APPLICATION NOTE
Accelerator Card Installation
Introduction
This document describes how to install the accelerator card in the Aurorean
Network Gateway 7000 series (illustrated in Figure 1). The accelerator card
provides hardware-based IPSec encryption computation and processing, and
increases the throughput of the ANG-7000 series to 100 Mbps with 3DES
encryption. The hardware accelerator card works with Aurorean Release 3.1 or later.
NOTE
If you wish to install the accelerator card on a release 3.0 or earlier Network
Gateway, you must install Release 3.1 software before installing the card.
Refer to the Installation & Service Guide for detailed instructions on upgrading
the system software. If you do not have Release 3.1, contact Enterasys’ Global
Technical Assistance Center at 800 872-8400.
Figure 1 ANG-7000 Series
Before You Begin
Before you begin installation, you will have to gain access to the inside of the
ANG. If the ANG is mounted in a relay-style rack, you can install the card while
the ANG is in the rack if there is enough room on top of the ANG (at least 12
inches of clearance) to open the ANG’s cover. If there is not enough room you will
have to remove the ANG from the rack.
If the ANG is mounted into the rack with sliding rails, you can easily remove the
ANG from the rack.
ANG-7000

Page 2 of 10 AVN-AN-ACC-R10
Before You Begin Application Note
Accelerator Card Installation
Removing the ANG-7000 Series from the Rack
To remove the ANG-7000 series from the rack, you must first gracefully shut it down
to avoid hard disk errors. Follow the instructions below:
1. On your desktop, click Start, select Programs and double-click Command
Prompt.
2. Telnet to your ANG. Type: telnet
xxx.xxx.xxx.xxx (your ANG IP address) and
press ENTER.
3. Login (the default is
netadmin ) and press ENTER.
4. Type your password (the default is
netadmin ) and press ENTER.
5. Login as superuser by typing su - and press ENTER.
6. Type the default password welcome and press ENTER.
7. Save the ANG configuration and shut down all Enterasys services by typing
init 0 and press ENTER.
8. Wait a couple minutes then power off the ANG by holding the power button in
for 4 seconds.
9. Remove the Ethernet cables.
10. Unscrew the two screws holding the server flanges to the rack as shown in
Figure 2.
Figure 2 ANG Fastened to Rack
11. Slide the server out of the rack as far as possible.
12. When the assembly locks, press the lock arm on both sides of the rails to
release the server as shown in Figure 3.
Remove screws

Application Note Removing the Cover
Accelerator Card Installation
AVN-AN-ACC-R10 Page3of10
Figure 3 Removing the ANG from the Rack
13. Remove the server from the rack.
Removing the Cover
One screw fastens the cover to the ANG. To remove the cover, perform the following:
Figure 4 Top Cover Mounting Screw Location
1. Remove the screw holding the cover of the ANG as shown in Figure 4.
Lock Arm
ANG-7000
Power Status Drive Link 100Mbps
12
Link 100Mb
Cover
mounting
screw

Page 4 of 10 AVN-AN-ACC-R10
Removing the Cover Application Note
Accelerator Card Installation
2. Slide the cover toward the rear of the ANG. It will move back about a 1/2 inch.
Using your fingers in the three indents on the cover top, apply pressure
toward the rear of the ANG. Refer to Figure 5.
Figure 5 Top Cover Screw Removed
3. From the rear of the ANG, lift the back edge of the cover. It will open as shown
in Figure 6.
Figure 6 Top Cover Removed
Power Status Drive Link 100Mbps
12
Link 100Mb
Aurorean
NetworkGateway
ExternalEthernet
TrustedEthernet

Application Note Accelerator Card PCI Slot Location
Accelerator Card Installation
AVN-AN-ACC-R10 Page5of10
Accelerator Card PCI Slot Location
The PCI slots, used to house upgrades, are located in the center of the ANG as shown
in Figure 7. The accelerator card is housed in the left PCI slot.
Figure 7 Hardware PCI Slots
Removing the Card Flange Holding Plate
To remove the card flange holding plate, perform the following step:
HRemove the two screws as shown in Figure 7.
The blank insert for the card is now accessible as shown in Figure 8.
Accelerator card PCI slot
Card flange holding plate
mounting screws

Page 6 of 10 AVN-AN-ACC-R10
Installing the Accelerator Card Application Note
Accelerator Card Installation
Figure 8 Card Holding Plate Removed
Installing the Accelerator Card
To install the accelerator card, perform the following steps. Refer to Figure 9 below.
Figure 9 Accelerator Card
1. Remove the insert from the back of the server as shown in Figure 10.
NOTE
Note how this blank plate is mounted to the back of the server. The card flange
will be installed so that it replaces the blank insert.
Accelerator card blank insert

Application Note Installing the Accelerator Card
Accelerator Card Installation
AVN-AN-ACC-R10 Page7of10
Figure 10 Accelerator Insert Blank Removed
2. Align the accelerator connector fingers with the PCI connector. Set the card
flange over the slots that will capture and hold it to the back of the ANG as
shown in Figure 11.
Figure 11 Aligning the Accelerator Card with the PCI Connector
Accelerator PCI connector
Accelerator insert blank
Card flange holding plate

Page 8 of 10 AVN-AN-ACC-R10
Replacing the Cover Application Note
Accelerator Card Installation
3. Insert the card fingers into the PCI connector, making sure the card flange is
seated in the respective slots on the back of the ANG.
4. Replace the card flange holding plate with the two mounting screws.
This holding plate will capture the card flange and hold it securely against the
back of the ANG. Refer to Figure 12.
Figure 12 Accelerator Card Installed
Replacing the Cover
In order to replace the cover, reverse the three steps in the section “Removing the
Cover” on page 3.
1. Set the cover as shown in Figure 6. Place the front of the cover about 1/2 inch
behind the front edge of the chassis.
2. Make sure the sides of the cover are inside the sides of the cabinet. The slots
on the cover will sit over the mounting screw inserts on the side of the chassis
and allow the cover to seat itself on top of the chassis sides.
If the cover will not seat onto the chassis sides, the slots are not aligned with
the screw inserts. Move the cover (back or forward) accordingly to allow the
cover to seat itself onto the chassis sides.
3. Push the cover forward until the screw holes align themselves as shown in
Figure 4.

Application Note Re-installing the ANG-7000 Series in the Rack
Accelerator Card Installation
AVN-AN-ACC-R10 Page9of10
Re-installing the ANG-7000 Series in the Rack
Refer to the section “Removing the ANG-7000 Series from the Rack” on page 2, and
reverse the steps to re-install the server into the rack. Connect the power cord to the
server. Connect the Ethernet cables to the back of the unit.
Checking the Accelerator Card
If you have System Software Release 3.1 loaded on the ANG-7000 and subsequently
install the accelerator card, the ANG-7000 series will automatically detect the presence
of the card and activate it. No further software configuration is required. You can
verify that the accelerator is installed and working though by issuing the dmesg
command on the Command Line Interface (CLI). To do so, perform the following
steps:
1. On your desktop, click Start, select Programs and double-click Command
Prompt.
2. Telnet to your ANG. Type: telnet
xxx.xxx.xxx.xxx (your ANG IP address) and
press ENTER.
3. Login and press ENTER.
4. Type your password and press ENTER.
5. Issue the dmesg command by typing dmesg and press ENTER.
In the resulting output, look for the following text toward the end of the file to
verify the installation was successful and the card is working correctly:
Aurorean Network Gateway interface for Bluesteel Networks
ubs5501
ubs5501 library version 1.0
Bus 0, device 22533, IRQ 7, Address FFAE0000
Subsec: Device crytpo selftest passed! 0
If the accelerator is not installed, you will get the following text:
ubs5501 library version 1.0
Subsec: Device startup failed
The ANG-7000 series will operate properly without the accelerator card.
