Operating Instructions
Tankside Monitor NRF81
Tank Gauging
BA01465G/00/EN/03.18
71406899
2018-06-07
01.02.zz (Device firmware)

Tankside Monitor NRF81
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Tankside Monitor NRF81 Table of contents
Endress+Hauser 3
Table of contents
1 About this document ................ 4
1.1 Document function ..................... 4
1.2 Symbols .............................. 4
1.3 Documentation ........................ 7
1.4 Registered trademarks ................... 9
2 Basic safety instructions ........... 10
2.1 Requirements for the personnel ........... 10
2.2 Designated use ....................... 10
2.3 Workplace safety ...................... 10
2.4 Operational safety ..................... 11
2.5 Product safety ........................ 11
3 Product description ................ 12
3.1 Product design ........................ 12
4 Incoming acceptance and product
identification ..................... 13
4.1 Incoming acceptance ................... 13
4.2 Product identification .................. 13
4.3 Storage and transport .................. 15
5 Installation ....................... 16
5.1 Installation conditions .................. 16
5.2 Post-installation check .................. 17
6 Electrical connection .............. 18
6.1 Terminal assignment ................... 18
6.2 Connecting requirements ................ 33
6.3 Ensuring the degree of protection .......... 34
6.4 Post-connection check .................. 34
7 Operability ........................ 35
7.1 Overview of the operation options ......... 35
7.2 Structure and function of the operating
menu .............................. 36
7.3 Access to the operating menu via the local
display ............................. 37
7.4 Access to the operating menu via the service
interface and FieldCare ................. 49
7.5 Access to the operating menu via Tankvision
Tank Scanner NXA820 and FieldCare ....... 50
8 System integration ................ 53
8.1 Overview of the Device Description files
(DTM) .............................. 53
9 Commissioning .................... 54
9.1 Initial settings ........................ 54
9.2 Configuring the tank gauging application .... 56
9.3 Advanced settings ..................... 82
9.4 Simulation ........................... 82
9.5 Protecting settings from unauthorized
access .............................. 82
10 Operation ......................... 83
10.1 Reading off the device locking status ....... 83
10.2 Reading off measured values ............. 83
11 Diagnostics and troubleshooting ... 84
11.1 General trouble shooting ................ 84
11.2 Diagnostic information on local display ...... 85
11.3 Diagnostic information in FieldCare ........ 88
11.4 Overview of the diagnostic messages ....... 90
11.5 Diagnostic list ........................ 97
11.6 Reset measuring device ................. 98
11.7 Device information .................... 98
11.8 Firmware history ...................... 98
12 Maintenance ...................... 99
12.1 Maintenance tasks ..................... 99
12.2 Endress+Hauser services ................ 99
13 Repair ........................... 100
13.1 General information on repairs ........... 100
13.2 Spare parts ......................... 100
13.3 Endress+Hauser services ............... 101
13.4 Return ............................. 101
13.5 Disposal ........................... 101
14 Accessories ...................... 102
14.1 Device-specific accessories .............. 102
14.2 Communication-specific accessories ....... 103
14.3 Service-specific accessories .............. 103
14.4 System components ................... 103
15 Operating menu .................. 104
15.1 Overview of the operating menu .......... 104
15.2 "Operation" menu ..................... 112
15.3 "Setup" menu ........................ 121
15.4 "Diagnostics" menu .................... 237
Index ................................. 246

About this document Tankside Monitor NRF81
4 Endress+Hauser
1 About this document
1.1 Document function
These Operating Instructions contain all the information that is required in various phases
of the life cycle of the device: from product identification, incoming acceptance and
storage, to mounting, connection, operation and commissioning through to
troubleshooting, maintenance and disposal.
1.2 Symbols
1.2.1 Safety symbols
Symbol Meaning
DANGER
DANGER!
This symbol alerts you to a dangerous situation. Failure to avoid this situation will
result in serious or fatal injury.
WARNING
WARNING!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can
result in serious or fatal injury.
CAUTION
CAUTION!
This symbol alerts you to a dangerous situation. Failure to avoid this situation can
result in minor or medium injury.
NOTICE
NOTE!
This symbol contains information on procedures and other facts which do not result in
personal injury.
1.2.2 Electrical symbols
Symbol Meaning
Direct current
Alternating current
Direct current and alternating current
Ground connection
A grounded terminal which, as far as the operator is concerned, is grounded via a
grounding system.
Protective ground connection
A terminal which must be connected to ground prior to establishing any other
connections.
Equipotential connection
A connection that has to be connected to the plant grounding system: This may be a
potential equalization line or a star grounding system depending on national or
company codes of practice.

Tankside Monitor NRF81 About this document
Endress+Hauser 5
1.2.3 Tool symbols
Symbol Meaning
A0013442
Torx screwdriver
A0011220
Flat blade screwdriver
A0011219
Cross-head screwdriver
A0011221
Allen key
A0011222
Hexagon wrench
1.2.4 Symbols for certain types of information
Symbol Meaning
Permitted
Procedures, processes or actions that are permitted.
Preferred
Procedures, processes or actions that are preferred.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information.
Reference to documentation
A
Reference to page
Reference to graphic
Notice or individual step to be observed
1.
,
2.
,
3.
… Series of steps
Result of a step
Help in the event of a problem
Visual inspection
1.2.5 Symbols in graphics
Symbol Meaning
1, 2, 3 ... Item numbers
1.
,
2.
,
3.
… Series of steps
A, B, C, ... Views
A-A, B-B, C-C, ... Sections

About this document Tankside Monitor NRF81
6 Endress+Hauser
Symbol Meaning
-
Hazardous area
Indicates a hazardous area.
.
Safe area (non-hazardous area)
Indicates the non-hazardous area.
1.2.6 Symbols at the device
Symbol Meaning
Safety instructions
Observe the safety instructions contained in the associated Operating Instructions.
Temperature resistance of the connection cables
Specifies the minimum value of the temperature resistance of the connection cables.

Tankside Monitor NRF81 About this document
Endress+Hauser 7
1.3 Documentation
For an overview of the scope of the associated Technical Documentation, refer to the
following:
• The W@M Device Viewer : Enter the serial number from the nameplate
(www.endress.com/deviceviewer)
• The Endress+Hauser Operations App: Enter the serial number from the nameplate
or scan the 2-D matrix code (QR code) on the nameplate.
1.3.1 Technical Information (TI)
The Technical Information contains all the technical data on the device and provides an
overview of the accessories and other products that can be ordered for the device.
Device Technical Information
Tankside Monitor NRF81 TI01251G
1.3.2 Brief Operating Instructions (KA)
The Brief Operating Instructions contain all the essential information from incoming
acceptance to initial commissioning.
Device Brief Operating Instructions
Tankside Monitor NRF81 KA01209G
1.3.3 Operating Instructions (BA)
The Operating Instructions contain all the information that is required in various phases of
the life cycle of the device: from product identification, incoming acceptance and storage,
to mounting, connection, operation and commissioning through to troubleshooting,
maintenance and disposal.
It also contains a detailed explanation of each individual parameter in the operating menu
(except the Expert menu). The description is aimed at those who work with the device
over the entire life cycle and perform specific configurations.
Device Operating Instructions
Tankside Monitor NRF81 BA01465G
1.3.4 Description of Device Parameters (GP)
The Description of Device Parameters provides a detailed explanation of each individual
parameter in the 2nd part of the operating menu: the Expert menu. It contains all the
device parameters and allows direct access to the parameters by entering a specific code.
The description is aimed at those who work with the device over the entire life cycle and
perform specific configurations.
Device Description of Device Parameters
Tankside Monitor NRF81 GP01083G (in preparation)

About this document Tankside Monitor NRF81
8 Endress+Hauser
1.3.5 Safety instructions (XA)
Ordering feature 010 "Approval" Meaning XA
BA ATEX II 2 (1)G Ex db [ia Ga] IIC T6 Gb XA01531G
FD FM C/US XP-AIS Cl.I Div.1 Gr.BCD T6
AEx d[ia] IIC T6
XA01532G
GA EAC Ex db[ia Ga] IIC T6 Gb in preparation
IA IEC Ex db [ia Ga] IIC T6 Gb XA01531G
KA KC Ex db[ia Ga] IIC T6 Gb in preparation
MA INMETRO Ex db[ia Ga] IIC T6 Gb in preparation
NA NEPSI Ex db[ia Ga] IIC T6 Gb in preparation
TA TIIS Ex d[ia] IIC T6 Ga/Gb in preparation

Tankside Monitor NRF81 About this document
Endress+Hauser 9
1.4 Registered trademarks
FieldCare®
Registered trademark of the Endress+Hauser Process Solutions AG, Reinach, Switzerland
MODBUS®
Registered trademark of the MODBUS-IDA, Hopkinton, MA, USA

Basic safety instructions Tankside Monitor NRF81
10 Endress+Hauser
2 Basic safety instructions
2.1 Requirements for the personnel
The personnel for installation, commissioning, diagnostics and maintenance must fulfill
the following requirements:
‣Trained, qualified specialists must have a relevant qualification for this specific function
and task.
‣Are authorized by the plant owner/operator.
‣Are familiar with federal/national regulations.
‣Before starting work, read and understand the instructions in the manual and
supplementary documentation as well as the certificates (depending on the
application).
‣Follow instructions and comply with basic conditions.
The operating personnel must fulfill the following requirements:
‣Are instructed and authorized according to the requirements of the task by the facility's
owner-operator.
‣Follow the instructions in this manual.
2.2 Designated use
Application and measured materials
The device described in these Operating Instructions is a monitoring unit for use with the
Endress+Hauser Micropilot M and Micropilot S-series radars and other HART compatible
devices. Mounted at the tank side, it provides indication of measured data, allows
configuration and supplies intrinsically safe (i.s.) or explosion proof (XP) power to the
connected sensors on the tank. Various industry standard digital gauging communication
protocols support integration into open architecture tank gauging and inventory systems.
Measuring devices for use in hazardous areas, in hygienic applications or in applications
where there is an increased risk due to process pressure, are labeled accordingly on the
nameplate.
To ensure that the measuring device remains in proper condition for the operation time:
‣Only use the measuring device in full compliance with the data on the nameplate and
the general conditions listed in the Operating Instructions and supplementary
documentation.
‣Check the nameplate to verify if the device ordered can be put to its intended use in the
approval-related area (e.g. explosion protection, pressure vessel safety).
‣If the measuring device is not operated at atmospheric temperature, compliance with
the relevant basic conditions specified in the associated device documentation is
absolutely essential.
‣Protect the measuring device permanently against corrosion from environmental
influences.
‣Observe the limit values in the "Technical Information".
The manufacturer is not liable for damage caused by improper or non-designated use.
2.3 Workplace safety
For work on and with the device:
‣Wear the required personal protective equipment according to federal/national
regulations.

Tankside Monitor NRF81 Basic safety instructions
Endress+Hauser 11
2.4 Operational safety
Risk of injury.
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
Conversions to the device
Unauthorized modifications to the device are not permitted and can lead to unforeseeable
dangers.
‣If, despite this, modifications are required, consult with the manufacturer.
Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe federal/national regulations pertaining to repair of an electrical device.
‣Use original spare parts and accessories from the manufacturer only.
Hazardous area
To eliminate a danger for persons or for the facility when the device is used in the
hazardous area (e.g. explosion protection, pressure vessel safety):
‣Based on the nameplate, check whether the ordered device is permitted for the
intended use in the hazardous area.
‣Observe the specifications in the separate supplementary documentation that is an
integral part of these Instructions.
2.5 Product safety
This measuring device is designed in accordance with good engineering practice to meet
state-of-the-art safety requirements, has been tested, and left the factory in a condition in
which it is safe to operate. It meets general safety standards and legal requirements.
2.5.1 CE mark
The measuring system meets the legal requirements of the applicable EC guidelines. These
are listed in the corresponding EC Declaration of Conformity together with the standards
applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.

Product description Tankside Monitor NRF81
12 Endress+Hauser
3 Product description
3.1 Product design
1
2
3
A0027767
 1 Design of Tankside Monitor NRF81
1 Housing
2 Display and operating module (can be operated without opening the cover)
3 Mounting plate for wall or pipe mounting

Tankside Monitor NRF81 Incoming acceptance and product identification
Endress+Hauser 13
4 Incoming acceptance and product
identification
4.1 Incoming acceptance
Upon receipt of the goods check the following:
• Are the order codes on the delivery note and the product sticker identical?
• Are the goods undamaged?
• Do the nameplate data match the ordering information on the delivery note?
• If required (see nameplate): Are the Safety Instructions (XA) enclosed?
If one of these conditions is not satisfied, contact your Endress+Hauser Sales Center.
4.2 Product identification
The following options are available for identification of the measuring device:
• Nameplate specifications
• Extended order code with breakdown of the device features on the delivery note
• Enter serial numbers from nameplates in W@M Device Viewer
( www.endress.com/deviceviewer ): All information about the measuring device is
displayed.
• Enter the serial number from the nameplates into the Endress+Hauser Operations App
or scan the 2-D matrix code (QR code) on the nameplate with the Endress+Hauser
Operations App: all the information for the measuring device is displayed.
For an overview of the scope of the associated Technical Documentation, refer to the
following:
• The W@M Device Viewer: Enter the serial number from the nameplate
(www.endress.com/deviceviewer)
• The Endress+Hauser Operations App: Enter the serial number from the nameplate or
scan the 2-D matrix code (QR code) on the nameplate.

Incoming acceptance and product identification Tankside Monitor NRF81
14 Endress+Hauser
4.2.1 Nameplate
1
215
16
17
5
8
10
9
13 14
6
12
7
18
19
20 21
3
4
Ext. ord. cd.:
Order code:
Ser. no.:
Tankside Monitor
Date:
Dual seal (MWP: 370bar)
FW: Dev.Rev.: ex works
DeviceID:
Ta:
if modification
see sep. label
X =
Tank ID:
Tank ref.height: FCC ID: LCG NMR8X
11
A0029745
 2 Nameplate Tankside Monitor NRF81
1 Manufacturer address
2 Order code
3 Serial number
4 Extended order code
5 Supply voltage
6 Thread for cable entry
7 Device ID
8 Firmware version
9 Device revision
10 Metrology certification numbers
11 Customized parametrization data
12 Ambient temperature range
13 CE mark / C-tick mark
14 Additional information on the device version
15 Ingress protection
16 Certificate symbol
17 Data concerning the Ex approval
18 General certificate of approval
19 Associated Safety Instructions (XA)
20 Manufacturing date
21 QR code for the Endress+Hauser Operations App
4.2.2 Manufacturer address
Endress+Hauser GmbH+Co. KG
Hauptstraße 1
79689 Maulburg, Germany
Address of the manufacturing plant: See nameplate.

Tankside Monitor NRF81 Incoming acceptance and product identification
Endress+Hauser 15
4.3 Storage and transport
4.3.1 Storage conditions
• Storage temperature: –50 to +80 °C (–58 to +176 °F)
• Store the device in its original packaging.
4.3.2 Transport
NOTICE
Risk of injury
‣Transport the measuring device to the measuring point in its original packaging.
‣Take into account the mass center of the device in order to avoid unintended tilting.
‣Comply with the safety instructions, transport conditions for devices over 18kg
(39.6lbs) (IEC61010).

Installation Tankside Monitor NRF81
16 Endress+Hauser
5 Installation
5.1 Installation conditions
5.1.1 Wall mounting
150 (5.9)
150 (5.9)
ø13.5 (0.53)
M12
≤15 Nm (11.06 lbf ")
A0029901
 3 Wall mounting of the Tankside Monitor
5.1.2 Pipe mounting
Ordering feature 620 "Accessory enclosed" Mounting kit
PV Mounting kit, pipe, DN32-50 (1-1/4" - 2")
PW Mounting kit, pipe, DN80 (3")
≤15 Nm (11.06 lbf ")
A0029899
 4 Mounting of the Tankside Monitor at a vertical pipe

Tankside Monitor NRF81 Installation
Endress+Hauser 17
≤15 Nm (11.06 lbf ")
A0029900
 5 Mounting of the Tankside Monitor at a horizontal pipe
5.2 Post-installation check
mIs the device undamaged (visual inspection)?
m
Does the device conform to the measuring point specifications?
For example:
• Process temperature
• Process pressure (refer to the chapter on "Material load curves" of the "Technical Information"
document)
• Ambient temperature range
• Measuring range
mAre the measuring point identification and labeling correct (visual inspection)?
mIs the device adequately protected from precipitation and direct sunlight?

Electrical connection Tankside Monitor NRF81
18 Endress+Hauser
6 Electrical connection
6.1 Terminal assignment
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
G1
3
2
POWER
G1
3
2
POWER
G1 N
G3 L
AC 85...264 V
A0027362
 6 Terminal compartment (typical example) and ground terminals
Terminal area Module
A/B/C/D
(slots for I/O
modules)
Up to four I/O modules, depending on the order code
• Modules with four terminals can be in any of these slots.
• Modules with eight terminals can be in slot B or C.
The exact assignment of the modules to the slots is dependent on the device version
→  20.
E HART Ex i/IS interface
• E1: H+
• E2: H-
F Remote display
• F1: VCC (connect to terminal 81 of the remote display)
• F2: Signal B (connect to terminal 84 of the remote display)
• F3: Signal A (connec t to terminal 83 of the remote display)
• F4: Gnd (connect to terminal 82 of the remote display)
G
Power supply: 85 to 264 VAC
• G1: N
• G2: not connected
• G3: L
Power consumption:
A0018339
Protective ground connection (M4 screw)

Tankside Monitor NRF81 Electrical connection
Endress+Hauser 19
6.1.1 Power supply
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
G1
3
2
POWER
4
F
1
1 3
2
2 4
HR
CDI
WP
SIM
G1
3
2
POWER
G1 N AC 85...264 V
A0033413
G1 N
G2 not connected
G3 L
4 Green LED: indicates power supply
Supply voltage
85 to 264 VAC, 50/60 Hz, 28.8 VA 1)
The supply voltage is also indicated on the nameplate.
6.1.2 HART Ex i/IS interface
D
E
F
C
B
A
1
1
1
1 3
2
2 4
1
HR
CDI
WP
on
SIM
2
2
3
3
4
4
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
i
E1
1
2
CDI
i
G1
3
2
POWER
3
A0033414
E1 H+
E2 H-
3 Orange LED: indicates data communication
This interface always operates as the main HART master for connected HART slave
transmitters. The Analog I/O modules, on the other hand, can be configured as a
HART master or slave →  27 →  29.
1) maximum value; actual value depending on modules installed. 28.8 VA includes the nominal power, and the cabling specification has to meet
this value. On the other hand, the effective power consumption is 12 W.

Electrical connection Tankside Monitor NRF81
20 Endress+Hauser
6.1.3 Slots for I/O modules
The terminal compartment contains four slots (A, B, C and D) for I/O modules. Depending
on the device version (ordering features 040, 050 and 060) these slots contain different
I/O modules. The table below shows which module is located in which slot for a specific
device version.
The slot assignment for the device is also indicated on a label attached to the back
cover of the display module.
1
D
C
B
A
A0030069
1 Label showing (among other things) the modules in the slots A to D.
A Cable entry for slot A
B Cable entry for slot B
C Cable entry for slot C
D Cable entry for slot D
