Energer ENB540DBT User manual

350W Drill Press
ENB540DBT
Barcode:5052931253630
Original Instructions_MNL_ENB540DBT_V02_111222
Warning! Read the instructions before using the product!

ENB540DBT by ENERGER
03
get started...
These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Getting started
Your product
Before you start
In more detail
Product functions
Care and maintenance
Trouble shooting
Recycling and disposal
Technical and legal information
Guarantee
EC declaration of conformity
Let's
GB
IE
03
04
05
12
18
19
24
28
30
31
32

04
Your product
Your product
１０
1. Pulley guard
2. Motor
3. Feed handles
4. Chuck guard
5. Column
6. Support lock
7. Base
8. Table
9. Chuck
10. Machine casing
11. On/off switch
12. Drill depth gauge
13. Grub screw
14. Pulley guard cross screw
15. Belt tension lock knob
13
14
15
12
GB
IE
Getting started...
ENB540DBT by ENERGER

07
Safety warnings
Technical and legal information
WARNING! When using electric tools basic safety precautions should
always be ic shock and personalfollowed to reduce the risk of fire, electr
injury including the following.
Read all these instructions before attempting to operate this product
and save these instructions.
Safe operation
1. Keep work area clear
- Cluttered areas and benches invite injuries.
2. Consider work area environment
- Do not expose tools to rain.
- Do not use tools in damp or wet locations.
- Keep work area well lit.
- Do not use tools in the presence of flammable liquids or gases.
3. Guard against electric shock
- Avoid body contact with earthed or grounded surfaces (e.g. pipes, radiators,
ranges, refrigerators).
4. Keep other persons away
- Do not let persons, especially children, not involved in the work touch the tool
or the extension cord and keep them away from the work area.
5. Store idle tools
- When not in use, tools should be stored in a dry locked-up place, out of reach
of children.
6. Do not force the tool
- It will do the job better and safer at the rate for which it was intended.
7. Use the right tool
- Do not force small tools to do the job of a heavy duty tool.
- Do not use tools for purposes not intended; for example do not use circular
saws to cut tree limbs or logs.
8. Dress properly
- Do not wear loose clothing or jewellery, they can be caught in moving parts.
- Non-skid footwear is recommended when working outdoors.
GB
IE
!
In more detail...
ENB540DBT by ENERGER

08
- Wear protective hair covering to contain long hair.
9. Use protective equipment
- Use safety glasses.
- Use face or dust mask if working operations create dust.
10.Connect dust extraction equipment
- If the tool is provided for the connection of dust extraction and collecting
equipment, ensure these are connected and properly used.
11. Do not abuse the cord
- Never yank the cord to disconnect it from the socket. Keep the cord away from
heat, oil and sharp edges.
12. Secure work
- Where possible use clamps or a vice to hold the work. It is safer than using
your hand.
13. Do not overreach
- Keep proper footing and balance at all times.
14. Maintain tools with care
- Keep cutting tools sharp and clean for better and safer performance.
- Follow instruction for lubricating and changing accessories.
- Inspect tool cords periodically and if damaged have them repaired by an
authorized service facility.
- Inspect extension cords periodically and replace if damaged.
- Keep handles dry, clean and free from oil and grease.
15. Disconnect tools
- When not in use, before servicing and when changing accessories such as
blades, bits and cutters, disconnect tools from the power supply.
16. Remove adjusting keys and wrenches
- Form the habit of checking to see that keys and adjusting wrenches are
removed from the tool before turning it on.
17. Avoid unintentional starting
- Ensure switch is in "off" position when plugging in.
18. Use outdoor extension leads
- When the tool is used outdoors, use only extension cords intended for outdoor
use and so marked.
Technical and legal information
GB
IE
In more detail...
ENB540DBT by ENERGER

09
19. Stay alert
- Watch what you are doing, use common sense and do not operate the tool
when you are tired.
20. Check damaged parts
- Before further use of tool, it shoul d be carefully checked to determine that it
will operate properly and perform its intended function.
- Check for alignment of moving parts, binding of moving parts, breakage of
parts, mounting and any other conditions that may affect its operation.
- A guard or other part that is damaged should be properly repaired or replaced
by an authorized service centre unless otherwise indicated in this instruction
manual.
- Have defective switches replaced by an authorized service centre.
- Do not use the tool if the switch does not turn it on and off.
21. Warning
- The use of any accessory or attachment other than one recommended in this
instruction manual may present a risk of personal injury.
22. Have your tool repaired by a qualified person
- This electric tool complies with t he relevant safety rules. Repairs should only
be carried out by qualified persons using original spare parts, otherwise this may
result in considerable danger to the user.
ADDITIONAL SAFETY RULES FOR BENCH DRILL PRESS
- This machine must be firmly secured to a suitable workbench or other stable
work surface. When selecting a suitable location for mounting this machine
consideration must be given to the maximum length of the material to be drilled or
machined and the position of the operator.
- Before starting the machine ensure that drills and other recommended cutting
tools are fitted correctly and that all the securing bolts are tight. Check all
guards are fitted and operating correctly and that the chuck key and any other
adjustment tools have been removed.
- Keep hands well away from rotating drills and other cutting tools at all times.
- When drilling use the correct cutting lubricant /coolant for the material being
drilled. Use only sufficient to prevent the drill from overheating and make sure that
Technical and legal information
GB
IE
In more detail...
!
Warning!
Ensure that power tools are disconnected from the mains supply when
not in use, making adjustments andbefore servicing, lubricating or
when changing accessories such as blades, bits and cutters.
ENB540DBT by ENERGER

10
it is kept well away from electrical components. Never use water as a coolant.
Keep drills and other cutters sharp and in good condition. This will improve cutting
and reduce the load on the machine ensuring a longer life of the cutting tools
and the machine.
- Use only drill bits, cutters and other accessories recommended by the
manufacturer. Select the correct spindle speed for the size of drill being used.
See the instruction manual. Do not attempt to modify the machine or its
accessories in any way.
- Do not force the machine, let the machine do the work. This will reduce the
wear on the machine and cutter and increase its efficiency and operating life.
- Use approved safety glasses or goggles at all times, and a face mask and ear
defenders when using for prolonged periods.
- When drilling long lengths of material ensure that there is adequate support at
both ends of the material.
Never use the machine without the safety guards in position and operating
correctly.
- When drilling wood and wood type materials, ensure that the work piece is free
from any nails or other foreign objects that could damage the drills and other
cutting tools.
- Always secure the workpiece in a suitable drill vice.
- Never try and secure the workpiece with your hands.
- Be aware that swarf can be very sharp and hot and can fly off the rotating drill.
When handling swarf always wear suitable gloves. Swarf should not be
disposed of with domestic waste, it should be disposed of at a recycling centre.
- Never leave the machine running while unattended. If you are interrupted when
operating the drill, complete the process and switch off before looking up.
- Always allow the machine to come to a complete stop and disconnect from the
power supply before leaving the unit unattended.
- Never use your hands to remove dust, chips or waste close by the drill bit.
Even when the tool is used as prescribed it is not possible to eliminate all residual
risk factors. The following hazards may arise in connection with the ｔｏｏｌ抯
construction and design:
- Contact with the drill bit.
- Kickback of work piece and parts of workpiece.
- Bit fracture.
Technical and legal information
GB
IE
In more detail...
ENB540DBT by ENERGER

11
- Catapulting of bit pieces.
- Damage to hearing if effective ear defenders are not worn.
- Damage to lungs if effective breathing protection is not worn in operations in
which dust is produced.
- Damage to sight if effective eye protection is not worn.
Wear goggles
Wear ear defenders
Wear a breathing mask
Technical and legal information
GB
IE
In more detail...
ENB540DBT by ENERGER

13
Fitting the column
Align the three threaded holes on the
base plate(7) with the column(5) support holes.
Secure with the three bolts.
Do not over tighten as this could crack the cast
base plate(7) and column(5)
support(Fig.3).
Fitting the table
Lower the table assembly onto the column(5). The
assembly will slide easily into position so do not use
O
force. Make sure the table assembly will rotate 360
Tighten the support lock to secure the table assembly
into position .(Fig.4)
Before you start
Fig.3
Fig.4
GB
IE
Mounting the base plate
Select a suitable location for the drill on a
workbench. Be aware of table legs and
anything which might reduce access to
the underneath of the workbench. A suitable
mains supply socket must also be accessible
for the plug. Locate the base plate(7) in the
selected position. Select two suitable length
bolts, washers and nuts (not supplied).
Using the base plate as a template drill(7)
two holes through the workbench.Bolt
the base plate to the bench. Do not over(7)
tighten as this could crack the cast base plate .(Fig.2)
Fig.2
Getting started...
ENB540DBT by ENERGER
7
5
5
8
6

GB
IE
14
Fitting the head stock and motor
Locate the two grub screws in the side of the
head stock and motor assembly. Using a
hexagonal key slacken the two grub screws.
Lift the head stock and motor assembly and
lower it onto the column(. Make sure that it
slides down and locates fully on the column.
Position the head stock and motor assembly
ensuring it is aligned with the base plate(7).
Tighten the two grub screws to secure the
head stock and motor assembly into place(Fig.5).
Retain the hexagonal keys for future adjustments.
Fitting the hand feed handles
Locate and install the three hand feed handles(3).
Simply screw the handles into the three(3)
threaded holes located in the feed shaft boss.
Make sure that all three handles are tight .(3) (Fig.6)
Fitting the chuck guard
without the chuck guard(4) fitted.
The telescopic chuck guard is partially(4)
assembled onto the machine.
Remove three cross head screws just
below the hinge on the red collar.
Position the transparence plastic shield into the
red collar and secure in place with the three
small cross head screws . The chuck(Fig.7-1)
guard(4) is spring loaded and on a hinge which
allows the guard to be moved upwards to(4)
expose the chuck for drill installation and(9)
Warning:never attempt to use the machine
Before you start
Fig.5
13
Fig.6
Fig.7-1
Fig.7-2
Getting started...
ENB540DBT by ENERGER
3

15
removal. Always return the guard(4) to cover rotating parts. Simply unscrew the
wing nuts and the two piece guard will extend vertically up or down. Chuck
guard(4) is adjustable to varying depths to give more protection(Fig.7-2).
Fitting the drill depth gauge
Remove the red pointer and uscrew M6
Nut from the bar. Insert the bar into the
hole and the hole guard(4),located in chuck
Fitting the 3 jaw chuck
This machine is supplied with a Morse taper
stub shaft fitted into the spindle. To fit the
chuck(9), clean the protective film from the
chuck internal taper and the stub shaft(9)
external taper with white spirit. Place the
chuck onto the exposed stub shaft. Place(9)
a piece of wood onto the drill table. Using the
feed handles(3) lower the chuck onto the(9)
wood.Gently apply pressure to engage the
taper and then let the spindle raise to its
upper position .(Fig.9)
The drill is now fully assembled and secured
in position. The following adjustments and
setting up instruction must be carried out
before connecting the machine to the mains
supply.
Before you start
then screw the nut, assemble the red
pointer in the spindle(Fig.8).
GB
IE
Fig.8
Fig.9
Fig.10
Getting started...
ENB540DBT by ENERGER
9

17
Safety
Check that you have noted all the following instructions:
Before starting you must have fully read and understood
the entire instruction manual.
Working with this product is demanding; therefore ensure
you are physically and mentally fit to complete the job
safely.
Ensure that you have all the accessories and tools needed
for assembly and operation.
Make sure that you wear suitable personal protective
equipment.
Ensure that no unauthorised people, especially children,
and pets are nearby or could enter the working area.
Ensure that the product is free from damage and that it is
not worn.
Make sure that safety devices and accessories are
correctly fixed.
Double check that all assembly tools have been removed
from the product before use.
Undertake periodic structural checks of this product; do not
use it if you have any doubts about its suitability for its
intended purpose.
WARNING! For your own and the safety of other people you must
read and follow the safety instructions in section “In more detail -
Technical and legal information - Safety warnings”.
GB
IE
Getting started...
ENB540DBT by ENERGER

18
In more detail
In more detail...
GB
IE
Product functions
Care and maintenance
Trouble shooting
Recycling and disposal
Guarantee
EC declaration of conformity
19
24
28
30
31
32
ENB540DBT by ENERGER

19
Product functions
Intended use
This drill press ENB540DBT is designated with a rated input of 350 Watts. This
product is used to drill holes in metal and wood.
The product should not be used on masonry and materials that are harmful to
health.
This product is intended for private domestic use only, not for any commercial
trade use. It must not be used for any purposes other than those described.
GB
IE
In more detail...
ENB540DBT by ENERGER
Adjusting the table height
To adjust the table height, slacken the(8)
support lock(6) at the rear of the table
support assembly.Raise table(8) up or down to
desired height. When the desired height has
been achieved, do not forget to re-secure the
support lock(Fig.11).
o
Work table swing 360
o
The table may also be swung through 180 either way to allow larger workpieces(8)
to be accommodated on the base plate. Simply unclamp the table and manoeuvre
either clockwise or anti-clockwise to the rear of the machine.
Fig.11
Tilting the table ±45°
Locate the securing bolt underneath the
table(8). With a suitable socket loosen the bolt.
On the table support assembly casting there
o
is a graduated 0 - 45 scale. Set the table to(8)
the required angle and retighten the bolt.
Note: The graduated scale is for guidance
only we recommend the use of an engineers
protractor when setting any angles. Fig.12
8
6

Using a machine vice(vice not supplied)
WARNING: The drill should never be used
without the work piece being securely held in
a machine vice or clamped directly to the drill
table . The drill table is designed to accept a(8) (8)
variety of machine vice which can be fastened
directly to the drill table . Always secure the(8)
vice to the table with bolts, washers and nuts.(8)
If the drill jams into the work piece an
unsecured machine vice will spin out of
control causing the drill to snap and possibly
injure the operator .(Fig.13)
Fig.13
Using the 3 jaw chuck
Select the drill bit required. Open the jaws and
insert the drill shank centrally into the chuck(9).
Rotate the chuck by hand until the jaws(9) grip
the drill bit. The chuck has three holes(9)
around the chuck body. Locate the chuck key
and using an even torque move from each
hole location until all three holes have been
covered. Continue with the steady torque
until tight. Do not over tighten otherwise you
will have difficulty removing the drill bit .(Fig.14)
Note: remove the chuck key before use.
Different drill bits and chisels can be used with this product depending
on the workpiece material and application required.
Fig.14
WARNING! Always use drill bits according to the intended use!
For example, never use a drill bit intended for working on wood for
working on stone or vice versa!
Observe the technical requirements of this product (see section
“Technical specifications＂）when purchasing and using drill bits!
Some drill bits are very sharp and become hot during use!
Handle them carefully! Wear safety gloves when handling drill bits in
order to avoid injuries like burns and cuts!
In more detail...
GB
IE Product functions
ENB540DBT by ENERGER
20
