Endress+Hauser Soliwave FDR56 User manual

BA01684F/97/EN/03.22-00
71560954
2023-12-06
Products Solutions Services
Operating Instructions
Soliwave FDR56/FQR56
Microwave barrier

2
Soliwave FDR56/FQR56
Endress+Hauser
Liquiphant FTL41
2 Endress+Hauser
Order code:
Ext. ord. cd.:
Ser. no.:
www.endress.com/deviceviewer Endress+Hauser
Operations App
XXXXXXXXXXXX
XXXXX-XXXXXX
XXX.XXXX.XX
Serial number
1.
3.
2.
A0023555

Soliwave FDR56/FQR56
Endress+Hauser 3
Table of contents
1 About this document � � � � � � � � � � � � � � � � � � � � � � 5
1.1 Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
1.1.1 Safety symbols . . . . . . . . . . . . . . . . . . . . . . .5
1.1.2 Electrical symbols . . . . . . . . . . . . . . . . . . . .5
1.1.3 Symbols for certain types of information 5
1.1.4 Symbols in graphics . . . . . . . . . . . . . . . . . .5
1.1.5 Device-specic symbols . . . . . . . . . . . . . . .6
2 Basic safety instructions � � � � � � � � � � � � � � � � � � � 6
2.1 Requirements for the personnel . . . . . . . . . . . . . . .6
2.2 Designated use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
2.3 Workplace safety. . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.4 Operational safety. . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.4.1 Conversions to the device. . . . . . . . . . . . . .7
2.4.2 Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
2.4.3 Hazardous area . . . . . . . . . . . . . . . . . . . . . .7
2.5 Product safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3 Product description� � � � � � � � � � � � � � � � � � � � � � � � 7
3.1 Product design . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Incoming acceptance and product
identication � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 8
4.1 Incoming acceptance. . . . . . . . . . . . . . . . . . . . . . . . .8
4.2 Product identication . . . . . . . . . . . . . . . . . . . . . . . .8
4.2.1 Nameplate . . . . . . . . . . . . . . . . . . . . . . . . . .9
4.2.2 Manufacturer address. . . . . . . . . . . . . . . . .9
4.3 Storage and transport. . . . . . . . . . . . . . . . . . . . . . . .9
4.3.1 Storage conditions. . . . . . . . . . . . . . . . . . . .9
4.3.2 Transporting the device . . . . . . . . . . . . . . .9
4.3.3 Disposal of packaging . . . . . . . . . . . . . . . . .9
5 Mounting � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 10
5.1 Mounting conditions. . . . . . . . . . . . . . . . . . . . . . . .10
5.1.1 Mounting position. . . . . . . . . . . . . . . . . . .10
5.1.2 Optimization of the signal quality. . . . . .10
5.1.3 Reector operation . . . . . . . . . . . . . . . . . .11
5.1.4 Parallel operation . . . . . . . . . . . . . . . . . . .11
5.1.5 Mounting with accessories. . . . . . . . . . . .12
5.1.6 Operating temperature range . . . . . . . . .12
5.1.7 Mounting dimensions. . . . . . . . . . . . . . . .12
5.2 Mounting the device . . . . . . . . . . . . . . . . . . . . . . . .13
5.2.1 Mounting in contact with the process . .13
5.2.2 Mounting without contact with
the process . . . . . . . . . . . . . . . . . . . . . . . . .15
5.3 Post-installation check . . . . . . . . . . . . . . . . . . . . . .21
6 Electrical connection � � � � � � � � � � � � � � � � � � � � � 22
6.1 Connection requirements. . . . . . . . . . . . . . . . . . . .22
6.1.1 Required tool . . . . . . . . . . . . . . . . . . . . . . .22
6.1.2 Connecting cable requirements. . . . . . . .22
6.2 Connect potential equalization . . . . . . . . . . . . . . .23
6.3 Connecting the device. . . . . . . . . . . . . . . . . . . . . . .23
6.3.1 Supply circuit connection . . . . . . . . . . . . .24
6.3.2 Connection signal circuit . . . . . . . . . . . . .25
6.4 Post-connection check . . . . . . . . . . . . . . . . . . . . . .26
7 Operation options � � � � � � � � � � � � � � � � � � � � � � � � 27
Table of contents
7.1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
7.1.1 Transceiver FDR56 . . . . . . . . . . . . . . . . . .27
7.1.2 Transmitter FQR56 . . . . . . . . . . . . . . . . . .27
7.2 On-site operation . . . . . . . . . . . . . . . . . . . . . . . . . .28
7.2.1 Operation of the FDR56 . . . . . . . . . . . . . .28
7.2.2 Operation of the FQR56 . . . . . . . . . . . . . .28
7.3 Parameterization. . . . . . . . . . . . . . . . . . . . . . . . . . .28
7.3.1 Adjustment with free or minimum
covered path (function 1). . . . . . . . . . . . .28
7.3.2 Adjustment with maximum
covered path (function 2). . . . . . . . . . . . .29
7.3.3 Advanced settings . . . . . . . . . . . . . . . . . . .30
7.4 Overview device functions . . . . . . . . . . . . . . . . . . .35
8 Commissioning � � � � � � � � � � � � � � � � � � � � � � � � � � 35
8.1 Function check. . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
8.2 Powering up the measuring device . . . . . . . . . . . .35
8.3 Conguring the device . . . . . . . . . . . . . . . . . . . . . .36
9 Diagnostics and troubleshooting � � � � � � � � � � � 36
9.1 General troubleshooting. . . . . . . . . . . . . . . . . . . . .36
9.2 Overview of the diagnostic functions . . . . . . . . . .36
9.3 Resettting the device. . . . . . . . . . . . . . . . . . . . . . . .36
10 Maintenance � � � � � � � � � � � � � � � � � � � � � � � � � � � � 36
10.1 Maintenance recommendation . . . . . . . . . . . . . . .37
10.2 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
11 Repair � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 37
11.1 General notes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
11.2 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
11.3 Replacing the electronics or a device . . . . . . . . . .37
11.4 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
11.4.1 Available electronics . . . . . . . . . . . . . . . . .38
11.4.2 Replacing the electronics . . . . . . . . . . . . .40
11.5 Return. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
11.6 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
12 Accessories� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 41
12.1 Mating connectors . . . . . . . . . . . . . . . . . . . . . . . . .41
12.2 Pre-fabricated connection cables . . . . . . . . . . . . .41
12.3 Mounting bracket . . . . . . . . . . . . . . . . . . . . . . . . . .42
12.4 Weld-in adapter . . . . . . . . . . . . . . . . . . . . . . . . . . .42
12.5 Screw-in adapter . . . . . . . . . . . . . . . . . . . . . . . . . . .43
12.6 Weld-in adapter with mounting arm . . . . . . . . . .43
12.7 Mounting ange . . . . . . . . . . . . . . . . . . . . . . . . . . .44
12.8 High pressure adapter. . . . . . . . . . . . . . . . . . . . . . .45
12.9 Plug . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
12.10 Sight glass tting. . . . . . . . . . . . . . . . . . . . . . . . . . .46
12.11 Insertion adapter. . . . . . . . . . . . . . . . . . . . . . . . . . .48
12.12 Weld-in nozzle. . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
12.13 Spacer tube (wave guide) . . . . . . . . . . . . . . . . . . . .49
12.14 Wave guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
12.15 High temperature adapter with extension. . . . . .50
12.16 Weather protection cover. . . . . . . . . . . . . . . . . . . .51
13 Technical data � � � � � � � � � � � � � � � � � � � � � � � � � � � 52
13.1 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

4
Soliwave FDR56/FQR56
Endress+Hauser
Table of contents
13.1.1 Measured variable. . . . . . . . . . . . . . . . . . .52
13.1.2 Measuring range (Detection range) . . . .52
13.1.3 Operating frequency . . . . . . . . . . . . . . . . .52
13.1.4 Transmitting power. . . . . . . . . . . . . . . . . .52
13.1.5 Antenna opening angle (3dB) . . . . . . . .52
13.2 Output. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
13.2.1 Output signal . . . . . . . . . . . . . . . . . . . . . . .52
13.2.2 Ex connection data . . . . . . . . . . . . . . . . . .52
13.3 Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
13.3.1 Supply voltage . . . . . . . . . . . . . . . . . . . . . .53
13.3.2 Power consumption. . . . . . . . . . . . . . . . . .53
13.4 Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
13.4.1 Ambient temperature . . . . . . . . . . . . . . . .53
13.4.2 Storage temperature . . . . . . . . . . . . . . . . .53
13.4.3 Degree of protection . . . . . . . . . . . . . . . . .53
13.4.4 Vibration resistance . . . . . . . . . . . . . . . . .53
13.4.5 Shock resistance . . . . . . . . . . . . . . . . . . . .53
13.4.6 Electromagnetic compatibility. . . . . . . . .54
13.5 Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
13.5.1 Process temperature . . . . . . . . . . . . . . . . .54
13.5.2 Process pressure . . . . . . . . . . . . . . . . . . . .54
13.6 Additional technical data . . . . . . . . . . . . . . . . . . . .54

Soliwave FDR56/FQR56
Endress+Hauser 5
About this document
1 About this document
1�1 Symbols
1�1�1 Safety symbols
This symbol alerts you to a dangerous situation. Failure to avoid this situation will result
in serious or fatal injury.
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
serious or fatal injury.
This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in
minor or medium injury.
This symbol contains information on procedures and other facts which do not result in
personal injury.
1�1�2 Electrical symbols
Protective Earth (PE)
A terminal which must be connected to ground prior to establishing any other connec-
tions.
1�1�3 Symbols for certain types of information
Permitted
Procedures, processes or actions that are permitted.
Forbidden
Procedures, processes or actions that are forbidden.
Tip
Indicates additional information
 Reference to documentation
 Reference to another section
 Reference to graphic
▸Notice or individual step to be observed
, , Series of steps
1�1�4 Symbols in graphics
A, B, C ��� View
1, 2, 3 ... Item numbers
-Hazardous area
.Safe area (non-hazardous area)

6
Soliwave FDR56/FQR56
Endress+Hauser
Basic safety instructions
1�1�5 Device-specic symbols
LED on
Indicates an illuminated LED
LED o
Indicates a non-illuminated LED
Conguration mode
Indicates the function number or value
Normal operation
Indicates only the signal strength of the limit detection
Key (+)
Indicates the key for increasing a function value
Key (-)
Indicates the key for reducing a function value
Free path
Indicates the free path between FDR and FQR
Covered path
Indicates the covered path between FDR and FQR
2 Basic safety instructions
2�1 Requirements for the personnel
The personnel must fulll the following requirements to carry out the necessary tasks,
e. g., commissioning and maintenance:
‣ Trained, qualied specialists must have a relevant qualication for the specic function
and task
‣Are authorized by the plant owner/operator
‣Are familiar with federal/national regulations
‣Must have read and understood the instructions in the manual and supplementary
documentation
‣Follow instructions and comply with conditions
2�2 Designated use
Use the microwave barrier only for point level detection and counting and control purpo-
ses. Improper use can pose hazards. Ensure that the measuring device is free of defects
while it is in operation.
• Use the measuring device only for media to which the process-wetted materials have an
adequate level of resistance
• Do not exceed or drop below the limit values for the measuring device
 TI00443F
Incorrect use
The manufacturer is not liable for damage caused by improper or non-designated use.
Clarication of borderline cases:
• In the case of special uids and media used for cleaning, Endress+Hauser is glad to
provide assistance in verifying the corrosion resistance of wetted materials, but does not
accept any warranty or liability.

Soliwave FDR56/FQR56
Endress+Hauser 7
Product description
Residual risks
The electronics housing and the modules installed in it can heat up to 80°C (176°F) du-
ring operation due to heat input from the process as well as the power dissipation of the
electronics.
Danger of burns from contact with surfaces!
‣If necessary, ensure protection against contact to prevent burns.
2�3 Workplace safety
For work on and with the device:
‣Wear the required protective equipment according to federal/national regulations.
2�4 Operational safety
Risk of injury!
‣Operate the device in proper technical condition and fail-safe condition only.
‣The operator is responsible for interference-free operation of the device.
2�4�1 Conversions to the device
Unauthorized modications to the device are not permitted and can lead to unforeseeable
dangers.
‣ If, despite this, modications are required, consult with Endress+Hauser.
2�4�2 Repair
To ensure continued operational safety and reliability,
‣Carry out repairs on the device only if they are expressly permitted.
‣Observe national regulations pertaining to the repair of an electrical device.
‣Only use original spare parts and accessories from Endress+Hauser.
2�4�3 Hazardous area
To eliminate danger to persons or the facility when the device is used in the hazardous
area (e.g. explosion protection):
‣Check the nameplate to verify whether the ordered device can be used as intended in
the hazardous area.
2�5 Product safety
The devices of the microwave barrier are designed in accordance with good engineering
practice to meet state-of-the-art safety requirements, has been tested, and le the factory
in a condition in which it is safe to operate.
They meet general safety standards and legal requirements. They also complies with the
EU directives listed in the device-specic EU Declaration of Conformity. Endress+Hauser
conrms this by axing the CE mark to the devices.
3 Product description
The Soliwave microwave barrier consists of the FQR56 transmitter and the FDR56 tran-
sceiver and is used for the non-contact point level detection of powdery to lumpy bulk
solids and liquids, for the purpose of monitoring and counting piece goods as well as for
the detection of build-up.
The devices of the Soliwave microwave barrier are available in dierent versions; the
choice of devices that are used depends on the specic application, as well as factors such
as the types of area for which they are approved and the electrical connection.

8
Soliwave FDR56/FQR56
Endress+Hauser
Incoming acceptance and product identication
3�1 Product design
A B C
0000000155
1 Devicevariants
Device variants Example
A B C
Housing F16 (Polyester) F15 (Stainless steel) F34 (Aluminum)
Electrical connection Cable gland M20 Connector M12 Thread 1/2"NPT
Process connection Thread G 1½ in
accordance with ISO
228-1
Thread R 1½ in
accordance with EN
10226
Thread 1½ NPT in
accordance with ANSI/
ASME
Details about the available device variants can be viewed in the product congurator
on the Endress+Hauser homepage www.endress.com.
4 Incoming acceptance and
product identication
4�1 Incoming acceptance
Check the following during goods acceptance:
Are the order codes on the delivery note and the product sticker identical?
Are the goods undamaged?
Do the nameplate data match the ordering information on the delivery note?
 If required (see nameplate): Are the Safety Instructions, e. g. XA, provided?
Is the device properly secured?
If one of these conditions is not met, please contact the manufacturer's sales oce.
4�2 Product identication
The measuring device can be identied in the following ways:
• Nameplate data
• Extended order code with breakdown of the device features on the delivery note
• Enter serial number from nameplates in W@MDeviceViewer (www.endress.com/de-
viceviewer): All of the information on the measuring device is displayed along with an
overview of the scope of technical documentation provided

Soliwave FDR56/FQR56
Endress+Hauser 9
Incoming acceptance and product identication
• Enter the serial number on the nameplate into the Endress+HauserOperationsApp or
use the Endress+HauserOperationsApp to scan the 2-D matrix code (QR Code) on the
nameplate
4�2�1 Nameplate
Soliwave 1
Order code:
2
Ext. ord. cd.:
Ser.-No.:
3

3
4
2 Nameplatedata
1 Manufactureraddress
2 Ordernumber,externalordercode,serialnumber
3 Technicaldata
4 Approval-specificinformation
4�2�2 Manufacturer address
Endress+Hauser SE+Co. KG
Hauptstraße 1
79689 Maulburg, Germany
4�3 Storage and transport
4�3�1 Storage conditions
Use original packaging.
Storage temperature
→ 53
4�3�2 Transporting the device
Transport the device to the measuring point in the original packaging.
4�3�3 Disposal of packaging
The carton is environmentally compatible and 100 % recyclable in accordance with Euro-
pean Directive 2004/12/EC on packaging (recyclability is conrmed by means of the RESY
symbol on the carton).

10
Soliwave FDR56/FQR56
Endress+Hauser
Mounting
5 Mounting
5�1 Mounting conditions
Minimization of application-specic inuences
‣ Vibration inuence → 53
5�1�1 Mounting position
The installation position is arbitrary under consideration of the following conditions:
• Microwaves are polarized: FDR56 and FQR56 must not be rotated against each other
along their longitudinal axis (except by 180° or for detection ranges smaller than
300mm (11.8in)).
• Maintain a minimum distance of 30mm (1.18in).
β
α
A B
0000000156
3 Mountingposition
A Detectionrange0.3to100m(11.8to3937in)
B Detectionrange0.03to0.3m(1.18to11.8in)
α Antennaopeningangleapprox.11°
β 90°
5�1�2 Optimization of the signal quality
If the microwave barrier devices are installed in front of microwave-permeable windows
or plugs, it is possible to optimize the signal quality by moving FQR56 and FDR56 on their
longitudinal axis aer an automatic adjustment has been performed. → 28
FQR56 FDR56
a
b
0000000158
4 Optimizationofthesignalquality

Soliwave FDR56/FQR56
Endress+Hauser 11
Mounting
Loosen device 1 (here FQR56) and move it slowly by a= ±10mm (±0.4in) until a
signal maximum is reached (LED signal strength), x device again.
Example: →
Then loosen device 2 (here FDR56) and move it slowly by b= ±10mm (±0.4in) until
a signal maximum is reached, x the device again.
Example: →
Position change performed (here horizontal shi)
‣ Perform automatic adjustment again
5�1�3 Reector operation
Direct comparison of FQR56 and FDR56 not possible�
‣Deflect microwave beam via plane metal mirrors (reflectors).
α
α
α
α
α
α
1 1 1
0000000165
5 Reflectoroperation
1 Reflector
α Angleofentrance=angleofemission
• Arrange devices symmetrically to the reector (entrance angle = exit angle).
• Range reduction per reector: 10%
5�1�4 Parallel operation
Mutual interference is to be avoided�
‣Rotate every second microwave barrier by 90°.
A
α α
D
0000000167
6 Paralleloperation
A Distancebetweenmicrowavebarriers
D Detectionrange
α 90°

12
Soliwave FDR56/FQR56
Endress+Hauser
Mounting
• Recommendation under ideal conditions: A ≥ D/2
• Applications with stronger reections: Increase Aas required
5�1�5 Mounting with accessories
Details of available accessories
→ 41
5�1�6 Operating temperature range
→ 53
5.1.7 Mounting dimensions
1 2
3 4 2
1 2
189 (7.44)
183 (7.20)
L3
n95 (3.74)
n 85 (3.35)
169 (6.65)
L1
175 (6.89)
29 (1.14)
n
49 (1.93)
164 (6.46)
L2
n
49 (1.93)
n 77 (3.03)
n
49
(1.93)
60 (2.36)
0000000154
7 Mountingdimensions.Unitofmeasurementmm(in)
1 ConnectionthreadR1½/1½NPT
2 HexagonSW55
3 ConnectionthreadG1½
4 Counternut(SW55)

Soliwave FDR56/FQR56
Endress+Hauser 13
Mounting
Dimensions L1 to L3, depending on the housing and electrical connection:
Housing
Electrical connection
Cable gland M20 Thread
1/2"NPT
Connector
M12
Connector
Harting HAN8D
L1 (F16) 114 (4.49) 111 (4.37) 101 (3.98) 133 (5.24)
L2 (F15) 93 (3.66) 94 (3.70) 88 (3.46) 120 (4.72)
L3 (F34) 116 (4.57) 117 (4.60) 111 (4.37) 143 (5.63)
5�2 Mounting the device
5�2�1 Mounting in contact with the process
The device is screwed directly into the process (for example in existing threads or vessel
sleeves) with its process connection (standard threads R 1½ according to EN 10226, G 1½
according to ISO 228-1 or 1½ NPT according to ANSI/ASME B1.20.1).
A B
0000000157
8 Directmountingwiththreadedconnection
• If the process connection is not screwed far enough into the process wall, there is a risk
that material will accumulate in front of the device (A), thereby damping the microwave
signal.
• If, on the other hand, the process connection is screwed too far into the process (B),
there is a risk of damage occurring as a result of large product items falling.
Mounting with connection thread
2.5
55
0000000166
9 Mountingwithconnectionthread

14
Soliwave FDR56/FQR56
Endress+Hauser
Mounting
Screw in connection thread. For G 1½ thread: Tighten counternut.
Align the electronics housing (cable gland or plug connector of both devices must
point in the same direction).
Fix the housing in place.
• When using the G 1½ process connection (standard thread according to ISO 228-1,
hexagon SW55) with counternut, the device can be mounted ush particularly easi-
ly, as it is a cylindrical thread.
• Seal (if necessary): to be provided by the customer
Mounting with weld-in adapter FAR52-A*
‣ Weld the adapter ush with the inner wall of the container.
‣ Screw in the device ush with the inner wall. For G 1½ thread: Tighten counternut.
Mounting with screw-in adapter FAR52-B*
‣ Screw in the adapter ush with the inner wall of the container.
‣Screw in the device as far as it will go.
1 2
70
0000000168
10 Weld-inorscrew-inadapterFAR52.Unitofmeasurementmm(in)
1 Screw-inadapterFAR52-B*
2 Weld-inadapterFAR52-A*
• Suitable weld-in and screw-in adapters of type FAR52 → 42
• Observe the installation instructions in the associated Technical Information.
• Seal (if necessary): to be provided by the customer

Soliwave FDR56/FQR56
Endress+Hauser 15
Mounting
Mounting for open processes
‣Mount the device with a mounting bracket, for example, on existing plant components.
1
0000000196
11 Mountingbracket
1 Mountingbracket
• For open processes, the mounting is arbitrary.
• Suitable mounting brackets → 42
5�2�2 Mounting without contact with the process
For a microwave-impermeable process wall (for example, metal vessel wall), mounting
is done in front of microwave-permeable windows such as plastic plugs, ceramic disks, or
sight glass ttings.
Mounting in front of microwave-permeable plugs of type FAR54
‣ Mount plug. → TI01371F
‣Mount the device in a suitable manner before the plug, for example with mounting
bracket on existing plant components.
1 2
D
A
T
0000000191
12 Mountinginfrontofmicrowave-impermeableprocesswall
1 Microwave-permeableplug
2 Microwave-permeableplugincaseofcondensateformationontheinnerprocesswall
• Observe maximum temperature T at the device connection. → 53
• Risk of condensate formation on the inner process wall → plug 2
• A minimize → minimize signal attenuation
• Observe the installation instructions in the associated Technical Information.
• Suitable plug of type FAR54 → 46

16
Soliwave FDR56/FQR56
Endress+Hauser
Mounting
Mounting with weld-in adapter with mounting arm
‣ Weld the adapter ush with the inner wall of the container.
‣Screw the mounting arm to the weld-in adapter using the plug.
‣Mount the device on the mounting arm using the enclosed mounting bracket.
3
2
1
4
5
0000000199
13 Weld-inadapterwithmountingarm.Unitofmeasurementmm(in)
1 Mountingbracket(aluminumorplastic)
2 Mountingarm
3 Weld-inadapter
4 Plug(flush-mountedwithweld-inadapter)
5 Plug(protrudingintotheprocess,incaseofcondensationontheinsidewallofthecontainer)
Suitable weld-in adapter with mounting arm
→ 43
Mounting in front of microwave permeable sight glass tting
‣ Weld the sight glass tting ush with the inner wall of the container.
‣ Mount the device in a suitable manner in front of the sight glass tting, for example
with a mounting bracket on existing plant components.
1 2
A
D
T
0000000269
14 Sightglassfitting
1 Sightglassfittingforprocessesupto10bar(145psi)
2 Sightglassfittingforunpressurizedprocesses
• Observe maximum temperature T at the device connection. → 53
• A minimize → minimize signal attenuation
• Suitable sight glass ttings and sight glass plates → 46

Soliwave FDR56/FQR56
Endress+Hauser 17
Mounting
Avoid material accumulation in front of the sight glass (risk of incorrect measurements).
0000000152
15 Impermissiblemountingwiththeriskofmaterialaccumulation
Mounting with waveguide type FAR55
‣ Mount waveguide. → TI01372F
‣ Insert the devices into the socket, align them and x them in place with the three enclo-
sed M8 hexagon socket screws (SW4) and locknuts (SW13).
T
2
1
200 ... 2000
(7.87 ... 78.74)
190
~
(7.50)
200 ... 2000 (7.87 ... 78.74) 190~ (7.50)
0000000268
16 WaveguideFAR55.Unitofmeasurementmm(in)
1 StraightversionFAR55-A*
2 AngulatedversionFAR55-B*
• Suitable waveguide type FAR55 → 50
• Observe the installation instructions in the associated Technical Information.
• Observe maximum temperature T at the device connection. → 53
• Seal (if necessary): to be provided by the customer
Mounting with mounting ange and plug → 18
‣Insert a suitable plug into the existing process connection piece.
‣ Mount suitable mounting ange.
‣ Screw the device into the mounting ange. For G 1½ thread: Tighten counternut.

18
Soliwave FDR56/FQR56
Endress+Hauser
Mounting
• Suitable mounting anges → 44
• Suitable plug of type FAR54 → TI01371F
• Gasket and mounting screws: to be provided by customer
Mounting on process nozzle
• Mounting of process nozzle with inclined process wall (A)
• Mounting in case of risk of material accumulation on inner process wall (B)
A
B
0000000153
17 Mountingonprocessnozzle
If there is a risk of condensation forming between the device and the plug: Use of
process connection type FAR50 with integrated venting element → 49
Mounting with weld-in socket type FAR50
‣ Mount weld-in socket. → TI01362F
‣ Screw the device into the mounting ange. For G 1½ thread: Tighten counternut.
1 2 3 4
0000000192
18 Weld-innozzleFAR50
1 Mountingflange
2 Processnozzle
3 Plug
4 Processinsulation

Soliwave FDR56/FQR56
Endress+Hauser 19
Mounting
• Observe maximum temperature T at the device connection. → 53
• Observe the installation instructions in the associated Technical Information.
• Suitable weld-in nozzles of type FAR50 → 49
• Seal (if necessary): to be provided by the customer
Mounting with insertion adapter type FAR51
‣ Mount plug-in adapter in existing process connection piece. → TI01368F
‣ Screw the device into the plug-in adapter. For G 1½ thread: Tighten counternut.
4
3
2
1
0000000279
19 InsertionadapterFAR51
1 Customer-suppliedinstallationmaterial
2 Processnozzle
3 Customer-suppliedgasket
4 Insertionadapter
• Observe maximum temperature T at the device connection. → 53
• Observe the installation instructions in the associated Technical Information.
• Suitable plug-in adapter type FAR51 → 48
• Seal (if necessary): to be provided by the customer
Mounting with high pressure adapter
‣Screw the high-pressure adapter into the existing process connection thread.
‣Screw the device into the adapter connection thread.
1 2
0000000195
20 Highpressureadapter
1 Highpressureadapter
2 Integratedventingelement

20
Soliwave FDR56/FQR56
Endress+Hauser
Mounting
• Suitable high pressure adapter → 45
• Seal: to be provided by the customer
Mounting with high temperature adapter and extensions
‣Mount high temperature adapter.
‣ If required: Mount extension(s).
‣ Screw the device into the connection thread. For G 1½ thread: Tighten counternut.
1 2 3 4 5
L
T
PT
HT T
0000000308
21 Hightemperatureadapterwithextension
1 Process
2 Wall
3 Hightemperatureadapter
4 Insulation
5 Lengthextensions(optional)
Observe the following temperatures:
• Temperature TP ≤ +450 °C (+842 °F) at the process connection of the high-temperature
adapter
• Temperature T ≤ +70 °C (+158 °F) at the device connection
• Temperature THT ≤ +160 °C (+320 °F) on the internal thread of the high-temperature
adapter when using the extension, otherwise THT ≤ T
• Lmust be selected depending on the process and ambient temperatures.
• Suitable high temperature adapter and extension → 50
Mounting with spacer tube (wave guide) type FAR53
‣ Mount spacer tube. → TI01370F
‣Mount the device to the mounting plate using the enclosed mounting bracket.
