Energy Connoisseur CC-10 User manual

CC-10
SPECIFICATIONS CC10
Speaker System 2.5-way center, magnetically shielded bass reex
with rear-ring port
Frequency Response (+/- 3dB) 60Hz - 20kHz
Tweeter 1-inch (25.4mm) hyperbolic aluminum-dome
Woofers 2 x 5.5-inch (140mm) w/Ribbed Elliptical
Surrounds
Crossover Point(s) 2.6kHz, 1.8kHz
Eciency (Room) 92dB
Impedance 4 Ohms min./8 Ohms nominal
Recommended Amp. Power 20-200 W /channel
Dimensions H x W x D 7.1 x 19.7 x 9.9 inches
18 x 50 x 25.2cm
Units/Carton 1
Product Weight (Single) 17.4 lbs / 7.9 kg
Packed Weight 20.5 lbs / 9.3 kg
Inputs Gold plated 5-way binding posts
Finish High gloss black bae with black ash cabinet
Included Accessories Manual, port plugs, rubber bumpers
All specifications are subject to change without notice.©2008
www.energy-speakers.com
Attractive center channel speaker with black ash cabinet
High gloss black bae, oating grille add to dramatic appearance
Convergent Source Module
Tweeter and woofer in proximity act as single source to increase
dispersion
Crisp 1-inch hyperbolic aluminum dome tweeter
Clear, accurate highs add detail to your listening
Two powerful 5.5-inch woofers with Ribbed Elliptical Surround
Deliver tight, distortion-free low-frequency response
Gold-plated 5-way binding posts
Ensure reliable connection for high-quality sound
Proven bass reex design with rear ring port
Provides outstanding bass extension; deep-reaching performance
All Energy brand components were developed with these sonic
principles in mind:
• Flat On-Axis Frequency Response with Wide Bandwidth
Speakers should reproduce the entire audio range in a uniform
manner. By ensuring that no one frequency dominates any other,
Energy ensures that every note is the way it was intended to be—and
the sound is as natural as possible.
• Wide and Constant Dispersion
Sound at all frequencies radiating from the speaker should be in an
even pattern, in all directions throughout the room.
• Low Distortion and Resonance
No speaker system is totally distortion- or resonance-free, but Energy
has achieved a signicantly lower distortion level—a clearly audible
improvement.
