entegris CR8 Manual Setup guide

P/N 01-1011422 | REV. C 09/18 | INSTRUCTION SHEET
CR8 Manual
Toggle Valve
Repair instructions
INSTRUCTIONS
—
CR8 manual toggle valves including all
media end connections.
CAUTION! Never attempt to dis-
assemble the actuator. Actuator
has compressed springs that could
cause injury if released.
CAUTION! Remove any pressurized
sources from the valve before
attempting repair.
1. Repair kit contents: toggle actuator
assembly, diaphragm and bolt caps.
Consult factory if replacement bolts
and lock washers are needed.
Handle diaphragm so that seal surfaces
are not damaged
2. Remove four bolt plugs and discard.
NOTE that the media leak port is
parallel to port 1 and points in the
same direction.
3. Remove four bolts and washers ⁄ turn
at a time in a cross pattern (1, 2, 3, 4)
with a ⁄" hex key. Save bolts and lock
washers unless new ones have been
purchased separately from the repair
kit.
CAUTION! Point actuator away from
personnel for this step.
Actuator
assembly
Bolt plugs Diaphragm
Media
leak port
Port 1
12
4
3

CR8 MANUAL MULTI-TURN VALVE
2P/N 01-1011422 | Rev. C 09/18 | Entegris, Inc.
4. Apply less than 103 kPa (15 psig) air or
nitrogen pressure to port 2 with port 1
capped to separate actuator assembly
from the body. Discard actuator
assembly and diaphragm after
removal.
5. Clean the sealing surfaces within
the body by spraying with isopropyl
alcohol and drying with clean dry air
or nitrogen.
CAUTION! Do not contact the valve
body seal surfaces as it may cause
damage.
Inspect the body poppet seat for signs
of damage and/or wear. Do not touch
the poppet seat. Magnification may be
required. If damage is evident, replace
the entire valve.
6. Place handle in position shown and
install diaphragm onto actuator as-
sembly by threading it clockwise into
the threaded stem until it is finger tight.
7. Place handle in position shown and
install actuator assembly onto the
valve body with the media leak port
facing in the same direction as noted
in step 2.
8. Push down on the actuator assembly
so that the four bosses enter the holes
in the body.
Seal
surface
Poppet seal
Handle

CR8 MANUAL MULTI-TURN VALVE
3Entegris, Inc. | P/N 01-1011422 | Rev. C 09/18
9. Install four bolts and lock washers into
the holes in the actuator assembly.
CAUTION! It is very important to
perform step 10 exactly as directed.
10. Tighten with a torque wrench to
0.11 N•m (1 in•lb) torque in a cross
pattern (1, 2, 3, 4). Repeat this step
in 0.11 N•m (1 in•lb) increments until
1.02 N•m (9 in•lb) torque is reached.
11. A recommended (but not required)
step is to visually check the gap
between the body and actuator. It
should measure less than 1.1 mm
(0.045") and not vary by more than
0.38 mm (0.015"). Use a feeler gauge
or caliper to measure the gap at the
corners of the valve.
12. Media test: Put valve in open position
as shown and apply 553 kPa (80 psig)
air or nitrogen pressure to port 2.
Attach a tube to the vent port and
submerge the other end in water.
Wait for 30 seconds and then observe
for one minute. No bubbles should be
seen in the next one minute period.
13. Port seal test: With the valve in closed
position, apply 552 kPa pilot (80 psig)
pressure to port 2.
No leakage should be observed at port
1 over a 60-second period of time.
14. Install the bolt plugs.
1
24
3
