DFX-9000
IMPACT PRINTER
Combining speed and reliability
for maximum productivity
Key Features
Blaze through critical reports with ultra-fast print speeds
■
Prints multipart forms, labels, and more at speeds
up to 1550 cps
Tackle the most demanding print tasks
■
Durable 9-pin performer offers an MTBF rating
of 20,000 POH at 25% duty cycle
Get dependable print performance, day after day
■
Boasts a 400-million-character print head life
Minimize your application costs
■
15-million-character ribbon cartridge ensures
low cost printing and reduces the need for frequent
user intervention
Simplify the integration process
■
Convenient LCD display allows for easy printer
configuration and menu navigation
Meet all your printing needs with flexible forms handling
capabilities
■
Prints 136-column, wide-format reports, plus forms
up to 10 parts thick
■
Front and rear paper paths
■
Platen gap adjusts automatically, according to the
paper thickness
■
Auto jam sensor eliminates wasting forms
Use with new or legacy systems
■
Enhanced connectivity supports
standard Parallel, Serial, and
USB interfaces
■
Accommodates optional internal
Type B interface boards for
easy networking
Enjoy the added confidence of
superior Epson service and support
■
Includes a one-year on-site
limited warranty in the U.S.
and Canada
• • • •
• • • •
• • • •
• • • •
• • • •
• • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •
• • • •
With speeds up to 1550 cps and
an MTBF rating of 20,000 power-
on hours (POH), the Epson DFX-
9000 offers the power and
durability to tackle the most
demanding print tasks. Day after
day, you can count on it to efficiently
process everything from reports and 10-part forms to shipping documents
or mailing labels.
A robust, dependable workhorse, this 9-pin, wide-format printer boasts
a 400-million-character print head life and 15-million-character ribbon
cartridge, which minimizes production costs and reduces the need for
frequent user intervention. Its advanced paper handling capabilities make
it the perfect solution for a wide variety of applications, including critical
spreadsheets, checks, invoices, bar codes and more.
Featuring two standard paper paths, the DFX-9000 easily switches between
multiple applications. Its intelligent paper sensor detects the paper width
and thickness, adjusting automatically for optimum performance and
high-quality results. It even features an automatic jam sensor to prevent
wasting forms in the unlikely event of a paper jam.
With Parallel, Serial, and USB interfaces standard, plus a type-B slot for
optional connectivity, the DFX-9000 easily attaches to new or legacy
systems in standalone or networked environments. And, its convenient
LCD display and intuitive menu selections mean setup has never
been easier. Plus, it’s all backed by Epson’s one-year on-site
warranty for superior service and support.
EPSON DFX-9000
• • • •
• • • •
• • • •

Printing Method
9-pin impact dot matrix
Print Direction
Text Mode: Bidirectional
Graphics Mode: Unidirectional (bidirectional via software)
Print Speed
High Speed Draft 1550 cps (10 cpi)
Draft 1320 cps (10 cpi)
Near Letter Quality 330 cps (10 cpi)
Character Sets
11 character tables, 13 international character sets
Resident Fonts (cpi)
Epson Super Draft 10
Epson Draft 10, 12
Epson NLQ Roman 10, 12, proportional
Epson NLQ San Serif 10, 12, proportional
Bar Code Fonts EAN-13, EAN-8, Interleaved 2 of 5,
UPC-A, UPC-E, Code-39, Code-128,
POSTNET
Printable Columns
136 columns (10 cpi)
Formatting
Tabs 10 sets vertical tabs, 32 horizontal tabs
Line spacing 1/6," 1/8" or programmable
(min 1/216")
Perforation skip Skip over perforation programmable
in lines
Paper Feed Speed
Approximately 26.5 ms/line at 1/6" line spacing; 15 inches per second
(continuous feed)
Paper Paths
Push tractor Front or rear in, top out
Pull tractor Front or rear in, top out
Paper Feed Methods
Dual push tractors/paper paths: automatic back-out and loading;
automatic paper thickness adjustment; automatic paper width detection;
microadjustment for top-of-form and tear-off mode; adjustable tractor
feed; perforation cutter (optional); pull tractor (optional)
Input Buffer
128KB or 0KB, user selectable
Software Drivers*
Windows 95, 98, 98SE, 2000, XP, Me and NT 3.51/4.0
Standard Interfaces
Bidirectional IEEE 1284 Parallel
USB 1.1, RS-232C Serial
Type B slot for optional interface boards
Optional Interfaces
10/100 Base T Ethernet, RS-232 Serial, Coax, Twinax
Printer Languages
ESC/P,®IBM PPDS
Paper Handling
Multi-part Forms
Front 1 original + 9 copies
Rear 1 original + 6 copies
Continuous Feed 3.0" to 16.5"
Labels 2.5" x .94" (min)
Page length 3.5" minimum for forms
with labels
Sound Level
58 dB (A)
Power Requirements
50 - 60Hz ±.5Hz; 200 watts; 100-240 volt
Energy Star compliant
Physical Dimensions
Height 14.3"
Width 27.6"
Depth 14.9"
Weight 75 lb
Reliability
MTBF 20,000 POH (25% duty cycle)
Print head life 400 million characters
Ribbon life 15 million characters (draft,
10 cpi, 14 dots/character)
Warranty
One-year on-site limited warranty in the U.S. and Canada
Support-The Epson ConnectionSM
Automated Technical Support [phone]
Pre-Sales Support U.S. & Canada [phone]
Internet Website www.epson.com
* Additional software drivers available in your Windows operating system, or at www.epson.com.
** Field upgrade of Flash ROM to be done by Epson authorized service centers
Printer Specifications
Epson DFX-9000 Description
C11C605001 Epson DFX-9000 printer
S015384 Epson DFX-9000 ribbon cartridge
C12C800381 Pull tractor unit
C815071 Perforation cutter
8502 Printer stand
C823051 Serial interface
C823071 32KB Serial interface
C823121 LocalTalk interface
C823141 Coax interface
C823151 Twinax interface
C823452 Bidirectional Parallel interface
C12C823912 Multiprotocol 10/100 Base-TX Ethernet Print Server
Ordering Information
