EnGenius FreeStyl SIP User manual

FreeStyl SIP
Long-Range SIP Cordless Phone
EnGenius Customer Service
hp:// www.engeniustech.com /
User Manual

~2~
Table of Contents
Safety Instructions ....................................................................................5
General Safety Instructions ...................................................................5
Product Safety Instructions ...................................................................5
Battery Safety Instructions....................................................................7
Regulatory Information.............................................................................8
Base Station..........................................................................................8
Portable Handset................................................................................10
Equipment Checklist................................................................................13
Handset Illustration.................................................................................14
Handset Features....................................................................................16
Basic Handset Features .......................................................................16
Additional Handset Features...............................................................18
Base Illustration..................................................................................24
Base Features..........................................................................................24
Basic Base Station Features.................................................................25
Charger Illustration .................................................................................26
Charger Features.....................................................................................27
Getting Started .......................................................................................28
Base Station Installation......................................................................28
Handset and Charger Installation ........................................................28
Basic Operations .....................................................................................30
Operation Modes................................................................................30
A. Base Operation Modes................................................................30
B. Handset Operation Modes ..........................................................30
Making a Telephone Call.....................................................................32
Making a 2-Way/ Intercom Call...........................................................32
Making a Broadcast.............................................................................33
Handset-to-Handset Calls................................................................33
Redial .................................................................................................34
Receiving a Telephone Call..................................................................35
Receiving an Intercom Call ..................................................................35
Ending a Call .......................................................................................36
Adjusting Handset Receiver (Earpiece) Voice Volume..........................36
Adjusting Handset Speakerphone Voice Volume .................................36
Placing a Call On Hold .........................................................................37
Mute...................................................................................................37

~3~
Do Not Disturb (Silent Ring) ................................................................37
Key Guard...........................................................................................37
Battery Recharge and Replacement ....................................................38
Advanced Operations..............................................................................39
Handset Registration...........................................................................39
Handset Group Subscription ...............................................................40
Call Transfer........................................................................................41
Transfer to EnGenius Handset.....................................................41
Transfer to PBX Extension...........................................................42
Phonebook Operations .......................................................................43
Programmable Feature Call.................................................................47
Caller ID..............................................................................................49
Call Manager.......................................................................................50
Incoming.............................................................................................51
Outgoing.............................................................................................51
Call Barring .........................................................................................52
Visual Message Waiting Indicator (VMWI)...........................................53
Adjust Handset Microphone Gain .......................................................53
Adjust Headset Ring............................................................................54
SIP Configuration ....................................................................................55
Introduction........................................................................................55
VoIP Features......................................................................................55
Registration Handsets.........................................................................55
Default Settings ..............................................................................55
Web Configuration .........................................................................56
LAN Configuration ..........................................................................56
Base Settings ..................................................................................57
Phone Book ....................................................................................57
SIP Configuration ................................................................................58
SIP Server .......................................................................................58
SIP Account.....................................................................................59
Individual Account ..........................................................................60
Group Account ...............................................................................61
Auto-Provision................................................................................62
Tools...................................................................................................63
Admin.............................................................................................63
Time ...............................................................................................64
Ping Test.........................................................................................64

~4~
Firmware........................................................................................65
Back-up ..........................................................................................65
Reset/Reboot/Registration .............................................................65
Menu Operations....................................................................................67
Technical Specifications ..........................................................................72
Index.......................................................................................................74

~5~
Safety Instructions
Caution: Your wireless telephone gives you freedom and flexibility to
stay in touch while you move around. However, when using your phone
equipment, safety instructions should be followed to avoid the risks of
fire, electric shock, injury to person, and damage to property.
General Safety Instructions
1. When using your wireless phone, ensure your safety and the safety of others:
a. Always watch where you are walking and standing.
b. Do not let a phone call distract you from working safely.
c. If power goes out, your phone will not work. Backup power is
recommended.
2. In an emergency:
a. If an emergency occurs, dial the emergency phone number. Remember: if
you are in an area where your phone does not have a clear signal from the
base, it is highly probable that the call may not go through. Locate the
nearest landline telephone or other communications device to call for help.
b. Emergency calls may not automatically provide emergency personnel with
your name, phone number or location.
3. Notice to Hearing Aid Users: This phone system is compatible with inductively
coupled hearing aids.
4. Notice to Cardiac Pacemaker Users: Preliminary studies done by the US FDA
and others have shown that, although interference to the implanted cardiac
pacemaker may occur when operating very closely, wireless telephones “do not
seem to pose a significant problem for pacemaker wearers.” However, until
more is known, the FDA suggests that people with pacemakers may want to
take precautions when using or carrying a wireless telephone to ensure that
there is ample distance between the telephone and the pacemaker. Do not
carry the handset in a breast pocket. If you have any reason to suspect that
interference is taking place, turn off your handset immediately.
Product Safety Instructions
1. Read and understand all instructions.
2. Follow all warnings and instructions including those marked on the product.

~6~
3. Changes or modifications to this product not expressly approved by the
manufacturer will void the warranty and the FCC authorization to operate the
equipment. Use only manufacturer provided accessories.
4. Do not use the telephone near water. Never spill liquid of any kind on this
product.
5. Unplug the product from the wall telephone jack and power outlet before
cleaning. Do not use liquid or aerosol cleaners. Use damp cloth for cleaning.
6. Do not place this product on an unstable cart, stand, or table. The product may
fall and cause personal injury or damage to the product or other property.
7. Power Outage: In the event of a power outage, your handset charger will not
recharge the handset battery, and the base station will not allow you to make
an outgoing call or take an incoming call. Both the charger and the base station
require electricity for operation. You should have a telephone that does not
require electricity available for use during power outages, or have a temporary
backup power supply.
8. Slots or openings in the product’s housing are provided for ventilation. These
openings must not be blocked or covered. Placing the product on a bed,
carpeting, or other similar surface may block these openings and should be
avoided. This product should never be placed near or over a radiator or heat
register, or in a built-in installation unless proper ventilation is provided.
9. Never push objects of any kind into this product through housing
slots/openings as they may damage the product, touch dangerous voltage
points or short out parts that could result in fire, electric shock, or injury.
10. This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your dealer or local power company.
11. Do not overload wall power outlets and extension cords as this may result in
fire or electric shock.
12. To avoid electric shock or burn, do not disassemble this product. Send this
product to an authorized service center when service or repair work is required.
Call Customer Service for locations near you. Opening or removing covers may
expose you to dangerous voltages, electrical currents or other risks. Incorrect
re-assembling of the product may cause electric shock when the product is
subsequently used.
13. Avoid using the product during a storm. There may be a risk of electric shock
from lightning.
14. Do not place the product where persons can step, trip, or fall on it.
15. Do not place conductive objects over or near the antenna.

~7~
16. Do not use the product to report a gas leak while in the vicinity of the leak.
17. Do not install the base station or the handset charger near microwave ovens,
radios, TV sets, speakers, or other electrical equipment. These appliances may
cause interference to the product or experience interference from the product.
18. Unplug the base station or the charger adaptor from the power outlet and refer
to an authorized service center under the following conditions:
a. If liquid has been spilled into the product.
b. When the power supply cord or plug is damaged or frayed.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally by following the operating
instructions.
e. If the product has been dropped or housing has been damaged.
f. If the product shows a distinct change in performance.
Battery Safety Instructions
1. Use only manufacturer approved Li-Ion rechargeable batteries and charger. Do
not use other types of rechargeable batteries or non-rechargeable batteries.
The batteries could short-circuit, and the battery enclosure may be damaged
causing a hazardous condition.
2. Follow the charging instruction in this manual and instruction labels and
markings in the handset and charger compartments.
3. Battery must be recycled or disposed of properly. Do not dispose the battery in
a fire. The cells may explode.
4. Do not dispose of the battery in municipal waste. Check with local codes for
disposal instructions.
5. Exercise care in handling the batteries so you do not short-circuit the battery
with conductive materials such as rings, bracelets, keys, pocketknives, and/or
coins. The battery or conductive material may overheat and cause burns or fire.
6. Do not expose batteries to rain or water.
7. Do not open or mutilate the battery. Released electrolyte is corrosive and may
cause injury to eyes or skin. The electrolyte may be toxic if swallowed.
8. During charging, the battery heats up. This is normal and is not dangerous.

~8~
Regulatory Information
FreeStyl SIP
FCC ID: A8J-FREESTYLSIP
IC: 10103A-FREESTYLSIP(Handset)
10103A-FREESTYLSIB(Base Station)
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received, including
interference that may cause undesired operation.
Privacy of communications may not be ensured when using this phone.
Base Station
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.

~9~
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Industry Canada Statement:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired
operation.
Déclaration d'Industrie Canada :
Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont
conformes aux RSS exemptés de licence d'Innovation, Sciences et Développement
économique Canada. L'exploitation est soumise aux deux conditions suivantes :
(1) Cet appareil ne doit pas provoquer d'interférences nuisibles, et (2) cet appareil
doit accepter toute interférence reçue, y compris les interférences pouvant
provoquer un fonctionnement indésirable.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.
This device has been designed to operate with a dipole antenna having a maximum
gain of 2dBi. Antenna having a higher gain is strictly prohibited per regulations of
Industry Canada. The required antenna impedance is 50 ohms.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC définies

~10~
pour un environnement non contrôlé. Cet équipement doit être installé et utilisé
avec une distance minimale de 20 cm entre le radiateur et votre corps.
Cet appareil a été conçu pour fonctionner avec une antenne dipôle ayant un gain
maximum de 2dBi. Une antenne ayant un gain plus élevé est strictement interdite
par les règlements d'Industrie Canada. L'impédance d'antenne requise est de 50
ohms.
Portable Handset
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate this
equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
IMPORTANT NOTE:
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating instructions
for satisfying RF exposure compliance. To maintain compliance with FCC RF
