Siemens SIMATIC NET RUGGEDCOM M2200 User manual

Edition 03/2020
Installation Manual
SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM M2200
https://www.siemens.com

SIMATIC NET
Rugged Ethernet Switches
RUGGEDCOM M2200
Installation Manual
Preface
Introduction 1
Installing the Device 2
Device Management 3
Communication Ports 4
Technical Specifications 5
Certification 6
03/2020
C79000-G8976-1044-16

Legal Information
Warning Notice System
This manual contains notices you have to observe in order to ensure your personal safety, as well as to prevent
damage to property. The notices referring to your personal safety are highlighted in the manual by a safety
alert symbol, notices referring only to property damage have no safety alert symbol. These notices shown be-
low are graded according to the degree of danger.
DANGER
indicates that death or severe personal injury will result if proper precautions are not taken.
WARNING
indicates that death or severe personal injury may result if proper precautions are not taken.
CAUTION
indicates that minor personal injury can result if proper precautions are not taken.
NOTICE
indicates that property damage can result if proper precautions are not taken.
If more than one degree of danger is present, the warning notice representing the highest degree of danger
will be used. A notice warning of injury to persons with a safety alert symbol may also include a warning relat-
ing to property damage.
Qualified Personnel
The product/system described in this documentation may be operated only by personnel qualified for the
specific task in accordance with the relevant documentation, in particular its warning notices and safety in-
structions. Qualified personnel are those who, based on their training and experience, are capable of identify-
ing risks and avoiding potential hazards when working with these products/systems.
Proper Use of Siemens Products
Note the following:
WARNING
Siemens products may only be used for the applications described in the catalog and in the relevant technical
documentation. If products and components from other manufacturers are used, these must be recommend-
ed or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and
maintenance are required to ensure that the products operate safely and without any problems. The permis-
sible ambient conditions must be complied with. The information in the relevant documentation must be ob-
served.
Trademarks
All names identified by ® are registered trademarks of Siemens AG. The remaining trademarks in this publica-
tion may be trademarks whose use by third parties for their own purposes could violate the rights of the own-
er.
Disclaimer of Liability
We have reviewed the contents of this publication to ensure consistency with the hardware and software de-
scribed. Since variance cannot be precluded entirely, we cannot guarantee full consistency. However, the in-
formation in this publication is reviewed regularly and any necessary corrections are included in subsequent
editions.
Siemens AG
Digital Industry
Process Automation
Postfach 48 48
90026 NÜRNBERG
GERMANY
© 03/2020 Subject to Change Copyright © Siemens 2020
All rights reserved

Table of Contents
Preface ............................................................................................................................................ v
Related Documents ................................................................................................................. v
Accessing Documentation ....................................................................................................... v
Registered Trademarks ............................................................................................................ v
Warranty ................................................................................................................................. v
Training .................................................................................................................................. vi
Customer Support .................................................................................................................. vi
Contacting Siemens ............................................................................................................... vii
1 Introduction ........................................................................................................................... 1
1.1 Feature Highlights ................................................................................................. 1
1.2 Description ............................................................................................................ 2
1.3 Required Tools and Materials ................................................................................. 3
1.4 Decommissioning and Disposal ............................................................................. 3
1.5 Cabling Recommendations .................................................................................... 4
1.5.1 Protection On Twisted-Pair Data Ports .................................................................... 4
1.5.2 Gigabit Ethernet 1000Base-TX Cabling Recommendations ...................................... 4
1.5.3 Supported Fiber Optic Cables ................................................................................ 5
2 Installing the Device ............................................................................................................. 7
2.1 General Procedure ................................................................................................. 7
2.2 Unpacking the Device ........................................................................................... 8
2.3 Mounting the Device ............................................................................................. 8
2.3.1 Mounting the Device to a Rack .............................................................................. 9
2.3.2 Mounting the Device to a Panel .......................................................................... 10
2.4 Connecting the Failsafe Alarm Relay .................................................................... 11
2.5 Connecting Power ............................................................................................... 12
2.5.1 Connecting AC or DC Power ................................................................................ 13
2.5.2 Wiring Examples .................................................................................................. 15
3 Device Management ........................................................................................................... 19
3.1 Connecting to the Device .................................................................................... 19
3.2 Configuring the Device ........................................................................................ 20
4 Communication Ports .......................................................................................................... 21
4.1 Copper Ethernet Ports ......................................................................................... 22
4.2 Fiber Optic Ethernet Ports ................................................................................... 23
5 Technical Specifications ...................................................................................................... 25
5.1 Power Supply Specifications ................................................................................ 25
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 iii

Table of Contents
5.2 Failsafe Relay Specifications ................................................................................ 25
5.3 Supported Networking Standards ........................................................................ 25
5.4 Copper Ethernet Port Specifications ..................................................................... 26
5.5 Fiber Optic Ethernet Port Specifications ............................................................... 27
5.6 Operating Environment ....................................................................................... 27
5.7 Mechanical Specifications .................................................................................... 27
5.8 Dimension Drawings ........................................................................................... 28
6 Certification ......................................................................................................................... 31
6.1 Approvals ............................................................................................................ 31
6.1.1 CSA ..................................................................................................................... 31
6.1.2 European Union (EU) .......................................................................................... 31
6.1.3 FCC ..................................................................................................................... 32
6.1.4 FDA/CDRH ........................................................................................................... 32
6.1.5 ISED .................................................................................................................... 32
6.1.6 ISO ...................................................................................................................... 33
6.1.7 RoHS ................................................................................................................... 33
6.1.8 Other Approvals .................................................................................................. 33
6.2 EMC and Environmental Type Tests ..................................................................... 33
iv RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16

Preface
This guide describes the RUGGEDCOM M2200. It describes the major features of the
device, installation, commissioning and important technical specifications.
It is intended for use by network technical support personnel who are responsible
for the installation, commissioning and maintenance of the device. It is also recom-
mended for use by network and system planners, system programmers, and line
technicians.
Related Documents
Other documents that may be of interest include:
Document Title Link
RUGGEDCOM ROS Configuration Manual https://support.industry.siemens.com/cs/ww/en/-
view/109737234
Accessing Documentation
The latest user documentation for RUGGEDCOM M2200 is available online at https://-
support.industry.siemens.com . To request or inquire about a user document, con-
tact Siemens Customer Support.
Registered Trademarks
RUGGEDCOM ™ and ROS™ are trademarks of Siemens AG.
Other designations in this manual might be trademarks whose use by third parties
for their own purposes would infringe the rights of the owner.
Warranty
Siemens warrants this product for a period of five (5) years from the date of pur-
chase, conditional upon the return to factory for maintenance during the warranty
term. This product contains no user-serviceable parts. Attempted service by unautho-
rized personnel shall render all warranties null and void. The warranties set forth in
this article are exclusive and are in lieu of all other warranties, performance guaran-
tees and conditions whether written or oral, statutory, express or implied (including
all warranties and conditions of merchantability and fitness for a particular purpose,
and all warranties and conditions arising from course of dealing or usage or trade).
Correction of nonconformities in the manner and for the period of time provided
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 v

Preface
Training
above shall constitute the Seller’s sole liability and the Customer’s exclusive remedy
for defective or nonconforming goods or services whether claims of the Customer
are based in contract (including fundamental breach), in tort (including negligence
and strict liability) or otherwise.
For warranty details, visit https://www.siemens.com or contact a Siemens customer
service representative.
Training
Siemens offers a wide range of educational services ranging from in-house training
of standard courses on networking, Ethernet switches and routers, to on-site cus-
tomized courses tailored to the customer's needs, experience and application.
Siemens' Educational Services team thrives on providing our customers with the es-
sential practical skills to make sure users have the right knowledge and expertise to
understand the various technologies associated with critical communications net-
work infrastructure technologies.
Siemens ' unique mix of IT/Telecommunications expertise combined with domain
knowledge in the utility, transportation and industrial markets, allows Siemens to
provide training specific to the customer's application.
For more information about training services and course availability, visit https://-
www.siemens.com or contact a Siemens Sales representative.
Customer Support
Customer support is available 24 hours, 7 days a week for all Siemens customers.
For technical support or general information, contact Siemens Customer Support
through any of the following methods:
Online
Visit http://www.siemens.com/automation/support-request to submit a
Support Request (SR) or check on the status of an existing SR.
Telephone
Call a local hotline center to submit a Support Request (SR). To locate a lo-
cal hotline center, visit https://w3.siemens.com/aspa_app/?lang=en.
Mobile App
Install the Industry Online Support app by Siemens AG on any Android,
Apple iOS or Windows mobile device and be able to:
• Access Siemens' extensive library of support documentation, includ-
ing FAQs and manuals
• Submit SRs or check on the status of an existing SR
• Contact a local Siemens representative from Sales, Technical Support,
Training, etc.
vi RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16

Preface
Contacting Siemens
• Ask questions or share knowledge with fellow Siemens customers
and the support community
Contacting Siemens
Address Siemens AG
Industry Sector
300 Applewood Crescent
Concord, Ontario
Canada, L4K 5C7
Telephone Toll-free: 1 888 264 0006
Tel: [phone]
Fax: [phone]
E-Mail [email protected]
Web https://www.siemens.com
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 vii

Preface
Contacting Siemens
viii RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16

Introduction 1
The RUGGEDCOM M2200 is a rugged, fully managed, modular Ethernet switch
specifically designed to operate reliably in electrically harsh and climatically de-
manding utility substation, railway and industrial environments. The RUGGEDCOM
M2200’s superior rugged hardware design coupled with the embedded Rugged Op-
erating System (ROS) provides improved system reliability and advanced cyber secu-
rity and networking features, making it ideally suited for creating Ethernet networks
for mission-critical, real-time, control applications.
The RUGGEDCOM M2200 ’s modular flexibility offers 1000BaseX fiber and
10/100/1000BaseTX copper port combinations. Optional front or rear mount connec-
tors make the RUGGEDCOM M2200 highly versatile for any application and can sup-
port multiple fiber connectors (SFP, GBIC, LC, SC) without loss of port density. The
RUGGEDCOM M2200 is packaged in a rugged galvanized steel enclosure with indus-
trial grade DIN, panel, or 48 cm (19 in) rack-mount mounting options.
1.1 Feature Highlights
Ethernet Ports
• Up to 9 x Gigabit Ethernet ports (copper and fiber)
• Up to 9 x 100Base-FX Fiber Fast Ethernet ports
• 2-port modules for tremendous flexibility
• Non-blocking, store and forward switching
• Supports many types of fiber (multimode, single mode, bidirectional single
strand)
• Full compliance with IEEE: 802.3, 802.3u & 802.3z
• Full duplex operation and flow control (IEEE 802.3x)
• Long haul optics allow Gigabit at distances up to 70 km
• Industry standard fiber optic connectors: LC, SC, SFP, GBIC
Rated for Reliability in Harsh Environments
• Immunity to EMI and heavy electrical surges
• Zero-Packet-Loss™ technology
• -40 to 85 °C (-40 to 185 °F) operating temperature (no fans)
• Conformal coated printed circuit boards (optional)
• 18 AWG galvanized steel enclosure
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 1

Introduction
1.2Description
Universal Power Supply Options
• Fully integrated, dual-redundant (optional) power supplies
• Universal high-voltage range: 88-300 VDC or 85-264 VAC
• Popular low voltage ranges: 24 VDC (10-36 VDC), 48 VDC (36-72 VDC)
• Screw or pluggable terminal blocks for reliable, maintenance-free connections
• CSA/UL 60950-1 safety approved to 85 °C (185 °F)
1.2 Description
The RUGGEDCOM M2200 features various ports, controls and indicator LEDs on the
display panel for connecting, configuring and troubleshooting the device. The dis-
play panel can be located on the rear, front or top of the device, depending on the
mounting configuration.
3
4
2
1
5
7
6
1 Fiber or Copper Ethernet Ports
2 Port Status Indicator LEDs
3 Mode Button
4 RS-232 Serial Console Port (RJ45)
5 Display Mode Indicator LEDs
6 Alarm Indicator LED
7 Power Module Indicator LEDs
Figure1.1 RUGGEDCOM M2200
Communication Ports Ports for communicating with other devices or accessing the
RUGGEDCOM RUGGEDCOM M2200 operating system are described
in "Communication Ports (Page 21)".
Port Status Indicator LEDs Port status indicator LEDs indicate the operational status of each
port, dependent on the currently selected mode.
Mode Color/State Description
Green (Solid) Link detected
Green (Blinking) Link activity
Status
Off No link detected
Green Full duplex mode
Orange Half duplex mode
Duplex
Off No link detected
2RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16

Introduction
1.3Required Tools and Materials
Mode Color/State Description
Green (Solid) 100 Mbps
Green (Blinking) 1000 Mbps
Orange (Solid) 10 Mbps
Speed
Off No link detected
Display Mode Indicator LEDs The display mode indicator LEDs indicate the current display mode
for the port status indicator LEDs (i.e. Status, Duplex or Speed).
Mode Button The Mode button sets the display mode for the port status indicator
LEDs (i.e. Status, Duplex or Speed). It can also be used to reset the
device if held for 5 seconds.
Alarm Indicator LED The alarm indicator LED illuminates when an alarm condition exists.
Power Module Indicator LEDs The power module indicator LEDs indicate the status of the power
modules.
•Green – The power supply is supplying power
•Red – Power supply failure
•Off – No power supply is installed
RS-232 Console Port The serial console port is for interfacing directly with the device and
accessing initial management functions. For information about con-
necting to the device via the serial console port, refer to "Connect-
ing to the Device (Page 19)".
1.3 Required Tools and Materials
The following tools and materials are required to install the RUGGEDCOM M2200:
Tools/Materials Purpose
AC power cord (16 AWG) For connecting power to the device.
CAT-5 Ethernet cables For connecting the device to the network.
Flathead screwdriver For mounting the device to a DIN rail.
Phillips screwdriver For mounting the device to a panel.
4 x #8-32 screws For mounting the device to a panel.
1.4 Decommissioning and Disposal
Proper decommissioning and disposal of this device is important to prevent malicious
users from obtaining proprietary information and to protect the environment.
Decommissioning
This device may include sensitive, proprietary data. Before taking the device out of
service, either permanently or for maintenance by a third-party, make sure it has
been fully decommissioned.
For more information, refer to the associated Configuration Manual.
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 3

Introduction
1.5Cabling Recommendations
Recycling and Disposal
For environmentally friendly recycling and disposal of this device and related acces-
sories, contact a facility certified to dispose of waste electrical and electronic equip-
ment. Recycling and disposal must be done in accordance with local regulations.
1.5 Cabling Recommendations
Before connecting the device, be aware of the recommendations and considerations
outlined in this section.
1.5.1 Protection On Twisted-Pair Data Ports
All copper Ethernet ports on RUGGEDCOM products include transient suppression
circuitry to protect against damage from electrical transients and conform with IEC
61850-3 and IEEE 1613 Class 1 standards. This means that during a transient electri-
cal event, communications errors or interruptions may occur, but recovery is auto-
matic.
Siemens also does not recommend using copper Ethernet ports to interface with de-
vices in the field across distances that could produce high levels of ground potential
rise (i.e. greater than 2500 V), during line-to-ground fault conditions.
1.5.2 Gigabit Ethernet 1000Base-TX Cabling Recommendations
The IEEE 802.3ab Gigabit Ethernet standard defines 1000 Mbit/s Ethernet commu-
nications over distances of up to 100 m (328 ft) using all 4 pairs in category 5 (or
higher) balanced, unshielded twisted-pair cabling. For wiring guidelines, system de-
signers and integrators should refer to the Telecommunications Industry Association
(TIA) TIA/EIA-568-A wiring standard that characterizes minimum cabling performance
specifications required for proper Gigabit Ethernet operation. For reliable, error-free
data communication, new and pre-existing communication paths should be verified
for TIA/EIA-568-A compliance.
The following table summarizes the relevant cabling standards:
Cabling
Category
1000Base-
TX Compliant
Required Action
< 5 No New wiring infrastructure required.
5 Yes Verify TIA/EIA-568-A compliance.
5e Yes No action required. New installations should be designed with Cate-
gory 5e or higher.
6 Yes No action required.
> 6 Yes Connector and wiring standards to be determined.
4RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16

Introduction
1.5.3Supported Fiber Optic Cables
Follow these recommendations for copper data cabling in high electrical noise envi-
ronments:
• Data cable lengths should be as short as possible, preferably 3 m (10 ft) in
length. Copper data cables should not be used for inter-building communica-
tions.
• Power and data cables should not be run in parallel for long distances, and
should be installed in separate conduits. Power and data cables should intersect
at 90° angles when necessary to reduce inductive coupling.
• Shielded/screened cabling can be used when required. Care should be taken to
avoid the creation of ground loops with shielded cabling.
1.5.3 Supported Fiber Optic Cables
The following fiber optic cable types are supported under the stated conditions.
Distance (m)Cable Type Wavelength (nm) Modal Band-
width (MHz·km) 100Base-FX 1000Base-SX 10GBase-SR
850 200 — 275 33OM1 (62.5/125)
1300 500 2000 — —
850 500 — 550 82OM2 (50/125)
1300 500 2000 — —
850 1500 — 550 300OM3 (50/125)a
1300 500 2000 — —
850 3500 — 550 400OM4 (50/125)a
1300 500 2000 — —
aLaser optimized.
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 5

Introduction
1.5.3Supported Fiber Optic Cables
6RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16

Installing the Device 2
The following sections describe how to install the device, including mounting the de-
vice, installing/removing modules, connecting power, and connecting the device to
the network.
DANGER
Electrocution hazard – risk of serious personal injury and/or damage to equip-
ment.
Before performing any maintenance tasks, make sure all power to the device has
been disconnected and wait approximately two minutes for any remaining energy
to dissipate.
WARNING
Radiation hazard – risk of serious personal injury
This product contains a laser system and is classified as a CLASS 1 LASER PRODUCT.
Use of controls or adjustments or performance of procedures other than those speci-
fied herein may result in hazardous radiation exposure.
NOTICE
This product contains no user-serviceable parts. Attempted service by unauthorized
personnel shall render all warranties null and void.
Changes or modifications not expressly approved by Siemens AG could invalidate
specifications, test results, and agency approvals, and void the user's authority to
operate the equipment.
NOTICE
This product should be installed in a restricted access location where access can only
be gained by authorized personnel who have been informed of the restrictions and
any precautions that must be taken. Access must only be possible through the use of
a tool, lock and key, or other means of security, and controlled by the authority re-
sponsible for the location.
2.1 General Procedure
The general procedure for installing the device is as follows:
NOTICE
The user is responsible for the operating environment of the device, including main-
taining the integrity of all protective conductor connections and checking equip-
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 7

Installing the Device
2.2Unpacking the Device
ment ratings. Make sure to review all operating and installation instructions before
commissioning or performing maintenance on the device.
1. Review the relevant certification information for any regulatory requirements.
For more information, refer to "Approvals (Page 31)".
2. Mount the device.
3. Connect the failsafe alarm relay.
4. Connect power to the device and ground the device to safety Earth.
5. Connect the device to the network.
6. Configure the device.
2.2 Unpacking the Device
When unpacking the device, do the following:
1. Inspect the package for damage before opening it.
2. Visually inspect each item in the package for any physical damage.
3. Verify all items are included.
NOTICE
If any item is missing or damaged, contact Siemens for assistance.
2.3 Mounting the Device
The RUGGEDCOM M2200 is designed for maximum mounting and display flexibili-
ty. It can be equipped with connectors that allow it to be installed in a 48 cm (19 in)
rack or directly on a panel.
NOTICE
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a reduc-
tion of ambient temperature and improve the long-term reliability of all equipment
mounted in the rack space.
Note
For detailed dimensions of the device with either rack or panel hardware installed,
refer to "Dimension Drawings (Page 28)".
8RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16

Installing the Device
2.3.1Mounting the Device to a Rack
2.3.1 Mounting the Device to a Rack
The RUGGEDCOM M2200 can be secured to a standard 48 cm (19 in) rack using sep-
arately purchased rack mount adapters. The adapters can be installed at the front or
rear of the chassis.
Each adapter kit includes four adapters.
NOTICE
Vibration hazard – risk of damage to the device
In high-vibration or seismically active locations, always install four rack mount
adapters (two at the front of the chassis and two at the rear).
NOTICE
Electrical/mechanical hazard – risk of damage to the device
Before installing the device in a rack, make sure of the following:
• When installing the device in a closed or multi-device rack, be aware the operat-
ing ambient temperature of the rack may be higher than the ambient tempera-
ture of the room. Make sure the rack is installed in a suitable environment that
can withstand the maximum ambient temperature generated by the rack.
• Make sure each device in the rack is separated by at least one rack-unit of space,
or 44 mm (1.75 in), to promote convectional airflow. Forced airflow is not re-
quired. However, any increase in airflow will result in a reduction of ambient
temperature and improve the long-term reliability of all equipment mounted in
the rack space.
• Do not exceed the maximum number of devices or weight restrictions specified
by the rack manufacturer.
• Do not overload the supply circuit. Refer to the over-current protection and pow-
er supply ratings specified by the rack manufacturer.
• Make sure the rack and all devices have a proper ground-to-Earth connection.
Pay particular attention to power supply connections other than direct connec-
tions to the branch circuit (e.g. power strips).
To secure the device to a standard 48 cm (19 in) rack, do the following:
Note
The device can be ordered with the communication ports located at the front or rear
of the device. Placing the ports at the rear allows all data and power cabling to be in-
stalled and connected at the rear of the rack.
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 9

Installing the Device
2.3.2Mounting the Device to a Panel
1. Make sure the rack mount adapters are installed on the correct side of the chas-
sis.
• To make the modules and ports accessible, install the rack mount adapters
at the rear of the chassis
• To make the management ports and LEDs accessible, install the rack mount
adapters at the front of the chassis
Note
The chassis features multiple mounting holes, allowing the rack mount adapters
to be installed up to 25 mm (1 in) from the face of the device.
1 2
3 3
1 Rear
2 Front
3 Rack Mount Adapter
Figure2.1 Rack Mount Adapters
2. If required, install adapters on the opposite side of the device to protect from vi-
brations.
3. Insert the device into the rack.
4. Secure the adapters to the rack using the supplied hardware.
2.3.2 Mounting the Device to a Panel
For panel installations, the RUGGEDCOM M2200 can be equipped with panel
adapters pre-installed on each side of the chassis. The adapters allow the device to
be attached to a panel using screws.
10 RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16

Installing the Device
2.4Connecting the Failsafe Alarm Relay
To mount the device to a panel, do the following:
1. Place the device against the panel and align the adapters with the mounting
holes.
11
11
2
2
2
1 Screw
2 Panel Adapter
Figure2.2 Panel Mounting
2. Install the supplied screws to secure the adapters to the panel.
2.4 Connecting the Failsafe Alarm Relay
The failsafe relay can be configured to latch based on alarm conditions. The NO
(Normally Open) contact is closed when the unit is powered and there are no ac-
tive alarms. If the device is not powered or if an active alarm is configured, the relay
opens the NO contact and closes the NC (Normally Closed) contact.
Note
Control of the failsafe relay output is configurable through RUGGEDCOM M2200 .
One common application for this relay is to signal an alarm if a power failure occurs.
For more information, refer to the RUGGEDCOM ROS Configuration Manual for the
RUGGEDCOM M2200.
The following shows the proper relay connections.
RUGGEDCOM M2200
Installation Manual, 03/2020, C79000-G8976-1044-16 11
