Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 1 of 18
EPILOG LASER
16371 Table Mountain Parkway
Golden, Colorado 80403
Phone [phone]
FAX [phone]
www.epiloglaser.com
Laser Alignment
For the Epilog Fusion CO2
10/10/2013
Requirements:
Tools:
•5/32” Allan Wrench
•3/32” Allan Wrench
•#1 Phillips Screwdriver
•Masking Tape (white)
•Alignment Target (provided with engraver)
•Manual Focus Gauge (provided with engraver)
•Safety Glasses (Lexan or Polycarbonate)
Overview:
This document illustrates the procedures required to align the laser inside of the
engraver. Safety glasses are required to be worn throughout the entirety of the following
procedures.

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 2 of 18
While performing the laser alignment all persons present in the room
during the performance of this procedure must be equipped with adequate
eye protection (Lexan safety glasses, eyeglasses or goggles), and that no
one looks or places any part of his or her body into the path of the laser
beam.
This procedure requires that the laser be operated with the
engraver’s door safety interlocks defeated or with protective covers
removed. While the laser power levels are reduced from those of normal
operation, they are sufficient to inflict eye injury or burns.

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 3 of 18
When to align the laser:
The Laser Alignment Procedure can be performed if any of the following apply to you.
•You are experiencing a general Loss of Power.
•You are experiencing ‘Fading’ in one of the corners of the table.
•You are losing power in certain positions on the table.
•You have replaced the X-Axis Rail.
•You have replaced a Laser Tube.
•You have replaced a Mirror or Optic.
•The engraver has been moved or transported.
Before you start…
Direction
Many of the instructions provided in this procedure will have a direction given,
such as left hand side or right hand side. Unless otherwise stated, these are all provided
as though you were facing the machine from the front.
Table Positions
For the following procedures the table will be broken into four (4) positions. Each
position is identified by its relative distance to the laser source and corresponds with the
mirror to adjust for that position.
1
2 4
3

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 4 of 18
Mirrors
The three (3) adjustment mirrors used for alignment are on the left side of the
engraver. The mirror numbers correspond directly with the positions on in the bed; for
example, if the lens carriage is in Position #1 than you will only adjust Mirror #1.
Jogging the lens carriage
When moving the lens carriage on the engraver you will be use the “Jog” mode
on the keyboard. When asked to move the lens carriage into a position you only need to
move it as far as practical. Move the carriage as far into the requested corner as you
can while maintaining the ability to see the red dot pointer on the alignment target.
Laser Jog Power
Set the lasers Jog Power to a level that is high enough to mark the tape but not
so high as to burn a large hole in the tape and target. Setting the lasers “Jog” power is
detailed in your machines owner’s manual. 10% is a good starting point.
Mirror #1
Mirror #2 Mirror #3

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 5 of 18
Procedure A: Align the Red Dot Pointer to the Cutting Beam
If you are performing the alignment due solely to a replaced Mirror or X-Axis Rail,
please move on to procedure B. For all other alignments this procedure must be
completed.
Step 1: Remove rear panel
Locate and remove the eight (8) 5/32” Allen screws which secure the lower rear
panel to the engraver. Remove the panel from the engraver.
Step 2: Attach alignment target
Locate the alignment target and place it into the left side of the lens carriage.

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 6 of 18
Step 3: Attach alignment target
Place a square of masking tape over the alignment target. The brown square
over the alignment target represents a piece of masking tape placed on the alignment
target.
Step 4: Make burn
Make sure the engraver is powered up. Use the arrow keys on the engraver’s
keypad to select Jog mode.

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 7 of 18
Step 5: Make burn
Use the Joystick on the engraver’s keypad to move the Lens Carriage to Position
4 on the bed.
Step 6: Make burn
To fire the laser in Jog mode, Depress the Fire Laser key (indicated by Arrow in
picture below) and move the Joy stick to the left or the right. This will need to be done
fairly quickly as it takes little power to burn the masking tape.
Burn simulated for photo
If you cannot get a burn in this position, please contact Epilog technical support.
4

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 8 of 18
Step 7: Activate red dot pointer
Press the Pointer key on the engraver’s keypad to activate the Red Dot Pointer.
The pointer should appear on the tape covering the Alignment Target.
Marks simulated for photo
Step 8: Align red dot to burn
Locate the Red Dot Pointer Mount in the rear of the engraver.

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 9 of 18
Step 9: Align red dot to burn
Use the adjustment screws on the Red Dot Pointer Mount to move the Red Dot
Pointer to the burn mark on the tape.
Marks simulated for photo
Once the Red Dot Pointer is aligned with the burn mark on the tape in Position 4,
it will accurately represent the path of the Cutting Laser for the rest of the alignment.
You may now remove the masking tape from the Alignment Target.

Laser Alignment
Fusion CO2
Revision Date: 10/10/2013 pg. 10 of 18
Procedure B: Aligning the laser
Step 1: Remove the left hand panels.
With the engraver powered on. Remove both the Left side Access Panels to gain
access to the mirrors. There are two black Panel Locks per panel holding them in place.
Using a 5/32” Allen wrench, turn the black Panel Locks ¾ of a turn counterclockwise.
Place the panels aside.
Step 2: Remove upper mirror access panel
Using the #1 Screwdriver, remove the Upper Mirror Access Panel.
