Endress+Hauser HART Proline Promass 80 User manual

BA00057D/06/EN/13.12
71197479
Valid as of version
V 3.01.XX (device software)
Operating Instructions
Proline Promass 80
Coriolis Mass Flow Measuring System
6

Proline Promass 80 Table of contents
Endress+Hauser 3
Table of contents
1 Safety instructions . . . . . . . . . . . . . . . . 5
1.1 Designated use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Installation, commissioning and operation . . . . . . . . 5
1.3 Operational safety . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.4 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.5 Notes on safety conventions and icons . . . . . . . . . . . 6
2 Identification . . . . . . . . . . . . . . . . . . . . 7
2.1 Device designation . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1.1 Nameplate of the transmitter . . . . . . . . . . . . 8
2.1.2 Nameplate of the sensor . . . . . . . . . . . . . . . 9
2.1.3 Nameplate for connections . . . . . . . . . . . . 10
2.2 Certificates and approvals . . . . . . . . . . . . . . . . . . . 11
2.3 Registered trademarks . . . . . . . . . . . . . . . . . . . . . . 11
3 Installation . . . . . . . . . . . . . . . . . . . . . 12
3.1 Incoming acceptance, transport and storage . . . . . . 12
3.1.1 Incoming acceptance . . . . . . . . . . . . . . . . . 12
3.1.2 Transport . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.1.3 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Installation conditions . . . . . . . . . . . . . . . . . . . . . . 13
3.2.1 Dimensions . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2.2 Mounting location . . . . . . . . . . . . . . . . . . . 13
3.2.3 Orientation . . . . . . . . . . . . . . . . . . . . . . . . 15
3.2.4 Special installation instructions . . . . . . . . . 17
3.2.5 Heating . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.2.6 Thermal insulation . . . . . . . . . . . . . . . . . . 20
3.2.7 Inlet and outlet runs . . . . . . . . . . . . . . . . . 20
3.2.8 Vibrations . . . . . . . . . . . . . . . . . . . . . . . . . 20
3.2.9 Limiting flow . . . . . . . . . . . . . . . . . . . . . . . 20
3.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.3.1 Turning the transmitter housing . . . . . . . . 21
3.3.2 Installing the wall-mount housing . . . . . . . 22
3.3.3 Turning the local display . . . . . . . . . . . . . . 24
3.4 Post installation check . . . . . . . . . . . . . . . . . . . . . . 24
4 Wiring . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1 Connecting the remote version . . . . . . . . . . . . . . . 25
4.1.1 Connecting the sensor/transmitter . . . . . . 25
4.1.2 Cable specification, connecting cable . . . . . 26
4.2 Connecting the measuring unit . . . . . . . . . . . . . . . 26
4.2.1 Transmitter connection . . . . . . . . . . . . . . . 26
4.2.2 Terminal assignment . . . . . . . . . . . . . . . . . 28
4.2.3 HART connection . . . . . . . . . . . . . . . . . . . 29
4.3 Degree of protection . . . . . . . . . . . . . . . . . . . . . . . 30
4.4 Post connection check . . . . . . . . . . . . . . . . . . . . . . 30
5 Operation . . . . . . . . . . . . . . . . . . . . . . 31
5.1 Display and operating elements . . . . . . . . . . . . . . . 31
5.2 Brief operating instructions to the function matrix . 32
5.2.1 General notes . . . . . . . . . . . . . . . . . . . . . . 33
5.2.2 Enabling the programming mode . . . . . . . . 33
5.2.3 Disabling the programming mode . . . . . . . 33
5.3 Error messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.3.1 Type of error . . . . . . . . . . . . . . . . . . . . . . . 34
5.3.2 Error message type . . . . . . . . . . . . . . . . . . . 34
5.4 Communication . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.4.1 Operating options . . . . . . . . . . . . . . . . . . . 35
5.4.2 Current device description files . . . . . . . . . 36
5.4.3 Device and process variables . . . . . . . . . . . 36
5.4.4 Universal / Common practice
HART commands . . . . . . . . . . . . . . . . . . . 37
5.4.5 Device status / Error messages . . . . . . . . . . 42
6 Commissioning . . . . . . . . . . . . . . . . . . 44
6.1 Function check . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
6.2 Switching on the measuring device . . . . . . . . . . . . 44
6.3 Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.3.1 "Commissioning" Quick Setup . . . . . . . . . . 45
6.4 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.4.1 One current output: active/passive . . . . . . 47
6.4.2 Two current outputs: active/passive . . . . . 48
6.5 Adjust . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.5.1 Zero point adjustment . . . . . . . . . . . . . . . . 49
6.5.2 Density adjustment . . . . . . . . . . . . . . . . . . 51
6.6 Rupture disk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
6.7 Purge and pressure monitoring connections . . . . . . 52
6.8 Data storage device (HistoROM) . . . . . . . . . . . . . . 52
6.8.1 HistoROM/S–DAT (sensor–DAT) . . . . . . . 52
7 Maintenance . . . . . . . . . . . . . . . . . . . . 53
7.1 Exterior cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . 53
7.2 Cleaning with pigs (Promass H, I, S, P) . . . . . . . . . . 53
7.3 Replacing seals . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
8 Accessories . . . . . . . . . . . . . . . . . . . . . 54
8.1 Device-specific accessories . . . . . . . . . . . . . . . . . . . 54
8.2 Measuring principle-specific accessories . . . . . . . . . 54
8.3 Communication-specific accessories . . . . . . . . . . . . 55
8.4 Service-specific accessories . . . . . . . . . . . . . . . . . . . 55
9 Troubleshooting . . . . . . . . . . . . . . . . . 56
9.1 Troubleshooting instructions . . . . . . . . . . . . . . . . . 56
9.2 System error messages . . . . . . . . . . . . . . . . . . . . . . 57
9.3 Process error messages . . . . . . . . . . . . . . . . . . . . . . 60
9.4 Process errors without messages . . . . . . . . . . . . . . 61
9.5 Response of outputs to errors . . . . . . . . . . . . . . . . . 62
9.6 Spare parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
9.6.1 Removing and installing printed
circuit boards . . . . . . . . . . . . . . . . . . . . . . . 64
9.6.2 Replacing the device fuse . . . . . . . . . . . . . . 68
9.7 Return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
9.8 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
9.9 Software history . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Proline Promass 80 Table of contents
4Endress+Hauser
10 Technical data . . . . . . . . . . . . . . . . . . . 71
10.1 Technical data at a glance . . . . . . . . . . . . . . . . . . . 71
10.1.1 Applications . . . . . . . . . . . . . . . . . . . . . . . . 71
10.1.2 Function and system design . . . . . . . . . . . . 71
10.1.3 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
10.1.4 Output . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
10.1.5 Power supply . . . . . . . . . . . . . . . . . . . . . . . 75
10.1.6 Performance characteristics . . . . . . . . . . . . 76
10.1.7 Operating conditions: Installation . . . . . . . . 93
10.1.8 Operating conditions: Environment . . . . . . 93
10.1.9 Operating conditions: Process . . . . . . . . . . 94
10.1.10 Mechanical construction . . . . . . . . . . . . . 103
10.1.11 Human interface . . . . . . . . . . . . . . . . . . . 108
10.1.12 Certificates and approvals . . . . . . . . . . . . 108
10.1.13 Ordering information . . . . . . . . . . . . . . . 109
10.1.14 Accessories . . . . . . . . . . . . . . . . . . . . . . . 109
10.1.15 Documentation . . . . . . . . . . . . . . . . . . . 109
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Proline Promass 80 Safety instructions
Endress+Hauser 5
1 Safety instructions
1.1 Designated use
The measuring device described in these Operating Instructions is to be used only for measuring the
mass flow rate of liquids and gases. At the same time, the system also measures fluid density and
fluid temperature. These parameters are then used to calculate other variables such as volume flow.
Fluids with widely differing properties can be measured.
Examples:
• Chocolate, condensed milk, liquid sugar
• Oils, fats
• Acids, alkalis, lacquers, paints, solvents and cleaning agents
• Pharmaceuticals, catalysts, inhibitors
• Suspensions
• Gases, liquefied gases etc.
The operational safety of the measuring devices cannot be guaranteed if the system is used
incorrectly or used for purposes other than those intended. The manufacturer accepts no liability for
damages being produced from this.
1.2 Installation, commissioning and operation
Note the following points:
• Installation, connection to the electricity supply, commissioning and maintenance of the device
must be carried out by trained, qualified specialists authorized to perform such work by the
facility's owner operator. Qualified personnel must have read and understood these Operating
Instructions and must follow the instructions contained therein.
• The device may be operated only by persons authorized and trained by the facility's owner-
operator. Strict compliance with the instructions in the Operating Instructions is mandatory.
• Endress+Hauser is willing to assist in clarifying the chemical resistance properties of parts wetted
by special fluids, including fluids used for cleaning. However, small changes in temperature,
concentration or the degree of contamination in the process can result in changes of the chemical
resistance properties. Therefore, Endress+Hauser can not guarantee or accept liability for the
chemical resistance properties of the fluid wetted materials in a specific application. The user is
responsible for the choice of fluid wetted materials in regards to their in-process resistance to
corrosion.
• If carrying out welding work on the piping, never ground the welding unit by means of the
measuring device.
• The installer must ensure that the measuring system is correctly wired in accordance with the
wiring diagrams. The transmitter must be earthed unless special protection measures have been
taken e.g. galvanically isolated power supply SELV or PELV (SELV = Save Extra Low Voltage;
PELV = Protective Extra Low Voltage).
• Invariably, local regulations governing the opening and repair of electrical devices apply.

Safety instructions Proline Promass 80
6Endress+Hauser
1.3 Operational safety
Note the following points:
• Measuring systems for use in hazardous environments are accompanied by separate "Ex
documentation", which is an integral part of these Operating Instructions. Strict compliance with
the installation instructions and ratings as stated in this supplementary documentation is
mandatory.
The symbol on the front of this supplementary Ex documentation indicates the approval and the
certification body i.e. 0Europe, 2USA, 1Canada.
• The measuring device complies with the general safety requirements in accordance with
EN 61010-1, the EMC requirements of IEC/EN 61326, the NAMUR recommendation NE 21,
NE 43 and NE 53.
• External surface temperature of the transmitter can increase by 10 K due to power consumption
of internal electronical components. Hot process fluids passing through the measuring device will
further increase the surface temperature of the measuring device. Especially the surface of the
sensor can reach temperatures which are close to process temperature. Additionally safety
precautions are required when increased process temperatures are present.
• For measuring systems used in SIL 2 applications, the separate manual on functional safety must
be observed.
• The manufacturer reserves the right to modify technical data without prior notice. Your
Endress+Hauser distributor will supply you with current information and updates to these
Operating Instructions.
1.4 Return
• Do not return a measuring device if you are not absolutely certain that all traces of hazardous
substances have been removed, e.g. substances which have penetrated crevices or diffused
through plastic.
• Costs incurred for waste disposal and injury (burns, etc.) due to inadequate cleaning will be
charged to the owner-operator.
• Please note the measures on ä69
1.5 Notes on safety conventions and icons
The devices are designed to meet state-of-the-art safety requirements, have been tested, and left the
factory in a condition in which they are safe to operate. The devices comply with the applicable
standards and regulations in accordance with EN 61010-1 "Protection Measures for Electrical
Equipment for Measurement, Control, Regulation and Laboratory Procedures". However, the
devices can be a source of danger if used incorrectly or for other than the designated use.
Consequently, always pay particular attention to the safety instructions indicated in these Operating
Instructions by the following icons:
#Warning!
"Warning" indicates an action or procedure which, if not performed correctly, can result in injury
or a safety hazard. Comply strictly with the instructions and proceed with care.
"Caution!
"Caution" indicates an action or procedure which, if not performed correctly, can result in incorrect
operation or destruction of the device. Comply strictly with the instructions.
!Note!
"Note" indicates an action or procedure which, if not performed correctly, can have an indirect
effect on operation or trigger an unexpected response on the part of the device.

Proline Promass 80 Identification
Endress+Hauser 7
2 Identification
The following options are available for identification of the measuring device::
• Nameplate specifications
• Order code with breakdown of the device features on the delivery note
• Enter serial numbers from nameplates in W@M Device Viewer
(www.endress.com/deviceviewer): All information about the measuring device is displayed.
For an overview of the scope of the Technical Documentation provided, refer to the following:
• The chapters "Documentation" ä109
•DerW@M Device Viewer: Enter the serial number from the nameplate
(www.endress.com/deviceviewer)
Reorder
The measuring device is reordered using the order code.
Extended order code:
• The device type (product root) and basic specifications (mandatory features) are always listed.
• Of the optional specifications (optional features), only the safety and approval-related
specifications are listed (e.g. LA). If other optional specifications are also ordered, these are
indicated collectively using the # placeholder symbol (e.g. #LA#).
• If the ordered optional specifications do not include any safety and approval-related specifications,
they are indicated by the + placeholder symbol (e.g. 8E2B50-ABCDE+).
2.1 Device designation
The "Promass 80" flow measuring system consists of the following components:
• Promass 80 transmitter
• Promass F, Promass E, Promass A, Promass H, Promass I, Promass S or Promass P sensor.
Two versions are available:
• Compact version: transmitter and sensor form a single mechanical unit.
• Remote version: transmitter and sensor are installed separately.

Identification Proline Promass 80
8Endress+Hauser
2.1.1 Nameplate of the transmitter
A0015928
Fig. 1: Example of a transmitter nameplate
1 Name of the transmitter
2 Order code
3 Serial number (Ser. no.)
4 Extended order code (Ext. ord. cd.)
5 Power supply, frequency and power consumption
6 Additional function and software
7 Available inputs / outputs
8Reservedforinformation on special products
9 Please refer to operating instructions / documentation
10 Reserved for certificates, approvals and for additional information on device version
11 Patents
12 Degree of protection
13 Ambient temperature range
Order Code:
Ser. no.:
Ext. ord. cd.:
i
1
5
6
7
8
234
10 11
13
12
9

Proline Promass 80 Identification
Endress+Hauser 9
2.1.2 Nameplate of the sensor
A0015930
Fig. 2: Example of a sensor nameplate
1 Name of the sensor
2 Order code
3 Serial number (Ser. no.)
4 Extended order code (Ext. ord. cd.)
5 Calibration factor with zero point (K-factor)
6 Nominal diameter device (Size)
7 Flange nominal diameter/Nominal pressure
8 Material of measuring tubes (Materials)
9 Max. fluid temperature (Tm)
10 Pressure range of secondary containment
11 Accuracy of density measurement (Density cal.)
12 Additional information
13 Reserved for information on special products
14 Ambient temperature range
15 Degree of protection
16 Please refer to operating instructions / documentation
17 Reserved for additional information on device version (approvals, certificates)
18 Patents
19 Flow direction
i
14
16
17
18
1
9
11
19
10
15
13
12
8
6
7
Size:
K-factor:
Tm:
Materials:
Density cal.:
Ser.No.:
Order Code:
5
4
3
2
Ext. ord. cd.:

Identification Proline Promass 80
10 Endress+Hauser
2.1.3 Nameplate for connections
A0015931
Fig. 3: Example of a connection nameplate
1 Serial number (Ser. no.)
2 Possible inputs and outputs
3 Signals present at inputs and outputs
4 Possible configuration of current output
5 Possible configuration of relay contacts
6 Terminal assignment, cable for power supply
7 Terminal assignment and configuration (see point 4 and 5) of inputs and outputs
8 Version of device software currently installed (Device SW)
9 Installed communication type (Communication)
10 Information on current communication software (Drivers: Device Revision and Device Description),
11 Date of installation (Date)
12 Current updates to data specified in points 8 to 11 (Update1, Update 2)
4
7
2
3
8 1210 11
1
9
6
26(+) / 27(-)
NC:
Versorgung /
Tension d'alimentation
Observer manuel d'instruction
See operating manual
Betriebsanleitung beachten
Communication:
Drivers:
Device SW:
Ser.No.:
Supply /
24(+) / 25(-)
22(+) / 23(-)
20(+) / 21(-)
N/L-
PE
A:
NO:
P:
L1/L+
12
319475-00XX
active
passive
normally open contact
normally closed contact
Date:
Update 1
ex works / ab Werk / réglages usine Update 2
5

Proline Promass 80 Identification
Endress+Hauser 11
2.2 Certificates and approvals
The devices are designed in accordance with good engineering practice to meet state-of-the-art
safety requirements, have been tested, and left the factory in a condition in which they are safe to
operate. The devices comply with the applicable standards and regulations in accordance with
EN 61010-1 "Protection Measures for Electrical Equipment for Measurement, Control, Regulation
and Laboratory Procedures" and with the EMC requirements of IEC/EN 61326.
The measuring system described in these Operating Instructions thus complies with the statutory
requirements of the EC Directives. Endress+Hauser confirms successful testing of the device by
affixing to it the CE mark.
The measuring system is in conformity with the EMC requirements of the "Australian
Communications and Media Authority (ACMA)".
2.3 Registered trademarks
KALREZ®and VITON®
Registered trademarks of E.I. Du Pont de Nemours & Co., Wilmington, USA
TRI–CLAMP®
Registered trademark of Ladish & Co., Inc., Kenosha, USA
SWAGELOK®
Registered trademark of Swagelok & Co., Solon, USA
HART®
Registered trademark of HART Communication Foundation, Austin, USA
HistoROM™, S-DAT®, FieldCare®Fieldcheck®, Field Xpert™, Applicator®
Registered or registration-pending trademarks of Endress+Hauser Flowtec AG, Reinach, CH

Installation Proline Promass 80
12 Endress+Hauser
3 Installation
3.1 Incoming acceptance, transport and storage
3.1.1 Incoming acceptance
On receipt of the goods, check the following points:
• Check the packaging and the contents for damage.
• Check that nothing is missing from the shipment and that the scope of supply matches your order.
3.1.2 Transport
The following instructions apply to unpacking and to transporting the device to its final location:
• Transport the devices in the containers in which they are delivered.
• The covers or caps fitted to the process connections prevent mechanical damage to the sealing
faces and the ingress of foreign matter to the measuring tube during transportation and storage.
Consequently, do not remove these covers or caps until immediately before installation.
• Do not lift measuring devices of nominal diameters > DN 40 (1 ½ ") by the transmitter housing
or the connection housing in the case of the remote version (å4). - Use webbing slings slung
round the two process connections. Do not use chains, as they could damage the housing.
#Warning!
Risk of injury if the measuring device slips.
The center of gravity of the assembled measuring device might be higher than the points around
which the slings are slung. At all times, therefore, make sure that the device does not unexpectedly
turn around its axis or slip.
a0004294
Fig. 4: Instructions for transporting sensors with > DN 40 (1 ½")

Proline Promass 80 Installation
Endress+Hauser 13
3.1.3 Storage
Note the following points:
• Pack the measuring device in such a way as to protect it reliably against impact for storage (and
transportation). The original packaging provides optimum protection.
• The permissible storage temperature is –40 to +80 °C (–40 °F to +176 °F), preferably +20 °C
(+68 °F).
• Do not remove the protective covers or caps on the process connections until you are ready to
install the device.
• The measuring device must be protected against direct sunlight during storage in order to avoid
unacceptably high surface temperatures.
3.2 Installation conditions
Note the following points:
• No special measures such as supports are necessary. External forces are absorbed by the
construction of the instrument, for example the secondary containment.
• The high oscillation frequency of the measuring tubes ensures that the correct operation of the
measuring system is not influenced by pipe vibrations.
• No special precautions need to be taken for fittings which create turbulence (valves, elbows,
T-pieces etc.), as long as no cavitation occurs.
• For mechanical reasons and in order to protect the pipe, it is advisable to support heavy sensors.
3.2.1 Dimensions
All the dimensions and lengths of the sensor and transmitter are provided in the separate
documentation entitled, "Technical Information".
3.2.2 Mounting location
Accumulated air or gas bubbles in the measuring tube can result in an increase in measuring errors.
Avoid the following mounting locations in the pipe installation:
• Highest point of a pipeline. Risk of air accumulating.
• Directly upstream of a free pipe outlet in a vertical pipeline.
a0003605
Fig. 5: Mounting location

Installation Proline Promass 80
14 Endress+Hauser
Installation in a vertical pipe
The proposed configuration in the following diagram, however, permits installation in a vertical
pipeline. Pipe restrictors or the use of an orifice plate with a smaller cross-section than the nominal
diameter prevent the sensor from running empty during measurement.
a0003597
Fig. 6: Installation in a vertical pipe (e.g. for batching applications)
1 Supply tank
2Sensor
3 Orifice plate, pipe restrictions (see Table)
4Valve
5 Batching tank
System pressure
It is important to ensure that cavitation does not occur, because it would influence the oscillation
of the measuring tube. No special measures need to be taken for fluids which have properties similar
to water under normal conditions.
In the case of liquids with a low boiling point (hydrocarbons, solvents, liquefied gases) or in suction
lines, it is important to ensure that pressure does not drop below the vapor pressure and that the
liquid does not start to boil. It is also important to ensure that the gases that occur naturally in many
liquids do not outgas. Such effects can be prevented when system pressure is sufficiently high.
Therefore, the following locations should be preferred for installation:
• Downstream from pumps (no danger of vacuum)
• At the lowest point in a vertical pipe
1
2
3
4
5
DN
Ø Orifice plate, pipe restrictor
DN
Ø Orifice plate, pipe restrictor
mm inch mm inch
1 1/24" 0.8 0.03" 40 1 ½" 22 0.87"
2 1/12" 1.5 0.06" 40 FB 1 ½" 35 1.38"
4 1/8" 3.0 0.12" 50 2" 28 1.10"
8 3/8" 6 0.24" 50 FB 2" 54 2.00"
15 1/2" 10 0.40" 80 3" 50 2.00"
15 FB 1/2" 15 0.60" 100 4" 65 2.60"
25 1" 14 0.55" 150 6" 90 3.54"
25 FB 1" 24 0.95" 250 10" 150 5.91"
FB = Full bore versions of Promass I

Proline Promass 80 Installation
Endress+Hauser 15
3.2.3 Orientation
Make sure that the direction of the arrow on the nameplate of the sensor matches the direction of
flow direction in which the fluid flows through the pipe.
Orientation Promass A
Vertical
Recommended orientation with direction of flow upwards. When fluid is not flowing, entrained
solids will sink down and gases will rise away from the measuring tube. The measuring tubes can
be completely drained and protected against solids build-up.
Horizontal
When installation is correct the transmitter housing is above or below the pipe. This means that no
gas bubbles or solids deposits can form in the bent measuring tube (single-tube system).
A0018978
Special installation instructions for Promass A
"Caution!
Risk of measuring pipe fracture if sensor installed incorrectly!
The sensor may not be installed in a pipe as a freely suspended sensor:
• Using the base plate, mount the sensor directly on the floor, the wall or the ceiling.
• Support the sensor on a firmly mounted support base (e.g. angle bracket).
Vertical
We recommend two installation versions when mounting vertically:
• Mounted directly on a wall using the base plate
• Measuring device supported on an angle bracket mounted on the wall
A0018980
Horizontal
We recommend the following installation version when mounting horizontally:
• Measuring device standing on a firm support base
A0018979
10 mm
4 x

Installation Proline Promass 80
16 Endress+Hauser
Orientation Promass F, E, H, I, S, P
Make sure that the direction of the arrow on the nameplate of the sensor matches the direction of
flow (direction in which the fluid flows through the pipe).
Vertical:
Recommended orientation with upward direction of flow (Fig. V). When fluid is not flowing,
entrained solids will sink down and gases will rise away from the measuring tube. The measuring
tubes can be completely drained and protected against solids buildup.
Horizontal (F, E):
The measuring tubes of Promass F and E must be horizontal and beside each other.
When installation is correct the transmitter housing is above or below the pipe (Fig. H1/H2).
Always avoid having the transmitter housing in the same horizontal plane as the pipe.
Horizontal (Promass H, I, S, P):
Promass H and Promass I can be installed in any orientation in a horizontal pipe run.
In order to ensure that the permissible ambient temperature range for the transmitter (ä93) is
not exceeded, we recommend the following orientations:
• For fluids with very high temperatures we recommend the horizontal orientation with the
transmitter head pointing downwards (Fig. H2) or the vertical orientation (Fig. V).
• For fluids with very low temperatures, we recommend the horizontal orientation with the
transmitter head pointing upwards (Fig. H1) or the vertical orientation (Fig. V).
Promass F, E Standard, compact Promass F, E Standard, remote Promass F High-temperature, compact Promass F High-temperature, remote Promass H, I, S, P Standard, compact Promass H, I, S, P Standard, compact
Fig. V:
Vertical
orientation
a0004572
✔✔ ✔✔ ✔✔ ✔✔ ✔✔ ✔✔
Fig. H1:
Horizontal
orientation
Transmitter head
up a0004576
✔✔ ✔✔
✘
TM > 200 °C
( 392 °F)
✔
TM > 200 °C
( 392 °F)
✔✔ ✔✔
Fig. H2:
Horizontal
orientation
Transmitter head
down a0004580
✔✔ ✔✔ ✔✔ ✔✔ ✔✔ ✔✔
Fig. H3:
Horizontal
orientation
Transmitter head
to the side a0007558
✘ ✘ ✘ ✘ ✔✔ ✔✔
✔✔ = Recommended orientation
✔= Orientation recommended in certain situations
✘= Impermissible orientation

Proline Promass 80 Installation
Endress+Hauser 17
3.2.4 Special installation instructions
Promass F, E, H, S and P
"Caution!
If the measuring tube is curved and the unit is installed horizontally, adapt the sensor position to
the fluid properties.
a0004581
Fig. 7: Horizontal installation of sensors with curved measuring tube.
1 Not suitable for fluids with entrained solids. Risk of solids accumulating.
2 Not suitable for outgassing fluids. Risk of air accumulating.
Promass I and P with Eccentric Tri-clamps
Eccentric Tri-Clamps can be used to ensure complete drainability when the sensor is installed in a
horizontal line. When lines are pitched in a specific direction and at a specific slope, gravity can be
used to achieve complete drainability. The sensor must be installed in the correct position with the
tube bend facing to the side, to ensure full drainability in the horizontal position. Markings on the
sensor show the correct mounting position to optimize drainability.
a0007396
Fig. 8: Promass P: When lines are pitched in a specific direction and at a specific slope: as per hygienic guidelines
(21 mm/m or approximatley 2%). Gravity can be used to achieve complete drainability.
1 The arrow indicates the direction of flow (direction of fluid flow through the pipe).
2 The label shows the installation orientation for horizontal drainability.
3 The underside of the process connection is indicated by a scribed line. This line indicates the lowest point of the
eccentric process connection.
12
1
2
321 mm/m (¼ in/ft) ~2%

Installation Proline Promass 80
18 Endress+Hauser
A0010011
Fig. 9: Promass I: When lines are pitched in a specific direction and at a specific slope: as per hygienic guidelines
(21 mm/m or approximatley 2%). Gravity can be used to achieve complete drainability.
1 The arrow indicates the direction of flow (direction of fluid flow through the pipe).
2 The label shows the installation orientation for horizontal drainability.
3 The underside of the process connection is indicated by a scribed line. This line indicates the lowest point of the
eccentric process connection.
Promass I and P with hygienic connections
(mounting clamp with lining between clamp and instrument)
It is not necessary to support the sensor under any circumstances for operational performance. If the
requirement exists to support the sensor the following recommendation should be followed.
A0007397
Fig. 10: Promass P, mounted with mounting clamp
EscEsc
E
-
+
1
2
3
21 mm/m ( 2%)~
0.83 in/3.28 ft ( 2%)~0.83 in/3.28 ft ( 2%)~
A
B
C
DN 815 25 40 50
A 298 402 542 750 1019
B 33 33 33 36.5 44.1
C 2828385675

Proline Promass 80 Installation
Endress+Hauser 19
A0010008
Fig. 11: Promass I, mounted with mounting clamp
3.2.5 Heating
Some fluids require suitable measures to avoid loss of heat at the sensor. Heating can be electric,
e.g. with heated elements, or by means of hot water or steam pipes made of copper or heating
jackets.
"Caution!
• Risk of electronics overheating! Make sure that the maximum permissible ambient
temperature for the transmitter is not exceeded. Consequently, make sure that the adapter
between the sensor and transmitter and the connection housing of the remote version always
remain free of insulating material. Note that a certain orientation might be required, depending
on the fluid temperature ä15.
• With a fluid temperature between 200 °C to 350 °C (392 to 662 °F) the remote version of the
high-temperature version is preferable.
• When using electrical heat tracing whose heat is regulated using phase control or by pulse packs,
it cannot be ruled out that the measured values are influenced by magnetic fields which may
occur, (i.e. at values greater than those permitted by the EC standard (Sinus 30 A/m)). In such
cases, the sensor must be magnetically shielded.
The secondary containment can be shielded with tin plates or electric sheets without privileged
direction (e.g. V330-35A) with the following properties:
– Relative magnetic permeability μr300
– Plate thickness d 0.35 mm (0.014")
• Information on permissible temperature ranges ä94
Special heating jackets which can be ordered as accessories from Endress+Hauser are available for
the sensors.
B
C
A
DN 815 15FB 25 25FB 40 40FB 50 50FB 50FB 80 80
Tri-Clamp ½" 3/4" 1" 1" 1 ½" 1 ½" 2" 2" 2 ½" 3" 2 ½" 3"
A 373 409 539 539 668 668 780 780 1152 1152 1152 1152
B 202030302828353557575757
C 404044.544.56060808090909090

Installation Proline Promass 80
20 Endress+Hauser
3.2.6 Thermal insulation
Some fluids require suitable measures to avoid loss of heat at the sensor. A wide range of materials
can be used to provide the required thermal insulation.
a0004614
Fig. 12: In the case of the Promass F high-temperature version, a maximum insulation thickness of 60 mm (2.4") must
be observed in the area of the electronics/neck.
If the Promass F high-temperature version is installed horizontally (with transmitter head pointing
upwards), an insulation thickness of min. 10 mm (0.4") is recommended to reduce convection. The
maximum insulation thickness of 60 mm (2.4") must be observed.
3.2.7 Inlet and outlet runs
There are no installation requirements regarding inlet and outlet runs. If possible, install the sensor
well clear of fittings such as valves, T-pieces, elbows, etc.
3.2.8 Vibrations
The high oscillation frequency of the measuring tubes ensures that the correct operation of the
measuring system is not influenced by pipe vibrations. Consequently, the sensors require no special
measures for attachment.
3.2.9 Limiting flow
Relevant information can be found in the "Technical Data" section under Measuring range ä71
or Limiting Flow ä95.
mm (inch)
max. 60 (2.4)
Esc
E
- +
max. 60 (2.4)
