User Reference Guide
User Reference Guide
Entrust Artista® CR805
Retransfer Card Printer
May 2021
527693-001EN, Rev H

2 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
Contents
The CR805 Card Printer................................................................................... 3
The CR805 Printer with Oponal Mul-Hopper .............................................. 4
Load Cards in a Single-Hopper Printer............................................................. 5
Use the Excepon Slot.................................................................................... 6
Load Cards in a Mul-Hopper Printer.............................................................. 7
Use the Mul-Hopper Excepon Slide ............................................................ 9
Replace the Color Ink Ribbon........................................................................ 10
Replace the Cleaning Sleeve ......................................................................... 12
Replace the Retransfer Film .......................................................................... 14
Empty the Reject Tray................................................................................... 16
Clear a K1 Horizontal Transport Card Jam ..................................................... 17
Clear a K2 Vercal Transport Card Jam.......................................................... 19
Clear a Flipper Card Jam ............................................................................... 20
Repair a Broken Ink Ribbon .......................................................................... 21
Repair Broken Retransfer Film ...................................................................... 22
Check the Power Connecon........................................................................ 23
Check the Data Connecon........................................................................... 24
Common Printer LCD Messages .................................................................... 25
Common Print Quality Concerns................................................................... 26
Cleaning Schedule ........................................................................................ 27
Use the Isopropanol Cleaning Card ............................................................... 28
Use the Adhesive Cleaning Card ................................................................... 31
Clean the Printhead...................................................................................... 35
Clean the Printhead Cam Rollers................................................................... 39
The CR805 Card Printer with Oponal CLM Laminator .................................. 41
Replace Laminator Supplies.......................................................................... 42
Empty the Laminator Reject Tray .................................................................. 44
Clear a Laminator Card Jam .......................................................................... 45
Clean the Laminator ..................................................................................... 46
Check the Laminator Power Connecon ....................................................... 48
Check the Laminator Data Connecon .......................................................... 49
Common Laminator LCD Messages ............................................................... 50
Notes ........................................................................................................... 51

AC
D
B
F E
G
H
J
M
LI K
N
O
P
User Reference Guide
Users Reference Guide 3
A Input Hopper
B Output Hopper
C Front Panel
D Printer Lock (oponal, see note)
E Printer Access Door
F User Reference Guide Slot
G Cleaning Spindle Handle (C3)
H Manual Advance Knob (K1)
I Ink Ribbon Cartridge (C1)
J Retransfer Cartridge (C2)
K Manual Advance Knob (K2)
L Rear Access Door Release (K3)
M Vercal Transport Area
N Reject Tray (RT1)
O Retransfer Film Cartridge Release
Buon
P Ink Ribbon Cartridge Release
Buon
LCD Front Panel
User Light &
User Buon
Up
Arrow
Enter
Status Lights:
Down
Arrow
Power
Buon
Ribbon
Cards
Front Panel
The CR805 Card Printer
If your printer does not have locks, disregard instrucons that ask
you to unlock or lock the printer.

A
B
C
D
E
F
G
H
I
J
4 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
The CR805 Printer with Optional Multi-Hopper
A = Output Hopper
B = Hopper Lock Bars
C = Input Hoppers 1–6
D = Mul-Hopper Lock
E = Lock Bar Release Buon (B1)
F = Cartridge Release Buons
G = Excepon Slide
H = Card Weight
I = Cartridge Door
J = Cartridge Door Release Buon

User Reference Guide
Users Reference Guide 5
Load Cards in a Single-Hopper Printer

6 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
Use the Exception Slot

a
1
23
3
2
1
User Reference Guide
Users Reference Guide 7
Load Cards in a Multi-Hopper Printer
1. Unlock the mul-hopper lock.
2. Slide the lock bar release buon (B1) to the le.
3. Rotate a lock bar to the le.

b
45
6
c
d
8 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
4. Press the cartridge release buon at the top of the
cartridge and open the cartridge door.
5. Li the card weight to the top of the cartridge and pull
it forward unl it locks in posion.
6. Load the cards into the cartridge.
Close the cartridge door to release the card weight so that it
rests on top of the cards.
Card Weight
Cards
Repeat for each input hopper cartridge.
Return all locks to the locked posion when nished.
Load Cards in a Mul-Hopper Printer (cont.)

a
b
User Reference Guide
Users Reference Guide 9
Use the Multi-Hopper Exception Slide
Excepon Slide
Pull out the mul-hopper excepon slide and insert the card.
Push in the excepon slide.

a
b
c
1
2
3
4
10 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
Replace the Color Ink Ribbon

d
e
f
g
User Reference Guide
Users Reference Guide 11
Replace the ink ribbon cartridge in the printer.
Click
Click
Replace the Color Ink Ribbon (cont.)

a
b
c
C3
12 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
Replace the Cleaning Sleeve

e
f
d
C3
User Reference Guide
Users Reference Guide 13
Replace the Cleaning Sleeve (cont.)

a
b
c
3
4
1
2
14 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
Replace the Retransfer Film

d
e
f
g
User Reference Guide
Users Reference Guide 15
Replace the retransfer lm cartridge in the printer.
Click
Click
Replace the Retransfer Film (cont.)

a
b
16 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
Empty the Reject Tray

a
b
c
User Reference Guide
Users Reference Guide 17
Clear a K1 Horizontal Transport Card Jam
Unlock the printer and open the printer access door.
Remove the retransfer lm cartridge.
Single-Hopper Printer
Turn the K1 manual advance knob counterclockwise to move
the jammed card into the output hopper.
Remove the card through the output hopper.
Replace the retransfer lm cartridge and close and lock the
printer.

a
b
18 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
Clear a K1 Horizontal Transport Card Jam (cont.)
Mul-Hopper Printer
1. Unlock the printer and open the printer access door.
2. Remove the ink ribbon and retransfer lm cartridges.
3. Locate the card in the printer. Turn the K1 manual
advance knob if necessary to access the card.
4. Remove the card from the printer.
Replace the cartridges and close and lock the printer.

a
b
c
User Reference Guide
Users Reference Guide 19
Clear a K2 Vertical Transport Card Jam
1. Unlock the printer and open the printer access door.
2. Press the K3 rear access door release to open the rear
access door.
3. Turn the K2 manual advance knob counterclockwise to
move the jammed card inside the vercal transport unl
it is accessible through the rear access door.
Remove the card through the rear access door.
Close the printer doors and lock the printer.

a
b
c
20 Arsta CR805 Retransfer Card Printer
Artista CR805 Retransfer Card Printer
Clear a Flipper Card Jam
Unlock the printer and open the printer access door.
Press the K3 rear access door release to open the rear access
door.
Rotate the ipper module to access the card.
Remove the card through the rear access door.
Close the printer doors and lock the printer.
