Encore ENDSL-A2+WIGX2 User manual

ENDSL-A2+WIGX2
ADSL2+ Modem with Wireless Router
ENDSL-A2+WIGX2 full rate ADSL2+ router is an all-in-one ADSL2+ router for
Home and SOHO applications. This gateway is with full-featured ADSL router
that provides high-speed Internet access, 4-port Ethernet switch direct
connections to individual PCs or local area network with 10/100 Base-T Ethernet
and a 54Mbps IEEE802.11g wireless connectivity.
ENDSL-A2+WIGX2 use advanced ADSL chipset solution with complete set of
industry standard features for high-speed Internet access. Also built-in 54Mbps
IEEE 802.11g wireless service can provide you easy and convenient way to
connect the PCs and Internet. User can enjoy higher quality multimedia and real-
time applications such as online gaming, Video-on-Demand, VoIP and other
bandwidth consuming services. Also the feature-rich routing functions are
seamlessly integrated to ADSL service for existing corporate or home users.
The switch is plug-n-play without any software to configure and also fully
compliant with all kinds of network protocols. Moreover, the rich diagnostic LED’s
on the front-panel can provide the operating status of individual port and whole
system.

Features:
•Full rate operation with up to 24Mbps downstream data rate and up to
1Mbps upstream data rate enables High-speed Internet access
•Compliant with IEEE802.11g standard and with data transfer rate up to
54Mbps
•Friendly GUI Configuration and Management
•Feature enhancements through FTP / TFTP download or upload of new
firmware and configuration files
•Universal Plug and Play (UPnP) support
•Provide ALG to support many major applications, such as MSN
Messenger, AIM (AOL Instant Messenger), CuseeMe, ICQ, IRC, LDAP,
PPTP, FTP, Quake, RTSP (RealTime Streaming Protocol), SIP, H.323…
•Enables end-to-end ATM support, which allows traffic management and
QoS.
•Built-in DHCP server automatically assigns IP addresses to all
workstations on your LAN.
All management and monitoring can be done through Telnet session.
Specifications:
ADSL Compliant:
‧ ANSI T1.413 issue 2
‧ ITU-T G.992.1 (G.dmt)
‧ ITU-T G.992.2 (G.lite)
‧ G.994.1 (G.hs, Multimode)
‧ ITU-T G.992.3 (ADSL2 G.dmt.bis)
‧ ITU-T G.992.4 (ADSL2 G.lite.bis)
‧ ITU-T G.992.5 (ADSL2+; Annex A, B, I, J, L & M)
‧ Reach Extended ADSL (RE ADSL)
ATM and PPP Protocols:
‧ Support up to 8PVCs
‧ ATM Forum UNI 3.1/4.0 PVC
‧ Multi Protocol over AAL5 (RFC1483 / 2684)
‧ VC and LLC Multiplexing
‧ PPP over Ethernet (RFC 2516)
‧ PPP over ATM (RFC 2364)
‧ Traffic Shaping (ATM QoS) UBR, CBR, VBR, VBR-rt, VBR-nrt
‧ OAM F4 and F5 segment end-to-end loop-back, AIS, and RDI OAM cells
‧ VPI is 0-255 and VCI is 32-65535

Bridging and Routing:
‧ Ethernet to ADSL self-learning Transparent Bridging (IEEE 802.1d)
‧ IP routing-RIPv2 (backward compatible with RIPv1)
‧ Static IP routing
‧ Routing (TCP/IP/UDP/ARP/ICMP)
‧ IP Multicast IGMP v1/v2
IP Management
‧ NAT (Network Address Translation)
‧ NAPT (Network Address and Port Translation)
‧ DHCP Server / Relay / Client (WAN Port)
‧ DNS Proxy
‧ Dynamic DNS,
‧ UPnP support
‧ Virtual Server and DMZ host
WLAN Network
‧ Compatible with IEEE 802.11b/g
‧ 64/128 bits WEP Encryption
‧ WPA-PSK, TKIP / WPA2-AES, PSK
‧ Supports Quality of Service (QoS), 802.11e, WMM
‧ MAC Address Filtering
Security
‧ PPP over PAP (Password Authentication Protocol; RFC1334)
‧ PPP over CHAP (Challenge Authentication Protocol; RFC1994)
‧ DoS Protection
‧ Stateful Packet Inspection (SPI)
‧ VPN (IPSec, PPTP, L2TP) Pass-Through
‧ Built-in NAT Firewall
‧ IP-based Packet filtering
‧ Password Protected System Management

Web Based Management
‧ Web-based GUI Configuration / Management
‧ Command-line Interpreter (CLI)
‧ Telnet Remote Management
‧ Firmware upgrade via FTP / TFTP
‧ Support SNMP V.1 and V.2C
‧ Built-in Diagnostic tool and IP Ping
‧ TR-069, CPE WAN Management Protocol
Interface
‧ Four RJ45 ports compatible with IEEE 802.3/802.3u, 10/100Mbps auto
selection
‧ One RJ11 port for ADSL connection
‧ One power switch button
‧ One reset button for restoration of factory default setting
LED Indicators
‧ Power, LAN, ADSL, LANx4
Antenna
‧ One detachable Reverse SMA external antenna
Wireless Frequency
‧ 2.400~2.4835 Ghz
Receiver Security
‧ IEEE 802.11b: -84 dBm (typical), IEEE 802.11g: -60 dBm (Typical)
Transmit Output Power
‧ 11b : 19±1 dBm, 11g : 15±1 dBm
Power Adapter
‧ Power Adapter: Input 110
±
10 or 230
±
10 VAC, Output 12VDC 1000mA
Dimensions (approximate)
160 mm (Length) x 130 mm (Width) x 24 mm (Height)
Net Weight (approximate)
‧ 320g
Operating Temperature
‧ 0°C ~ 45°C
Humidity
‧ 5% ~ 95% (Non condensing)

Storage Temperature
‧ -20°C ~ 70°C
Supported Operating System
‧ Windows® 998SE, ME, 2000, XP, Windows Vista™, MAC OS X
Regulations
‧ FCC Part 15, CE
