ENSIM SENSORS ELM Series User manual

OPERATING
MANUEL
LEVEL SWITCH
ELM
Model :
Model : 12-2017-004
Information in this manual is reviewed and completely reliable. Responsibility is not assumed due to any typing error.
Products in this manual are available only for information purpose and they may be changed without notice.
Important Notes:
Used Symbols :
Please read this manual carefully before installation of the level switch. User is responsible for
accidents and losses arising from failure to comply with the warnings in this manual.
In the event that level switch is broken, take measures in order to prevent accidents and losses which
can occur in its system.
There is not any fuse and circuit breaker on the instrument; they should have been added to the system
by the user.
This manual should be stored in an easily accessible place for subsequent use.
Do not operate the system before making assembly in compliance with the assembly chart related
to the instrument.
Do not make any modification on the instrument and do not try to repair it. Reparation should be made
by authorized service personnel.
The instrument's useful life, determined and announced by the ministry, is 10 years.
Products which do not contain label and serial number are considered to be excluded from the warranty scope.
: Caution : Note
Table of Contents :
1. General Information...........................................................................................................................................2
2. Installation ..................................................................................................................................................3
3. Failure Detection..............................................................................................................................................6
4. Disassembly of Instrument ..................................................................................................................................6
5. Service ......................................................................................................................................................6
6. Recalibration...............................................................................................................................6
7. Repair....................................................................................................................................................................6
8. Disposal................................................................................................................................................6
9. Terms of Warranty .....................................................................................................................................6
10.Terms of Return ..............6
1
: Disposal
ELM31 , ELM41 , ELM51 , ELM71
ELM32 , ELM42 , ELM52 , ELM72
ELM51s
ELM61 , ELM61s , ELM61m
ELM62 , ELM63
ELM81s , ELM82s
Modeller :

2
1. General Information :
1.1. Material Acceptance
Check that there is no damage on the packages during the transportation immediately after the material acceptance. If packages are
damaged, open the packages immediately and check whether products are affected or not, if there is any damage, send your
complaint report to the transporter company and its photocopy to the address of our company.
1.2. Information about Areas of Use
It should be used in allowed using medium and application areas! It is not used in the corrosive mediums,
ambient with explosive and flammable material. Conformity with medium to be measured should be also taken into consideration.
Responsibility is not assumed in case of inappropriate use, modification and injure, and such cases are not covered by warranty.
Ambient Conditions: Relative Humidity: 5-95 %RH Ambient temperature: 70C (It is not used under -5 C)
1.3. Operating Princible
ELM level switches are used for checkin level of tank. It is preferred by machine manufacturers, especially in terms of its ease ofg use and
economy. The ELM level switched can be mounted in litte places because of their mini design. The switches are made by stainless steel
material and so can be used in various liquids.
When magnetic field of magnet in the float is aligned withreed sensor in the tube , it opens or closes
the electric circuit.When float moves away , sensor reverts back ( upon demand , drawn contact may be made).
Level informationcan be assessed with a relay circuit.

3
Technical Specifications :
MODEL
DIM. Cylinder
a
b
c
d
e
f
ð
x
y
z
28
28
8
45
60
5
15
17Hex
17Hex
1/8"BSP or M10
Spherical
43
43
8
70
75
5
15
17Hex
17Hex
1/8"BSP or M10
52
52
13
100
120
8
20
24Hex
24Hex
3/8"BSP or 1/2"BSP
Spherical
73
73
13
115
137
8
20
24Hex
24Hex
3/8"BSP or 1/2"BSP
ELM 31 ELM 41 ELM 51 ELM 71
Spherical
z
y
f
f
g
x
d
b
e
c
a
Closed
Black
Blue
Single Contact NO
Cable
Nut
O-Ring
Thread
St.St Pipe
Float
Ring
ELM 71ELM 51ELM 41ELM 31
Float Material
Wetted Parts Material
Pipe Material
Float Type
Working Temperature
Mechanical Connection
Max. Pressure (Bar)
Min. Density (g/cm3)
Electrical Connection
Number of Float
Number of Contact
Optional
304 Stainless Steel
304 Stainless Steel
304 Stainless Steel
S1Y
10
0.8
Max. 150 C
1/8"BSP or M10
Cable
1 Std.
SPST-NO
Liquid Level Relay SK-P2
316 Stainless Steel
304 Stainless Steel
304 Stainless Steel
S2A
30
0.75
Max. 150 C
1/8"BSP or M10
Cable
1 Std.
SPST-NO
Liquid Level Relay SK-P2
316 Stainless Steel
304 Stainless Steel
304 Stainless Steel
S4A/S40A
30
0.7
Max. 150 C
3/8"BSP or 1/2"BSP
316 Stainless Steel
304 Stainless Steel
304 Stainless Steel
S5A
30
0.55
Max. 150 C
3/8"BSP or 1/2"BSP
INSTALLITION VERTICAL VERTICAL VERTICAL VERTICAL
Cable
1 Std.
SPST-NO
Liquid Level Relay SK-P2
Cable
1 Std.
SPST-NO
Liquid Level Relay SK-P2
200 VDC / 140 VAC
1 A
200 VDC / 140 VAC
1 A
10 W / VA 10 W / VA
Max. Contact Power
Max.Switching Voltage
Contact Current
200 VDC / 140 VAC
1 A
10 W / VA
200 VDC / 140 VAC
1 A
10 W / VA
All dimensions are given in mm.

4
DÝKEY
DÝKEY
MODEL
DIM. Cylinder
a
b
c
d
e
f
ð
x
y
z
28
28
8
72
58
5
15
17Hex
17Hex
1/8" BSP
Spherical
43
43
8
92
65
5
15
17Hex
17Hex
1/8" BSP
52
52
13
95
80
8
20
24Hex
24Hex
3/8" BSP or 1/2 BSP
Spherical
73
73
13
125
100
8
20
24Hex
24Hex
3/8"BSP or 1/2"BSP
ELM 32 ELM 42 ELM 52 ELM 72
Spherical
g
ff
e
x y
z
c
a
d
b
Closed
Black
Blue
Single Contact NO
Cable
Nut
O-Ring
Thread
St.St Pipe
Float
Ring
All dimensions are given in mm.
ELM 32 ELM 42 ELM 52 ELM 72
Float Material
Wetted Parts Material
Pipe Material
Float Type
Working Temperature
Mechanical Connection
Max. Pressure (Bar)
Min. Density (g/cm3)
Electrical Connection
Number of Float
Number of Contact
Optional
304 Stainless Steel
304 Stainless Steel
304 Stainless Steel
S1Y
10
0.8
Max. 150 C
1/8"BSP or M10
304 Stainless Steel
304 Stainless Steel
304 Stainless Steel
S2A
30
0.75
Max. 150 C
1/8"BSP or M10
316 Stainless Steel
304 Stainless Steel
304 Stainless Steel
S4A/S40A
30
0.7
Max. 150 C
3/8"BSP or 1/2"BSP
316 Stainless Steel
304 Stainless Steel
304 Stainless Steel
S5A
30
0.55
Max. 150 C
3/8"BSP or 1/2"BSP
INSTALLITION VERTICAL VERTICAL VERTICAL VERTICAL
Cable
1 Std.
SPST-NO
Liquid Level Relay SK-P2
Cable
1 Std.
SPST-NO
Liquid Level Relay SK-P2
Cable
1 Std.
SPST-NO
Liquid Level Relay SK-P2
Cable
1 Std.
SPST-NO
Liquid Level Relay SK-P2
200 VDC / 140 VAC
1 A
10 W / VA
Max. Contact Power
Max.Switching Voltage
Contact Current
200 VDC / 140 VAC
1 A
10 W / VA
200 VDC / 140 VAC
1 A
10 W / VA
200 VDC / 140 VAC
1 A
10 W / VA

Technical Specifications :
Float Material
Wetted Parts Material
Pipe Material
Float Type
Working Temperature
Mechanical Connection
Max. Pressure (Bar)
Min. Density (g/cm3)
Electrical Connection
Number of Float
Number of Contact
Optional
304 Stainless Steel
Max. 150 C
1/2BSP
Cable PG7
1 Std.
SPST-NO
INSTALLITION HORIZONTAL
304 Stainless Steel
304 Stainless Steel
S3Y
5
HORIZONTAL HORIZONTAL
0.7
304 Stainless Steel
Max. 150 C
1/2BSP
304 Stainless Steel
304 Stainless Steel
5
0.7
S3Y
304 Stainless Steel
Max. 150 C
1/2BSP+Nut
304 Stainless Steel
304 Stainless Steel
5
0.7
S3Y
ELM 61 ELM 61s ELM 62
Liquid Level Relay SK-P2 Liquid Level Relay SK-P2 Liquid Level Relay SK-P2
DIN43650C Socket
1 Std.
SPST-NO
Cable
1 Std.
SPST-NO
Max. 150 C
1/2BSP
304 Stainless Steel
5
0.7
S3Y
Liquid Level Relay SK-P2
Clemens
1 Std.
SPST-NO
HORIZONTAL
ELM 61m
Housing Material - - - Aluminum
304 Stainless Steel
304 Stainless Steel
180 VDC / 130 VAC
0,7 A
10 W / VA
180 VDC / 130 VAC
0,7 A
10 W / VA
180 VDC / 130 VAC
0,7 A
10 W / VA
180 VDC / 130 VAC
0,7 A
10 W / VA
All dimensions are given in mm.
Max. Contact Power
Max.Switching Voltage
Contact Current
5
Ø17
15
26 10 31 47
ELM 62
Ø17
15
23
ELM 61m
Closed
55
36
Hex 24 1/2BSP
Hex 24 3/8BSP
Ø17
15
47508
23
Hex 24 1/2BSP
ELM 61
Ø17
15
47508
23
ELM 61s
Hex 24 1/2BSP
Closed
With Clemens
Single Contact NOSingle Contact NO
2
3
1
With Socket
Black
Blue
Single Contact NO
With Cable
ELM 63
Closed
40°
Ø17
15
Hex 16 M10
637 58
58

6
LEVEL CONTROL DEVICE
SK-P2
72x72 mm
25
90
1/2BSP
17
47
62
3/4BSP
22
ELM 82sELM 81s
2
3
1
Closed
Single Contact NO
All dimensions are given in mm.
Float Material
Wetted Parts Material
Pipe Material
Float Type
Working Temperature
Mechanical Connection
Max. Pressure (Bar)
Min. Density (g/cm3)
Electrical Connection
Number of Float
Number of Contact
Optional
304 Stainless Steel / PP
(-) 20 / (+) 80C
1/2''BSP / 3/4"BSP
DIN43650A Socket
1 Std.
SPST-NO
INSTALLITION HORIZONTAL
304 Stainless Steel
304 Stainless Steel
S3Y / P81
5
HORIZONTAL
0.75
304 Stainless Steel
304 Stainless Steel
5
ELM 81s ELM 82s
304 Stainless Steel / PP
(-) 20 / (+) 80C
1/2''BSP / 3/4"BSP
S3Y / P81
0.75
Liquid Level Relay SK-P2 Liquid Level Relay SK-P2
DIN43650A Socket
1 Std.
SPST-NO
200 VDC / 140 VAC
1 A
200 VDC / 140 VAC
1 A
10 W / VA 10 W / VA
Max. Contact Power
Max.Switching Voltage
Contact Current
Power Supply
Output
Working Temperature
Dimensions
Input
Isolation
220 VAC, 2.8 VA
2 pcs.5A/250 VAC Relay (Start/Stop)
-20 + 70oC
72 x 72 mm
Contact Information , coming from ELP
Input and output are isolated

7
Technical Specifications :
Black
Blue
Single Contact NO
Float Material
Wet Part Material
Pipe Material
Float Type
Working Temperature
Mechanical Connections
Maximum Pressure (Bar)
Minimum Intensity (g.cm3)
Electrical Connection
Float Sayýsý
Contact Sayýsý
Optional
304 Stainless Steel
304 Stainless Steel
S1Y
10
0.8
Max. 150 C
1/8" BSP or M10
Cable
1 Std.
SPDT-NO / NC
Liquid Level Relay SK-P2
INSTALLITION ELM 51s
304 Stainless Steel
200 VDC / 250 VAC
1,5 A
50 W / VA
Max. Contact Power
Max.Switching Voltage
Contact Current
2m.Cable
60.3
45
160
115
Closed

8
1.5. Target Group
This operating manual has been prepared for qualified technical personnel.
1.6. Security Notes
Following notes should be taken into consideration in order to avoid dangers which can occur on the operator and around
the ambient:
Installation, operation and maintenance of this instrument should be made only by people who have read the operating manual and
who are knowledgeable about work safety!
It should be complied with work safety, accident prevention regulations and national installation standards.
Product should be used only within the scope of stated specifications!
You can assemble the instrument only when pressure is not available!
1.7. Content of Package
Please check whether you have taken delivery of below listed content completely or not and check its conformity with
criterions in your order:
*Level switch
*This operating manual
2. Installation
2.1. General Notes
Installation of the instrument should be made only by authorized personnel.
Do not apply force to the instrument during the installation!
Do not use the level switch with a greater pressure than recommended pressure.
Do not forget that instrument is precise, carry it carefully and prevent to be damaged.
It should be guaranteed that there are not any magnetic particles.
2.2. General Installation Stages
*Remove level switch from the box carefully
*Check whether gasket is appropriate for fluid or not. If is not appropriate, contact with the producer.
*Then, apply below mentioned explanations according to structure of the design.
2.3. Special Notes
*Please ensure that there is no mechanical stress on the shaft following installation.
Such case will cause slipping in thecharacteristic curve.
*Level switch should be placed in completely vertical or horizantal position on the line.
*Allocate valve certainly in the process connection while instrument is used.
*Allocate blowdown valve under bottom flange for blowdown.
*If instrument is mounted outside and if there is any danger of lightning or
excessive pressure, take preventive measures by taking necessary measures.
*In the operating conditions, level switch may be hot according
to situation of fluid, in this case, do not touch the switch, otherwise your
skin is damaged.
2.4. Installation For Mechanical Connections
*Use appropriate O-Ring or gasket for tightness.
*Ensure that its surface is clean and smooth.
*Assemble the instrument manually.
*Connect the contacts as shown in the figure.
(Max.10 Nm for 1/8"BSP and 1/4"BSP, Max.15 Nm for 1/2"BSP, Max.20N Nm for 1"BSP)
1.8. Label Information
Type
Max Press.
Max Temp.
Max Current
:
:
:
:
ELM81s
5 bar
80°C
0,5A SN: 150689-05
Output Serial No
Specifications
Type
Output
S.N.
:
:
:
ELM61s
SPST-NO
Max.100mA
150689-05
Serial No
Output
Model Type Flow Direction
Mark
Serial No
Model Type
Flow Direction
Model Type
Muff
Muff
Max.22mm Max.20mm
Mounting
Direction
Mounting
Direction
Mounting
Direction
Max.20mm Mounting
Direction
Mounting Direction
Muff
Mounting direction for NO Mounting direction for NC

9
2.6. Electrical Installation
Make the electrical connection of the instrument according to details on its label, table and cable figures in this manual.
Inductive Load
When reed switch is used for loads such as electromagnetic relay ,contactor or solenoid, reed switch may be exposed to very high
voltage depending on value of inductive load. This causes either failure of switch or shortening its service life. Therefore, it is
recommended to be used as follows depending on used voltage, for the purpose of protection of switch.
When reed switch is used with capacitive load, it may cause that high current passes over reed switch, depending on value of
capacity during Charge '96 Discharge of capacity. So this may cause failure of switch. It is recommended to be used as follows
depending on used voltage, for the purpose of protection of switch.
Capacitive Load
Inductive Load Inductive Load Inductive Load
Neon Lamp
2.5. Reed Relay and Protection Circuit
Glass Tube Contact
Inert Gas Magnetic Reed
Wire
SPST-NO
Single Pole-Single Throw
Normally Open
SPST-NC
Single Pole-Single Throw
Normally Closed
SPDT-NO/NC
Single Pole-Double Throw
Open / Closed Contact
Blue 1
Black 2
Single Contact NO
With Clemens
1 2
Reed Switch 1
Reed Switch 2
Single Contact NO
Reed Switch 1
Reed Switch 2
Single Contact NO
Normaly Closed Blue 1
Common Black 3
Normaly Open Brown 2
Single Contact NO/NC
With Cable With Socket

10
ELM 31 - 001 - 001 - 001 - 06 - 80 / 0 ELM 31, Horizontal Type, 304 St. St., 30 cm Cabled, NC, 1/8BSP
EXAMPLE
Order Form : Please consider sample models when coding!..
ELM
Horizontal Type, Ø 28mm , L= 45mm .............................31
Vertical Type, Ø 28mm , L= 72mm ..........................32
Horizontal Type, Ø 41mm , L= 70mm .............................41
Vertical Type, Ø 41mm , L= 92mm ..........................42
Horizontal Type, Ø 52mm , L= 80mm .............................51
Vertical Type, Ø 52mm , L= 120mm .......................52
Horizontal Type, Ø 73mm , L= 115mm ............................71
Vertical Type, Ø 73mm , L= 125mm ........................72
Cable, Jacketed (for bilge).........................................51s
Cabled..................................................................61
With Socket................................................................61s
With Metal Housing ...........................................61m
With Plastic Housing............................................81s
Interior Mounted......................................................62
Interior Mounted Montajlý OEM....................................63
CERTIFICATE
None......................................................................................0
CONNECTION
1/8 BSP.................................................................001
3/8 BSP.............................................................................003
1/2 BSP..........................................................................004
M10x1......................................................................081
Special.............................................................................x
MATERIAL
304 St. St. ......................................................................001
316 St. St. .........................................................................002
Special............................................................................x
CONTACT STRUCTURE
NO Reed Relay.................................................................06
NC Reed Relay...................................................................07
NO / NC Reed Relay....................................................08
ELECTRIC CONNECTION
Polyamide Big Socket P01.............................................50
Polyamide Small Socket P02.............................................51
PVC Cable (Max.60°C)................................................80
PVC Cable (Max.105°C)..........................................81
Silicon Cable (Max.200°C).................................82
OPTIONAL
None.................................................................... / 0
Wave Preventive Jacket, For ELM 31 and ELM 32 ..... / D1
Wave Preventive Jacket, For ELM 41 and ELM 42 ..../ D2
Wave Preventive Jacket, For ELM 51 and ELM 42..../ D3
8
E-GSM Device.................................................../ E-GSM
Level Control Device........................................../ SK-P2
Level Relay , 24VDC - 5A - .........................../ ESR24
Level Relay , 220VAC - 8A - ......................../ ESR220
CABLE LENGTH
30cm (Std.) .......................................................................001 Special............................................................................x
6
7

11
2.7.
WARNINGS !!!
Please pay attention to following matters in order to operate your level switch properly.
Please do not mount
slant way, otherwise
switch do not work correctly
Do not pull the cable strongly,
otherwise the characteristics
might be changed.
Please keep away from magnetic materials
like iron board ; otherwise the
characteristics might be affected.
Please do not dip cables
potting into liquids,otherwise
instulation problem may cause.
Please keep away from magnetic
field ,otherwise it might
be mis-operated.
Please do not drop ,
otherwise the characteristics
might be changed.
Vibration might be
caused instability. In case vapour splash cable potting points,insulation
problem may cause.
Excess current , to be drawn as
a result of direct connection to motor ,
may burn relay of switch
Do not remove the plastic parts
of the bottom of the switch body ,
do not loosen.
Please avoid using with liquids which
damage materials of parts ,
otherwise quality can not be
maintained accurately.
Do not remove the float from
connection part. Because its pin
might be damaged.

12
3. Failure Delection
If you find an error, try to eliminate it by using this table or send the instrument to our service address for repair.
The instrument should be repaired only by authorized service!
4. Disassembly of Instrument
Instrument should be disassembled while feeding and pressure is not available!
5. Service
6. Recalibration
Calibration is not required during long period useful life of a level switch.
7. Repair '96Manufacturer Address
If irreparable breakdowns occur, the instrument should be sent to us for repair purpose. Before this, the instrument should be
cleaned carefully and packaged so as not to be broken. Furthermore, you should also add a detailed explanation which
describes the breakdown while instrument is sent. If your instrument contacts with harmful substances, decontamination
report should be also sent additionally. In the event that instrument does not have any decontamination report or our service
department has doubts about instrument, repair process will not start until an acceptable report is sent.
8. Disposal
The instrument should be disposed according to 2002/96/EC and 2003/108/EC European Directives (waste electrical and
electronic instruments). Waste electrical and electronic equipment should not be mixed with domestic wastes!
If the instrument has contacted with harmful substances, special attention should be paid for its disposal!
9. Terms of Warranty
The instrument has warranty legally for 24 months after delivery date. Warranty demands are not accepted in case of
inappropriate operation, damage on the instrument or any modification on the instrument.
10. Terms of Return
In the return of materials, user should send an open list related to damage or problem, malfunction of the material
to be returned or its operation in the different modification, with the instrument. If it is required to return the
material, used in the dangerous, corrosive or toxic fluid, in this case, used part should be cleaned very carefully.
Security of personnel should be ensured. All products to be returned should be sent to our company address, which
we have stated.
The instrument does not require maintenance. If it is desired, residue accumulated inside should be blown according to kind
of fluid and instrument can be cleaned with soft cleaning solutions. Measures should be taken during the disassembly.
Breakdown
Fluid is leaking
It does not contact
or it contacts
continuously
Body was broken
Unsteady operation
in the contact
Thread is scraped
Probable cause
There is a hole on the body.
-Socket connection is not touched.
-Product was exposed to the magnetic field
in the ambient.
-Connetion angle is not corrrect.
-Contact may have been burned.
-Tightening the screws more than adequate during
the assembly.
-Product falling or taking a blow from outside.
-Product was exposed to the magnetic field in the ambient.
-Product was exposed to vibration.
-Product was exposed to high temperature.
Thread is scraped -Inform authorized service
Failure detection\correction
-Check that is worked under appropriate condition
and then contact with producer company.
-Check for socket connections.
-The factor which constitutes the magnetic field
should be removed or insulated.
-Correct assembly angle.
-Inform authorized service.
-Inform authorized service.
-The factor which constitutes the magnetic fieldshould
be removed or insulated.
-Vibration which will effect the product should
be prevented or it should be attached to any place
without vibration.
-Use in the appropriate opearating temperature.
If the instrument contacts with hazardous substances, necessary measures should be taken for decontamination!
Service -Manufacturer Company Name and Address:
LONCA PAZ. MAK. SAN. TÝC. A.Þ.Piyalepaþa Cad. Stad Sokak No: 29/6 Kasýmpaþa - ÝSTANBUL - TÜRKÝYE
Tel: [phone] Faks: 0212 297 70 32 E-Mail: [email protected] Web: www.ensim.com.tr
