Epson 740 Series User manual

EPSON Stylus COLOR 740
Manual

Page 2
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted
in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of SEIKO EPSON CORPORATION. The information contained herein is designed only for
use with this EPSON printer. EPSON is not responsible for any use of this information as applied to other
printers.
Neither SEIKO EPSON CORPORATION nor its affiliates shall be liable to the purchaser of this product or
third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of:
accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this product,
or (excluding the U.S.) failure to strictly comply with SEIKO EPSON CORPORATION’s operating and
maintenance instructions.
SEIKO EPSON CORPORATION shall not be liable for any damages or problems arising from the use of any
options or any consumable products other than those designated as Original EPSON Products or EPSON
Approved Products by SEIKO EPSON CORPORATION.
EPSON, EPSON Stylus, and ESC/P are registered trademarks and ESC/P 2 is a trademark of SEIKO EPSON
CORPORATION. SoundAdvice is a service mark and PhotoEnhance and EPSON FaxAdvice are trademarks
of Epson America, Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks
of their respective owners. EPSON disclaims any and all rights in those marks.
The ENERGY STAR emblem does not represent EPA endorsement of any product or service.
Copyright © 1999 by Epson America, Inc. ESC7400399
3/99

Page 3
Contents
Introduction 9
Windows System Requirements 10
Macintosh System Requirements 12
Printer Parts 14
How To Use Your Manuals 15
Warnings, Cautions, Notes, and Tips 16
ENERGY STAR Compliance 16
Year 2000 Ready 17
Important Safety Instructions 17
Basic Printing 20
Printing from Windows 20
Setting Printer Options from Windows Applications 21
Setting Default Printer Options 24
Checking Printer Status 25
Printing from a Macintosh 28
Setting Up Background Printing Options 31

Page 4
Advanced Printing 33
Using Custom Project Types 34
Customizing Print Quality and Special Effects 37
Customizing Color Settings 41
Using PhotoEnhance3 or Digital Camera Correction
Mode 42
Using Custom Color Management Modes 43
Using a Color Correction System 46
Using ColorSync on the Macintosh 47
Selecting Paper Size and Orientation Options 49
Selecting Paper Options in Windows 50
Selecting Paper Options on a Macintosh 55
Selecting Print Layout Options 60
Choosing Print Layout Options in Windows 60
Choosing Print Layout Options on a Macintosh 70
Using Print Preview on the Macintosh 77
Saving Custom Settings 79
Redefining Custom Settings 80
Deleting Custom Settings 81

Page 5
Printing on Special Media 82
Selecting Special Media 83
Media Loading and Handling Guidelines 85
Letterhead, Preprinted Forms, and Legal-size Paper 86
EPSON Photo Quality Glossy Paper, Film, and
Transparencies 86
Envelopes 88
EPSON Photo Paper 89
EPSON Photo Quality Ink Jet Cards 92
EPSON Photo Stickers 93
EPSON Photo Quality Self Adhesive Sheets 93
EPSON Cool Peel Iron-On Transfer Paper 94
Managing Print Jobs 95
Managing Print Jobs in Windows 95, Windows 98, and
Windows NT 4.0 96
Selecting the Speed & Progress Options 97
Using the Spool Manager 100
Using Status Monitor 2 101
Managing Print Jobs in Windows 3.1 111
Using the Spool Manager 111

Page 6
Managing Print Jobs on a Macintosh 114
Using Monitor3 115
Using the Macintosh Status Monitor 118
Selecting Configuration Options 120
Maintenance and Transportation 122
Replacing an Ink Cartridge 123
Removing and Installing Ink Cartridges 124
Replacing an Outdated Ink Cartridge 127
Cleaning the Print Head 128
Using the Head Cleaning Utility 128
Using the Control Panel 129
Examining the Nozzle Check Pattern 131
Aligning the Print Head 132
Cleaning the Printer 133
Transporting the Printer 134

Page 7
Troubleshooting 135
Diagnosing Problems 136
Checking the Control Panel Lights 137
Running a Printer Operation Check 138
Confirming the Printer ID Number 139
Improving Print Quality 140
Solving Printing Problems 146
Solving Printer Software Problems 150
Fixing Paper Problems 155
Solving Miscellaneous Printout Problems 158
Uninstalling Printer Software 162
Windows 95, Windows 98, and Windows NT 4.0
Instructions 162
Windows 3.1 Instructions 163
Macintosh Instructions 163
Where To Get Help 165

Page 8
Specifications 167
Printing 167
Paper 168
Ink Cartridges 172
Mechanical 173
Electrical 174
Environmental 174
Safety Approvals 175
DOS Support 175
Control Panel Settings 176
Character Tables 177
Interfaces 178
Index 180

Page 9
Introduction
Your EPSON Stylus®COLOR 740 printer is the ideal output device
for business graphics, layout proofs, digital photography, or any
project youcreate on your computer. With resolutions up to1440 by
720 dpi and EPSON’s unique variable micro droplet technology,
you get amazingly realistic photographic images, vivid color
graphics, and razor-sharp black text.
The printer software for Microsoft®Windows®and Macintosh®
provides advanced color management with adjustable levels of
brightness, contrast, sharpness, and other settings. Support for
ColorSync™2.01 and two Windows color matching methods gives
you even more precise color control.
EPSON’s specially formulated ink cartridges and wide variety of ink
jet papers offer the most flexibility for getting the results you want.
With standard parallel, serial, and high-speed USB (Universal
Serial Bus) ports, setting up your printer is fast and easy.
This chapter gives you general information about your printer in
these sections:
◗Windows System Requirements
◗Macintosh System Requirements
◗Printer Parts

Introduction Page 10
◗How To Use Your Manuals
◗ENERGY STAR Compliance
◗Year 2000 Ready
◗Important Safety Instructions
Windows System Requirements
To use your printer and its software with a PC, your system should
have:
◗An IBM®compatible PC with at least a 386/25 MHz (for
Windows 3.1x), 486/25 MHz (for Windows 95 or Windows
NT®4.0), or 486/66 MHz (for Windows 98) processor
(Pentium®processor recommended)
◗DOS, Microsoft Windows 3.1x, Windows 95, Windows 98, or
Windows NT 4.0
◗At least 16MB of RAM (32MB for Windows 3.1, 95, or 98 or
64MB for Windows NT 4.0 recommended)
◗At least 50MB of free hard disk space for storing images
(100MB recommended)
◗VGA, Super VGA, or better display adapter and monitor
◗Double-speed CD-ROM drive (quad-speed or faster
recommended) for installing the printer software

Introduction Page 11
◗For parallel connection, a high-speed, bidirectional, IEEE-1284
compliant parallel cable (6 to 10 feet long). The cable must
have a D-SUB, 25-pin, male connector foryour computer and a
36-pin, Centronics®compatible connector for the printer.
For USB connection to a computer with Windows 98 and a
Windows 98 compliant USB port, a shielded USB “AB”
interface cable, from Series A (computer) to Series B (printer)
up to 6.5 ft. (2 meters) long
Caution:
Using an improperly
shielded USB cable—
especially a cable
more than 6.5 ft.
(2 meters) long—may
cause the printer to
malfunction.

Introduction Page 12
Macintosh System Requirements
To use your printer and its software with a Macintosh, your system
should have:
◗One of the following Macintosh models:
LC475, LC575, LC630
Quadra series
Centris series
PowerBook®series (190, 520, 540, 550 or later)
PowerBook Duo 280, 2300c/100
Performa®475, 575, 588, 630, 5210 or later
Power Macintosh®series
iMac™ Series (USB connection only
Power Macintosh G3 (USB connection only)
◗For serial connection: System 7.1 or later (7.6 or later
recommended); some application software on the EPSON
CD-ROM may require System 7.52 or later
For USB connection: iMac or Power Macintosh G3 with Ssytem
8.1 or later
◗At least 16MB of RAM (20MB or more recommended)
◗At least 50MB of free hard disk space for storing images
(100MB recommended)
◗13-inch RGB display or better
Caution:
If your iMac is running
OS 8.1, you must
download and install
the iMac Update 1.0
from Apple at
http://swupdates.info.
apple.com before yo
install the EPSON
USB printer software.
Contact Apple
Computer if you have
problems installing
this update.
If you iMac is running
OS 8.5, you don’t
need to download
and install the iMac
Update 1.0; your
system includes full
support for the
EPSON USB printer
software.

Introduction Page 13
◗Double-speed CD-ROM drive (quad-speed or faster
recommended) for installing the printer software
◗For serial connection, an ImageWriter®II serial cable or
equivalent (8-pin mini DIN male/male, Belkin F2V024
recommended)
For USB connection to an iMac or Power Macintosh G3, a
shielded USB “AB” interface cable, from Series A (computer) to
Series B (printer) up to 6.5 ft. (2 meters) long
Caution:
Using an improperly
shielded USB cable—
especially a cable
more than 6.5 ft.
(2 meters) long—may
cause the printer to
malfunction.

Introduction Page 14
Printer Parts
paper support
printer cover
output tray
output tray extensions
edge
guides
sheet feeder
paper thickness
lever
control panel
ink cartridge holders

Introduction Page 15
How To Use Your Manuals
To set up your printer and install the printer software, see the Start
Here card. This manual contains the following information:
Basic Printing covers the basics of printing with Windows or
Macintosh.
Advanced Printing tells you how to print using custom settings for
print quality, color management, and distinctive layouts.
Printing on Special Media gives guidelines for selecting the right
paper or other media for your print job and instructions for loading it
in your printer.
Managing Print Jobs explains how to control print jobs and check
printer status while you’re printing.
Maintenance and Transportation gives instructions for replacing ink
cartridges, cleaning and aligning the print head, and cleaning and
transporting the printer.
Troubleshooting provides solutions for any problems you may have
with your printer or software.
Specifications provides the technical details on your printer, ink
cartridges, and EPSON papers.
To go right to the section you need, see the Index.

Introduction Page 16
Warnings, Cautions, Notes, and Tips
You’ll find this information throughout your manual:
Warnings must be followed carefully to avoid bodily injury.
Cautions must be observed to avoid damage to your equipment.
Notes contain important information about your printer.
Tips contain additional hints for great printing.
ENERGY STAR Compliance
As an ENERGY STAR Partner, EPSON has determined that this
product meets the ENERGY STAR guidelines for energy efficiency.
The EPA ENERGY STAR Office Equipment program is a voluntary
partnership with the computer and office equipment industry to
promote the introduction of energy-efficient personal computers,
monitors, printers, fax machines, and copiers in an effort to reduce
air pollution caused by power generation.

Introduction Page 17
Year 2000 Ready
Your EPSON printer is Year 2000 Ready . However, be sure
the other parts of your computer system are also ready for the
year 2000.
Important Safety Instructions
Before using your printer, read the following safety instructions to
make sure you use the printer safely and effectively:
◗Turn off and unplug the printer before cleaning. Clean with a
damp cloth only. Do not spill liquid on the printer.
◗Do not place the printer on an unstable surface or near a
radiator or heating vent.
◗Do not block or cover the openings in the printer’s cabinet or
insert objects through the slots.
◗Use only the type of power source indicated on the printer’s
label.
◗Connect all equipment to properly grounded power outlets.
Avoid using outlets on the same circuit as photocopiers or air
control systems that regularly switch on and off.
Caution:
Always turn the
printer off using the
Ppower button.
Don’t switch off the
electrical outlet or
powerstrip, or unplug
the printer until the
Ppower light is off.

Introduction Page 18
◗Place the printer near a wall outlet where the plug can be easily
unplugged.
Placez l’imprimante près d’une prise de contacte où la fiche
peut être débranchée facilement.
◗Do not let the power cord become damaged or frayed.
◗If you use an extension cord with the printer, make sure the
total ampere rating of the devices plugged into the extension
cord does not exceed the cord’s ampere rating. Also, make
sure the total ampere rating of all devices plugged into the wall
outlet does not exceed the wall outlet’s ampere rating.
◗Except as specifically explained in this manual, do not attempt
to service the printer yourself.
◗Unplug the printer and refer servicing to qualified service
personnel under the following conditions:
If the power cord or plug is damaged; if liquid has entered the
printer; if the printerhas been dropped or the cabinet damaged;
if the printer does not operate normally or exhibits a distinct
change in performance. Adjust only those controls that are
covered by the operating instructions.
◗Do not put your hand inside the printer or touch the cartridge
during printing.
◗Under normal circumstances, ink will not come out of the
cartridge. If it does get on your skin, wash it off with soap and
water. If it gets in your eyes, flush them immediately with water.

Introduction Page 19
◗Keep ink cartridges out of the reach of children.
◗Do not dismantle the ink cartridges or try to refill them. This
could result in damage to the print head.
◗Once you install an ink cartridge, do not open the clamp or
remove the cartridge except to replace it with a new one. The
cartridge may become unusable otherwise.
◗Install the ink cartridge immediately after you remove it from its
foil package. Leaving the cartridge unpacked for a long time
before use may result in reduced print quality.
◗Do not use an ink cartridge beyond the date printed on the
cartridge package. For best results, use up the ink cartridges
within six months of installing them.
◗Do not shake an ink cartridge; this can cause leakage.
◗Always turn the printer off using the Ppower button. When you
press this button, the Ppower light flashes briefly then goes
out. Do not unplug the printer or turn off the power to the outlet
until the Ppower light is off.
◗Before transporting the printer, make sure the print head is
capped in the far right position and the ink cartridges are in
place.

Page 20
Basic Printing
It’s easy to print all your color and monochrome documents with
your EPSON Stylus COLOR 740. First set up your printer and
install the software, following the instructions in the Start Here card.
Read this chapter to find out about:
◗Printing from Windows
◗Printing from a Macintosh
Printing from Windows
This section tells you about:
◗Setting Printer Options from Windows Applications
◗Setting Default Printer Options
◗Checking Printer Status
Note:
For instructions on
printing with DOS,
see DOS Support.
