Chapter 1 Introduction
S5U13515P00C100 Evaluation Board User Manual (Rev 1.1) EPSON 5
Chapter 1 Introduction
This manual describes the setup and operation of the S5U13515P00C100 Evaluation Board. The evaluation board
is designed as an evaluation platform for the S2D13515 Display Controller.
The S5U13515P00C100 evaluation board can be used with many native platforms via the host connector which
provides the appropriate signals to support a variety of CPUs. The S5U13515P00C100 evaluation board can also
connect to the S5U13U00P00C100 USB Adapter board so that it can be used with a laptop or desktop computer, via
USB 2.0.
This user manual is updated as appropriate. Please check the Epson Research and Development Website at
www.erd.epson.com for the latest revision of this document before beginning any development.
We appreciate your comments on our documentation. Please contact us via email at [e-mail].

Chapter 2 Features
6 EPSON S5U13515P00C100 Evaluation Board User Manual (Rev 1.1)
Chapter 2 Features
The S5U13515P00C100 Evaluation Board includes the following features:
• 256-pin PBGA S2D13515 Display Controller
• On-board SDRAM, configurable as 32MB (32-bit wide) or 16MB (16-bit wide)
• On-board Serial Flash Memory, 32Mbit
• Headers for connection to various Host Bus Interfaces (includes all S2D13515 Host Bus Interface signals)
• Headers for connection to the S5U13U00P00C100 USB Adapter board
• Headers for connection to various LCD panels (includes all S2D13515 FP1IO and FP2IO interface signals)
• Header for connection to cameras
• Header for I2S outputs
• On-board 3x3 keypad
• On-board 20MHz crystal
• 14-pin DIP socket (if an oscillator for CLKI input is required)
• 3.3V input power
• On-board voltage regulator with 1.8V output
• On-board voltage regulator with adjustable 12~25V output, 60~100mA max., to provide power for LED back-
light of LCD panels.

Chapter 3 Installation and Configuration
S5U13515P00C100 Evaluation Board User Manual (Rev 1.1) EPSON 7
Chapter 3 Installation and Configuration
The S5U13515P00C100 evaluation board incorporates a DIP switch, jumpers, and 0 ohm resistors which allow it to
be used with a variety of different configurations.
3.1 CNF[7:0] Configuration Inputs
The S2D13515 has 8 configuration inputs (CNF[7:0]), which can be configured through a combination of a DIP
switch and 0 ohm resistors. CNF[2:0] are dedicated inputs and are configured using DIP switch SW1. CNF[7:3] are
multiplexed with some host interface signals and are configured by 0 ohm resistors.
3.1.1 CNF[2:0]
CNF[2:0] are configured using DIP switch SW1 as described below.
The following figure shows the location of DIP switch SW1 on the S5U13515P00C100 evaluation board.
Figure 3-1: Configuration DIP Switch (SW1) Location
Table 3-1: CNF[2:0] Configuration Settings
CNF[2:0] 1 (connected to HIOVDD) 0 (connected to VSS)
CNF2 CNF[2:1] are used in combination with CNF[7:3] to select the host bus interface. For a
summary of the possible host bus interfaces, see Section Table 3-3 :, “Host Interface
Configuration Settings” on page 9.
CNF1
CNF0 OSCI is the source for Input Clock 1 CLKI is the source for Input Clock 1
= suggested settings

Chapter 3 Installation and Configuration
8 EPSON S5U13515P00C100 Evaluation Board User Manual (Rev 1.1)
3.1.2 CNF[7:3]
CNF[7:3] are configured using 0 Ohm resistors as described below.
Note
CNF3 and CNF6 are mapped to different pins depending on the combination of the other CNF inputs.
The following figure shows the location of the 0 Ohm resistors used to configure CNF[7:3].
Figure 3-2: CNF[7:3] 0 Ohm Resistor Locations
Table 3-2: CNF[7:3] Configuration Settings
CNF Pin 1 (connected to HIOVDD) 0 (connected to VSS)
CNF3
(see Note)
TEA# R100 populated
R107 not populated R100 not populated R107 populated
AB0 R99 populated
R106 not populated R99 not populated R106 populated
CNF4 BDIP# R95 populated
R102 not populated R95 not populated R102 populated
CNF5 BURST# R96 populated
R103 not populated R96 not populated R103 populated
CNF6
(see Note)
AB3 R98 populated
R105 not populated R98 not populated R105 populated
BE1# R97 populated
R104 not populated R97 not populated R104 populated
AB0 R99 populated
R106 not populated R99 not populated R106 populated
CNF7 AB4 R101 populated
R108 not populated R101 not populated R108 populated
= default settings, required settings when using S5U13U00P00C100 USB Adapter Board

Chapter 3 Installation and Configuration
S5U13515P00C100 Evaluation Board User Manual (Rev 1.1) EPSON 9
3.1.3 Host Interface Configuration
The host bus interface used by the S5U13515P00C100 evaluation board is selected using a combination of the
CNF[2:1] pins and unused hostinterface pins. Many host bus interfaces have unused pins that can be used as config-
uration pins (CNF[7:3]) to select the host bus interface. The following table summarizes the available settings.
Table 3-3 : Host Interface Configuration Settings
CNF1 CNF2 CNF3 CNF4 CNF5 CNF6 CNF7 Host Interface
0 0 0 (TEA#) 0 (BDIP#) 0 (BURST#) 0 (AB3) XIndirect, 8-bit, Intel80 Type1
0 0 0 (TEA#) 0 (BDIP#) 0 (BURST#) 1 (AB3) XIndirect, 8-bit, Intel80 Type2
0 0 0 (TEA#) 0 (BDIP#) 1 (BURST#) 1 (AB3) 0 (AB4) SPI
0 0 0 (TEA#) 0 (BDIP#) 1 (BURST#) 1 (AB3) 1 (AB4) I2C
0 0 0 (TEA#) 1 (BDIP#) 0 (BURST#) 0 (AB3) XIndirect, 8-bit, NEC V850 Type1
0 0 0 (TEA#) 1 (BDIP#) 0 (BURST#) 1 (AB3) XIndirect, 8-bit, NEC V850 Type2
0 0 0 (TEA#) 1 (BDIP#) 1 (BURST#) 0 (AB3) XIndirect, 8-bit, Renesas SH4
0 1 0 (TEA#) 0 (BDIP#) 0 (BURST#) 0 (AB3) XIndirect, 16-bit, Intel80 Type1
0 1 0 (TEA#) 0 (BDIP#) 0 (BURST#) 1 (AB3) XIndirect, 16-bit, Intel80 Type2
0 1 0 (TEA#) 0 (BDIP#) 1 (BURST#) 1 (AB3) 0 (AB4) SPI (2-stream)
0 1 0 (TEA#) 0 (BDIP#) 1 (BURST#) 1 (AB3) 1 (AB4) I2C
0 1 0 (TEA#) 1 (BDIP#) 0 (BURST#) 0 (AB3) XIndirect, 16-bit, NEC V850 Type1
0 1 0 (TEA#) 1 (BDIP#) 0 (BURST#) 1 (AB3) XIndirect, 16-bit, NEC V850 Type2
0 1 0 (TEA#) 1 (BDIP#) 1 (BURST#) 0 (AB3) XIndirect, 16-bit, Renesas SH4
0 0 1 (TEA#) 0 (BDIP#) 0 (BURST#) 0 (BE1#) XDirect, 8-bit, Intel80 Type1
0 0 1 (TEA#) 0 (BDIP#) 0 (BURST#) 1 (BE1#) XDirect, 8-bit, Intel80 Type2
0 0 1 (TEA#) 0 (BDIP#) 1 (BURST#) 1 (BE1#) 0 (AB4) SPI
0 0 1 (TEA#) 0 (BDIP#) 1 (BURST#) 1 (BE1#) 1 (AB4) I2C
0 0 1 (TEA#) 1 (BDIP#) 0 (BURST#) 0 (BE1#) XDirect, 8-bit, NEC V850 Type1
0 0 1 (TEA#) 1 (BDIP#) 0 (BURST#) 1 (BE1#) XDirect, 8-bit, NEC V850 Type2
0 0 1 (TEA#) 1 (BDIP#) 1 (BURST#) 0 (BE1#) XDirect, 8-bit, Renesas SH4
0 1 1 (TEA#) 0 (BDIP#) 0 (BURST#) 0 (AB0) XDirect, 16-bit, Intel80 Type1
0 1 1 (TEA#) 0 (BDIP#) 0 (BURST#) 1 (AB0) XDirect, 16-bit, Intel80 Type2
0 1 1 (TEA#) 0 (BDIP#) 1 (BURST#) 0 (AB0) XDirect, 16-bit, Intel PXA3xxs
0 1 1 (TEA#) 0 (BDIP#) 1 (BURST#) 1 (AB0) 0 (AB4) SPI
0 1 1 (TEA#) 0 (BDIP#) 1 (BURST#) 1 (AB0) 1 (AB4) I2C
0 1 1 (TEA#) 1 (BDIP#) 0 (BURST#) 0 (AB0) XDirect, 16-bit, NEC V850 Type1
0 1 1 (TEA#) 1 (BDIP#) 0 (BURST#) 1 (AB0) XDirect, 16-bit, NEC V850 Type2
0 1 1 (TEA#) 1 (BDIP#) 1 (BURST#) 0 (AB0) XDirect, 16-bit, Renesas SH4
1 0 0 (AB0) X X X X Indirect, 16-bit, TI EBI
1 0 1 (AB0) X X X X Direct, 16-bit, TI EBI
1 1 0 (BE1#) X X X X Indirect, 16-bit, MPC555
1 1 1 (BE1#) X X X X Direct, 16-bit, MPC555
= default settings, required settings when using S5U13U00P00C100 USB Adapter Board
X= don’t care

Chapter 3 Installation and Configuration
10 EPSON S5U13515P00C100 Evaluation Board User Manual (Rev 1.1)
3.2 Configuration Jumpers
The S5U13515P00C100 has 16 jumpers which configure various evaluation board settings. The jumper positions
for each function are shown below.
Table 3-4: Configuration Jumper Settings
Jumper Function Position 1-2 Position 2-3 No Jumper
JP1 COREVDD Normal —COREVDD current measurement
JP2 PLL1VDD Normal —PLL1VDD current measurement
JP3 PLL2VDD Normal —PLL2VDD current measurement
JP4 OSCVDD Normal —OSCVDD current measurement
JP5 PIO1VDD Normal —PIO1VDD current measurement
JP6 HIOVDD Normal —HIOVDD current measurement
JP7 HIOVDD Source H4 connector, pin 31 3.3VDD —
JP8 PIO1VDD Source H9 connector, pin 9 3.3VDD —
JP9 PIO2VDD Source H9 connector, pin 10 3.3VDD —
JP10 CM1VDD Normal —CM1VDD current measurement
JP11 PIO2VDD Normal —PIO2VDD current measurement
JP12 CM1DD Source H9 connector, pin 8 3.3VDD —
JP13 IOVDD Source H9 connector, pin 7 3.3VDD —
JP14 IOVDD Normal —IOVDD current measurement
JP15 SDVDD Normal —SDVDD current measurement
JP16 SDRAM Width Select
(see Note) 32-bit wide SDRAM 16-bit wide SDRAM —
= Required settings when using S5U13U00P00C100 USB Adapter board

Chapter 3 Installation and Configuration
S5U13515P00C100 Evaluation Board User Manual (Rev 1.1) EPSON 11
JP1, JP2, JP3, JP4, JP5, JP6, JP10, JP11, JP14, JP15 - Power Supplies for the S2D13515
JP1, JP2, JP3, JP4, JP5, JP6, JP10, JP11, JP14, and JP15 can be used to measure the current consumption of each
S2D13515 power supply.
When the jumper is at position 1-2, normal operation is selected.
When no jumper is installed, the current consumption for each power supply can be measured by connecting an
ammeter to pin 1 and 2 of the jumper.
The jumper associated with each power supply is as follows:
JP1 for COREVDD JP2 for PLL1VDD
JP3 for PLL2VDD JP4 for OSCVDD
JP5 for PIO1VDD JP6 for HIOVDD
JP10 for CM1VDD JP11 for PIO2VDD
JP14 for IOVDD JP15 for SDVDD
Figure 3-3: Configuration Jumper Locations (JP1, JP2, JP3, JP4, JP5, JP6, JP10, JP11, JP14, JP15)

Chapter 3 Installation and Configuration
12 EPSON S5U13515P00C100 Evaluation Board User Manual (Rev 1.1)
JP7 - HIOVDD Source
JP7 is used to select the source for the HIOVDD supply voltage.
When the jumper is at position 1-2, the HIOVDD voltage must be provided to pin 31 on the H4 connector.
When the jumper is at position 2-3, the HIOVDD voltage is provided by the 3.3V power supply of the board.
Figure 3-4: Configuration Jumper Location (JP7)
JP8 - PIO1VDD Source
JP8 is used to select the source for the PIO1VDD supply voltage.
When the jumper is at position 1-2, the PIO1VDD voltage must be provided to pin 9 on the H9 connector.
When the jumper is at position 2-3, the PIO1VDD voltage is provided by the 3.3V power supply of the board.
Figure 3-5: Configuration Jumper Location (JP8)

Chapter 3 Installation and Configuration
S5U13515P00C100 Evaluation Board User Manual (Rev 1.1) EPSON 13
JP9 - PIO2VDD Source
JP9 is used to select the source for the PIO2VDD supply voltage.
When the jumper is at position 1-2, the PIO2VDD voltage must be provided to pin 10 on the H9 connector.
When the jumper is at position 2-3, the PIO2VDD voltage is provided by the 3.3V power supply of the board.
Figure 3-6: Configuration Jumper Location (JP9)
JP12 - CM1VDD Source
JP12 is used to select the source for the CM1VDD supply voltage.
When the jumper is at position 1-2, the CM1VDD voltage must be provided to pin 8 on the H9 connector.
When the jumper is at position 2-3, the CM1VDD voltage is provided by the 3.3V power supply of the board.
Figure 3-7: Configuration Jumper Location (JP12)

Chapter 3 Installation and Configuration
14 EPSON S5U13515P00C100 Evaluation Board User Manual (Rev 1.1)
JP13 - IOVDD Source
JP13 is used to select the source for the IOVDD supply voltage.
When the jumper is at position 1-2, the IOVDD voltage must be provided to pin 7 on the H9 connector.
When the jumper is at position 2-3, the IOVDD voltage is provided by the 3.3V power supply of the board.
Figure 3-8: Configuration Jumper Location (JP13)
JP16 - SDRAM Width Select
JP16 is used to select the bus width of the external SDRAM.
When the jumper is at position 1-2, the external SDRAM is 32 bits wide and the memory size is 32M bytes. In this
configuration, the memory consists of 2 chips in parallel, each16M bytes and 16 bits wide.
When the jumper is at position 2-3, the external SDRAM is 16 bits wide and the memory size is 16M bytes. In this
configuration, one memory chip is disabled and only one chip is active (16M bytes and 16 bits wide).
Figure 3-9: Configuration Jumper Location (JP16)

Chapter 4 Technical Description
S5U13515P00C100 Evaluation Board User Manual (Rev 1.1) EPSON 15
Chapter 4 Technical Description
4.1 Power
4.1.1 Power Requirements
The S5U13515P00C100 evaluation board requires an external regulated power supply (3.3V / 1A). The power is
supplied to the evaluation board through pin 33 of the H4 header, or pin 5 of the P2 header.
The green LED “3.3V Power” is turned on when 3.3V power is applied to the board.
4.1.2 Voltage Regulators
The S5U13515P00C100 evaluation board has an on-board linear regulator to provide the 1.8V power required by
the S2D13515 Display Controller. It also has a step-up switching voltage regulator to generate adjustable 12~25V,
which can be used to power the LED backlight on some LCD panels.
4.1.3 S2D13515 Power
The S2D13515 Display Controller requires 1.8V power and 2.3~2.7V or 3.0~3.6V power.
COREVDD, PLL1VDD, PLL2VDD, and OSCVDD require 1.8V power which is provided by an on-board linear
voltage regulator.
HIOVDD, PIO1VDD, PIO2VDD, CM1VDD, and IOVDD input power may be in the range 2.3V~2.7V or
3.0V~3.6V. When JP7, JP8, JP9, JP12, or JP13 are set to the 2-3 position, the corresponding power input is
connected to 3.3V. If a different voltage is required, set the corresponding jumper to the 1-2 position and connect
the external power supply to the evaluation board as indicated in Table 3-4: “Configuration Jumper Settings,” on
page 10.
SDVDD input power may be in the range 2.3V~2.7V or 3.0V~3.6V. On the evaluation board, SDVDD is connected
to 3.3V.
4.1.4 LCD Backlight Power
On the evaluation board there is an adjustable 12~25V power supply. At 12V, the maximum current available is
100mA. At 25V, the maximum current available is 60mA. This power supply is intended for use to power the LED
backlight on some LCD panels. The voltage is adjusted by the R175 pot.
Note
For LCD panels that use a CCFL backlight, an external power supply must be used to provide power to the inverter
for the CCFL backlight. Usually, the inverter current consumption is higher than the maximum 100mA current
available from the on-board voltage regulator.

Chapter 4 Technical Description
16 EPSON S5U13515P00C100 Evaluation Board User Manual (Rev 1.1)
4.2 Clocks
The clock for the S2D13515 Display Controller is provided by a 20MHz crystal connected to the OSCI and OSCO
pins.
Additionally, the S5U13515P00C100 evaluation board can also use an oscillator if the DIP14 footprint is populated.
If populated, the oscillator is connected to the CLKI input clock of the S2D13515 Display controller.
Note
For details on the S2D13515 clock structure, refer to the S2D13515 Hardware Functional Specification, document
number X83A-A-001-xx.
4.3 Reset
The S2D13515 Display Controller on the S5U13515P00C100 evaluation board can be reset using a push-button
switch (SW2), or via an active low reset signal from the host development platform (pin 30 on the H4 connector).
Figure 4-1: Reset Switch (SW2) Location

Chapter 4 Technical Description
S5U13515P00C100 Evaluation Board User Manual (Rev 1.1) EPSON 17
4.4 Memory
4.4.1 SDRAM
The S5U13515P00C100 evaluation board has 2 SDRAM ICs, each 128Mbit x16-bit, CL=2 in a TSOP54 package.
When the S2D13515 DisplayController isconfigured for32-bitwide DRAMbus, bothSDRAM ICs are used. When
the S2D13515 Display Controller is configured for 16-bit wide DRAM bus, only one of the SDRAM ICs is used
and the other SDRAM ICs is disabled by having its chip select input pulled high to inactive state, by putting jumper
JP16 in 2-3 position.
4.4.2 Serial Flash Memory with SPI interface
The S2D13515 Display Controller has a SPI Flash Memory interface which is connected to a 32Mbit Flash EPROM.
4.5 Host Interface
4.5.1 Direct Host Bus Interface Support
All S2D13515 host interface pins are available on connectors H3 and H4. This allows the S5U13515P00C100 evalu-
ation board to be connected to a variety of development platforms. For S2D13515 host interface pin mapping, refer
to the S2D13515 Hardware Functional Specification, document number X83A-A-001-xx.
The following figureshowsthe location of host bus connectors H3 and H4. H3 is a 0.1” x 0.1” 40-pin header(20x2)
and H4 is a 0.1” x 0.1” 34-pin header (17 x 2).
Figure 4-2: Host Bus Connector Location (H3 and H4)
For the pinout of connectors H3 and H4, see Section Chapter 6, “Schematic Diagrams” on page 29.

Chapter 4 Technical Description
18 EPSON S5U13515P00C100 Evaluation Board User Manual (Rev 1.1)
4.5.2 Connecting to the Epson S5U13U00P00C100 USB Adapter Board
The S5U13515P00C100evaluationboard is designed to connect to aS5U13U00P00C100 USB Adapter Board. The
USB adapter board provides a simple connection to any computer via a USB 2.0 connection. The
S5U13515P00C100 directly connects to the USB adapter board through connectors P1 and P2.
The USB adapter board also supplies the 3.3V power required by the S5U13515P00C100 evaluation board.
HIOVDD should be configured for 3.3V and JP7 should be set to the 2-3 position.
When theS5U13515P00C100 is connected to the S5U13U00P00C100USB Adapter board, there are 2 LEDson the
S5U13515P00C100 which provide a quick visual status of the USB adapter. LED1 blinks to indicate that the USB
adapter board is active. LED2 turns on to indicate that the USB has been enumerated by the PC.
The following diagram shows the location of connectors P1 and P2. P1 and P2 are 2mm x 2mm, 40-pin headers
(20 x 2) located on the underside of the board.
Figure 4-3: USB Adapter Connector Locations (P1 and P2)
For the pinout of connectors P1 and P2, see Section Chapter 6, “Schematic Diagrams” on page 29.
Note
A windows driver must be installed on the PC when the S5U13515P00C100 is used with the S5U13U00P00C100
USB Adapter Board. The S1D13xxxUSB driver is available at www.erd.epson.com.

Chapter 4 Technical Description
S5U13515P00C100 Evaluation Board User Manual (Rev 1.1) EPSON 19
4.6 LCD Interface
The LCD interface uses the FP1IO[23:0] and FP2IO[27:0]pins. All signals on these pins are available on connectors
H5, H6, and H7.
Connectors H5, H6, and H7 are 0.1” x 0.1”, 40-pin headers (20 x 2). The following diagram shows the location of
these connectors.
Figure 4-4: FP1IO and FP2IO Connectors Location (H5, H6, H7)
For the pinout of connectors H5, H6, and H7, see Section Chapter 6, “Schematic Diagrams” on page 29.
4.6.1 FP1IO Interface
TheFP1IO interfacesignalshavemultiplexed functions.AllFP1IO interfacesignals,exceptFP1IO18and FP1IO19,
are available on connector H6. FP1IO18 and FP1IO19 signals go through 0 ohm resistors and are available on
connector H7.
The FP1IO interface can be configured as a LCD interface, 18-bit RGB input stream interface, or 8-bit YUV camera
interface and keyboard interface. For S2D13515 FP1IO interface pin mapping, refer to the S2D13515 Hardware
Functional Specification, document number X83A-A-001-xx.
4.6.2 FP2IO Interface
All FP2IO interface signals are available on connectors H5 and H7. For S2D13515 FP2IO interface pin mapping,
refer to the S2D13515 Hardware Functional Specification, document number X83A-A-001-xx.

Chapter 4 Technical Description
20 EPSON S5U13515P00C100 Evaluation Board User Manual (Rev 1.1)
4.7 Camera / I2C Interface
The S2D13515 Display Controller has a Camera interface. All the camera interface signals are available on
connector H10. To control the camera, the S2D13515 Display Controller has anI2C master interface. The SDA and
SCL signals are pulled high to CM1VDD by 2.2 kΩresistors and are available on connector H10. The reset signal
provided on H10 is active low and is pulled to HIOVDD when inactive.
Connector H10 is a 0.1” x 0.1”, 20-pin header (10 x 2). The following figure shows the location of the connector
H10.
Figure 4-5: Camera Connector Location (H10)
For the pinout of connector H10, see Section Chapter 6, “Schematic Diagrams” on page 29.
