Epson ME Office 535 Assembly instructions

Basic Operation Guide
- for use without a computer -

2
Getting More Information (Introduction of Online Manuals)
For troubleshooting information and instructions on how to print or scan
from a computer, see the online User’s Guide.
For information on network setup and network troubleshooting, see the
online Network Guide (network-compatible models only).

3
About This Guide..................................................................................................................................................... 4
Important Safety Instructions............................................................................................................................. 4
Adjusting the Angle of the Panel.......................................................................................................................5
Power Saving Function..........................................................................................................................................5
Guide to Control Panel..........................................................................................................................................6
Using the LCD Screen.............................................................................................................................................6
Handling Media and Originals
Selecting Paper.................................................................................................................................................... 9
Loading Paper....................................................................................................................................................10
Inserting a Memory Card ...............................................................................................................................12
Placing Originals ...............................................................................................................................................14
Copying/Printing/Scanning
Copying Photos or Documents ...................................................................................................................16
Printing Photos..................................................................................................................................................18
Scanning to a Computer................................................................................................................................20
Maintenance
Checking the Ink Cartridge Status..............................................................................................................23
Checking/Cleaning the Print Head.............................................................................................................25
Aligning the Print Head..................................................................................................................................27
Changing UI Language...................................................................................................................................28
Restoring Default Settings ............................................................................................................................29
Solving Problems
Error/Warning Messages ...............................................................................................................................31
Ink Precautions ..................................................................................................................................................32
Replacing Ink Cartridges................................................................................................................................33
Paper Jam ............................................................................................................................................................35
Print Quality/Layout Problems.....................................................................................................................37
Contacting Epson Support............................................................................................................................38
Copyright Notice ...................................................................................................................................................39
Contents

4
About This Guide
Follow these guidelines as you read your instructions:
wcQR&
Warning:
Warnings must be followed
carefully to avoid bodily injury.
Caution:
Cautions must be observed
to avoid damage to your
equipment.
Must be observed to avoid
bodily injury and damage to
your equipment.
Note:
Notes contain important
information and hints for using
the printer.
Indicates a page number where
additional information can be
found.
Important Safety Instructions
Use only the power cord
that comes with the
printer. Use of another
cord may cause re or
shock. Do not use the cord
with any other equipment.
Place the printer near
a wall outlet where the
power cord can be easily
unplugged.
Use only the type of
power source indicated on
the printer.
Make sure the power cord
meets all relevant local
safety standards.
Do not let the power
cord become damaged
or frayed.
Keep the printer away
from direct sunlight or
strong light.
Do not open the scanner
unit while copying,
printing, or scanning.
Do not use aerosol products
that contain ammable
gases inside or around
the printer. Doing so may
cause re.
Except as specically
explained in your
documentation, do not
attempt to service the
printer yourself.
Keep ink cartridges out of
the reach of children.
If ink gets on your skin, wash the area
thoroughly with soap and water. If ink gets
into your eyes, ush them immediately
with water. If discomfort or vision problems
continue after a thorough ushing, see a
doctor immediately. If ink gets into your
mouth, spit it out immediately and see a
doctor right away.
Do not shake the ink
cartridges too vigorously;
otherwise ink may leak from
the cartridge.
If you remove an ink cartridge
for later use, protect the ink
supply area from dirt and
dust and store it in the same
environment as the printer. Do
not touch the ink supply port
or surrounding area.

5
Power Saving Function
After 13 minutes of inactivity, the screen turns black to save energy. Press
any button to return the screen to its previous state.
Adjusting the Angle of the Panel
To lower or close the panel, unlock by pulling the lever on the rear until it
clicks, and then lower down. Simply lift the panel to raise it.

6
Using the LCD Screen
a b c d
Press uor dto set the number
of copies.
Press lor rto select the copy
color mode or to change the
photo displayed on the LCD
screen.
Press uor dto change the
menu item.
Press lor rto change the
menu setting option. If no
other settings are available, l
and rare not displayed.
The actual screen display may
dier slightly from those shown in
this guide.
Q
Guide to Control Panel
a b c d e f
Pl, u, r, d, OK x y
Turns on/o printer. Network status light. Only
provided on network
compatible models. For more
details, see the online Network
Guide.
Returns to the top menu. When
on the top menu, switches
between Copy, Print Photos,
Scan, and Setup mode.
Selects photos and
menus.
Starts the operation you
selected.
Cancels an ongoing
operation or returns to
the previous screen.

7

8
Handling Media and Originals

9
Selecting Paper
The availability of special paper
varies by area.
If you want to print
on this paper...
Choose this on
the control panel
Loading capacity
(sheets)
a Plain paper *¹ Plain Paper [11 mm] *²
b Epson Bright White
Ink Jet Paper
Plain Paper 80 *²
c Epson Premium
Glossy Photo Paper
Photo Paper 20
d Epson Premium
Semigloss Photo
Paper
e Epson Ultra Glossy
Photo Paper
f Epson Glossy
Photo Paper
g Epson Photo Paper
*1 Paper with a weight of 64 to 90 g/m².
*2 30 sheets for paper that already has printing on one side.

10
Loading Paper
Slide out. Fan and align the stack of paper. Load printable side up. Fit.
B C D E
When using Legal size paper or envelopes, see the online User’s Guide.
QA
Flip forward.

11
You can use A4 paper with two binder holes.
Q
Do not load paper above the H
arrow mark inside the edge guide.
Q
F
Flip back.

12
Do not try to force the card all the
way into the slot. It should not be
fully inserted.
c
Inserting a Memory
Card A B
Insert one card at a time. Check the light stays on.
Removing a Memory
Card
Check the light stays on.
A B
Remove.
On Flashing
Q

13
If the memory card needs an adapter then attach it before
inserting the card into the slot, otherwise the card may get stuck.
c
*Adapter required
SD
SDHC
MultiMediaCard
MMCplus
SDXC
MMCmobile *
MMCmicro *
miniSD *
miniSDHC *
microSD *
microSDHC *
Memory Stick
Memory Stick PRO
MagicGate Memory Stick
Memory Stick Duo *
Memory Stick PRO Duo *
Memory Stick PRO-HG Duo *
MagicGate Memory Stick Duo *
Memory Stick Micro *

14
Placing Originals
Place face-down horizontally.
A B
Slide to the corner.

15
Copying/Printing/Scanning

16
Copying Photos or
Documents AR&10 B C
Load paper. Place original horizontally. Select Copy.
Set the number of copies.
D F
Check the settings and start copying.
To change the settings, press d
and go to step G.
Q
E
Select a color mode.

17
H
Start copying.
If you want to specify a percentage to reduce or enlarge your copy, select
a setting other than Auto Fit from Reduce/Enlarge, and specify the
percentage in Custom Size.
Q
Except for the number of copies, the copy settings remain unchanged until
the printer is turned o.
Q
GR&6
Select the item and change the
setting.
If you want to change the color mode or the number of copies, press yto
display the screen in step D, make the changes, and then press x.
Q

18
Printing Photos AR&10 BR&12 C
Load photo paper. Insert a memory card. Select Print Photos.
F
Display the current print settings.
E
Set the number of copies.
To select more photos, repeat
steps Dand E.
Q
D
Select a photo.

19
HR&6
Select the item and change the
setting.
G
Check the settings and start printing.
I
Start printing.
To change the settings, press dand go to step H. If you want to change the number of copies, press yto display
the screen in step E, make the changes, and then press x.
Q
When Borderless is selected, the image is slightly enlarged and cropped to
ll the paper. Print quality may decline in the top and bottom areas, or the
area may be smeared when printing.
Q

20
Scanning to a
Computer Make sure you have installed software for this printer on your computer
and connected following the instructions on the Start Here poster.
QA
Place original horizontally.
B
Select Scan.
D
Select your PC and start scanning.
C
Select an item.Select an item and start scanning.
