Endress+Hauser Solimotion FTR20 User manual

BA01136F/97/EN/07.20
71467968 Products Solutions Services
Operating Instructions
Solimotion FTR20
Flow indicator for bulk solids

Solimotion FTR20
2Endress+Hauser
Liquiphant FTL41
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555
TI00447F/97/EN/14.17
71387792
Products Solutions Services
Technical Information
Solimotion FTR20
Flow indicator for bulk solids
Compact measuring device for non-contact ow detection for bulk solids
Application
TheFTR20 flow indicator for bulk solids is a non-contact
devicebased on microwave technology. It is ideally suited for
monitoringpneumatic and mechanical transport processes for
bulksolids. The compact device can be used wherever the cost-
effectivemonitoring of bulk solids movement is required.
Typicalareas of application or bulk solids are:
•Buildingmaterials industry: Cement, plaster, wood chips etc.
•Chemicalindustry: Fertilizers, plastic powder, granules etc.
•Foodindustry: Coffee, tea, tobacco, cereals, malt etc.
•Energyproduction: Coal, carbon dust, fly-ash, coke etc.
Individualadjustments to the application are carried out
bymeans of configurable functions (including automatic
calibration).In addition, changes in the mass flow can be
analyzedby the optional 4 - 20 mA current output.
Deviceproperties
•Detection range up to 20 m depending on the bulk solids
•Processtemperatures up to +70 °C (+158 °F) or +450 °C
(+842°F) with optional adapter for temperature reduction
•Processpressure up to 680 kPa (6.8 bar) absolute or 2 MPa
(20bar) absolute with optional high pressure adapter
•Foruse in hazardous areas (dust and gas)
Your benets
•Compact device:
Sensor, transmitterand power unit are mounted in a
housing, which means less eort is required for installation
andmounting.
• The device can be used wherever cost-eective monitoring
of a mass ow (present or not present) is required.
•Flush-mountedinstallation, non-contact installation
possible
•Easymounting using R 1½, 1½ NPT or G 1½ thread or a
suitablemounting bracket
•Electronicshousing can be rotated by 360 °, allowing
orientation into optimum position aer installation
•Mechanicalrobustness
-No wear
-Process-wetted ceramic sensor diaphragm (optional)
-Long service life
-Maintenance-free
• Signaling of mass ow
• Adjustable sensitivity
• Compliant with ATEX, CSA and IECEx
TI00447F/97/EN/14.17
71387792 Products Solutions Services
Technical Information
Solimotion FTR20
Flow indicator for bulk solids
Compact measuring device for non-contact ow detection for bulk solids
Application
TheFTR20 flow indicator for bulk solids is a non-contact
devicebased on microwave technology. It is ideally suited for
monitoringpneumatic and mechanical transport processes for
bulksolids. The compact device can be used wherever the cost-
effectivemonitoring of bulk solids movement is required.
Typicalareas of application or bulk solids are:
•
Buildingmaterials industry: Cement, plaster, wood chips etc.
•
Chemicalindustry: Fertilizers, plastic powder, granules etc.
•
Foodindustry: Coffee, tea, tobacco, cereals, malt etc.
•
Energyproduction: Coal, carbon dust, fly-ash, coke etc.
Individualadjustments to the application are carried out
bymeans of configurable functions (including automatic
calibration).In addition, changes in the mass flow can be
analyzedby the optional 4 - 20 mA current output.
Deviceproperties
•
Detectionrange up to 20 m depending on the bulk solids
•
Processtemperatures up to +70 °C (+158 °F) or +450 °C
(+842°F) with optional adapter for temperature reduction
•
Processpressure up to 680 kPa (6.8 bar) absolute or 2 MPa
(20bar) absolute with optional high pressure adapter
•
Foruse in hazardous areas (dust and gas)
Your benets
•Compact device:
Sensor, transmitterand power unit are mounted in a
housing, which means less eort is required for installation
andmounting.
• The device can be used wherever cost-eective monitoring
of a mass ow (present or not present) is required.
•Flush-mountedinstallation, non-contact installation
possible
•Easymounting using R 1½, 1½ NPT or G 1½ thread or a
suitablemounting bracket
•Electronicshousing can be rotated by 360 °, allowing
orientation into optimum position aer installation
•Mechanicalrobustness
-No wear
-Process-wetted ceramic sensor diaphragm (optional)
-Long service life
-Maintenance-free
• Signaling of mass ow
• Adjustable sensitivity
• Compliant with ATEX, CSA and IECEx
Solimotion FTR20
Order code:
Ext. ord. cd.:
Ser.-No.:
Date:
TI00447F/97/EN/14.17
71387792 Products Solutions Services
Technical Information
Solimotion FTR20
Flow indicator for bulk solids
Compact measuring device for non-contact ow detection for bulk solids
Application
TheFTR20 flow indicator for bulk solids is a non-contact
devicebased on microwave technology. It is ideally suited for
monitoringpneumatic and mechanical transport processes for
bulksolids. The compact device can be used wherever the cost-
effectivemonitoring of bulk solids movement is required.
Typicalareas of application or bulk solids are:
•
Buildingmaterials industry: Cement, plaster, wood chips etc.
•
Chemicalindustry: Fertilizers, plastic powder, granules etc.
•
Foodindustry: Coffee, tea, tobacco, cereals, malt etc.
•
Energyproduction: Coal, carbon dust, fly-ash, coke etc.
Individualadjustments to the application are carried out
bymeans of configurable functions (including automatic
calibration).In addition, changes in the mass flow can be
analyzedby the optional 4 - 20 mA current output.
Deviceproperties
•
Detectionrange up to 20 m depending on the bulk solids
•
Processtemperatures up to +70 °C (+158 °F) or +450 °C
(+842°F) with optional adapter for temperature reduction
•
Processpressure up to 680 kPa (6.8 bar) absolute or 2 MPa
(20bar) absolute with optional high pressure adapter
•
Foruse in hazardous areas (dust and gas)
Your benets
•Compact device:
Sensor, transmitterand power unit are mounted in a
housing, which means less eort is required for installation
andmounting.
• The device can be used wherever cost-eective monitoring
of a mass ow (present or not present) is required.
•Flush-mountedinstallation, non-contact installation
possible
•Easymounting using R 1½, 1½ NPT or G 1½ thread or a
suitablemounting bracket
•Electronicshousing can be rotated by 360 °, allowing
orientation into optimum position aer installation
•Mechanicalrobustness
-No wear
-Process-wetted ceramic sensor diaphragm (optional)
-Long service life
-Maintenance-free
• Signaling of mass ow
• Adjustable sensitivity
• Compliant with ATEX, CSA and IECEx
Liquiphant FTL41
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Solimotion FTR20 Table of contents
Endress+Hauser 3
Table of contents
1 About this document����������������������������������������������������������������������������������������������������� 5
1.1 Document function ............................................................................................................................................................. 5
1.2 Symbols ............................................................................................................................................................................... 5
1.3 Documentation ................................................................................................................................................................... 6
2 Basic safety instructions����������������������������������������������������������������������������������������������� 8
2.1 Requirements for personnel .............................................................................................................................................. 8
2.2 Designated use .................................................................................................................................................................... 8
2.3 Workplace safety ................................................................................................................................................................ 9
2.4 Operational safety .............................................................................................................................................................. 9
2.5 Product safety ..................................................................................................................................................................... 9
3 Product description����������������������������������������������������������������������������������������������������� 10
3.1 Product design .................................................................................................................................................................. 10
3.2 Functional principle ......................................................................................................................................................... 10
4 Incomingacceptanceandproductidentication������������������������������������������������������ 11
4.1 Incoming acceptance ........................................................................................................................................................ 11
4.2 Productidentication ...................................................................................................................................................... 11
4.3 Nameplate ......................................................................................................................................................................... 12
4.4 Storage and transportation ............................................................................................................................................. 12
4.5 Disposal of packaging ...................................................................................................................................................... 12
5 Installation������������������������������������������������������������������������������������������������������������������� 13
5.1 Installation requirements ................................................................................................................................................ 13
5.2 Installing the FTR20 ........................................................................................................................................................ 14
5.3 Post-installation check .................................................................................................................................................... 16
6 Electrical connection��������������������������������������������������������������������������������������������������� 17
6.1 Connection requirements ................................................................................................................................................ 17
6.2 Potential equalization ...................................................................................................................................................... 18
6.3 Connecting the device ...................................................................................................................................................... 18
6.4 Post-connection check ..................................................................................................................................................... 25
7 Operability������������������������������������������������������������������������������������������������������������������� 26
7.1 Overview ............................................................................................................................................................................ 26
7.2 Structure and function of the operating menu .............................................................................................................. 27
8 Commissioning������������������������������������������������������������������������������������������������������������ 28
8.1 Installation and function check ....................................................................................................................................... 28
8.2 Switching on the device ................................................................................................................................................... 28
8.3 Conguringthedevice ..................................................................................................................................................... 28
8.4 Advanced settings ............................................................................................................................................................ 39
8.5 Resetting to factory defaults (function F) ...................................................................................................................... 45
8.6 Simulation ......................................................................................................................................................................... 46
9 Diagnostics and troubleshooting������������������������������������������������������������������������������� 47
9.1 General troubleshooting .................................................................................................................................................. 47
9.2 Diagnostic information .................................................................................................................................................... 47
9.3 Resetting the device ......................................................................................................................................................... 47
10 Maintenance���������������������������������������������������������������������������������������������������������������� 48
10.1 Maintenance recommendation ....................................................................................................................................... 48
10.2 Endress+Hauser services ................................................................................................................................................. 48

Solimotion FTR20
Table of contents
4Endress+Hauser
11 Repair��������������������������������������������������������������������������������������������������������������������������� 49
11.1 General notes .................................................................................................................................................................... 49
11.2 Spare parts ........................................................................................................................................................................ 50
11.3 Return ................................................................................................................................................................................ 52
11.4 Disposal ............................................................................................................................................................................. 52
12 Accessories������������������������������������������������������������������������������������������������������������������ 54
13 Technicalspecications���������������������������������������������������������������������������������������������� 55
14 Appendix���������������������������������������������������������������������������������������������������������������������� 56
14.1 Settings of the Solimotion FTR20 ................................................................................................................................... 56
14.2 Overview of the device functions .................................................................................................................................... 57
Index�������������������������������������������������������������������������������������������������������������������������������������� 59

Solimotion FTR20 About this document
Endress+Hauser 5
1 About this document
1�1 Document function
These operating instructions contain all the information that is required in the various phases
ofthelifecycleofthedevice:Fromproductidentication,incomingacceptanceandstorage,to
installation,connection,operationandcommissioningthroughtotroubleshooting,maintenance
and disposal.
1�2 Symbols
1�2�1 Safety symbols
This warning alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
This note contains information on procedures and other facts that do not entail a risk of
personal injury.
1�2�2 Electrical symbols
Direct current
Alternating current
Protectiveearthconnection
A terminal which has to be grounded before other connections can be established.
1�2�3 Tool symbols
Flat-blade screwdriver
Phillips head screwdriver
Allen key
Open-ended wrench
1.2.4 Symbolsfordierenttypesofinformation
Permitted
Indicatesprocedures,processesoractionsthatarepermitted.
Tip
Indicates additional information.
Reference to documentation
Reference to page
Referencetogure
, , Series of steps

Solimotion FTR20
About this document
6Endress+Hauser
1�2�5 Device-specicsymbols
LED on
Indicates an illuminated LED
LEDo
Indicates a non-illuminated LED
Congurationmode
Indicates the function number or value
Normal operation
Indicates only the signal strength of the bulk solids movement
Key (+)
Indicates the key for increasing a function value
Key (-)
Indicates the key for reducing a function value
Minimumbulkow
Indicatesaminimumorabsentbulkow
Maximumbulkow
Indicatesamaximumbulkow
1�2�6 Symbols in graphics
A, B, C ��� View
1,2,3...Itemnumber
-Hazardous area
.Safe area (non-hazardous area)
1�3 Documentation
The document types listed are available:
 IntheDownloadareaoftheEndress+Hauserwebsite:www.endress.com→Downloads
1�3�1 Standard documentation
Document Purpose and content of the document
Technical information
TI00447F/97/EN
Planning aid for your device
Thisdocumentcontainsallthetechnicalspecicationsforthe
device and provides an overview of all the items that can be
ordered for use in conjunction with or as part of the device.

Solimotion FTR20 About this document
Endress+Hauser 7
1�3�2 Supplementary device-dependent documentation
Dependingontheapproval,safety instructions (XA) are supplied with the device when it is
delivered. These safety instructions are an integral part of the operating instructions.
Feature 010 Approval Safety instructions
BA ATEX II 1/2D Ex ta/tb IIIC T102°C Da/Db IP66
ATEX II 2D Ex tb IIIC T102°C Db IP66
XA00524F/97/A3
CB CSAC/USClassII,Div.1,GroupE-G XA01245F/97/EN
IA IECEx Ex ta/tb IIIC T102°C Da/Db IP66
IECEx Ex tb IIIC T102°C Db IP66
XA00544F/97/EN

Solimotion FTR20
Basic safety instructions
8Endress+Hauser
2 Basic safety instructions
2�1 Requirements for personnel
Thepersonnelforinstallation,commissioning,diagnosticsandmaintenancemustmeetthe
following requirements:
•Trained,qualiedspecialists:Mustbequaliedforthisspecicroleandtask
• Authorized by the plant operator
• Familiar with national regulations
• Before starting work: Read and make sure you have understood the instructions in the
manualandsupplementarydocumentationaswellasthecerticates(dependingonthe
application)
• Follow the instructions and comply with the general requirements
Operating personnel must meet the following requirements:
• Must be instructed and authorized according to the requirements of the task by the plant
operator
• Follow the instructions in this manual
2�2 Designated use
The device described in these Instructions is intended only for movement detection of bulk
productsandthedetectionofchangesofamassow.Dependingontheversionordered,the
devicecanalsomeasurepotentiallyexplosive,ammable,poisonousandoxidizinguids.
To ensure that the device remains in proper condition for the operation time:
• Use the device only for fluids against which the process-wetted materials are adequately
resistant.
•Observethelimitvalues(→55).
Incorrect use
The manufacturer is not liable for damage caused by improper or non-designated use.
Verification for borderline cases:
•Forspecialfluidsandfluidsforcleaning,Endress+Hauserisgladtoprovideassistance
inverifyingthecorrosionresistanceoffluid-wettedmaterials,butdoesnotacceptany
warranty or liability.
Possible burn hazard from touching surfaces!
•Forelevatedfluidtemperature,ensureprotectionagainstcontacttopreventburns.
TheSolimotionFTR20owindicatorisapprovedforuseinhazardousareas.
Proceed in accordance with the safety instructions.
→8

Solimotion FTR20 Basic safety instructions
Endress+Hauser 9
2�3 Workplace safety
When working on and with the device:
• Wear the required personal protective equipment in accordance with national regulations.
2�4 Operational safety
Risk of injury!
• The device may only be operated if it is in perfect working order and is free from faults.
• The operator is responsible for ensuring that the device operates without incident.
Hazardous area
To eliminate danger to persons or the plant when the device is used in the hazardous area
(e.g. explosion protection):
• Check the nameplate to verify whether the ordered device can be used as intended in the
hazardous area.
•Observethespecicationsintheseparatesupplementarydocumentation,whichisan
integral part of these operating instructions.
2�5 Product safety
This state-of-the-art device has been tested to make sure that it is designed and manufactured
inaccordancewithgoodengineeringpracticeandoperatessafelyandreliably.Itlethe
factory in perfect working order.
It meets the general safety standards and legal requirements. It also complies with the EU
directiveslistedinthedevice-specicEUDeclarationofConformity.Endress+Hauserconrms
this by displaying the CE mark on the device.

Solimotion FTR20
Product description
10 Endress+Hauser
3 Product description
TheSolimotionFTR20owindicatorforbulksolidsworksusingmicrowavetechnologyand
detectsthemovementofbulksolidsandchangesinthemassowofasolidow.
3�1 Product design
DierentversionsofthedevicesusedtomaketheSolimotionFTR20owindicatorare
available;thechoiceofdevicesthatareuseddependsonthespecicapplication,aswellas
factors such as the types of area for which they are approved and the electrical connection.
A B C
1 Productversions
Versions Examples
A B C
Housing F16 Polyester F15 Stainless steel F34 Aluminium
Electrical connection M20gland,plastic Connector M12
(Binder series 713/763)
½NPTthread,metal
Process connection G 1½ thread R 1½ thread 1½ NPT thread
Detailsabouttheavailabledevicevariantscanbeviewedintheproductconguratoron
the Endress+Hauser homepage www.endress.com.
3�2 Functional principle
TheFTR20transmitsasignalthatisreectedbythemovingbulksolids.Indoingso,the
devicemeasuresthestrengthofthereected,frequency-shiedenergy(Dopplereect)and
uses it to form a display value or output signal.
Details about Technical data
→TI00447F/97/EN

Solimotion FTR20 Incomingacceptanceandproductidentication
Endress+Hauser 11
4 Incomingacceptanceandproductidentication
4�1 Incoming acceptance
DELIVERY NOTE
1 = 2
Is the order code on the delivery note (1) identical to the order code on the product sticker (2)?
1
2
3
4
5
6
Are the goods undamaged?
Dothespecicationsonthenameplatecorrespondtotheorderinformationandthedelivery
note?
 Ifoneoftheconditionsisnotsatised:
Contact your Endress+Hauser sales center
4�2 Productidentication
You can identify your device in the following ways:
• Using the nameplate specifications
•Using the order code with a breakdown of the device features on the delivery note
• Entering the serial numbers from the nameplates in W@M Device Viewer
(www.endress.com/deviceviewer): All information about the device will be displayed.
Foranoverviewofthescopeofthetechnicaldocumentationprovided,refertothefollowing:
• The "Additional documentation" section
•The W@M Device Viewer: Enter the serial number from the nameplate
(www.endress.com/deviceviewer)

Solimotion FTR20
Incomingacceptanceandproductidentication
12 Endress+Hauser
4�3 Nameplate
Solimotion FTR20
Order code:
Ext. ord. cd.:
Ser. no.:
Date:
1
2
3
4
5
6
7
8
10
9
2 Exampleofanameplate
1 Placeofmanufacture
2 Ordercode
3 Extendedordercode
4 Serialnumber
5 Degreeofprotection(IPrating)
6 Ambienttemperaturerange,optionaltextforapproval
7 Operatinginstructionsandsafetyinstructionsforthedevice
8 Dateofmanufacture:Year-Month
9 CEmark
10 Inputandoutputparameters
4�4 Storage and transportation
Please note the following points:
•Store in the original packaging to ensure protection from shock.
• The permitted storage temperature is -40 to +80 °C (-40 to +176 °F); storage at the
temperature limits is only permitted for a limited time (maximum 48 hours).
4�5 Disposal of packaging
The carton is environmentally compatible and 100% recyclable in accordance with European
Directive 2004/12/EC on packaging (recyclability is confirmed by means of the RESY symbol
on the carton).

Solimotion FTR20 Installation
Endress+Hauser 13
5 Installation
5�1 Installation requirements
TheSolimotionFTR20owindicatorforbulksolidscomeswithastandardthread
(R1½asperEN10226,1½NPTasperANSI/ASMEB1.20.1orG1½asperISO228-1)asa
process connection. This enables easy installation in existing container couplings or nozzles.
 Fordevicesintendedforuseinhazardousareas,pleasereadtheinformationandcomply
with the instructions in the Ex documentation (XA).
Foroptimalorientationaerinstallationintheprocess,theelectronicshousingcanberotated
as desired (by 360 °).
αα
3 Installationposition
•AnyorientationispossiblefortheFTR20owindicatorforbulksolids.However,asmall
angleαmayincreasethesignalquality.
•We recommend an angle of 45 ° for applications with material detection on conveyor belts.

Solimotion FTR20
Installation
14 Endress+Hauser
1
2
3
4
5
6
α = 45 °
4 Installationpositionformaterialdetectiononconveyorbelt
•Choosealocationtoinstallthedevicewhereapplication-specicinuenceswillbeminimal.
• With vibrating mounting locations it is recommended to use devices with encapsulated
electronics (see ordering structure "Accessory mounted").
 Fordevicesintendedforuseinhazardousareas,pleasereadtheinformationandcomply
with the instructions in the Ex documentation (XA).
5�2 Installing the FTR20
5�2�1 Direct mounting with threaded connection
Thesimplestmountingmethodisbyscrewingintotheprocesswall.Todothis,a
correspondinginternalthread(Rp1½,1½NPTorG1½)mustbeavailableintheprocess.
5�2�1�1 Installation with self-sealing connection thread (R 1½ and 1½ NPT)
5 Installationwithself-sealingconnectionthread

Solimotion FTR20 Installation
Endress+Hauser 15
Installation procedure:
Screw the R 1½ or 1½ NPT self-sealing connecting thread into existing screw-in thread.
55 mm (AF)
Align the housing of the electronics.
Fix the housing in place.
2 mm
5�2�1�2 Installation with non-self-sealing connection thread (G 1½)
6 Installationwithnon-self-sealingconnectionthread
Installation procedure:
Slide the enclosed process seal over the process connection and screw the non-self-sealing
connection thread G 1½ into the existing screw-in thread.
55 mm (AF)
Tighten the lock nut on the connection thread.
55 mm (AF)
Align the housing of the electronics.
Fix the housing in place.
2 mm
•Iftheprocessconnectionisnotscrewedfarenoughintotheprocesswall,thereisariskthat
materialwillaccumulateinfrontoftheFTR20,therebydampingthemicrowavesignal.
•If,ontheotherhand,theprocessconnectionisscrewedtoofarintotheprocess,thereisa
risk of damage occurring as a result of large product items falling.

Solimotion FTR20
Installation
16 Endress+Hauser
5�2�2 Installation with accessories
Achoiceofdierentprocessadaptersisavailablefromtherangeofaccessories,dependingon
where you want to install the device and on the process conditions.
• For more information on the range of available accessories
→54
• For more information on the various installation options
→TI00447F/97/EN
5�3 Post-installation check
Is the device undamaged (visual inspection)?
 Doesthedeviceconformtothemeasuringpointspecications?
For example:
• Process temperature
• Process pressure
• Ambient temperature
Arethemeasuringpointidenticationandlabelingcorrect(visualinspection)?
Is the device adequately protected from moisture and direct sunlight?
Is the device properly secured?

Solimotion FTR20 Electrical connection
Endress+Hauser 17
6 Electrical connection
6�1 Connection requirements
Please note the following points before connecting up the device:
•Thevoltagesupplymustmatchthevoltagespeciedonthenameplate.
•Switchothesupplyvoltagebeforeconnectingthedevice.
• Connect a potential matching line to the terminal to be used on the FTR20 before
connecting the device to the power supply.
•Whenconnectingtothepublicpowersupply,apowerswitchforthedevicemustbeinstalled
withineasyreachofthedevice.Theswitchistobeidentiedasadisconnectingdevicefor
the device (EN/IEC 61010).
•Thecableglandsandconnectorsarepermittedforconnectingxedcablesandlinesonly.
The operator must ensure adequate strain relief.
• The device is to be attached so that the cable gland is protected from mechanical damage
(degree of mechanical hazard "low" – impact energy: 4 joules).
•Unusedguideopeningsmustbesealedousingsealingplugs,theplastictransportsealing
plug does not meet this requirement and must therefore be replaced during installation.
 Fordevicesintendedforuseinhazardousareas,pleasereadtheinformationandcomply
with the instructions in the Ex documentation (XA).
6�1�1 Required tools
Connection Tool
TerminalsandscrewedcontactoftheoptionalM12plugconnector,Binder
series 713/763 0.6 x 3.5 mm
Potential equalization PZ2
Cable glands (F16 plastic housing) SW25
Cableglands(F15stainlesssteelhousing,F34aluminiumhousingand
optional Harting HAN8D plug connector) SW22
Cablegland(optionalM12plugconnector,Binderseries713/763) SW13
Crimp contacts optional Harting HAN8D plug connector Suitable crimping tool
6�1�2 Connecting cable requirements
Theconnectingcablesprovidedbythecustomermustfullthefollowingrequirements:
• Electrical safety in accordance with applicable national regulations.
•Permittedtemperaturerange→55
• Normal installation cable with at least three wires
• Cable cross-sections: 0.2 to 2.5 mm2or AWG 24 to 12
•Theterminalsareonlyapprovedforconnectingxedcables.Theoperatormustprovide
suitable strain relief.

Solimotion FTR20
Electrical connection
18 Endress+Hauser
Theoptionalenclosedplugconnectorsmustfullthefollowingrequirements:
• Clamping range of the connection cable:
-6...8mm(M12plugconnector,Binderseries713/763)
- 7 ... 10.5 mm (Harting HAN8D plug connector)
• Cable cross-sections: max. 0.75 mm2or AWG 18
•Theplugconnectorsareonlyapprovedforconnectingxedcables.Theoperatormust
provide suitable strain relief.
For the electrical connection with connectors there are suitable prefabricated connection
cablesavailableasaccessory(→54).
6�2 Potential equalization
The following requirements apply to the potential equalization:
• The potential equalization must be connected to the external ground terminal on the
FTR20.
•Foroptimalelectromagneticcompatibility,thepotentialequalizationlineshouldbeasshort
as possible.
• The recommended cable cross-section is 2.5 to 4 mm2.
• The potential equalization for the FTR20 must be integrated into the existing potential
equalization on site.
6�3 Connecting the device
There are terminals on the inside or connectors on the outside for the electrical connection.
• For the electrical connection with connectors there are suitable mating connectors available
fororderingaccordingtotheproductconguratororasaccessory.
• Prefabricated connection cables with suitable mating connectors are also available as
accessory.
• For more information on the range of available accessories
→54

Solimotion FTR20 Electrical connection
Endress+Hauser 19
6�3�1 Connection of F16 housing (plastic)
1
2
3
4
5
7 6
7 DeviceconnectionF16housing
1 Connectionterminals
2 Internalpotentialequalizationconnection
3 Externalpotentialequalizationconnection
4 Cablegland(clampingareas5to10mmasperEN50262or7to10mmasperUL-514B)
5 Connectioncable
6 M12connector(Binderseries713/763)
7 HartingconnectortypeHAN8D
Procedure of connection with terminals and cable glands:
Insertcableintocablegland,tightencapnutuntiltherubbersealistouchedallaround
and then tighten cap nut with by ½ turn.
Connect the protective ground.
Connect the power supply and signal output.
Procedure of connection with connectors:
Connect the protective ground.
Connecttheconnectorsandxthem.
• For the electrical connection with connectors there are suitable mating connectors available
fororderingaccordingtotheproductconguratororasaccessory.
• Prefabricated connection cables with suitable mating connectors are also available as
accessory.
• For more information on the range of available accessories
→54

Solimotion FTR20
Electrical connection
20 Endress+Hauser
6�3�2 Connection of F15 housing (stainless steel)
1
2
3
7 6 5 4
8 DeviceconnectionF15housing
1 Connectionterminals
2 Cablegland(clampingarea7to10.5mm)
3 Connectioncable
4 Internalpotentialequalizationconnection
5 M12connector(Binderseries713/763)
6 Externalpotentialequalizationconnection(onlyfordeviceversionswithconnector)
7 HartingconnectortypeHAN8D
Procedure of connection:
Insertcableintocablegland,tightenthecapnut(torqueofupto10Nm).
Connect the protective ground.
Connect the power supply and signal output.
Procedure of connection with connectors:
Connect the protective ground.
Connecttheconnectorsandxthem.
• For the electrical connection with connectors there are suitable mating connectors available
fororderingaccordingtotheproductconguratororasaccessory.
• Prefabricated connection cables with suitable mating connectors are also available as
accessory.
• For more information on the range of available accessories
→54
