AMGO Hydraulics 409-DP Manual

FOUR POST PARKING LIFT
MODEL: 409-DP 409-DPX
Original
Cargo Claims
If there is any missing or damage of
the cargo during transportation, the
buyer should claim on the carrier,
since the invoices issued by the
carrier is made out to the buyer.
⚠DANGER
Read the entire contents of this manual
before using this product. Failure to follow
instructions and safety precautions could
result in serious injury or even death. Make
sure all other operators also read this
manual. Keep this manual near the
machine so that it can be seen by all users.
By proceeding with installation and
operation, you agree that you are fully
understand the contents of this manual and
take full responsibility for the use of the
product.

1
CONTENTS
WARRANTY .................................................................................. 2
SAFETY INSTRUCTION .................................................................... 4
I. PRODUCT FEATURES AND SPECIFICATIONS ................................... 6
II. INSTALLATION REQUIREMENT .....................................................8
III. INSTALLATION STEPS ..............................................................10
IV. EXPLODED VIEW ..................................................................... 38
V. TEST RUN ................................................................................ 43
VI. OPERATION INSTRUCTIONS ..................................................... 44
VII. MAINTENANCE SCHEDULE .......................................................45
VIII. TROUBLE SHOOTING .............................................................46
IX. CAR LIFT SAFETY TIPS .............................................................47
X. LIFT DISPOSAL ........................................................................ 47
Explanation of the safety warning symbols used in this manual
⚠DANGER
Risk of death or injury.
⚠WARNING
Dangerous or unsafe practices that may result in death or
injury.
⚠CAUTION
Dangerous or unsafe practices that may result in personal
injury, product damage or property damage.
ATTENTION
Conditions that may result in damage to products or property.

2
WARRANTY
The warranty period for the steel structure part of new lift machine is 5 years,
hydraulic components, bronze bush, slider and plastic parts warranty for 3
years, electrical components and cable warranty for 2years, rubber pad is
consumable without warranty. During the warranty period, the manufacturer
will repair or replace the defective parts free of charge and bear the freight cost.
This warranty does not cover damage caused by wearing parts or improper use,
damage in transit and damage caused by non-maintenance as required.
This warranty is unique and supersedes what is expressed and implied in all
other warranties. The manufacturer shall not be liable for any particular,
indirect or accidental damage resulting in breach of or delay in the execution of
the warranty. The manufacturer reserves the right to design and improve the
product and has no obligation to make notice of the changes in advance.
The product warranty based on the above clause is based on the model number
and serial number of the equipment. This information must be provided in
conjunction with all warranty information at the time of service and warranty.

3
SAFETY WARNING LABEL
Fig. 1

4
SAFETY INSTRUCTION
In order to properly maintain your product and ensure operator safety, it is the
responsibility of the product owner to read and follow these instructions!
1. Ensure product installation complies with all applicable local regulations and rules,
such as Occupational Safety and Health Administration regulations and electrical
codes.
2. Ensure that all operators are properly trained, know how to operate the unit safely,
and are properly supervised.
3. Do not operate the product until you are sure all parts are in place and operating
correctly.
4. Keep your hands and feet away from the machine. Keep hands and feet away from
any moving parts. Keep your feet away from the lift as it descends to avoid pressing
on pointed objects.
5. Keep the work area clean. A cluttered workspace can lead to injuries.
6. The machine is only approved for indoor installation and use. Outdoor installation is
prohibited.
7. Only trained operators are allowed to handle the lift machine. All untrained persons
must stay away from the workplace. Never allow untrained persons to handle or
operate the machine.
8. Use the lift properly. Use the lift in the correct way.
9. Warning! Keep no one under the lift when lifting the car.
10. If the vehicle is at risk of falling, keep no one around the lift.
11. Before preparing to approach or service the vehicle, ensure that the safety device
is in effect.
12. Dress appropriately when operating machines, and consider wearing non-slip
steel-soled shoes for added safety..
13. Beware of electric shock. In order to protect the operator from electric shock, the
lift in use must be grounded. Do not connect the green wire to the terminal. This is
the ground wire.

5
14. Danger! The power supply used in this type of lift has high voltage. Please
disconnect the power supply before any circuit repair. Unplug in case the power
supply is accidentally switched on during maintenance.
15. Warning! There is a risk of explosion. There are parts in the equipment that
produce arc light and spark. Do not be exposed to easy gas. This machine should not
be placed in the lounge or basement.
16. Maintain with care. Keep the machine clean for better and safer operation. Perform
proper lubrication and maintenance procedures according to the manual. Keep
handles or buttons clean, dry, and free of oil.
17. Stay alert. Use common sense to observe what you are doing and stay alert.
18. Check for damaged parts. Check for adjustments to moving parts, damage to parts,
or anything that may affect their operation. Do not use the machine if the parts are
damaged.
19. Do not remove relevant safety parts from the machine. Do not use a lift if it is
damaged or missing.
20. Operate the lift only temperature from 410F to 1040F (50C to 400C).
⚠DANGER Be very careful when installing, operating, maintaining or
repairing this equipment. Failure to comply may result in property damage,
product damage, injury or (in very rare cases) death. Ensure that only
authorized personnel operate the equipment. All repairs must be carried out
by an authorized technician. Do not modify the machine, this voids the
warranty and increases the probability of personal injury or property
damage.

6
I. PRODUCT FEATURES AND SPECIFICATIONS
DOUBLE PARKING FOUR POST LIFT FEATURES
Model 409-DP, 409-DPX
· Cable transmission, drived by single hydraulic cylinder
· Single point manual safety release, more convenient and reliable for decent operation.
· Four mechanical locking devices, include primary mechanical safety lock with secondly
cable-brake safety lock , ensure the vehicle safety.
· Double parking design, allows to park 4 vehicles maximum. Max single vehicle weight
parked on the platform is 6000lbs .
· Non-skid diamond platforms and adjustable safety lock ladders.
Fig. 2

7
Dimension
SPECIFICATIONS
Model
Lifting
Capacity
Lifting
Time
A
B
C
D
E
F
G
Overall
Length (inc.
Ramps)
Overall
Length ( Not
Inc. Ramps)
Overall
Width
Width
Between
Columns
Drive
Through
Width
Overall
Height
Minimum
Height
409-DP
9,000lbs
47S
207 9/32"
173 13/16"
201 9/16"
192 1/16"
177 23/32"
82 7/8"
6 3/32"
409-DPX
9,000lbs
57S
234 27/32"
201 3/8"
201 9/16"
192 1/16"
177 23/32"
96 21/32"
6 3/32"
Model
H
I
J
K
L
Motor
Lifting
Height
Max. lock
height to
top of
runway
Max. height
underneath
runway
Max. lock
height
underneath
runway
Width
between
runway
Overall
width of
single
parking unit
Width
Between
two parking
units
409-DP
73 11/16"
70 15/16"
69 3/4"
67"
37"
74 13/32"
21 21/32"
220V 2.0HP
Single Phase
409-DPX
87 11/16"
84 15/16"
83 3/4"
80 31/32"
37"
74 13/32"
21 21/32"
⚠CAUTION When driving the vehicle into the lift, make sure it is positioned in
middle of either group of runways. Any hit of the lift could result in damage to either
the vehicle or lift.
Car-in Direction
Fig. 3

8
II. INSTALLATION REQUIREMENT
A.TOOLS REQUIRED
Rotary Hammer Drill (Φ19) Carpenter’s Chalk
Hammer Screw Sets
Level Bar Tape Measure (7.5m)
English Spanner (12") Pliers
Wrench set Lock wrench
(10#, 13#, 14#, 15#, 17#, 19#, 24#,27#, 30#,)
Ratchet Spanner With Socket (28#) Socket Head Wrench (3#, 5#, 8#)
Fig. 4

9
B. Equipment storage and installation requirements.
1．Store the equipment in a dry, non-moldy, non-flammable environment.
2．The lift is generally approved for indoor installation and use. If need outdoor
installation, the optional motor protect cover is required. (Kits No.: 40810)
3．When installing the device, take safety precautions according to the instructions to
avoid device damage.
4．During installation, all parts should be fastened to ensure the stability and smooth
operation of the machine.
5．After installation, the whole machine should be checked to make sure that every
component is working properly.
C. The equipment should be unload and transfer by forklift.
D. SPECIFICATIONS OF CONCRETE (See Fig. 7)
Specifications of concrete must be adhered to the specification as following.
Failure to do so may result in lift and/or vehicle falling.
1. Concrete must be thickness 4” minimum and without reinforcing steel bars, and
must be totally dry before lift installation.
2. Concrete must be in good condition and must be of test strength 3000psi
(210kg/cm²) minimum. Solidify at least 15 days.
3. The installation ground must be smooth and level without cracks.
Fig.5

10
E. POWER SUPPLY
1.You are required to engage a licensed and qualified electrician for the installation
process.
2.The power supply must be 220VAC single phase , with a cord larger than
3.3mm²(12AWG), and must be properly grounded.
III. INSTALLATION STEPS
A. Location of installation
1. Installation space: Ensure there is enough space for the lift. Accurately measure
the front, back, side and top mounting dimensions and refer to the below figure
data(See Fig. 7).
2. Overhead obstacle: Check for overhead obstacles, such as building supports,
heaters, lights, wires, and low ceilings, etc..
Fig. 6
Concrete intensity must be 3000psi (210kg/cm²)
≥4”
⚠DANGER All electrical wiring must be performed by a licensed and
certified electrician. Attempting to connect the circuit without proper
certification may result in damage to the lift or electrocution, resulting in
serious injury or death.

11
3. Installation: The lift is only approved for indoor installation and use. If need
outdoor installation, the optional motor protect cover is required. (Kits No.: 40810)
4. Floor: Install lift only on flat concrete floor. Do not install on asphalt or any other
surface. The surface must be flat. Do not install if the surface slope exceeds 30.
Lift installation and concrete construction must comply with the latest version of the National
standard "Automotive Lifts - Safety Requirements for Construction, Testing and Verification".
Uniform building codes of other agencies or International Building Codes (IBC) for any special
regional structures must meet seismic standards.
59”
Car-in direction
Fig. 7

12
Power
side
Platform
Drive-in ramps
B. Check the parts before assembly. Make sure all parts of the lift are
complete.
1. Packaged lift and hydraulic power unit(See Fig. 8).
2. Move the lift aside with a fork lift or hoist, unpack the lift, tear off the shipment
parts list and check the components in the package according to the list. (See Fig. 9)
3. Loosen the bolts of the upper package, then take out the offside platform on the top.
(See Fig. 10)
Columns
Offside
Platform
Fig. 10
Fig. 8
Fig. 9
Shipment Parts list

13
4. Take out the parts in the offside platform, loosen the bolts of the middle package,
take out the offside platform/power side platform of the middle package. (See Fig.
11)
5. Take out the parts in the offside platform, take offer the package rack.
6. Move aside the parts and check the parts according to the shipment parts lift.(See
12 )
Fig. 11
Fig. 12
73

14
7. Check the parts of the parts box according to parts box list (See Fig. 13).
8. Check the parts of the parts bag according to parts bag list (See Fig. 14)
Fig. 14
Fig. 13
Parts bag 2
Parts bag 1
Only for 409-DPX

15
C.Use a carpenter’s chalk line to establish installation layout as per
Fig.15. Place the columns at the right position.
Note: Reserve space front and behind the installation site.
MODEL
A
B
C
409-DP
173 13/ 16"
201 9/ 16"
266 3/ 16"
409-DPX
201 3/8"
201 9/ 16"
284 29/32"
Use a carpenter’s chalk line to establish
installation layout
Fig.15
Power side column
A
B
C
1
5

16
D. Install cross beam assy.
1. Prepare the assembly parts shown as below, see fig 16
2. Install cross beam assy. See fig 17.
W/O rotation device
W/ rotation device
W/ rotation device
4: Cross Beam Connection A
2: Cross Beam Connection B
3: Cross Beam
W/O rotation device
Note: Each cross beam has 4
M16 nuts welded on one side,
and 2 M12 nuts welded on the
other side. It’s important to
pay attention to the direction
when installing.
Fig.16
8
M14*50 Hex Bolt,
with 2 flat washers
and 2 nuts.
4
有 旋 转
This cross beam assy.
hereinafter referred to as
cross beam I.
This cross beam assy.
hereinafter referred to as
cross beam II.
W/ rotation device
3
2
3
2
4
W/O rotation device
Rotation device.
Fig.17
74

17
Enlarged view after installation.
Cross Beam II
Fig.18
Cross Beam I
Make sure the window of
cross beam connection is
towards inside
Make sure the 4 M16 nuts
welded on the cross beam
are towards outside.
Make sure the 2 M12 nuts welded on the
cross beam are towards inside.
Make sure the window of
cross beam connection
is towards inside.

18
Pass the safety device cou pl i ng ba r assy
into the cros s beam assy from the side
E. Assemble safety device coupling bar assembly,and bolted with
cross beam assembly .
1. One safety device coupling bar assembly include one unit coupling bar,
two units connecting bar, all parts see fig 19.
2. Assembly of coupling bar assembly. See fig 20
3. Bolt safety device coupling bar assembly with the cross beam assembly.
Make sure the safety device works well. See fig 21.
29 (coupling bar)
L=150 25/32”
30
(connecting bar)
32
Φ8 lock
washer
31 M8 Hex Nut
Fig.19
Holes Distance=179 31/32
Distance between the two Φ8 holes after assembly
32
31
1Screw in the M8 hex nut on the external thread of the connecting bar, turn
it to the end, then put on φ8 lock washer.
2Screw the external thread of connecting bar into the internal thread of the
coupling bar.
3Adjust the φ8 holes of the connecting bar at both ends to the correct
distance, then tighten with two M8 nuts.
Note: the Φ8 holes of the connecting bar at both ends should be
parallel to each other after installation.
Fig.20
33
Rotation device.
34
M8*25 Hex Bolt with with flat
washer, nylok nut
Note: Tighten the hex bolt with nylok
nut, and then loosen about 1/4
turn(when install coupling bar assembly)
Fig.21
M8*20 Hex Bolt with flat
washer, nylok nut
74

19
4
F. Install cross beam assy. to columns
Noted: The windows of cross beam assy. should be towards inside, and the
rotation devices should be at the same side of power side column. See Fig.22
Cross Beam II
Cross Beam I
Power side column
The column with 4-Φ10 holes is power side, and
rotation device must be towards outside.
Fig.22
2
4
2
