EOS SteamRock Basic User manual

INNOVATIVE SAUNA TECH N O L OGY
Made in Germany
SteamRock Basic
steam generator
EN Installation and operation manual
print no. 29344968 / 42.19
Subject to technical changes
Version 09 | rmware R0.91

2EN
English
Contents
1. Identification and legal notes................................................................................. 4
1.1 Manufacturer................................................................................................... 4
1.2 Copyright .......................................................................................................... 4
1.3 Identification of the device......................................................................... 4
1.4 Intended use.................................................................................................... 4
1.5 Foreseeable incorrect use........................................................................... 5
1.6 Applicable norms........................................................................................... 5
2. Safety advice ................................................................................................................. 6
3. Specifications................................................................................................................ 9
4. Delivery scope ............................................................................................................10
5. Installation ...................................................................................................................11
5.1 Installation overview ..................................................................................11
5.2 Construction and location of components ................................. 12-13
5.3 Prerequisites on the installation site.....................................................14
5.4 Mechanical installation..............................................................................14
5.5 Opening water tank ....................................................................................16
5.6 Checking the level sensor.........................................................................17
5.7 Water supply and drain..............................................................................18
5.8 Steam pipe connection..............................................................................18
6. Electrical connection................................................................................................19
6.1 SteamRock Basic 18 kW terminals................................................................19
6.2 SteamRock Basic 9 kW terminals...................................................................20
6.3 Inner wiring diagrams................................................................................ 21-22
6.4 Connection to Emotouch II+ Steam.............................................................23
6.5 Connection to Emotouch II+ Sauna, Emotec H, Econ H .......................24
6.6 Connection to Econ S2......................................................................................25
6.7 Leakage current...................................................................................................26
6.7 Special advice for water quality.....................................................................26
7. Cleaning system.........................................................................................................27
7.1 General information ..........................................................................................27
7.2 Setup and operation of the cleaning system ...........................................28
8. Power selection..........................................................................................................29
9. Operation modes.......................................................................................................31
10. General operation .....................................................................................................33
11. Maintenance and servicing....................................................................................34
12. Troubleshooting ........................................................................................................35
13. Disposal.........................................................................................................................36
14. Warranty .......................................................................................................................38

3
EN
Introduction
Dear customer
Thank you very much for purchasing EOS sauna & steam equipment. You have purchased a mod-
ern, technically advanced product which will provide you with years of reliable operation.
EOS steam generators have been designed and tested to comply or exceed the currently applica-
ble European safety norms and are produced in our factory in accordance with the quality man-
agement norms DIN EN ISO 9001:2008.
This installation manual or operating guide is intended for your information. Please read it careful-
ly before installing and operating the steam generator, in order to prevent damages of the device
or physical injuries. Please keep this document for further references.
We wish you a pleasant and relaxing time in your steam room.
Your EOS team.

4EN
1. Identication
1.1 Manufacturer
EOS Saunatechnik GmbH
Schneiderstriesch 1
D-35759 Driedorf, Germany
Tel.: [phone]
Fax: [phone]
1.2 Copyright
The copyright owner of the present installation manual and operating guide is EOS Saunatechnik
GmbH.
1.3 Identication of the product
Steam generator SteamRock Basic
1.4 Intended use
The SteamRock Basic steam generator is intended for production of steam in steam rooms or sau-
na rooms with humid operation. The SteamRock Basic requires an external control unit (e.g. Econ
S2) which is not included in the scope of delivery. Third party control units may not be used with-
out prior written consent of EOS Saunatechnik GmbH.

5
EN
1.5 Foreseeable incorrect use
Following may be regarded as foreseeable incorrect use:
• Steam room size does not match the steam generator power (incorrect power selection).
• Operation without legally required safety and protection features.
• Operation without proper knowledge of the safety advices (chapter 3).
• Operation without adherence to the required operation rules, maintenance and servicing re-
quirements.
• Operation of the device after unauthorized technical alterations or repairs.
• Operation or use by infants or persons with limited mental abilities without the proper prior
instruction.
• Operation or use by persons with certain ailments or health conditions, such as for instance
heart and cardiovascular disorders, which might lead to physical injuries through the use of a
sauna or a steam room (a doctor should be consulted in advance).
1.6 Applicable norms
DIN EN 60335-1:2012-10 Household and similar electrical appliances - Part 1: General re-
quirements
DIN EN 60335-2-53:2012-06 Household and similar electrical appliances. Safety - Part 2-53:
Particular requirements for sauna heating appliances and infra-
red cabins
DIN EN 60335-2-98:2009-04 Household and similar electrical appliances. Safety - Part 2-98:
Particular requirements for air humidiers
DIN EN 60335-2-101:2009-02 Household and similar electrical appliances. Safety - Part 2-101:
Particular requirements for vaporizers
DIN EN 1717:2011-08 Protection against pollution of potable water installations and
general requirements of devices to prevent pollution by back-
ow
DIN 1988-100:2011-08 Codes of practice for drinking water installations - Part 100: Pro-
tection of drinking water, drinking water quality control
DIN EN 55014-1:2012-05 Electromagnetic compatibility - Requirements for household ap-
pliances, electric tools and similar apparatus - Part 1: Emission
DIN EN 55014-2:2009-06 Electromagnetic compatibility - Requirements for household ap-
pliances , electric tools and similar apparatus - Part 2: Immunity
DIN VDE 0100-703:2006-02 Low voltage installations – Requirements for special installations
or locations - Rooms and cabins containing sauna heaters
DIN EN 82079:2012 Requirements for instruction manuals in the European Market

6EN
2. Safety advices
!DANGER
Risk of re and danger of electric shock.
Risk of re by incorrect installation.
• Make sure to have the steam generator installed only by an ap-
propriately qualied specialist according to the present instruction
manual.
• All electrical connections in the steam generator and other equip-
ment with a permanent connection may be only carried out by an
appropriately qualied and licensed electrician. All applicable lo-
cal legal codes and safety requirements should be observed. In the
case of a warranty claim a proof of such installation (e.g. invoice of
the electrician) should be presented.
!DANGER
Risk of health damage by too long operation time.
• If the device is used in a commercial (public) sauna so that it does
not switch o automatically after a certain time, then it should be
appropriately supervised.
• By operation with certain time intervals or by switching through
a remote system the sauna cabin should be visually inspected be-
fore it is switched on.
• This is also required if the device has been set to a stand-by mode
in order to be switched on at a later time.

7
EN
!DANGER
Risk of scalding.
Hot steam may cause burns, scalding and dangerous to life injuries, if
the steam generator has not been properly installed or is operated not
as per its intended use.
• During planning and installation make sure, that the steam out-
put always remains open and may not be blocked.
• The overpressure release vent and its drain pipe should be in-
stalled and connected so, that it the case of a unforeseen release
of hot water by overpressure there is no risk of scalding.
!DANGER
Danger to life and risk or dangerous to life injuries
The use of sauna by persons with certain health conditions may cause
severe dangerous to life injuries or even death.
• Please consult a doctor before using a sauna if there is possibility
that the use of sauna may lead to heath damages.
• Please make sure to read carefully the present installation manual
and operating guide before using the steam generator.

8EN
!WARNING
Risk of burns through hot surfaces in the device.
The steam generator has hot surfaces, e.g. pipelines, water tank,
which may cause burns.
• Keep a secure distance to hot surfaces of the device.
!ATTENTION
So-called plasticizers are able to modify the water surface tension in the
steam generator water tank.This can lead to strong foaming, so that the
hot water may come out of the steam outlet. Furthermore this can lead
to incorrect water level detection and overheating errors.
Please ensure that the water supply is clear of plasticizers or similar sub-
stances.
Plasticizers and similar substance are, among others, oils (e.g. essenc-
es), detergents, lubricants or specic chemicals contained in plastics like
PVC. It must be ensures that the water supply line does not use any ma-
terials which may contain plasticizers.
!ATTENTION
In areas with hard water (over 5° dH), it is recommended to install a water
softener to remove lime or a system for automatic descaling.
The softener must not be foam-forming or contain harmful chemicals. This is
especially advisable in public areas.
!ATTENTION
This device can be used by children over the age of 8 or by persons with
physical, sensory, or mental disabilities, or who have inadequate experi-
ence and knowledge, if they are instructed on the safe use of the device,
or initially supervised, and if they understand the risk associated with
this device. Children may not play with this unit. Children may not
clean or service the unit unless supervised by an instructed adult.
Children should be supervised to ensure that they do not play with the
unit.

9
EN
3. Specications
Dimensions H x W x D [mm] 670 x 460 x 350 mm
Weight [kg] 28 kg (type 1 - 9 kW) / 30 kg (type 2 - 18 kW)
Water supply pressure [bar] 2 - 8 bar
Operation pressure max. [bar] Pressureless type steam generator
Performance at 3 bar [steam/h] 3 kW - 4 kg/h, 6 kW - 8 kg/h, 9 kW - 12 kg/h, 12 kW -
16 kg/h, 15 kW - 20 kg/h, 18 kW - 24 kg/h
Protection class IP x4
Water tank High grade stainless steel
Internal overheating protection Thermofuse with capillary sensor, 3-pole circuit
breaker
Heating system External heating elements, switchable in 3 kW steps
Cleaning and drain system Integrated automatic descaling and draining
system, built-in peristaltic pump, external 5 l
container for cleaning liquid with level probe
Water drain 1“ drain pipe at the unit’s bottom side
Water level control Automatic with overheating protection
Control system not included (external control unit required)
Water supply ¾“ external thread
Steam output 1 1/4“ external thread, with 2-part brass union
Ambient temperature (operation / storage) 5°C to 45°C / 0°C to 60°C
Ambient humidity (operation) 30% bis 75%
Outputs / Connections • Mains (pre-mounted mains cable)
• Connection for external control unit
• Connection for essence level probe
Power output [kW] type 1 - 3.0 / 6.0 / 9.0 kW (9 kW default)
type 2 - 9 / 12 / 15 / 18 kW (18 kW default)
Fuse protection [A] type 1 - 3 x 16 A
type 2 - 3 x 32 A
Min. cross section power supply line type 1 - 5 x 2,5 mm²
type 2 - 5 x 6,0 mm²
Power supply 400 V 3N AC, 50/60Hz, with pre-mounted mains
cable with Cekon-type plug

10 EN
4. Delivery scope
SteamRock Basic delivery includes:
• SteamRock steam generator
• 4 mounting screws 5 x 35
• 4 dowels S6
• 2-part brass union 1 1/4“ to 35 mm
• 0,5 m steel braided water supply hose 500 mm 3/8“ to 3/4“
• 5 l plastic container for descaler liquid with level probe
• Installation manual and operating guide
• Pre-mounted power supply cable with CEKON type plug (16A or 32A)
• Steam outlet
Accessories (optional)
• Filtering grill (for drain blockage prevention) item 94.6819
Notice:
This ltering grill is recommended for use in regions with water containing a high quantity of lime.
The grill will retain deposits falling o the inner surfaces of the water tank and therefore exclude the
risk of possible blockage of the drain.

11
EN
5.1 Installation overview
5. Installation
1000
300
150-250
1600 - 1700
floor drain
Steam pipeline
Cabin light
Steam outlet
Door Exhaust vent in ceiling
Temperature sensor*
Floor drain in the steam room
Container for descaler liquid
Steam generator
* for temperature sensor installation de-
tails please refer to the corresponding
installation manual of the control unit

12 EN
Discharge hose from over-
pressure release valve
Pilot lamp for operation
status and error codes.
Water supply connection,
3/4”external thread
Drain
Descaler level
probe cable
Cable glands for con-
trol unit connection
Connection tube for desca-
ling (cleaning) system
Steam output pipe, 1 1/4”
external thread
5.2 SteamRock Basic - construction overview
Overpressure release valve
with drain hose
Water tank / water tank lid
Water filling line (slow)
Water filling line (fast) /
pressurized water injection
level sensor
Descaler filling tube
Steam output pipe with
pivot joint
Chassis with ventilation
openings
Bottom
view
view
from top
Power supply cable with plug
Sicht von
oben

13
EN
Water tank
Overheating protection
and insulation jacket
Terminal block with colour
coded terminals
Main board
Water supply tubes
Dual-way water inlet valve
Pilot lamp for operating
status and error codes
Fuse switches
9 kW - F1/F2/F3
18 kW - F1/F2/F3/F4/F5/F6
Peristaltic pump for clean-
ing / descaling system
Connection tube for desca-
ling (cleaning) system
Thermofuse with manual
reset button
Solenoid valve for main
drain line, discharge open-
ing at the bottom
Contactors
Mains connection cable
with Cekon plug

14 EN
5.3 Installation site and requirements
The steam generator is designed for installation outside steam room (sauna) only and should be
connected to the steam room (sauna) with a steam pipeline. The following ambient climate condi-
tions should be observed at the installation site:
• Ambient temperature during operation 5°C to 40°C
• Air humidity during operation 30% to 75% rel. air humidity
• Storage temperature 0°C to 60°C
5.4 Mechanical installation
The SteamRock Basic is a wall-hanging device. It is mounted to the wall with 4 screws. Please en-
sure that the wall is able to carry the load of min. 45 kg. We recommend to allow certain reserve
for safety. Please consider that the steam generator is subject to light vibrations during operation.
To mount the steam generator rst take the outer housing o the chassis. See pic. 1 below.
• Remove two xation screws at the bottom side on the left and on the right.
• Pull the side walls of the housing slightly apart, so that the mounting aps of the housing
are not blocked by the chassis.
• Tilt the housing with the bottom slightly forward (from wall) and lift it upwards. Take the
housing o the chassis.
1.
3.
4.
2.
knock-out circle for steam
pipe installation upwards
Pic. 1 alle Maße in mm
535
670
min. 250
1000
460
420
min. 100 min. 100
all sizes in mm

15
EN
Pic. 2
Drill 4 mounting holes in the wall as shown on the template below. If
necessary use the appropriate dowels to securely mount the screws in
the drilled holes.
At rst screw in the two upper screws. As shown on the pic. 2.
please make sure to leave 3 mm gap between the screw
head and the wall surface.
Now hang the steam generator with the
corresponding mounting holes in the chas-
sis on these two screws. Make sure that the
generator is hanging vertically (by using a
spirit level).
After that secure the generator by screw-
ing the bottom pair of screws to the wall
through the corresponding bottom mount-
ing holes in the chassis. After that also tight-
en the upper pair of screws.
See the pic. 3 for details.
3
535
420
alle Maße in mm
all sizes in mm
Pic. 3
Important note:
Make sure that the device is
mounted vertically and ho-
rizontally.

16 EN
5.5 Opening water tank
The water tank can, if necessary, be opened in the following way:
2.
Loosen 6 allen screws
above on the cover.
4.
Loosen 2 screws on
the bottom plate.
4
8
1. Disconnect the generator from the power supply and turn o the water.
2
8.
Lift the cover with the
connected compo-
nents, slightly till it
to the right and take
it out of the vessel.
7.
Disconnect the steam
pipe connection.
33.
Loosen the descaler
tube and pull it o
the nozzle.
5.
Loosen both hose
clamps on the double
valve in order to pull
o the exible water
pipe.
5
6.
Unplug 2-core cable
from the level probe
at the main board.
1
7
6

17
EN
9. Put the cover on the vessel again. Make sure that the silicone seal ring ts on the mounting holes
so that the Allen screws can be tightened. Also pay attention that the bae plate on the bottom
side of the cover will not be bended. Connect the steam pipeline back to the steam output con-
nector on the steam generator.
10. Before commissioning verify that all screws are tight. The entire system has to be checked on
tightness.
5.6 Checking the level probe
level sensor current flow
Loosen the 3 Allen screws (A), lift disc (B) with seal (C) and pull level probe upwards out of the tank.
Unplug the level probe cable from the the main board
The level probe can be checked for proper functioning with a regular multimeter.
The float in top position - signal should pass through (resistance 0 W), float in bottom position - no
signal should pass through (resistance ∞).
A
B
C
open

18 EN
• Connect the cold water supply using the included water connection hose to the water
supply connector (3/4”) on the bottom side of the generator. The supplied water should
have drinking water quality. The water pressure in the supply line should be 2 to 8 bar.
• Connect the main drain and the additional drain hose from overpressure release valve at
the bottom of the generator to the drain system. Please notice that the generator has an
automatic drain system.
• Caution: the drain water may be hot, the appropriate precautions should be met.
• The limescale contained in water will lead to deposits on the inner surfaces of the water
tank, which may cause overheating and considerably reduce the service life of the heat-
ing elements and of the generator.
• By commercial use it is obligatory to install a water softening system in order to reduce
the amount of limescale getting into the generator with water. By home use such wa-
ter softening system is recommended by water hardness from 14° dH (~ 2,5 mmol/l).
Make sure to observe additional notes on the pages 35-37!
Notice: damages resulting from the limescale deposits are excluded from warranty!
Important Notice:
Please observe the EN 1717 / DIN 1988 and DIN 1986 / EN 12056 4 requirements. It must be ensured
that the water may not ow back into the water supply system. If necessary the additional equipment
has to be installed to prevent the back-ow. Please consult your water supplier or specialist dealer.
5.7 Water supply and drain connection
Important! The diame-
ter may not be smaller!
Important! No sharp
bends in the drain pipe!
How to connect the drain:

19
EN
5.8 Steam pipe connection
• The steam pipe should be heat-resistant to at least 110°C. We recommend copper or
stainless steel pipes with Ø35 mm. Do not use small diameter steam pipes!
• The steam pipeline should be reclining towards the steam outlet. Sharp angles should
be avoided. If there is a risk that the water condensate may block the pipeline a syphon
has to be integrated. The layout of the pipeline should prevent the back ow of the con-
densed water into the generator.
• Use the supplied 2-part brass union 1 ¼“ to 35 mm for steam pipe
connection. This will facilitate the connection or disconnection
of the pipeline.
• The steam output pipe features an innovative pivot
joint connection at the water tank lid.You can turn the
pipe around to rise upwards. For this unscrew the x-
ation nut in the bottom plate and turn the steam pipe
around. Push out the knock-out circle in the housing
before mounting it back on the chassis.
Notice: by the use of essence dosing systems the essence
injection line should be connected to the steam pipe so that no essences may get into the
water tank with the back ow of the steam or water condensate. Even the small quantity
of essences in the water tank may lead to malfunctions. Place the injection point possible
close to the steam outlet.
Pic. 4
Pic. 5
Connect and lead the steam pipe correctly!
• No sharp bends.
• Should decline towards steam outlet.
• Diameter may not be smaller.
• Avoid water condensation in the pipe.

20 EN
6. Electrical connections
Danger! Risk of electric shock. In the event of a faulty electrical installation,
there is a risk of electric shock (even after completion of the installation work).
The electrical installation may only be carried out by a qualied electrician.
The connections are made according to the connection diagram or according to the following
terminal diagrams - see Fig. 6 or Fig. 7.
Make the electrical connections as shown on the connection diagrams on pages 18 - 19.
The generator has a pre-mounted power supply cable with a Cekon type plug (16A or 32A). For
connection the appropriate socket with fuse protection has to be used.
The control unit is connected as shown in the connection diagram on pages 21-22.
In order to simplify the installation, the terminals are color-coded and numbered individually.
Connection terminals and power se-
lection switches (18 kW model).
6.1 SteamRock Basic 18 kW connec-
tion terminals
Pic. 6
Terminal Marking Description
1 L1 L1 phase
2 L1 (L4)
3 L2 L2 phase
4 L2 (L5)
5 L3 L3 phase
6 L3 (L6)
7 N N
11 N (N line 2)
15 PE PE power supply
16 PE (PE power supply 2)
21 N N - control unit
22 S1 S1 - control unit
23 Wb Steam on - control
24 PE PE - control unit
25 N Signal - output
26 A2 Signal - output
27 Fragrance Fragrance
28 PE PE - Fragrance
Terminal diagram for SteamRock Basic with 18 kW, 400 V con-
nection (3 x 32 A).
