Encore EN-MGS24 User manual

24 Port Bandwidth Management Gigabit Ethernet Switch
EN-MGS24
Encore Electronics is proud to
present the 24 Port Manageable
Gigabit Ethernet Switch. This
version supports 24 ports
capable of speeds of up to
1000Mbps. Experience efficient
file transfer and improved
network performance.
Managing the switch is easy using the built-in web interface. It offers many
advanced features for network administrators such as VLAN, Port Aggregation,
Port Mirroring, Discover, Port Management and flow control. In addition, QoS
functions provide priority to bandwidth intensive services such as VoIP and video
conferencing. Rack-mountable facilitates clean organization of switches.
Installation is simple. The unit is able to function as a standalone switch right out
of the box. Auto-negotiation detects networking speeds of either 10,100 or
1000Mbps while determining Full or Half-duplex modes. Auto MDI and MDI-x
supports both straight-through or crossover cables for connection between hubs,
routers, PCs and other switches.
Figure 1 Front View
Figure 2 Rear View
Encore Electronics 2005
WWW.ENCORE-USA.COM
EN-MGS24
1

Figure 3 Network Application
Key Features
•24 fixed 10/100/1000Mbps Gigabit
Ethernet ports for easy network
connecting application.
•Provide Auto-discovery Function for easy
Network management.
•Provide 8K MAC address entries and 24
groups VLAN table
•Support up to 8 ports and 4 groups port
aggregation.
•Support TOS and Tag based QoS for
better communication quality.
•Support full duplex flow control and half
duplex back pressure
•Store-and-forward forwarding scheme
•Error packet filtering
•Support Jumbo frame 9K bytes
•Supports 512K buffer Memory
•Support Web-based management
interface.
Specifications
Standard
IEEE802.3, 802.3u, 802.3ab, 802.3x, 802.1p
802.1q standards
Interface
24* 10/100/1000 Mbps RJ-45 ports
One Restore Default Button
NWay Protocol Support
Network speed: 10Mbps, 100Mbps and
1000Mbps
Duplex mode: Full and Half (1000BaseT
support full duplex only)
Diagnostic LEDs
System Power (Green/ off)
Ports 1000M (Green/ off)
Link/ACT(Green/Blinking Green/Off)
Operating Humidity
10% ~ 90% non-condensing
Operating Temperature
0 Degrees ~ 4 Degrees C (32 ~104 F)
Dimension
441x196x44 mm
Power Supply
Internal power supply 100~240VAC, 50/60Hz
Certification
FCC Class A, CE
