Epson S1C31D50 User manual

© Seiko Epson Corporation 2018. All rights reserved.
Sound MCU: S1C31D50
Evaluation Board
“Getting Started”
Rev.１.0.0
*The information in this file is subject to change without notice.

2
Please prepare following before start.
①S1C31D50 Evaluation Board (from EPSON)
②Speaker Cable (from EPSON)
③Speaker
④USB Micro–B Cable
⑤USB Power(USB battery, PC etc)
Preparation
①
②③
④
⑤

3
Pre-install DEMO

4
•Please set the board as following.(Default)
1 2 3 4
ON
1 2 3 4
ON
to
speaker
connect all
Board Setting

5
①Connect Speaker cable & Speaker
②Connect USB and Supply power, LED shows power supply turns on
③After pressing reset button, LED shows Demo Ready turns on
Board Connect
①
②
LED(power supply)
①
LED(Demo Ready)
Reset Button
③

6
①Please set Language you want to show.
②Push “Reset” button. ... S1C31D50 reads DIP SW setting
Setup Demo
Reset button
※1
1 2 3 4
ON
1234
ON
1 2 3 4
ON
Japanese English Korean
Set language as you want
1234
ON
Chinese
①
②
※1: Push reset button
every time after change
the language
1 2 3 4
ON
FireAlarm 4language

7
Japanese Pre-Install Demo Contents
CH0:“Voice Speed” can be changed
1 2 3 4
ON
Japanese
CH0 ... voice CH1 ... music
1
「あと
5分でお風呂が沸きます。」
♪
Amazing Grace
2
「お風呂が沸きました。」
♪
Canon
3
「給湯温度が
/30℃に設定されました。」
♪
4
「給湯温度が
/31℃に設定されました。」
♪
5
「給湯温度が
/32℃に設定されました。」
♪
6
「給湯温度が
/33℃に設定されました。」
♪
7
「給湯温度が
/34℃に設定されました。」
♪
8
...
♪
Note: Demo Contents might be changed without notification.
“/” can achieve to share a common phrase automatically
(Please see EPSER2 Manual)

8
English Pre-Install Demo Contents
CH0:“Voice Speed” can be changed
1 2 3 4
ON
English
CH0 ... voice CH1 ... music
1
The coffee is ready, enjoy!
♪
Amazing Grace
2
It's ready, enjoy the dinner.
♪
Canon
3
The bath is ready.
♪
4
The temperature is set at 3
8//
degree.
♪
5
The temperature is set at 3
9//
degree.
♪
6
The temperature is set at
40 //
degree.
♪
7
The temperature is set at
41 //
degree.
♪
8
...
♪
Note: Demo Contents might be changed without notification.
“/” can achieve to share a common phrase automatically
(Please see EPSER2 Manual)

9
Chinese Pre-Install Demo Contents
CH0 ... voice CH1 ... music
1
我準備好洗澡了
♪
Amazing Grace
2
设
定的温度是/30度
♪
Canon
3
设
定的温度是/31度
♪
4
设
定的温度是/32度
♪
5
设
定的温度是/33度
♪
6
设
定的温度是/34度
♪
7
设
定的温度是/35度
♪
8
...
♪
CH0:“Voice Speed” can be changed
1 2 3 4
ON
Chinese
Note: Demo Contents might be changed without notification.
“/” can achieve to share a common phrase automatically
(Please see EPSER2 Manual)

10
Korean Pre-Install Demo Contents
CH0 ... voice CH1 ... music
1
온도가
38도로 /설정되었습니다.
♪
Amazing Grace
2
온도가
39도로 /설정되었습니다.
♪
Canon
3
온도가
40도로 /설정되었습니다.
♪
4
온도가
41도로 /설정되었습니다.
♪
5
온도가
42도로 /설정되었습니다.
♪
6
목욕준비가
완료되었습니다.
♪
7
건전지를
교체해 주세요.
♪
8
...
♪
CH0:“Voice Speed” can be changed
1 2 3 4
ON
Korean
Note: Demo Contents might be changed without notification.
“/” can achieve to share a common phrase automatically
(Please see EPSER2 Manual)

11
Fire Alarm 4 Language Demo Contents
CH0 ... voice CH1 ... music
1
♪
(Sweep), ♪(Sweep),
煙が感知されました。
A Smoke is
detected
检测
到烟雾。
연기가
감지되었습니다.
-
1 2 3 4
ON
FireAlarm
Note: Demo Contents might be changed without notification.

12
①Please push Reset button
②Please start the demo(see following)
Ex1)
1. Push①Reset
- Voice Speed Normal(100%) LED turns on
2. Push③Background music start
- CH1 LED turns on
3. Push②Voice start
(mixed with music)
- CH0 LED turns on
Ex2)
1. Push①Reset
- Voice Speed Normal(100%) LED turns on
2. Push④Change Voice speed(105% Slow)
- Voice Speed Slow LED turns on
3. Push③Background music start
- CH1 LED turns on
4. Push②Voice start
(mixed with music)
- CH0 LED turns on
5. Push⑤Pause
- CH1 LED Blink
6. Push⑥Release Pause
- CH1 LED turns on
Play/Stop
Voice
Speed
Volume Pause/Mute reserved
ch0 ch1 ch0 ch0 ch1 ch0 ch1 -
One push Play/Next
+5%
+3db Pause/
Release Pause
-
Double push
Play/Previous
-5% -3db Mute/
Release Mute
-
Long Push
(more than 1sec)
Stop
100%
Default -
Start pre-install Demo
Reset Button
①
② ③ ④⑤

13
Thank you.
