill
FREESTANDING DECK MOUNT PATIO MOUNT

5


ASSEMBLING
1
2
A x1
B x25
A
Bx25
x1
Assemble on box or other
smooth surface.
We recommend
2 people for
a smoother
assembly.

6
3
4
C x2
A x1
Cx2

Concrete
Drill Bit
Matching
Wrench
¼" Concrete Wedge
Anchor 2¼" Length (4)
Hammer Drill
Hammer
PATIO MOUNT
7
FREESTANDING
5
F x10
PAGE 8
SURFACE MOUNTED RECOMMENDED
PAGE 9 13
Fx10
OR
Freestanding application
is only recommended
for indoor usage or
environments with low
wind exposure.
¼" Lag Screws 3"
Length (4)
Matching
Driver Bit
Wood
Drill Bit
Power Drill
DECK MOUNT
Surface mounting hardware
not included
Screen does not serve as a substitute for a
security railing for the prevention of falling

Ix4 Kx4
D
8
1
2H x4 I x4 J x8 K x4
FREESTANDING
FREESTANDING FREESTANDING
L x2
x2
H
K x4
D
L
D x2 E x2 G x4 J x4
E
L x1
x2
G
Jx2
2x x2
K
Ix2

9
1
MOUNTED
2
MOUNTED
SURFACE MOUNTED (DECK)
H x4 I x4 J x8 K x4 L x2

10
10 3
MOUNTED
4
MOUNTED
If mounting to deck
boards only, a support
block should be added
underneath
Refer to mounting hardware instructions
to ensure proper installation.
(Surface mounting hardware not included)

11
1
MOUNTED
2
MOUNTED
SURFACE MOUNTED (PATIO)
H x4 I x4 J x8 K x4 L x2
Ensure there is at least
3" between the edge
of the concrete and the
surface mount.
3"
3"

12
10 3
MOUNTED
4
MOUNTED
Refer to mounting hardware instructions
to ensure proper installation.
(Surface mounting hardware not included)

13
5
MOUNTED
6
MOUNTED
Refer to mounting hardware instructions
to ensure proper installation.
(Surface mounting hardware not included)

www.encloscreens.com
[e-mail]
704-892-5222
877-234-6196
6935 Reames Rd. Ste. K.
Charlotte, NC 28216
