Epilog Laser Legend 6000 User manual

Owner's Manual for EPILOG Legend Model 6000
Revision E, December, 2000
500 Corporate Circle - Suite L
Golden, CO 80401
Phone [phone]
Fax [phone]
Technical Support [phone]

Owner's Manual for EPILOG Legend Model 6000
December, 2000
TABLE OF CONTENTS
Section Page No.
Table of Contents ii
HOW TO USE THIS OWNER’S MANUAL ............................................................................IV
STRUCTURE OF THE MANUAL...............................................................................................iv
1) GETTING STARTED...........................................................................................................1
UNPACKING YOUR MACHINE................................................................................................1
CONNECTING THE COMPUTER..............................................................................................2
CONNECTING THE EXHAUST .................................................................................................3
CONNECTING POWER...............................................................................................................4
CONFIGURING YOUR COMPUTER – PRINT DRIVER INSTALLATION...........................5
2) SAFETY..................................................................................................................................6
LASER SAFETY ...........................................................................................................................6
ELECTRICAL SAFETY ...............................................................................................................7
FIRE SAFETY ...............................................................................................................................7
SAFETY FEATURES AND REGULATORY COMPLIANCE..................................................8
3) DO’S AND DON’TS ............................................................................................................13
DON’T! ..........................................................................................................................................13
DO ..................................................................................................................................................13
4) JOB SET UP GUIDE...........................................................................................................14
5) USING THE EPILOG LEGEND PRINT DRIVERS.......................................................17
INSTALLING THE STAMP DRIVERS.......................................................................................17
USING THE LEGEND ENGRAVER PRINT DRIVER ..............................................................17
USING THE EPILOG LEGEND RUBBER STAMP PRINT DRIVER......................................21
6) USING THE EPILOG LEGEND.......................................................................................25
KEYBOARD COMMANDS.........................................................................................................25
LEGEND LCD MENU HEADINGS ............................................................................................28
LEGEND LIQUID CRYSTAL DISPLAY....................................................................................29
OPTICS ..........................................................................................................................................34
LOADING YOUR WORK............................................................................................................35
OPERATION .................................................................................................................................35
7) ENGRAVING MACHINE MAINTENANCE...................................................................36
CLEANING - IMPORTANT! .......................................................................................................36
LASER TUBE................................................................................................................................38
8) SPEED AND POWER RECOMMENDATIONS .............................................................39
35 WATTS OR LESS ....................................................................................................................39
50 WATTS OR GREATER...........................................................................................................40
9) NETWORK PRINTING .....................................................................................................41
SERVER-LESS PRINTING WITHOUT A HUB.........................................................................41
SERVER-LESS PRINTING USING A HUB ...............................................................................42
SERVER BASED PRINTING.......................................................................................................43
INSTALLING INTELLISCRIBE: ................................................................................................43
10) ENGRAVING TECHNIQUES...........................................................................................49
ACRYLIC.......................................................................................................................................49
ANODIZED ALUMINUM............................................................................................................50
BRASS - PAINTED.......................................................................................................................50
GLASS ...........................................................................................................................................52
NOTARY SEALS - DELRIN........................................................................................................53
PLASTIC........................................................................................................................................54
WOOD............................................................................................................................................55
11) MEMORY CONFIGURATION ........................................................................................59
SINGLE JOB MODE:....................................................................................................................59
MULTIPLE JOB MODE:..............................................................................................................59

Owner's Manual for EPILOG Legend Model 6000
December, 2000
TABLE OF CONTENTS
Section Page No.
Table of Contents iii
12) OPTIONAL EQUIPMENT ................................................................................................60
DOUBLE HEAD............................................................................................................................60
ROTARY OPTION........................................................................................................................62
AIR ASSIST OPTION...................................................................................................................64
AUTO FOCUS OPTION ...............................................................................................................65
13) MATERIAL SUPPLIERS ..................................................................................................66
14) IN CASE OF DIFFICULTY...............................................................................................69
AVOIDING COMMON PRINT PROBLEMS: ............................................................................69
15) SERVICING THE LEGEND .............................................................................................73
SERVICE MODULE LOCATION DIAGRAM...........................................................................74
CONTROLLER..............................................................................................................................75
POWER SUPPLY..........................................................................................................................76
LASER MODULE.........................................................................................................................77
RF MODULE.................................................................................................................................78
KEYBOARD/DISPLAY................................................................................................................80
X BEAM.........................................................................................................................................80
16) UPGRADING THE OPERATIONAL FIRMWARE.......................................................82
INSTALLING FLASHMASTER ONTO YOUR COMPUTER. .................................................82
INSTALLING NEW LEGEND FIRMWARE ONTO YOUR COMPUTER ..............................82
INSTALLING NEW FIRMWARE FROM YOUR COMPUTER TO YOUR LEGEND ...........83
17) SPECIFICATIONS .............................................................................................................86
LEGEND 32 SPECIFICATIONS..................................................................................................86
COMPATIBILITY.........................................................................................................................86
RECOMMENDED COMPUTER..................................................................................................87
SCANNER .....................................................................................................................................87
SOFTWARE ..................................................................................................................................87
ABOUT THE LASER....................................................................................................................87

Owner's Manual for EPILOG Legend Model 6000
December, 2000
How to Use This Owner’s Manual iv
HOW TO USE THIS OWNER’S MANUAL
Thank you for purchasing an Epilog Legend Model 6000 Laser System (Legend). The Legend has been
designed to be easy to operate, but you will utilize it to its fullest potential by taking some time to read this
owner’s manual prior to use. You will be ready to use the Legend as soon as you read the first four sections.
Then you can refer to topics in the remaining chapters, as you work.
STRUCTURE OF THE MANUAL
SECTIONS 1-4
How to uncrate and set up your Legend, important safety information you need to know before you use it, the
do’s and don’ts of operating the Legend and a brief user’s guide to running your first job.
SECTIONS 5-7
Basic Legend operations and maintenance
SECTIONS 8-13
Advanced Legend operations, system options, and material suppliers.
SECTIONS 15-17
Problem troubleshooting, service information, and Legend specifications.

Owner's Manual for EPILOG Legend Model 6000
December, 2000
Section 1 – Getting Started 1
1) GETTING STARTED
You will need to do the following to use your machine:
1) Remove it from the crate
2) Connect your computer
3) Connect the exhaust system
4) Connect power
5) Configure your computer
You may need a contractor to install the exhaust (all models) and the 208-240 volts (100 watt lasers only).
This must be done PRIOR to the arrival of the Epilog installation technician.
UNPACKING YOUR MACHINE
1) Cut and remove the strapping around the box and the plywood top. Remove the plywood top.
2) Cut the tape on the top of the box. Open the flaps and remove as much packing as you can. Please
save this packing material. This includes the foam top supports and four wood and foam corner
supports.
3) Remove eight (8) Phillips head screws (w/ large washers) located around the base of the corrugated
box.
4) With a friend, lift the box up over the machine. PLEASE do not throw away the box, you may need it
later. Remove the plastic bag over the machine.
5) On the pallet (the wooden platform the machine is sitting on) locate the edge that is secured with two
screws. Loosen and remove the screws, and remove the wooden 2”x2”.
6) Under the machine (all the way under), locate the ramps. They will be wrapped in plastic. Remove
them and place the metal hooks into the slots on the pallet. These ramps will allow you to roll the
machine off the pallet. There is a left and a right ramp. The raised edges must be on the outside, not
facing each other.
7) Locate the four wooden blocks supporting the machine on the pallet. These blocks need to be pulled
out. CAUTION is urged. These machines can weigh in excess of 400 lbs. With a friend or two, lift
one side of the machine just high enough to remove two of the blocks. Do the same with the other
side to remove the remaining two blocks.
8) With a friend helping, carefully roll the machine off the pallet and down the ramps. You may need to
unlock the front casters before the machine will roll freely.
9) Locate the accessory kit in the open compartment at the bottom front of the engraver. Remove this
box.
10) Open the main door to the engraver. Inside the cabinet, locate and remove two 5/8” diameter RED
shipping locks. They are toward the front of the machine and on either side of the X carriage. Turn

Owner's Manual for EPILOG Legend Model 6000
December, 2000
2 Section 1 – Getting Started
the screw locks counterclockwise to remove. Please save them. Also cut and remove the tie strap
holding the lens carriage in place.
CONNECTING THE COMPUTER
You have two choices for connecting your computer. For basic installations with a single Legend and a
single computer, you will probably want to use the parallel port. The Legend will connect to the printer port
on your computer. For more technical users where a computer network is in place, the Legend should be
connected through the ethernet port. The network port allows for higher transfer rates, as well as allowing for
data to be transferred from any of several computers. A network is also the best way to connect multiple
Legends.
Serial Port
Storage Slot
Network Port
Parallel Port
The data port connections are on the right side of the machine, towards the rear. The previous drawing shows
the location of all the ports. Some features may be optional or not available on your machine.
1) Parallel Port: Locate the printer cable from your accessory kit. A printer cable is the only cable
supplied with the Legend. The connection point on the Legend is on the right side of the machine,
near the rear. The connector is recessed in a small rectangular cutout. Mate the larger end of the

Owner's Manual for EPILOG Legend Model 6000
December, 2000
printer cable to the Legend. The connector can be connected only one way. Close the wire retainer
clips around the ends of the cable.
2) Ethernet Port: Because of the unpredictable physical nature of a network, Epilog does not supply a
network cable with the Legend. The Legend uses a 10BaseT style connection. The port is located on
the right side of the machine, near the rear. The network parameters can be set at the Legend, and
details for doing so are in Section 5, “Using the Epilog Legend”.
CONNECTING THE EXHAUST
A contractor prior to the arrival of the Epilog installation technician should install the exhaust system. The
blower should be mounted outside your building for noise considerations. The blower should not be more
than twenty feet from the Legend. You should provide a rigid, smooth duct from the blower to the vicinity of
the Legend. The Legend 32 requires 400 CFM at 6” of static pressure and the Legend 24 requires 400 CFM at
4” of static pressure. Remember to put the blower switch in an obvious and accessible place so it will be
routinely switched on prior to using the engraver. Please connect the blower as shown below.
1) Locate the exhaust port connector on the rear of the machine. The port is a 6” diameter tube for the
Legend 32 and a 4” diameter tube for the Legend 24. Slip the 6” or 4” flex hose over the port, and
secure with a hose clamp.
LEGEND
BLOWER
ROOF OR
EXTERIOR WALL
Legend 32 - 6” METAL DUCT
Legend 24 - 4” METAL DUCT
Legend 32 - 6” FLEX HOSE
Legend 24 - 4” FLEX HOSE
Section 1 – Getting Started 3

Owner's Manual for EPILOG Legend Model 6000
December, 2000
4 Section 1 – Getting Started
CONNECTING POWER
Laser systems 50 watts and under: Requires a 100 to 240 VAC, single-phase electricity outlet. The Legend
will automatically adjust for the line voltage. The Legend should be provided with a dedicated 15-amp
circuit, which can be shared with the computer running the Legend. The 50 watt Legend will leave little
reserve power on a normal 15 amp 115 Volt service, and the computer may require a separate circuit.
Laser systems over 240 VAC, single phase electrical outlet. The electrical outlet should be fitted with a
NEMA L6-15R receptacle (HUBBEL 4560 or equivalent). If not already available, a licensed electrician
prior to the arrival of the Epilog installation technician must perform the proper circuit wiring.
The location of the power cord receptacle of the Legend is shown in the drawing below, and is located on the
left side of the machine near the back.
On/Off
Switch
Power Cord
Receptacle
Circuit
Breakers
On/Off
Switch
Power Cord
Receptacle
UNDER 50 WATTS 50 WATTS AND ABOVE
1) Locate the “Power” label on the left side of the machine, near the back. The label indicates the
required operating voltage range for the machine. Please verify that the machine is the correct

Owner's Manual for EPILOG Legend Model 6000
December, 2000
voltage for your building. Do not proceed if the voltage is incorrect. Call Epilog technical support at
303-215-9171.
2) Locate the power cord in the accessory kit. The end with the recessed terminals connects to the
Legend. Locate the power entry receptacle next to the “Power” label on the left side of the machine.
Insert the power cord firmly into the receptacle.
3) Plug the machine into your wall power outlet, and turn the machine on. The power switch is next to
where the power cord connects to the Legend. The machine should beep and the carriage should
move towards home position.
CONFIGURING YOUR COMPUTER – PRINT DRIVER INSTALLATION
Epilog provides two “printer drivers” for use with Windows based computers. The first is the standard
“Legend Engraver Driver” and the second is the “Legend Stamp Driver”. The drivers are included in the
accessories kit on a 3.5-inch diskette labeled EPILOG. With the computer turned on and Windows open,
insert the diskette into your 3.5-inch disk drive to install the print drivers. Your computer must have
Windows 95 or Windows 98 already installed.
INSTALLING THE EPILOG LEGEND PRINT DRIVERS
1) Click on the “START” button at the bottom left of your screen.
2) Click on “SETTINGS”.
3) Click on “PRINTERS”.
4) Double Click on “ADD PRINTER”.
5) In the ADD PRINTER WIZARD click on “Next”.
6) Normally you should select “Local Printer”, and then click “Next”.
7) Click on “Have Disk”.
8) In the “Install From Disk” window your 3.5” floppy drive should be pre-selected in the “Install From
Manufacturer’s Disk” box. If it is, click on OK. If necessary, change the drive designation, and then
click on “OK”.
9) Click on Legend under “Manufacturer’s”, then click on “Legend Engraver”, and then click on “Next”.
10) Under “Available Ports” highlight LPT1: Printer Port, then click on “Next”.
11) Click on “Yes” or “No” depending on whether you want this to be the default printer. “Yes” is
recommended. Click on “Next”.
12) Click on “No” to printing a test page, then click on “Finish”. Your “Legend Engraver” print driver is
now installed.
13) Follow the above procedure again to install the “Legend Stamp” driver.
14) It is recommended that you turn your computer off and restart it after you have installed a new print
driver.
Section 1 – Getting Started 5

Owner's Manual for EPILOG Legend Model 6000
December, 2000
6 Section 2 – Safety
2) SAFETY
LASER SAFETY
Epilog Legend Model 6000 Laser Systems are Class IIIa laser products, as defined in 21 CFR 1040, the
Federal Performance Standards for Light-Emitting Products.
The output of the high-power engraving laser is fully contained. The Legend’s cabinet has interlocked doors,
and no special precautions are necessary to operate the high-power laser safely. However, the visible output
beam of the Legend’s Laser Diode Pointer (Red Dot Pointer) is accessible to the operator. While this device
employs the same technology as the familiar laser pen-pointers, like them it is potentially hazardous if its
beam is directed into the eye.
We have made every effort to make the Laser Diode Pointer (Red Dot Pointer) as safe as possible. Its beam
path is located well inside the cabinet, and under normal conditions, no hazardous levels of laser radiation can
escape.
The operator of the Legend Model 6000 should observe the following general precautions:
•DO NOT disassemble the machine or remove any of its protective covers while the unit is plugged
in.
•DO NOT attempt to defeat the door and window interlocks.
•DO NOT look directly into the beam of the Laser Diode Pointer (Red Dot Pointer).
•DO NOT operate the Laser Diode Pointer (Red Dot Pointer) without the machine’s focus lens in
place. If the unfocused beam strikes a reflective surface, it could be directed out of the cabinet.
The standard reference for laser safety is the American Standard for the Safe Use of Lasers, Z136.1-1993,
developed by the American National Standards Institute (ANSI). This reference is the basis for many of the
federal regulations for laser and laser system manufacturers, and for the Occupational Safety and Health
Administration (OSHA) laser safety guidelines. It contains detailed information concerning proper
installation and use of laser systems.
While the ANSI standard itself does not have the force of law, its recommendations, including warning
signage, training, and the designation of a laser safety officer, may be compulsory under local workplace
regulations when operating laser systems above Class I. It is the operator’s responsibility to ensure that the
installation and operation of the Epilog Legend Model 6000 Laser System is performed in accordance with all
applicable laws.

Owner's Manual for EPILOG Legend Model 6000
December, 2000
Copies of ANSI Standard Z136.1-1993 are available from Epilog Corporation or from:
Laser Institute of America
12424 Research Parkway, Suite 125
Orlando, FL 32826
[phone]
ELECTRICAL SAFETY
The AC input power to the Epilog Legend Model 6000 Laser System is potentially lethal and is fully
contained within the cabinet.
•DO NOT open any of the access panels on the rear of the machine while the unit is plugged in.
Opening these panels may expose the operator to the unit’s AC input power.
•DO NOT make or break electrical connections to the system when the unit is turned on.
FIRE SAFETY
Laser engraving machines represent a significant fire hazard. Most engraving materials are inherently
combustible, and while the objective of most engraving and cutting operations is to vaporize material without
burning, it is easy to ignite a flame. Usually this is a simple “flare” of burning gases, issuing from the focused
spot on the work piece, which follows the moving spot and which extinguishes itself as soon as the laser beam
is modulated off. But should the work piece actually be set on fire, the fire must be extinguished by the
operator at once, or the machine will be seriously damaged or destroyed!
•DO NOT operate the machine in the presence of unnecessary combustible materials, explosives, or
volatile solvents such as acetone, alcohol, or gasoline.
•DO NOT let the machine operate unattended, especially when performing slow cutting operations on
easily combustible materials such as paper or poster-board. Again, if a fire starts, it can destroy the
machine!
Section 2 – Safety 7

Owner's Manual for EPILOG Legend Model 6000
December, 2000
8 Section 2 – Safety
•ALWAYS keep a properly maintained and inspected fire extinguisher on hand. Epilog recommends
a carbon dioxide (CO2) or Halon®fire extinguisher. We do not recommend dry-chemical fire
extinguishers, because they discharge a corrosive powder, which will severely damage the machine’s
electrical and mechanical components.
SAFETY FEATURES AND REGULATORY COMPLIANCE
Epilog has incorporated specific safety features into its Legend Model 6000 Laser Systems in order to meet
the requirements of 21 CFR 1040.10 and the European standard EN 60825-1. These safety features include:
•A safety enclosure (cabinet), which fully encloses the engraving laser and its beam path.
•Dual redundant interlock systems that turn off the engraving laser when either the cabinet door or
window is opened.
•A visible emission indication when the Laser Diode Pointer (Red Dot Pointer) is operating. There is
an LED indicator on the machine’s front panel.
21 CFR 1040.10 requires that certification, identification, and warning labels be placed on laser products.
Reproductions of labels on the Legend Model 6000 Laser System follow, with their locations specified:
1) Certification/Identification Label. This engraved plate is located on the left-hand side of the
machine’s cabinet, by the power inlet connector. The example shown is for the Model 6000/30
product.
Epilog Corporation
500 Corporate Circle, Suite L
Golden, CO 80401 USA
Model Number: 6000/30 Laser Engraver
Serial Number: 6025-00000132
Date of Manufacture: January 2000
Class IIIa Laser Product
This product complies with 21 CFR 1040.10
and EN 60825-1: 1994
2) Class IIIa Warning Logotype. This label is located on the left-hand side of the machine’s cabinet,
below the access door.

Owner's Manual for EPILOG Legend Model 6000
December, 2000
3) Non-interlocked Protective Housing Safety Labels (2). One is located on the steering mirror cover
inside the laser bay at the rear of the cabinet, and the other is under the cover so that it is visible when
the cover has been removed.
4) Defeatably-interlocked Protective Housing Safety Label. This label is located on the right side of the
machine’s cabinet, below the access door. A special fixture is required to defeat the interlocks on the
Model 6000 product.
5) Aperture Safety Label. This label is located inside the machine’s cabinet, at the right rear, above the
aperture through which the laser and Laser Diode Pointer (Red Dot Pointer) beams enter the cabinet.
6) Electrical Safety Label. This label is located on the power supply access panel on the rear of the
cabinet.
Section 2 – Safety 9

Owner's Manual for EPILOG Legend Model 6000
December, 2000
10 Section 2 – Safety
HIGH VOLTAGE INSIDE CABINET
DISCONNECT POWER
BEFORE OPENING PANEL
7) Fire Safety Label. This label is located on the top of the laser bay cover, at the rear of the machine.
FIRE HAZARD
DO NOT OPERATE
MACHINE UNATTENDED

Owner's Manual for EPILOG Legend Model 6000
December, 2000
Legend Model 6000 products exported to the European Union are labeled in accordance with the European
standard EN 60825-1. Reproductions of the European labels follow.
8) Warning Label. This label, and the Explanatory label which follows, replace the Warning Logotype
(item 2 above). It is located on the left side of the machine’s cabinet, below the access door.
9) Explanatory Label. This label is located directly below the Warning label, item 8, on the left side of
the cabinet.
LASER RADIATION
DO NOT STARE INTO BEAM OR VIEW
DIRECTLY WITH OPTICAL INSTRUMENTS
CLASS 3ALASER PRODUCT
4 mWCWMAXIMUM 630 - 680 nm
10) Non-interlocked Protective Housing Safety Labels (2). These labels replace items 3 above. One is
located on the steering mirror cover inside the laser bay at the rear of the cabinet, and the other is
under the cover so that it is visible when the cover has been removed.
CAUTION - VISIBLE AND INVISIBLE
LASERRADIATION WHEN OPEN
AVOID EYE OR SKIN EXPOSURE
TO DIRECT OR SCATTERED
RADIATION
Section 2 – Safety 11

Owner's Manual for EPILOG Legend Model 6000
December, 2000
12 Section 2 – Safety
11) Defeatably-interlocked Protective Housing Safety Label. This label replaces item 4 above, and is
located on the right side of the machine’s cabinet, below the access door. A special fixture is required
to defeat the interlocks on the Model 6000 product.
CAUTION - INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCK DEFEATED
AVOID EYE OR SKIN EXPOSURE
TO DIRECT OR SCATTERED
RADIATION

Owner's Manual for EPILOG Legend Model 6000
December, 2000
3) DO’s AND DON’Ts
DON’T!
NEVER operate the machine without a properly operating vent to the outside! Most material will only
produce an irritating smoke when engraved. Some materials, including but not limited to paint, varnish,
composition board and plastics produce compounds that can be harmful if concentrated. A properly installed
vent is the only way to ensure that problems do not occur.
NEVER engrave or cut any material containing PVC or vinyl. When engraved, a corrosive agent is produced
that will destroy your machine. Your warranty will be void if your machine is damaged by corrosion from
engraving or cutting Vinyl.
NEVER operate your machine unattended. There is a significant risk of fire if the machine is set improperly,
or if the machine should experience a mechanical or electrical failure while operating.
NEVER engrave or cut acrylic material unattended. This is a popular material to laser however its fumes are
extremely flammable and cause flare up in your machine. Always watch carefully when using this material.
NEVER operate with any of the covers or enclosures removed, and never modify the enclosure. The laser
beam is invisible!
DO
Please allow a few minutes a week for cleaning your machine. Just a small amount of effort at the end of the
week will pay off with years of trouble free operation of your machine. See Section 8 “Engraving Machine
Maintenance” of this manual for specifics.
YOUR LEGEND IS NOW READY FOR USE!
Section 3 – Dos and Don’ts 13

Owner's Manual for EPILOG Legend Model 6000
December, 2000
14 Section 4 – Job Setup Guide
4) JOB SET UP GUIDE
To run a sample piece of material on your new Legend follow these instructions.
1. Setup your Legend machine and computer as instructed in Section 1, “GETTING STARTED”.
2. Read Sections 2 and 3, “SAFETY” and “DO’S AND DON’Ts”
3. Follow the setup guidelines detailed below.
JOB SETUP
1. Measure the length and width of your material piece to be cut or engraved. Load your material. The
home position of the engraving field is at the upper left corner of the engraving table. Place the
material to be engraved on the engraving table in the upper left hand corner, pressed firmly against
the metal stops along the top and left edges.
2. Focus on your material
¾Manual Focus: A metal focus gauge is provided to determine the correct distance from the work
piece to the focus lens. The focus gauge is included in the accessory kit. Place the focus gauge on
the lens carriage. Pressing the ”FOCUS” key and then turning the jog/shuttle knob raises or
lowers the table to move your work piece closer to, or further from, the fixed focus lens. The
work piece should be raised just to the point where the gauge touches the material. Remove the
gauge when you are done focusing. If the item has a taper, pick an intermediate point between
the highest and lowest points being engraved. Press ENTER when you are done focusing. That
will restore the control knob to the menu.
Auto Focus Gauge
Manual Focus Gauge

Owner's Manual for EPILOG Legend Model 6000
December, 2000
Section 4 – Job Setup Guide 15
¾Auto Focus: Alternatively, you can use the optional auto focus if installed on your Legend.
oSet the Auto Focus on your computer in the print properties window of the Legend print
driver: An “X” in the auto focus box will enable the auto focusing system of the Legend.
The table will automatically move the object to the correct height for processing. Please
be careful when you auto focus on the inside of anything like a bowl or a dish. If the
edge is more than an inch higher than the area to be lasered, the part may contact the
carriage prior to reaching the correct focus point. Longer focal length optics are available
for doing deeper parts. Contact your Epilog Representative for more information.
oSet the Auto Focus on the Legend on the LCD Display panel. See Sections 7 “USING
THE EPILOG LEGEND” of this manual for step by step instructions.
3. Turn on the exhaust fan.
4. Close the door and press the GO key.
5. Layout your Artwork in your drawing program.
ARTWORK LAYOUT
¾Now go into your drawing program (CorelDRAW, etc.) and set the page size to the same dimensions
of the material piece you have loaded. Then create your design to be engraved or cut within the page
outline.
¾You can engrave (raster) text, clip-art, photographs, or line drawings. Use your imagination and
creativity. Note: thin outlines in clip-art may vector rather than raster if thin enough. If you only
want to raster make sure you select raster only in the PROPERTIES print setup window.
¾You can also cut (vector) by
setting objects and text to be
unfilled and drawn with a
0.001 inch outline. The thin
outline will cut produce a vector
cut. When vectoring, cover
your engraving table with either
a piece of sheet metal or a
vector table to protect it from
laser marking. For more
information on vectoring read
Section 5, “Using the Legend
Print Driver” of this manual. “” – Vector Cut on Vector Table

Owner's Manual for EPILOG Legend Model 6000
December, 2000
16 Section 4 – Job Setup Guide
PRINT SETUP
1. Once you have the image ready to engrave, you can select FILE, PRINT. Change the printer name to
“Legend”, then select the PROPERTIES button to set your print settings. This is where you set the
resolution, speed, power, and again enter the piece size.
2. If placement of your artwork is critical, place a couple layers of masking tape onto the area of the
material piece to be engraved and practice at high speed and low power to mark only the tape.
3. For more information on the print setup read Section 5, “Using the Legend Print Driver” of this
manual. Now press print and you are engraving and cutting.
REMEMBER THE STEPS:
1. Turn on the power to the engraver, and wait for a “Beep” to note the machine is ready.
2. Insert the item to be engraved. (make sure table is low enough to accommodate piece)
3. Focus with gauge (or enable auto focus).
4. Close the door.
5. Confirm the exhaust is on.
6. Press GO on the Legend.
7. Create your artwork layout on your computer in a software program (i.e. CorelDRAW).
8. Set your print setup properties in the Legend print driver window.
9. Print to the Legend.
