Epson S1D13743 User manual

Revision 1.0
S1D13743 Mobile Graphics Engine
S5U13743P00C100 Evaluation Board
User Manual
Document Number: X70A-G-001-01
Status: Revision 1.0
Issue Date: 2007/08/15

Page 2 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
NOTICE
No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko
Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any lia-
bility of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or cir-
cuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as,
medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there is
no representation or warranty that anything made in accordance with this material will be free from any patent or copyright
infringement of a third party. When exporting the products or technology described in this material, you should comply with
the applicable export control laws and regulations and follow the procedures required by such laws and regulations. You are
requested not to use, to resell, to export and/or to otherwise dispose of the products (and any technical information furnished,
if any) for the development and/or manufacture of weapon of mass destruction or for other military purposes.
All brands or product names mentioned herein are trademarks and/or registered trademarks of their respective companies.
©SEIKO EPSON CORPORATION 2007 - 2012, All rights reserved.
Evaluation Board/Kit and Development Tool Important Notice
1. This evaluation board/kit or development tool is designed for use for engineering evaluation, demonstration, or develop-
ment purposes only. Do not use it for other purposes. It is not intended to meet the requirements of design for finished
products.
2. This evaluation board/kit or development tool is intended for use by an electronics engineer and is not a consumer product.
The user should use it properly and in a safe manner. Seiko Epson does not assume any responsibility or liability of any
kind of damage and/or fire caused by the use of it. The user should cease to use it when any abnormal issue occurs even
during proper and safe use.
3. The part used for this evaluation board/kit or development tool may be changed without any notice.

Epson Research and Development Page 3
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Configuration DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3.2 Configuration Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.1 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.2 Voltage Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.3 S1D13743 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2 Clocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.3 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4 Power Save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.5 Host Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5.1 Direct Host Bus Interface Support . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5.2 Connecting to the Epson S5U13U00P00C100 USB Adapter Board . . . . . . . . . 15
4.6 LCD Panel Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.7 GPIO Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5 Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6 Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8.1 Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8.2 Document Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
9 Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
9.1 EPSON Display Controllers (S1D13743) . . . . . . . . . . . . . . . . . . . . 27
9.2 Ordering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Page 4 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0

Epson Research and Development Page 5
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
1 Introduction
This manual describes the setup and operation of the S5U13743P00C100 Evaluation
Board. The evaluation board is designed as an evaluation platform for the S1D13743
Mobile Graphics Engine.
The S5U13743P00C100 evaluation board can be used with many native platforms via the
host connector which provides the appropriate signals to support a variety of CPUs. The
S5U13743P00C100 evaluation board can also connect to the S5U13U00P00C100 USB
Adapter board so that it can be used with a laptop or desktop computer, via USB 2.0.
This user manual is updated as appropriate. Please check the Epson Research and Devel-
opment Website at www.erd.epson.com for the latest revision of this document before
beginning any development.
We appreciate your comments on our documentation. Please contact us via email at
documentati[email protected].

Page 6 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
2 Features
The S5U13743P00C100 Evaluation Board includes the following features:
• 121-pin FCBGA S1D13743 Mobile Graphics Engine
• Header with all S1D13743 Host Bus Interface signals
• Headers for connection to the S5U13U00P00C100 USB Adapter board
• Headers for connecting to LCD panels
• Header for S1D13743 GPIO pins (optional)
• On-board 4MHz oscillator
• 14-pin DIP socket (if a clock other than 4MHz must be used)
• 3.3V input power
• On-board voltage regulator with 1.5V output
• On-board voltage regulator with adjustable 6~24V output, 40mA max., to provide
power for LED backlight of LCD panels.

Epson Research and Development Page 7
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
3 Installation and Configuration
The S5U13743P00C100 evaluation board incorporates a DIP switch, jumpers, and 0 ohm
resistors which allow it to be used with a variety of different configurations.
3.1 Configuration DIP Switch
The S1D13743 has 3 configuration inputs (CNF[2:0]). A DIP switch (SW1) is used to
configure CNF[2:0] as described below.
The following figure shows the location of DIP switch SW1 on the S5U13743P00C100
board.
Figure 3-1: Configuration DIP Switch (SW1) Location
Table 3-1: Summary of Power-On/Reset Options
SDU13743P00C100
SW1-[4:1] Config
S1D13743
CNF[2:0] Config
Power-On/Reset State
1 (ON) 0 (OFF)
SW1-[1] CNF0 Host Data lines are normal Host data lines are swapped
SW1-[2] CNF1 Host Data is 16-bit Host data is 8-bit
SW1-[3] CNF2 PIOVDD output current = 6.5mA PIOVDD output current = 2.5mA
SW1-[4] - not used
= Required settings when using S5U13U00P00C100 USB Adapter board
DIP Switch
SW1

Page 8 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
3.2 Configuration Jumpers
The S5U13743P00C100 has 6 jumpers which configure various board settings. The jumper
positions for each function are shown below.
Jumper Function Position 1-2 Position 2-3 No Jumper
JP1 COREVDD Normal — COREVDD current
measurement
JP2 PLLVDD Normal — PLLVDD current
measurement
JP3 IOVDD Normal — IOVDD current
measurement
JP4 IOVDD Source H1 connector, pin 32 3.3VDD —
JP5 PIOVDD Normal — PIOVDD current
measurement
JP6 PIOVDD Source H4 connector, pin 8 3.3VDD —
= Required settings when using S5U13U00P00C100 USB Adapter board

Epson Research and Development Page 9
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
JP1, JP2, JP3, JP5 - Power Supplies for the S1D13743
JP1, JP2, JP3, JP5 can be used to measure the current consumption of each S1D13743
power supply.
When the jumper is at position 1-2, normal operation is selected.
When no jumper is installed, the current consumption for each power supply can be
measured by connecting an ammeter to pin 1 and 2 of the jumper.
The jumper associated with each power supply is as follows:
JP1 for COREVDD
JP2 for PLLVDD
JP3 for IOVDD
JP5 for PIOVDD
Figure 3-2: Configuration Jumper Locations (JP1, JP2, JP3, JP5)
JP3
JP5
JP1
JP2

Page 10 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
JP4 - IOVDD Source
JP4 is used to select the source for the IOVDD supply voltage.
When the jumper is at position 1-2, the IOVDD voltage must be provided to the H1
connector, pin 32.
When the jumper is at position 2-3, the IOVDD voltage is provided by the 3.3V power
supply of the board.
Figure 3-3: Configuration Jumper Location (JP4)
JP4

Epson Research and Development Page 11
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
JP6 - SIOVDD Source
JP6 is used to select the source for the PIOVDD supply voltage.
When the jumper is at position 1-2, the PIOVDD voltage must be provided to the H4
connector, pin 8.
When the jumper is at position 2-3, the PIOVDD voltage is provided by the 3.3V power
supply of the board.
Figure 3-4: Configuration Jumper Location (JP6)
JP6

Page 12 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
4 Technical Description
4.1 Power
4.1.1 Power Requirements
The S5U13743P00C100 evaluation board requires an external regulated power supply
(3.3V / 0.5A). The power is supplied to the evaluation board through pin 34 of the H1
header, or pin 5 of the P2 header.
The green LED ‘3.3V Power’ is turned on when 3.3V power is applied to the board.
4.1.2 Voltage Regulators
The S5U13743P00C100 evaluation board has an on-board linear regulator to provide the
1.5V power required by the S1D13743 Mobile Graphics Engine. It also has a step-up
switching voltage regulator to generate adjustable 6~24V, which can be used to power the
LED backlight on some LCD panels.
4.1.3 S1D13743 Power
The S1D13743 Mobile Graphics Engine requires 1.5V and 1.65~3.6V power supplies.
1.5V power for COREVDD and PLLVDD is provided by an on-board linear voltage
regulator.
IOVDD can be in the range of 1.65~3.6V. When JP4 is set to the 2-3 position, IOVDD is
connected to 3.3V. If a different voltage is required for IOVDD, set JP4 to the 1-2 position
and connect the external power supply to pin 32 of connector H1.
Note
If the IOVDD voltage is less than 3.0V, an oscillator working at the selected IOVDD
voltage must be used.
PIOVDD is the power used by the LCD interface and can be in the range of 1.65~3.6V.
When JP6 is set to the 2-3 position, PIOVDD is connected to 3.3V. If a different voltage is
needed for PIOVDD because of the LCD panel requirements, set JP6 to the 1-2 position
and connect the external power supply to pin 8 of connector H4.

Epson Research and Development Page 13
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
4.2 Clocks
The clock for the S1D13743 Mobile Graphics Engine is provided by a 4MHz oscillator.
The S5U13743P00C100 evaluation board has a DIP14 footprint for an optional second
oscillator, Y2. This is provided for cases requiring a different clock frequency for the
S1D13743 Mobile Graphics Engine. To use Y2, an oscillator must be populated in the Y2
footprint and the following board modifications must be made.
1. Remove R10 (33 ohm resistor, size 0402) to cut the output of Y1.
2. Populate R13 with a 33 ohm resistor, size 0402, to connect the output of Y2 to the
CLKI input of the S1D13743 Mobile Graphics Engine.
Note
If the board is configured for an IOVDD voltage below 3.0V, an oscillator working at
the selected IOVDD voltage must be used at Y2. The on-board 4MHz oscillator is not
specified to work below a 3.0V supply voltage.
TheS1D13743MGEcan outputtheinputclockontheCLKOUTpindependingonthestate
of the CLKOUTEN input. Both these signals are available on the H4 connector: CLKOUT
on pin 1 and CLKOUTEN on pin 4. On the board the CLKOUTEN pin is pulled down
which disables the CLKOUT signal. Note that connector H4 is not populated on the
S5U13743P00C100 evaluation board.
4.3 Reset
The S1D13743 Mobile Graphics Engine on the S5U13743P00C100 evaluation board can
be reset using a push-button (SW2), or via an active low reset signal from the host devel-
opment platform (pin 33 on the H1 connector).
4.4 Power Save
The S1D13743 chip has an input called PWRSVE that will enable (when high) or disable
(when low) the power save mode. This signal is available on pin 5 of the H4 connector. On
the board the PWRSVE pin is pulled down which means power save mode is controlled
only by the S1D13743 register setting. Note that connector H4 is not populated on the
S5U13743P00C100 evaluation board.

Page 14 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
4.5 Host Interface
4.5.1 Direct Host Bus Interface Support
All S1D13743 host interface pins are available on connector H1 which allows the
S5U13743P00C100 evaluation board to be connected to a variety of development
platforms. For detailed S1D13743 pin mapping, refer to the S1D13743 Hardware
Functional Specification, document number X70A-A-001-xx.
The following figure shows the location of host bus connector H1. H1 is a 0.1x0.1”
34-pin header (17x2).
Figure 4-1: Host Bus Connector Location (H1)
For the pinout of connector H1, see “Schematic Diagrams” on page 21.
H1

Epson Research and Development Page 15
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
4.5.2 Connecting to the Epson S5U13U00P00C100 USB Adapter Board
The S5U13743P00C100 evaluation board is designed to connect to a S5U13U00P00C100
USB Adapter Board. The USB adapter boardprovidesa simple connection to anycomputer
via a USB 2.0 connection. The S5U13743P00C100 directly connects to the USB adapter
board through connectors P1 and P2.
The USB adapter board also supplies the 3.3V power required by the S5U13743P00C100.
IOVDD should be selected for 3.3V and JP4 should be set to the 2-3 position.
When the S5U13743P00C100 is connected to the S5U13U00P00C100 USB Adapter
board, there are 2 LEDs on S5U13743P00C100 which provide a quick visual status of the
USB adapter. LED1 blinks to indicate that the USB adapter board is active. LED2 turns on
to indicate that the USB has been enumerated by the PC.
The following diagram shows the location of connectors P1 and P2. P1 and P2 are 40-pin
headers (20x2).
Figure 4-2: USB Adapter Connector Locations (P1 and P2)
For the pinout of connectors P1 and P2, see “Schematic Diagrams” on page 21.
Note
A windows driver must be installed on the PC when the S5U13743P00C100 is used
with the S5U13U00P00C100 USB Adapter Board. The S1D13xxxUSB driver is avail-
able at www.erd.epson.com.
P1
P2

Page 16 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
4.6 LCD Panel Interface
The LCD interface signals are available on connectors H2 and H3. For S1D13743 LCD
interface pin mapping, refer to the S1D13743 Hardware Functional Specification,
document number X70A-A-001-xx.
ConnectorH2 is 0.1x0.1” 20-pin header (10x2) and connector H3 is 0.1x0.1” 40-pin header
(20x2). For the pinout of connectors H2 and H3, see “Schematic Diagrams” on page 21.
On the evaluation board there is an adjustable 6~24V, 40mA max. power supply. This
voltage is provided only on connector H3 (it is not used elsewhere on the board). It is
intended for use to power the LED backlight on some LCD panels. The voltage is adjusted
by the R24 pot.
Note
For LCD panels that use a CCFL backlight, an external power supply must be used to
provide power to the inverter for the CCFL backlight. Usually, the inverter current con-
sumption is higher than the maximum 40mA current available from the on-board volt-
age regulator.
The following diagram shows the location of the LCD panel connectors H2 and H3.
Figure 4-3: LCD Panel Connectors Location (H2, H3)
For the pinout of connectors H2 and H3, see “Schematic Diagrams” on page 21.
H2
H3

Epson Research and Development Page 17
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
4.7 GPIO Connections
The S1D13743 Mobile Graphics Engine has 8 GPIO pins. All the GPIO pins are routed to
the H4 connector. Note that connector H4 is not populated on the S5U13743P00C100
evaluation board.
The following figure shows the location of the GPIO connector, H4.
Figure 4-4: GPIO Connector Location (H4)
For the pinout of connector H4, see “Schematic Diagrams” on page 21.
H4

Page 18 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
5 Parts List
Table 5-1: Parts List
Item Qty Reference Part Description Mfg / Mfg PN / Notes
116
C1, C2, C3, C4, C9, C12,
C13, C14, C18, C19, C20,
C21, C26, C27, C28, C30,
C32
0.1uF C0402 Yageo America
04022F104Z7B20D
212
C5, C6, C7, C8, C15, C16,
C17, C22, C23, C24, C25, 0.01uF C0402 Yageo America 0402ZRY5V7BB103
3 1 C10 1nF C0402 Yageo America
04022R102K9B20D
4 1 C11 10uF C0805 Panasonic - ECG
ECJ-CV50J106M
5 1 C29 100uF 4V T C3528 Kemet T494B107M004AS
6 2 C31, C33 0.01uF C0402 Kemet
C0402C103K4RACTU
7 1 C34 4.7uF 10V T C3528 Kemet T491B475K010AS
8 1 C35 10pF C0402 Panasonic - ECG
ECJ-0EC1H100D
9 1 C36 1uF 50V C1206 TDK C3216X7R1H105K
10 3 D1, D2, D3 LED0603
Panasonic - SSG
LNJ308G8LRA
LED GREEN SS TYPE
LOW CUR SMD
11 1 D4 MBR0530 SOD-123 Micro Commercial Co.
MBR0530-TP
12 2 F1, F2 ACF451832-222
TDK ACF451832-222
FILTER 3-TERM 60MHZ
300MA SMD
13 1 H1 HEADER_17X2 AMP 1-87215-7
14 1 H2 Extended LCD Connector Samtec TST-110-01-G-D
15 1 H3 LCD Connector Samtec TST-120-01-G-D
16 0 H4 HEADER 8X2 Samtec TSW-108-07-G-D
17 4 JP1, JP2, JP3, JP5 SIP2
CONN HEADER VERT
2POS .100 TIN or
GENERIC
18 2 JP4, JP6 SIP3
CONN HEADER VERT
3POS .100 TIN or
GENERIC
19 2 L1, L2 Ferrite R0603
Steward
HZ0603B751R-10
FERRITE 200MA 938
OHMS 0603 SMD

Epson Research and Development Page 19
Vancouver Design Center
S5U13743P00C100 Evaluation Board User Manual S1D13743
Issue Date: 2007/08/15 X70A-G-001-01
Revision 1.0
20 1 L3 10uH IND_ELL6
Panasonic - ECG
ELL-6SH100M
COIL 10UH 1300MA
CHOKE SMD
21 2 P1, P2 HEADER_20X2 HDR2X20/2MM 3M 151240-8422-RB
22 3 R1, R2, R3 10k R0402
23 3 R4, R7, R19 0 R0603
24 1 R5 150k 1% R0402
25 5 R6, R8, R9, R11, R20 0 R0402
26 1 R10 33 1% R0402
27 0 R12, R13 NP R0402
28 3 R14, R15, R16 270 1% R0402
29 3 R17, R18, R23 47k R0402
30 1 R21 887k 1% RC0603
31 1 R22 22k R0402
32 1 R24 200k Panasonic - ECG
EVN-5ESX50B25
33 6 SH1, SH2, SH3, SH4,
SH5, SH6 .100 in. Jumper Shunt Not Applicable
Sullins Electronics Corp.
STC02SYAN
JUMPER SHORTING TIN
34 1 SW1 SW4_DIPSW4 DIPSW4
CTS Corp 218-4LPST
SWITCH DIP HALF
PITCH 4POS
35 1 SW2 SW TACT-SPST SW_EVQQW
ITT Industries
KSC241GLFS
SWITCH TACT SILVER
PLT GULLWING
36 2 TPGND1, TP3.3VDD1 TP_SMT TP_1206
Keystone 5015
PC TEST POINT
MINIATURE SMT
37 0 TP1, TP2, TP3, TP4 T POINT F SIP1
38 1 U1 S1D13743
Table 5-1: Parts List
Item Qty Reference Part Description Mfg / Mfg PN / Notes

Page 20 Epson Research and Development
Vancouver Design Center
S1D13743 S5U13743P00C100 Evaluation Board User Manual
X70A-G-001-01 Issue Date: 2007/08/15
Revision 1.0
39 1 U2 TPS76915DBVT SOT23-5
Texas Instruments
TPS76915DBVT
IC 1.5V 100MA LDO REG
SOT-23-5
40 1 U3 TPS61040 SOT23-5
TI TPS61040DVBR
IC CONV DC/DC BOOST
LP SOT-23-5
41 1 Y1 4M OSC
Connor-Winfield
CWX823-4.0M
OSC 4.0000MHz 3.3V
50ppm SMD
42 0 Y2 14-Pin DIP AMP 2-641609-1
Table 5-1: Parts List
Item Qty Reference Part Description Mfg / Mfg PN / Notes
