Epson LX-800 User manual

LX-HOO
TECHNICAL MANUAL
—
.—
EPSON

REV.-A
PREFACE
This manual describes functions, theory of electrical and mechanical opera-
tions, maintenance, and repair of the LX-800.
The instructions and procedures included in this document are intended for
the experienced repair technician, who should pay attention to the precautions
on the preceding page. The chapters are organized as follows:
Chapter 1 —
—
Chapter 2 —
Chapter 3 —
Chapter 4 —
Chapter 5 —
Chapter 6 —
Provides a general product overview, lists specifications, and
illustrates the main components of the printer
Describes the theory of printer operation
Discusses the options
Includes a step-by-step guide for product disassembly, assem-
bly, and adjustment
Provides Epson-approved techniques for troubleshooting
Describes preventive maintenance techniques and lists lubri-
cants and adhesives required to service the equipment
● The contents of this manual are subject to change without notice.
- iv -
