Enerpac MLSF3 User manual

Document Number: L4535
Document Revision: B
Document Revision Date: JUN-2022
Document Language: ENGLISH EN
Operation and Maintenance Manual
MLSF, MLSD, MLSR
Enerpac Load Skates
To reduce the risk of injury, user must read and understand this document before use.

L4535_b 1
ABOUT US
Enerpac is a global market leader in high pressure
hydraulic tools, controlled force products, portable
machining, on-site services and solutions for precise
positioning of heavy loads. As a leading innovator with a
110-year legacy, Enerpac has helped move and maintain
some of the largest structures on earth. When safety and
precision matters, elite professionals in industries such as
aerospace, infrastructure, manufacturing, mining, oil & gas
and power generation rely on Enerpac for quality tools,
services and solutions. For additional information, visit
www.enerpac.com.
WARRANTY
Refer to the Enerpac Global Warranty document for terms and conditions of the product warranty. Such warranty
information can be found at www.enerpac.com.
NAMEPLATE
AVAILABLE LANGUAGES
L4535 is available in the following languages, visit www.enerpac.com for a copy.
• Weitere Sprachen finden Sie unter www.enerpac.com.
• Para otros idiomas visite www.enerpac.com.
• Muunkieliset versiot ovat osoitteessa www.enerpac.com.
• Pour toutes les autres langues, rendez-vous sur www.enerpac.com.
• Per altre lingue visitate il sito www.enerpac.com.
•その他の言語は www.enerpac.com でご覧 いた だ けます。
•이 지침 시트의 다른 언어 버전은 www.enerpac.com.
• Ga voor de overige talen naar www.enerpac.com.
• For alle andre språk henviser vi til www.enerpac.com.
• Inne wersje językowe można znaleźć na stronie www.enerpac.com.
• Para outros idiomas consulte www.enerpac.com.
• Информацию на других языках вы найдете на сайте www.enerpac.com.
• För andra språk, besök www.enerpac.com.
•如需其他语言，请前往www.enerpac.com.
www.enerpac.com
Made in Germany
WEIGHT 14 kg | 30.8 lbs
SPEED 2 km/h | 1.25 mph
MAX CAP 3,000 kg | 6,614 lbs
MLSF-3
ENERPAC TOOL GROUP CORP
N86 W12500 Westbrook Crossing
Menomonee Falls, WI 53051, USA
www.facebook.com/enerpac
www.youtube.com/enerpac
www.linkedin.com/company/enerpac
www.twitter.com/enerpac

2L4535_b
Contents
1. SAFETY.......................................................................................................................................................... 3
1.1 SAFETY PRECAUTIONS ...................................................................................................................... 3
2. COMPLIANCE STATEMENT......................................................................................................................... 4
2.1 EU DECLARATION OF CONFORMITY ............................................................................................... 4
3. FEATURES & COMPONENTS ...................................................................................................................... 5
3.1 MLSF FEATURES DIAGRAM................................................................................................................ 5
3.2 MLSD FEATURES DIAGRAM ............................................................................................................... 6
3.3 MLSR FEATURES DIAGRAM ............................................................................................................... 7
4. TECHNICAL PRODUCT DATA...................................................................................................................... 8
4.1 MLSF LOAD SKATE .............................................................................................................................. 8
4.2 MLSD LOAD SKATE ............................................................................................................................. 9
4.3 MLSR LOAD SKATE ........................................................................................................................... 10
4.4 CONNECTING BARS .......................................................................................................................... 11
4.5 HANDLES ........................................................................................................................................... 11
4.6 AVAILABLE SETS ................................................................................................................................ 11
5. OPERATION................................................................................................................................................. 11
5.1 PLACING LOAD ON SKATES ............................................................................................................. 11
5.2 MOVING THE LOAD............................................................................................................................ 12
5.3 REMOVING THE LOAD ...................................................................................................................... 13
6. STORAGE & MAINTENANCE ..................................................................................................................... 13
7. SERVICE PARTS LIST................................................................................................................................. 14
7.1 MLSF EXPLODED VIEW ..................................................................................................................... 14
7.2 MLSD EXPLODED VIEW..................................................................................................................... 15
7.3 MLSR EXPLODED VIEW..................................................................................................................... 16
8. TROUBLESHOOTING ................................................................................................................................. 17

L4535_b 3
1. Safety
1.1 Safety Precautions
Failure to observe and comply with the following
precautions could result in death or serious personal
injury. Property damage could also occur.
• Always wear protective head-wear, ear protectors,
footwear and gloves (at a minimum rigger type
gloves) suitable for safe operation of the tool.
The protective clothing must not interfere with
safe operation of the tool or restrict the ability to
communicate with co-workers.
• Be sure your workplace is safe. Follow the
instructions in your workplace’s standard
operating procedures and be sure to observe all
communicated safety precautions.
• Before placing the device into operation, check that
all components (including protective equipment)
are securely attached. Be sure that all bolts and
other fasteners are properly tightened. Verify that
all moving parts operate smoothly.
• Read and completely understand the safety
precautions and instructions in this manual before
operating the load skates. Always follow all the
safety precautions and instructions, including
those that are contained within the procedures of
this manual
• Do not use the device if you are tired, ill, under the
influence of drugs, alcoholic drinks, or medications
• Even when the device is used properly and all
safety guidelines are followed, understand that
some residual risks may remain.
• Abide by all the safety instructions and precautions
stated in this manual. Act responsively toward
others when using the device.
• Be sure the operator has completed safety induction
training, specific to the work surroundings. The
operator should be thoroughly familiar with the
controls and the proper use of the tool.
• The operator must be of at least the minimum age
required by applicable local regulations, laws and
the facility standard operating procedures.
• Do not overload the equipment. Never attempt to
move a load weighing more than the capacity of
the load skates. Over loading causes equipment
failure and possible personal injury.
• Ensure the skate/load setup is stable before
moving the load.
• While the load is positioned on the skates, no
person is to be on the load and must maintain a
minimum of 5 ft (1.5 m) from the load to avoid injury.
Staying under lifted load is strictly prohibited.
• Keep hands away from load skate wheels to avoid
injury. This especially applies while the load is on
the skates, but also as a general guideline to avoid
risk of injury even when the skates are unloaded
and stationary.
• Verify the floor can successfully support the load
WARNING
Read all instructions carefully. Follow all recommended
safety precautions to avoid personal injury as well
as damage to the product and / or damage to other
property. Enerpac cannot be responsible for any
damage or injury from unsafe use, lack of maintenance,
or incorrect operation. Do not remove warning labels,
tags, or decals. In the event that any questions or
concerns arise, contact Enerpac or a local Enerpac
distributor for clarification.
Save these instructions for future use.
If you have never been trained on high-pressure
hydraulic safety, consult your distributor or service
center for information about Enerpac Hydraulic Safety
Courses.
This manual follows a system of safety alert symbols,
signals, words, and safety messages to warn the user of
specific hazards. Failure to comply with these warnings
could result in death or serious personal injury, as well
as damage to the equipment or other property.
The Safety Alert Symbol appears throughout
this manual. It is used to alert you to potential
physical injury hazards. Pay close attention
to Safety Alert Symbols and obey all safety
messages that follow this symbol to avoid the possibility
of death or serious injury.
Safety Alert Symbols are used in conjunction with certain
Signal Words that call attention to safety messages or
property damage messages and designate a degree or
level of hazard seriousness. The Signal Words used in
this manual are DANGER, WARNING, CAUTION, and
NOTICE.
Indicates a hazardous situation that, if not
avoided, will result in death or serious personal injury.
Indicates a hazardous situation that, if not
avoided, could result in death or serious personal injury.
Indicates a hazardous situation that, if not
avoided, could result in minor or moderate personal
injury.
Indicates information considered
important, but not hazard related (e.g. messages related
to property damage). Please note that the Safety Alert
Symbol will not be used with the signal word.
DANGER
WARNING
CAUTION
NOTICE

4L4535_b
capacity and provides a flat, level surface. Failure
to do so can result in damage to the floor, the
skates, or cause the load to tip.
• Do not use the load skates on inclines, uneven floor
surfaces, near floor edge drop offs, over stairs, or
over gaps in the floor exceeding 0.4 in (1.0 cm) in
width.
• Do not use the load skates if the load pad is
damaged or slick with oil. This could result in the
load unintentionally shifting.
• No person is to be present in between the wall and
the load being moved.
• Do not use the load skates if the wheels appear to
be deformed or damaged.
• Do not push the load with the load skate handle.
Failure to observe and comply with the following
precautions could result in minor or moderate
personal injury. Property damage could also occur.
• Do not allow people to ride on the device.
• Only start to move the load after you have ensured
that all persons have moved away from the danger
area and that the load can sit safely and stably on
the transport skate.
• When placing or moving a load from the skates, do
so in a slow controlled manner.
• Do not load the skates quickly, as this can damage
the skates.
• The loaded skate must never be left unsupervised
and can only remain in the same position for a
short period of time (PU rollers max. 15 min).
• Lowering of the load onto the skate must be
controlled and executed slowly. Excessive lowering
speed poses a safety hazard and can lead to
damage to the device.
• Secure the load to be transported so it does not
roll away or tip over.
• Do not exceed 1.25 mi/h (2.0 Km/h) when moving
the load to ensure a short stopping distance.
• Do not make abrupt changes of direction.
• Verify that the rated capacity of the load skate set
is adequate for the load to be moved. This also
applies to loads with uneven centers of gravity.
Some applications may require front and rear
skates of different capacities. This calculations
must be done prior to moving the load by the lead
person responsible.
• When moving load, verify there is vertical clearance
between both fixed and movable objects. It is best
to block off areas where unintended contact could
occur to avoid possible damage to the load or the
facility in which the load is being moved.
Failure to observe and comply with the following
precautions could result in property damage and/or
void the product warranty.
• Always use Enerpac replacement parts.
• In severe service conditions, be aware that the load
CAUTION
NOTICE
skate must be inspected, cleaned and lubricated
more frequently than normal.
• Monitor the skate and the load during all movements
so that you can react quickly if a problem arises.
• If you must overcome a gradient, use a towing
vehicle with sufficient braking force. Make sure
that the steerable transport skate is not pulled out
from under the load when pulling with the towing
vehicle, or establish a fixed connection with the
load to be transported.
• If the load skate is dropped from a significant
height, have the tool inspected and checked for
proper operation before placing it back into service.
• Always follow the inspection and maintenance
instructions contained in this manual. Perform
maintenance and inspection activities at the
specified time intervals.
• When placing a load onto the skates, evenly
distribute the load.
• When moving the load, do so in a controlled
direction and avoid non-linear travel when possible.
• When moving a load, maintain a minimum
clearance of 1.6 ft (0.5 m) to walls from the load.
• The angle of the handle when pulling the load is
not to exceed 25º from horizontal to the floor.
• Maintain a clean load path free of debris. Verify
that the load will not travel over any speed bumps
or drainage grates.
• When the MSLR skates are used, verify that the
wheels are unlocked so they can freely rotate.
• The operator is responsible for accidents or risks
to other persons.
• Do not overreach. Always maintain proper footing
and balance during use.
• Provide adequate lighting when working with the
device. Keep your work area clean and tidy.
• To avoid any uncertainties during the process, plan
your procedure before starting work.
2. Compliance
Statement
2.1 EU Declaration of Conformity
Enerpac declares that these product(s) have been tested
and conforms to applicable standards and the product(s)
are compatible to all EU and UK Requirements.
Copies of the EU Declaration as well as the UK Self-
Declaration are enclosed with each shipment.
These tools conform with
the requirements for
CE and UKCA.
•MLSF •MLSD •MLSR

L4535_b 5
3. Features & Components
3.1 MLSF Features Diagram
1. MLSF Chassis
2. Handle
3. Load Pad
4. Polyurethane (or optional Nylon) wheels
5. Wheel box
Figure 1: Major features and components of MLSF load skates
4
3
2
1
5

6L4535_b
3.2 MLSD Features Diagram
1. MLSD Chassis
2. Load Pad
3. Connecting Bar
4. Polyurethane (or optional Nylon) wheels
Figure 2: Major features and components of MLSD load skates
2
4
3
1

L4535_b 7
3.3 MLSR Features Diagram
1. MLSR Chassis
2. Wheel Box
3. Nylon Wheels
4. Load Pad
Figure 3: Major features and components of MLSR load skates
3
4
1
2

8L4535_b
4. Technical
Product Data
4.1 MLSF Load Skate
4.1.1 Dimensional Callout Art
Figure 4: MLSF load skate dimensions
4.1.2 Dimensional Table
Product A
in [mm]
W
in [mm]
L
in [mm]
D
in [mm]
H
in [mm]
MLSF3 5.8
[150]
10.4
[268]
9.3
[238]
39
[1000]
4.3
[110]
MLSF7 5.8
[150]
18.8
[483]
13.2
[339]
39
[1000]
4.3
[110]
MLSF10 6.6
[170]
30.4
[780]
20.6
[525]
45.6
[1170]
4.3
[110]
MLSF13 6.6
[170]
38.3
[982]
20.7
[528]
45.6
[1170]
4.3
[110]
MLSF17 8.6
[220]
28.2
[724]
22.1
[567]
63.8
[1620]
7.0
[180]
MLSF27 8.6
[220]
36.3
[931]
22.1
[567]
63.8
[1620]
7.0
[180]
MLSF35 9.7
[250]
45
[1142]
22.1
[567]
63.8
[1620]
7.0
[180]
4.1.3 MLSF Load Skate Description
Enerpac MLSF load skates are an ideal solution for
a wide variety of transporting applications, in which
moving high weight material in a non linear path is
required.
MLSF load skates are high load capacity carts with
different number of wheels depending on the load
capacity, which ranges from 3 to 35 tons. Integrated with
all MLSF models is an articulated handle (either manual
or towable depending on the capacity) that should be
used to pull the skate.
4.1.4 MLSF Load Skate Capabilities
Product Capacity Weight Nº. of
wheels
lbs kglbs kg
Polyurethane Wheels
MLSF3 6,614 3,000 30.8 14 4
MLSF7 13,228 6,000 57.3 26 8
MLSF10 19,842 9,000 125.6 57 12
MLSF13 26,455 12,000 149.9 68 16
MLSF17 35,274 16,000 291 132 8
MLSF27 52,911 24,000 348.3 158 12
MLSF35 70,548 32,000 432.1 196 16
Nylon Wheels *
MLSF3 8,818 4,000 30.8 14 4
MLSF7 17,637 8,000 57.3 26 8
MLSF10 26,455 12,000 1225.6 57 12
MLSF13 35,274 16,000 149.9 68 16
MLSF17 44,092 20,000 291 132 8
MLSF27 66,139 30,000 348.3 158 12
MLSF35 88,185 40,000 432.1 196 16
*NOTE: Nylon Wheels are optional.

L4535_b 9
4.2 MLSD Load Skate
4.2.1 Dimensional Callout Art
Figure 5: MLSD load skate dimension

4.2.2 Dimensional Tables
Product A1
in [mm]
A2
in [mm]
L
in [mm]
MLSD3 5.9 [150] 2.9 [75] 9.7 [246]
MLSD7 4.7 [120] 8.7 [220] 11.5 [291]
MLSD10 6.7 [170] 7.1 [180] 11.6 [295]
MLSD13 7.9 [200] 8.7 [220] 11.5 [291]
MLSD17 12.5 [318] 7.5 [190] 17.9 [456]
MLSD27 12.5 [318] 11.2 [285] 17.9 [456]
MLSD35 12.5 [318] 15.0 [382] 17.9 [456]
Product Skate Width
in [mm]
W
in [mm]
H
in [mm]
MLSD3 4.7 [120] 4.7-39.3
(120-1000) 4.3 [110]
MLSD7 8.7 [220] 16.5-43.3
(420-1100) 4.3 [110]
MLSD10 11.6 [295] 18.1-45
(460-1145) 4.3 [110]
MLSD13 15.0 [382] 22-43.1
(560-1095) 4.3 [110]
MLSD17 8.5 [216] 8.6-76.4
(220-1940) 7.0 [180]
MLSD27 12.3 [313] 12.6-76.4
(320-1940) 7.0 [180]
MLSD35 16.1 [410] 16.5-65.4
(420-1660) 7.0 [180]
4.2.3 MLSD Load Skate Description
Enerpac MLSD load skates are an ideal solution for
a wide variety of transporting applications, in which
moving high weight materials is required.
MLSD load skates are high load capacity carts
composed of two MLS single load skates joined by a
connecting bar. Their load capacity ranges from 3 to 35
tons. MLSD dual skates are typically used as trailing or
tracking skates behind an MLSF skate, usually part of
an MLSS set.
MLSD load skates come with standard polyurethane
wheels, but also nylon wheel kits will be available for
this skate
4.2.4 MLSD Load Skate Capabilities
Product Capacity Weight Nº. of
wheels
lbs kglbs kg
Polyurethane
Wheels
MLSD3 6,614 3,000 30.9 14 4
MLSD7 13,228 6,000 63.9 29 8
MLSD10 19,842 9,000 79.4 36 12
MLSD13 26,455 12,000 99.2 45 16
MLSD17 35,274 16,000 202.8 92 8
MLSD27 52,911 24,000 262.3 119 12
MLSD35 70,548 32,000 335.1 152 16
Nylon Wheels *
MLSD3 8,818 4,000 30.9 14 4
MLSD7 17,637 8,000 63.9 29 8
MLSD10 26,455 12,000 79.4 36 12
MLSD13 35,274 16,000 99.2 45 16
MLSD17 44,092 20,000 202.8 92 8
MLSD27 66,139 30,000 262.3 119 12
MLSD35 88,185 40,000 335.1 152 16
*NOTE: Nylon Wheels are optional.

10 L4535_b
4.3 MLSR Load Skate
4.3.1 Dimensional Callout
Figure 6: MLSR load skate dimensions
4.3.2 Dimensional tables
Product A
in [mm]
L
in [mm]
B
in [mm]
H
in [mm]
MLSR3 6.7 [170] 23.1 [588] 18.4 [467] 4.3 [110]
MLSR7 8.6 [220] 25.6 [650] 23 [585] 4.3 [110]
MLSR9 8.6 [220] 32.6 [829] 30.9 [786] 4.3 [110]
Product Skate width with connecting bar
in mm
MLSR3 21.3 - 76.4 540 - 1940
MLSR7 31.2 - 76.4 792 - 1940
MLSR9 36.3 - 76.4 922 - 1940
4.3.3 MLSR Load Skate Description
Enerpac MLSR load skates are an ideal solution for
a wide variety of transporting applications, in which
moving high weight material with high manoeuvrability
is required.
MLSR load skates are high load capacity carts with
different number of nylon wheels depending on the load
capacity required, which ranges from 3 to 9 tons.
WARNING
MLSR skates come standard with nylon wheels.
Polyurethane wheels have a lower capacity than
nylon wheels and should not be used unless
approved by Enerpac.
MLSR models have pivoting wheel boxes which allow
the skate to rotate 360º with minimal linear travel. The
slot situated on the front of the skate allows connecting
bars or handles to be installed.
Figure 7: MLSR locking mechanism detailed view
MLSR skates are meant to be combined as various sets
depending on the type of application.
4.3.4 MLSR Load Skate Capabilities
Product
(NY
Wheels)
Capacity Weight Nº. of
wheels
lbs kglbs kg
MLSR3 6,614 3,000 77 35 8
MLSR7 13,200 6,000 94.6 43 16
MLSR9 17,600 8,000 129.8 59 20
Locking Pin

L4535_b 11
4.4 Connecting bars
Depending on the load capacity, MLSD skate models
come standard with a connecting bar. Optional
connecting bars are available for MLSR models.
Reference Compatible
models
Length
mm in
MLSCDR MLSD3 1000 39.4
MLSCDS
MLSD17
MLSD27
MLSD35
2000 78.7
MLSCDF
MLSD7
MLSD10
MLSD13
1315 51.8
MLSCR6
MLSR3
MLSR7
MLSR9
2000 78.7
MLSCR8
MLSR3
MLSR7
MLSR9
2500 98.4
MLSCRH8*
MLSR3
MLSR7
MLSR9
2,500 98.4
*MLSCRH8 has handle joint to accept handle.
4.5 Handles
Depending on the load capacity, MLSF skate models
come standard with either a manual or towable handle
for easy maneuvering of heavy loads. Optional handles
are available for MLSR models.
Product visual Reference Compatible
models
MLSHT MLSF3
MLSF7
MLSHR MLSF10
MLSF13
MLSHF
MLSF17
MLSF27
MLSF35
MLSHRR
MLSR3
MLSR7
MLSR9
MLSHRT
MLSR3
MLSR7
MLSR9
4.6 Available Sets
MLSF and MLSD skates can be ordered as 1 single set.
The available sets are in the following table.
Set Model
Nº.
Components Set Capacity
(Tons)
MLSS7 x1 MLSF3 and x1 MLSD3 6.6
MLSS13 x1 MLSF7 and x1 MLSD7 13.2
MLSS20 x1 MLSF10 and x1 MLSD10 19.8
MLSS27 x1 MLSF13 and x1 MLSD13 26.4
MLSS35 x1 MLSF17 and x1 MLSD17 35.3
MLSS53 x1 MLSF27 and x1 MLSD27 52.9
MLSS70 x1 MLSF35 and x1 MLSD35 70.6
5. Operation
5.1 Placing load on skates (Figure 9)
Do not use skates if the wheels appear to be dam-
aged or deformed.
To position the load onto the skates, lift one end of the
load to allow the load skate to move underneath the
load.
Once the load is lifted, MLSD or MLSR trailing skates
must be positioned at 90 degrees from (or perpendicular
to) the center axis of the load. The load can now be
lowered slowly to rest on the rear skates.
Repeat this operation to position the front skate (MLSF
or MLSR) under a suitable location on the opposite end
of the load. If necessary, block the rear skate wheels so
the load is not able to move.
If enough lifting devices or a crane or forklift are
available, the load can be lifted evenly and set on all
skates simultaneously.
While the load is positioned on the skates, no per-
son is to be on the load and must mantain a min-
imum of 5 ft (1.5 m) from the load to avoid injury
Before disconnecting the lifting device and trying to
move the skates, verify that the front skate (MLSF or
MLSR) is located along the center axis of the load.
When placing or removing load from the skates,
do so in a slow, controlled manner
Verify that the rated capacity of the load skate
set is adequate for the load to be moved. This
also applies to loads with uneven centers of grav-
ity. Some applications may require front and rear
skates of different capacities. These calculations
must be done prior to moving the load by the lead
person responsible.
Ensure that the load is distributed equally between the
two skates to avoid any potential overloading.
Figure 8: Distribution of the load
CAUTION
WARNING
CAUTION
CAUTION
NOTICE

12 L4535_b
Keep hands away from the load skate wheels
to avoid injury. This especially applies while the
load is on the skates, but also as a general re-
quirement to avoid risk of injury even when the
skates are unloaded and stationary.
Do not use the load skates if the load pad is dam-
aged or slick with oil. This could result in the load
unintentionally shifting.
5.2 Moving the load
When moving a load there has to be a vertical clearance
between the load and fixed objects. Properly secure any
movable object in the load to avoid possible damage to
the facility where the load is moved.
Use the proper handle depending on the skate that is
being used and the load that is been moved.
Verify the floor supporting the load is able to do
so and provides a flat and level surface. Failure
to do so could result in damage to the floor, the
skates, or cause the load to tip.
Do not use the load skates on inclines, uneven
floor surfaces, near floor edge drop offs, over
stairs, or over gaps in the floor excceding 0.4 in
(1.0 cm).
Move the load slowly and carefully, maintain a minimum
distance of 1.6 ft (0.5 m) to walls from the load. The
angle of the handle when pulling the load is not to
exceed 25º from horizontal to the floor.
When moving the load do so in a controlled direction
and try to avoid non - linear travel when possible.
Figure 11: Safety measures when moving the load
If using MSLR load skates, verify that the rotating skates
are unlocked before begin to move the load. Also verify
that the rotational load pad functions correctly.
When moving a load over a step, approach the step
with the steering skate. Once at the step verify there is
enough of the load overhanging the step to then allow
WARNING
WARNING
WARNING
WARNING
NOTICE
NOTICE
Figure 9: Lifting process
When lifting a load onto skates of different capacities
and heights, a spacer block may need to be installed
between the shorter skate and the load to ensure the
load is level or a minimally inclined angle.
Figure 10: Secondary lifting process

L4535_b 13
unauthorised use.
Ensure that the warning labels are always in good
working order.
Before placing the device into operation, check all
components (including protective equipment) are
securely attached. Be sure that all bolts and other
fasteners are properly tightened. Verify that all moving
parts operate smoothly.
If your device requires repair, reach out to your nearest
Authorized Enerpac Service Center and source
replacement components only from Enerpac. This will
ensure that the safety of the device is maintained.
Insufficient maintenance and care can lead to unforeseen
accidents and injuries.
Keep the device handle clean, dry and free of spilled oil
or grease. Never clean the device and it´s components
with solvents, flammable or toxic liquids. Use only a
damp cloth.
the steering skate to be repositioned under the load on
the higher elevation of the step.
Lift the load with the lifting device and then reposition
the steering skate under the load on the other side of
the step. Lower the load slowly to rest again on the
repositioned front skate. Move the load forward and
repeat this operation for the rear trailing skate.
5.3 Removing the load
To remove the load from the skates, lift the end of the
load, which is on the steering skate, with a lifting device.
Remove the skate and lower the load to the floor. Repeat
same process on the other side of the load.
Figure 12: Moving a load over a step
Load removal must be done as carefully and
slowly as load lifting and moving
Keep body parts away from lifted loads and mov-
able parts and never put them below the load.
6. Storage &
Maintenance
Use appropriate lifting equipment for transportation.
The device must be stored in a dry place and protected
from frost.
Lock the device in a proper place to protect it from
CAUTION
WARNING

14 L4535_b
7. Service Parts List
7.1 MLSF Exploded View
Figure 13: MLSF load skate exploded view
7.1.1 MLSF Service Parts List
MLSF Load Skate Service Parts List
Item Compatible Skates Part Number Description Qty. Per Skate
1
MLSF3
MLSWPU85874
Polyurethane Wheel Kit
85mm diameter X 87mm width
Kit includes 4 wheels
1
MLSF7 2
MLSF10 3
MLSF13 4
MLSF17
MLSWPU140854
Polyurethane Wheel Kit
140mm diameter X 85mm width
Kit includes 4 wheels
2
MLSF27 3
MLSF35 4
2
MLSF3, MLSF7 MLSHT T Handle, Load Skate 1
MLSF10, MLSF13 MLSHR Ring Handle, Load Skate 1
MLSF17, MLSF27, MLSF35 MLSHF Frame Handle, Load Skate 1
3
MLSF3, MLSF7 DD9199202 Galvanized Lock Pin, 12mm x 82mm 1
MLSF10,MLSF13 DD9201202 Galvanized Lock Pin, 20mm x 85mm 1
MLSF17, MLSF27, MLSF35 DD9203202 Galvanized Lock Pin, 20mm x 95mm 1
4
MLSF3, MLSF7 N/A - -
MLSF10,MLSF13 DD9202202 Galvanized Lock Pin, 20mm x105mm 1
MLSF17, MLSF27, MLSF35 DD9204202 Galvanized Lock Pin, 20mm x 50mm 2
5
MLSF3, MLSF7 MLSFRP37 Rubber Pad, Round 150mm x 8mm 1
MLSF10, MLSF13 MLSFRP1013 Rubber Pad, Round 170mm x 8mm 1
MLSF17, MLSF27 MLSFRP1727 Rubber Pad, Round 220mm x 8mm 1
MLSF35 MLSFRP35 Rubber Pad, Round 250mm x 8mm 1
6 All Models N/A Wheel Box N/A
7 All Models N/A Skate Chassis N/A
1
2
1
6
76
5
4
3

L4535_b 15
7.1.2 MLSF Accessories
MLSF Load Skate Accessories
Item Compatible Skates Part Number Description Qty. Per Skate
1
MLSF3
MLSWNY85874
Nylon Wheel Kit
85mm diameter X 87mm width
Kit includes 4 wheels
1
MLSF7 2
MLSF10 3
MLSF13 4
MLSF17
MLSWNY140854
Nylon Wheel Kit
140mm diameter X 85mm width
Kit includes 4 wheels
2
MLSF27 3
MLSF35 4
7.2 MLSD Exploded View
Figure 14: MLSD load skate exploded view
7.2.1 MLSD Service Parts List
MLSD Load Skate Service Parts List
Item Compatible Skates Part Number Description Qty. Per
Skate
1
MLSF3
MLSWPU85874
Polyurethane Wheel Kit
85mm diameter X 87mm width
Kit includes 4 wheels
1
MLSF7 2
MLSF10 3
MLSF13 4
MLSF17
MLSWPU140854
Polyurethane Wheel Kit
140mm diameter X 85mm width
Kit includes 4 wheels
2
MLSF27 3
MLSF35 4
2
MLSD3 MLSCDR Round Connecting Bar, Dual Load Skate 1
MLSD7, MLSD10, MLSD13 MLSCDF Folding Connecting Bar, Dual Load Skate 1
MLSD17, MLSD27, MLSD35 MLSCDS Square Connecting Bar, Dual Load Skate 2
3
MLSD3 MLSRP1 Rubber Pad, 75mm x 150mm x 8mm 2
MLSD7 MLSRP3 Rubber Pad, 120mm x 220mm x 8mm 2
MLSD10 MLSRP5 Rubber Pad, 170mm x 180mm x 8mm 2
MLSD13 MLSRP7 Rubber Pad, 200mm x 220mm x 8mm 2
MLSD17 MLSRP9 Rubber Pad, 318mm x 188mm x 8mm 2
MLSD27 MLSRP13 Rubber Pad, 318mm x 285mm x 8mm 2
MLSD35 MLSRP17 Rubber Pad, 318mm x 382mm x 8mm 2
4 All Models N/A Skate Chassis N/A
2
1
1
3
4
4

16 L4535_b
7.2.2 MLSD Accessories
MLSD Load Skate Accessories
Item Compatible Skates Part Number Description Qty. Per Skate
1
MLSD3
MLSWNY85874 Nylon Wheel Kit 85mm diameter x
87mm width Kit includes 4 wheels"
1
MLSD7 2
MLSD10 3
MLSD13 4
MLSD17
MLSWNY140854 Nylon Wheel Kit 140mm diameter X
85mm width Kit includes 4 wheels
2
MLSD27 3
MLSF35 4
7.3 MLSR Exploded View
Figure 15: MLSR load skate exploded view
7.3.1 MLSD Service Parts
MLSR Load Skate Service Parts List
Item Compatible Skates Part Number Description Qty. Per Skate
1
MLSR3
MLSWNY85434
"Nylon Wheel Kit
85mm diameter X 43.5mm width
Kit includes 4 wheels"
2
MLSR7 4
MLSR9 5
2
MLSR3 MLSRRP3 Rubber Pad, Round 170mm x 8mm,
including center and lock pin holes
1
MLSR7, MLSR9 MLSRRP79 Rubber Pad, Round 220mm x 8mm,
including center and lock pin holes
1
3 All Models N/A Wheel Box N/A
4 All Models N/A Skate Chassis N/A
5*All Models DD9199202 Galvanized Lock Pin, 12mm x 82mm 2
*NOTE: Item not Shown
1
1
3
2
4
3

L4535_b 17
7.3.2 MLSR Accessories
MLSR Load Skate Service Parts List
Item Compatible Skates Part Number Description Qty. Per Skate
1 MLSR3, MLSR7, MLSR9 MLSHRT T Handle, Rotational Load Skate 1
2 MLSR3, MLSR7, MLSR9 MLSHRR Ring Handle, Rotational Load Skate 1
3 MLSR3, MLSR7, MLSR9 MLSCR6 6.5 Ft Connecting Bar, Rotational
Load Skate 1
4 MLSR3, MLSR7, MLSR9 MLSCR8 8.0 Ft Connecting Bar, Rotational
Load Skate 1
5 MLSR3, MLSR7, MLSR9 MLSCRH8 8.0 Ft Connecting Bar with Handle
Joint, Rotational Load Skate 1
6 MLSR3, MLSR7, MLSR10 MLSRTT Turntable Assembly, Rotational Load
Skate, Round 170mm x 37mm 1
8. Troubleshooting
Troubleshooting Guide
Symptom Possible Cause Solution
1. Load is more difficult to move. a. Fatigue or corrosion on the skate
body.
Clean corrosion. If damaged, reach out
to your nearest Authorized Enerpac
Service Center for repair/replacement
options.
b. Corrosion on the wheel bearings.
c. Load path with debris. Clean load path.
d. Deformed PU or NY layer on wheel. Change old wheels for new ones.
e. MLSR skates have locking pins in-
stalled, preventing rotation
If the application requires rotation of the
MLSR skate, remove the locking pins
2. Load gets stuck in position and is not
able to be moved.
a. Fatigue or corrosion on the skate
body.
Clean corrosion. If damaged, reach out
to your nearest Authorized Enerpac
Service Center for repair/replacement
options.
b. Corrosion on the wheel bearings.
c. Fatigue or corrosion on the wheel box.
d. Corrosion or fatigue on the skate´s
handle.
3. Load is not be able to be steered in
the correct direction.
a. Corrosion on the load pad top swivel. Clean corrosion. If damaged, reach out
to your nearest Authorized Enerpac
Service Center for repair/replacement
options.
b. Load path with debris. Clean load path.
c. Corrosion or fatigue on the skate´s
handle.
Clean corrosion. If damaged, reach out
to your nearest Authorized Enerpac
Service Center for repair/replacement
options.
4. Load shifts from the rubber pad. a. Oil spilled on the rubber pad. Clean rubber load pad or if necessary,
replace rubber load pad.

NOTES
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
18
