Epson ST-2000 Instruction Manual

Start Here
IMPORTANT: Before using this product, make sure you read
these instructions and the safety instructions in the online User’s
Guide.
1Unpack
Note: Do not open the ink bottles until you are ready to fill the ink
tanks. The ink bottles are vacuum packed to maintain reliability.
1 Remove all protective materials from the product.
2 Lift up the scanner unit. Remove all protective materials
from inside the product.
Caution: Do not touch the flat white cable or the ink tubes and
their translucent cover.
2Fill ink tanks
Note: This product requires careful handling of ink. If ink spills, wipe
it off immediately with a damp towel to avoid permanent stains. If ink
gets on your clothes or belongings, it may not come off.
Caution: Keep the ink bottles out of the reach of children and do not
drink the ink.
1 Open the ink tank cover, then open the cap for the ink
tank you are going to fill.
2 Unpack one of the ink bottles. Hold the ink bottle upright
and slowly turn the bottle cap to remove it.
Caution: Do not shake or squeeze the ink bottles. Do not touch
the top of the ink bottle after its cap is removed.
3 Position the top of the ink bottle along the slot in front of
the filling port, then slowly stand the bottle up to insert it.
Note: Refer to the color-coded sticker on the ink tank unit to
identify the color of each tank. Do not force the bottles into
position; they are keyed for each color.
4 Wait for the ink to fill the tank. Do not squeeze the bottle.
Ink flows into the tank and stops automatically when the
ink is filled to the upper line.
Note: If ink does not flow from the bottle, lift and reinsert the
bottle.
ST-2000

12 When the message to start initialization appears on the
LCD screen, press the start button to start charging
the ink. Ink charging takes approximately 10 minutes. A
message appears when ink charging is complete. Press
the OK button to continue.
Caution: Do not turn off the product, raise the scanner unit, or
load paper while the product is charging or you’ll waste ink.
Note: The included ink bottles are designed for reliable printer
setup and cannot be resold. After setup, the remaining ink is
available for printing.
13 To complete filling the ink tanks, repeat steps 1 through 6
using the remaining ink in the bottles.
Note: Replace the bottle cap before disposing of the bottles.
14 Close the ink tank cover and scanner unit.
15 Select Maintenance > Reset Ink Levels, then follow the
on-screen instructions to reset the ink levels.
16 Follow the on-screen instructions to adjust the print
quality. Press the OK button to continue.
Note: You can change these settings later using the product’s
control panel. For more information, see the online User’s Guide.
3Load paper
See the online User’s Guide for information about loading
capacity and available paper types and sizes.
1 Make sure the product is not charging. Then flip the
feeder guard forward, raise the paper support, and tilt it
backwards slightly.
2 Slide the edge guides all the way out.
5 When the ink tank is full, remove the ink bottle and
securely close the ink tank cap. Place the remaining ink
aside; you will need it later.
Note: Replace the bottle cap and tighten it.
6 Repeat the previous steps for the other colors.
7 Close the ink tank cover and then the scanner unit.
8 Connect the power cord to the back of the product and to
an electrical outlet.
Caution: Do not connect to your computer yet.
9 Raise the control panel, then press the power button to
turn on the product.
Note: If an error message appears, turn off the product and
check that no protective material has been left inside the product.
10 Press or to select your language on the LCD screen,
then press the OK button.
Note: You can change this setting later using the product’s
control panel. For more information, see the online User’s Guide.
Follow steps 11 and 12 to continue ink charging.
11 When the message to see the Start Here sheet appears
on the LCD screen, press the OK button. On the next
screen, press and hold the help button for 3 seconds.

4 When you see the Select Your Connection screen, select
one of the following:
• Wireless connection
In most cases, the software installer automatically
attempts to set up your wireless connection. If setup
is unsuccessful, you may need to enter your network
name (SSID) and password.
• Direct USB connection
Make sure you have a USB cable (not included).
Mobile printing
Connect wirelessly from your smartphone, tablet, or computer.
Print documents and photos from across the room or around
the world:
• Print directly from your iOS device. Simply connect your
printer and device to the same network and tap the action
icon to select the print option.
• Use Epson Print Enabler (free from Google Play™) with
Android™ devices (v4.4 or later). Then connect your printer
and device to the same network and tap the menu icon to
print.
• Print remotely with Epson Connect™ and Google Cloud
Print™. See the online User’s Guide for instructions or learn
more at www.epson.com/connect (U.S.) or
www.epson.ca/connect (Canada).
Any problems?
Network setup was unsuccessful.
• Make sure you select the right network name (SSID).
• Restart your router (turn it off and then on), then try to
connect to it again.
• The printer can only connect to a network that supports
2.4 GHz connections. If your router offers both 2.4 GHz and
5 GHz connections, make sure 2.4 GHz is enabled.
• If you see a firewall alert message, click Unblock or Allow
to let setup continue.
• If your network has security enabled, make sure you enter
your network password (WEP key or WPA passphrase)
correctly. Be sure to enter your password in the correct
case.
There are lines or incorrect colors in my printouts.
Run a nozzle check to see if any of the nozzles are clogged.
Then clean the print head, if necessary. See the online User’s
Guide for more information.
3 Load paper, glossy or printable side up and short edge
first, in the middle of the rear paper feed slot.
4 Slide the edge guide against the paper, but not too tightly.
5 Pull out the output tray.
6 Select the paper settings on the product’s control panel.
4Install software
Note: An Internet connection is required to obtain the product
software.
To print from a Chromebook™, go to
www.epson.com/support/gcp (U.S.) or
www.epson.ca/support/gcp (Canada) for instructions.
1 Make sure the product is NOT CONNECTED to your
computer.
Windows®:If you see a Found New Hardware screen, click
Cancel and disconnect the USB cable.
2 Download and run your product’s software package:
www.epson.com/support/st2000 (U.S.) or
www.epson.ca/support/st2000 (Canada)
3 Follow the instructions on the computer screen to run the
setup program.

EPSON is a registered trademark, EPSON Exceed Your Vision is a registered logomark, and
Epson Connect is a trademark of Seiko Epson Corporation.
Designed for Excellence is a trademark of Epson America, Inc.
Windows is a registered trademark of Microsoft Corporation in the United States and/or other
countries.
Mac is a trademark of Apple Inc., registered in the U.S. and other countries.
Android, Google Cloud Print, Chromebook, and Google Play are trademarks of Google LLC.
General Notice: Other product names used herein are for identification purposes only and may
be trademarks of their respective owners. Epson disclaims any and all rights in those marks.
This information is subject to change without notice.
© 2018 Epson America, Inc., 9/18
Printed in XXXXXX CPD-56461
The product’s screen is dark.
Make sure your product is turned on, and press any button to
wake it from sleep mode.
Setup is unable to find my product after connecting it
with a USB cable.
Make sure your product is on and securely connected as
shown:
Any questions?
User’s Guide
Windows: Click the icon on your desktop or Apps screen to
access the online User’s Guide.
Mac: Click the icon in Applications/Epson Software/Guide to
access the online User’s Guide.
If you don’t have a User’s Guide icon, go to the Epson website,
as described below.
Technical support
Visit www.epson.com/support/st2000 (U.S.) or
www.epson.ca/support/st2000 (Canada) to download drivers,
view manuals, get FAQs, or contact Epson.
Call [phone] (U.S.) or [phone] (Canada), 6 am to
8 pm Pacific Time, Monday through Friday, and 7 am to 4 pm,
Pacific Time, Saturday. Days and hours of support are subject
to change without notice. Toll or long distance charges may
apply.
Recycling
Epson offers a recycling program for end of life hardware and
ink bottles. Please go to www.epson.com/recycle (U.S.) or
www.epson.ca/recycle (Canada) for information on how to
return your products for proper disposal.
Need paper and ink?
Ensure brilliant results with Epson®specialty
papers, engineered specifically for Epson
printers. Find specialty papers and Epson
Genuine Ink at www.epson.com (U.S. sales) or
www.epson.ca (Canadian sales) and at Epson
authorized resellers. Call 800-GO-EPSON
(800-463-7766).
ST-2000 replacement inks
Color Part number
Black 502
Cyan 502
Magenta 502
Yellow 502
