Mistral CCT Mirror
Safety Warnings
INSTRUCTION MANUAL
• This product is only suitable for connection to a 240V~50Hz supply in accordance with current IEE wiring regulations.
It should be installed in accordance with local building regulations and is for domestic ceiling use only.
• Beforeinstallingyourmirroralwaysswitcho󰀨themainssupplyandremovetheappropriatefuseorswitcho󰀨the
appropriate circuit breaker before commencing installation.
• This is a Class I product, and must be Earthed. The terminal blocks are supplied according to requirements of the
tting.
• Thisproductcontainnon-replaceableLEDs.IftheLEDsstopworkingthenthettingmustbereplaced.
• Thisproductcontainsdelicateparts–becarefulduringhandlingandmaintenancetoavoidbreakage.
• Thisttingisheavy,andinstallationwillbeeasierwiththehelpofanassistant.
• This product has special protection against the ingress of water, and is rated IP44.
• This mirror may be installed in Zones 1 and 2 and Outside Zones of
a bathroom where water jets are not used for cleaning purposes. If
installing in a bathroom, a 30mA RCD must be used in accordance
with IEE Wiring Regulations and the Building Regulations. An
electrician must be consulted if you are in any doubt about your
own competency or meaning of bathroom “Zones”, “Equipotential
Bonding” or “RCD”.
• Ifanymodicationismadeitwillinvalidatethewarrantyandmay
render the product unsafe.
Assembly/ User Instructions
Before you start
Pleasereadtheseinstructionscarefullybeforettingandretainforreference.Checkthepackagingandmakesure
thatyouhavealltherequiredparts.Followeachassemblystepinordertopreventincorrectassembly.Ensurethatthe
product is fully assembled as illustrated before use. This mirror is suitable for use with the remote.
The mirror pack contains:
Mirror.
Fixingpack.
The following tools may be required:
Selectionofcrossandatheadscrewdrivers.
Electric drill and assorted drill bits.
Wire strippers.
Care Information
Allow 10 minutes to cool before replacing, adjusting or cleaning.
Cleanwithadryclothonly.Donotuseliquidorabrasivecleanersonthisproduct.
OUTSIDE ZONES
ZONE
2
ZONE
1
0.6m
0.6m
2.25m
Ceiling
1. Always switch o󰀨 the electricity supply at the mains during installation and maintenance. We recommend that
thefuseiswithdrawnorcircuitbreakerswitchedo󰀨atthedistributionboardwhilstworkisinprogress. 
Refer to Assembly Diagram 1.
2. Thismirrorxestothewallbylocatingthekeyholeshapedslotsoverthemountingscrewsinthewall.Itisimportant
togetthescrewpositionscorrecttoensureeasyandsecuretting.Measurethedistancebetweentheholecentres
onthexinglugs.Markthepositionsofthescrewholesonthewall.Checkforconcealedpipesandwiringbefore
drilling.Usesuitabledrillbitsformasonryandceramictiles.Suppliedwallplugsareforsolidwallsonly.Forallother
walltypesensurecorrectxingsareused.Fitappropriatewallxingsandtsuppliedscrews.Screwheadsmust
protrudeapprox3-5mmfromthewalltoenablelugstotoveradequately.Refer to Assembly Diagram 2.
These assembly diagrams are intended as a guide – if in doubt consult a qualied electrician.

Endon Lighting, LS9 0SE
3. UndoJunctionBoxscrewsandremovelid,ensuringyoudonotdamagethewaterproofseal.Pierceaholeinthe
cableinletgrommetandfeedcablethroughintojunctionbox,allowingadequateextomanoeuvrethemirroron
ando󰀨thewall.Connectwirestoterminalblock,makingsureyoufollowcorrectwiringorientationsandprocedures,
as shown in Assembly Diagram 3.
4. Carefullylocatefixingslotsonframeoverscrews,ensuringproductisfullyseatedonallmounts.Ensurethecorrect
orientationisusedwiththejunctionboxsituatedatthebottom.Refer to Assembly Diagram 4.
5. Replacefuseorcircuitbreakerandswitchonusingthetouchon/o󰀨switchonthefrontofthemirror.Thisproductis
colour changing and can be either warm white (3000K) or cool white (4000K). Press and hold the switch to choose
desiredcolour.Simplyswitchontoactivateando󰀨todeactivate.Donotleavethedemisterrunningformorethan
30 minutes.Thedemistinge󰀨ectwillspreadapproximately10-20%furtherthanthepaditself.Thedemisterpad
will warm the mirror surface. Refer to Assembly Diagram 5 & 6.
79668-Mistral CCT-Mirror 20190620
Assembly/ User Instructions Continued
PUSH DOWN
