CF-30
SPECIFICATIONS CF30
Speaker System 2.5-way oorstanding, magnetically shielded bass
reex with front-ring port
Frequency Response (+/- 3dB) 43Hz - 20kHz
Tweeter 1-inch (25.4mm) hyperbolic aluminum dome
Woofers 2 x 5.5-inch (140mm) w/Ribbed Elliptical
Surrounds
Crossover Point(s) 2kHz, 1.6kHz
Eciency (Room) 90dB
Impedance 4 Ohms min./8 Ohms nominal
Recommended Amp. Power 20-200 W /channel
Dimensions H x W x D
including feet
36 x 7.1 x 12.3 inches
91.5 x 18 x 31.3 cm
Units/Carton 1
Product Weight (Single) 30.8 lbs / 14 kg
Packed Weight 36.2 lbs / 16.4 kg
Inputs Dual gold plated 5-way binding posts
Finish High gloss black bae with black ash cabinet
Included Accessories Manual, port plug
All specifications are subject to change without notice.©2008
www.energy-speakers.com
Compact oorstanding speaker with attractive black ash cabinet
High gloss black bae, oating grille add to dramatic appearance
Convergent Source Module
Tweeter and woofer in proximity act as single source to increase
dispersion
1-inch hyperbolic aluminum dome tweeter
For clear, accurate highs that add detail to your listening
Two booming 5.5-inch woofers with Ribbed Elliptical Surround
Deliver tight and powerful distortion-free low-frequency response
Dual gold-plated 5-way binding posts
Ensure reliable connection for high-quality sound; bi-wire, bi-amp
enabled
Proven bass reex design with front ring port
Provides outstanding bass extension; deep-reaching performance
All Energy brand components were developed with these sonic
principles in mind:
• Flat On-Axis Frequency Response with Wide Bandwidth
Speakers should reproduce the entire audio range in a uniform
manner. By ensuring that no one frequency dominates any other,
Energy ensures that every note is the way it was intended to be—and
the sound is as natural as possible.
• Wide and Constant Dispersion
Sound at all frequencies radiating from the speaker should be in an
even pattern, in all directions throughout the room.
• Low Distortion and Resonance
No speaker system is totally distortion- or resonance-free, but Energy
has achieved a signicantly lower distortion level—a clearly audible
improvement.
