A
STYLUS COLOR 640
Page 8

A
STYLUS COLOR 640
Page 7

A
STYLUS COLOR 640
Page 6

A
STYLUS COLOR 640
Page 5
REF. PART NO. DESCRIPTION QTY
755 1031178 BUSHING, FASTEN, SHAFT, LEFT 1
756 1037724 PAPER SUPPORT, SUUPPORT, UPPER 1
757 1042947 HOLDER, PAPER SUPPORT, SUPPORT, UPPER 1
758 1036849 EXTENSION SPRING, 0.29 1
759 1037575 COVER CARTRIDGE, BK 1
760 1040656 COVER, CARTRIDGE, C; B 1
761 1030378 SEPARATOR, CARTRIDGE, BK 1
762 1030379 SEPARATOR, CARTRIDGE, C 1
763 2021854 DETECTOR, HP 1
764 1043828 CORK; B 1
765 1034969 CLEANER, HEAD, ASP 1
END

A
STYLUS COLOR 640
Page 4
REF. PART NO. DESCRIPTION QTY
589 B101254590 LEAF SPRING 1
590 1030972 PLAIN WASHER, 2.6X0.5X8 1
700 F059000 PRINT HEAD, IJ160-0A0 KIT – F059000-D 1
701 1030383 FASTENER, HEAD 1
702 1030954 TORSION SPRING, 49 1
703 1024130 C.B.P-TITE SCREW, 3X6, F/ZN 4
704 2023353 CABLE, HEAD 1
705 1030386 HOLDER, CABLE 1
706 1033220 SPACER, CABLE HEAD 1
707 1038244 FRAME, ASF; B 1
708 1040589 HOPPER 1
709 1040590 EDGEGUIDE 1
710 1040606 CORK 1
711 1030429 SLIDER, EDGE GUIDE 1
712 1030960 COMPRESSION SPRING, 3.23 1
713 1033016 PAD, BRAKE EDGE GUIDE 1
714 1040645 REINFORCEMENT PLATE, HOPPER 1
716 1040661 PAD ASSY., RIGHT 1
717 1030450 LEVER, PAD, RELEASE, RIGHT 1
718 1030420 ROD SPRING, HOLDER, PAD 2
719 1040608 HOLDER, EDGE GUIDE, RIGHT 1
720 1036867 COMPRESSION SPRING, 1.17 2
721 1036874 EXTENSION SPRING, 0.62 2
722 1040595 LEVER, PAPER RETURN, RIGHT 1
723 1040646 EXTENSION SPRING, 0.294 2
724 1040596 ROLLER, LD, SUPPORT 2
725 1040648 HOLDER, ROLLER, LD, SUPPORT, RIGHT 1
726 1040660 PAD ASSY., LEFT 1
727 1030449 LEVER, PAD, RELEASE, LEFT 1
728 1040602 HOLDER, EDGE GUIDE, LEFT 1
729 1040594 LEVER, PAPER RETURN, LEFT 1
730 1040647 HOLDER, ROLLER, LD, SUPPORT, LEFT 1
731 1040658 ROLLER ASSY., LD, LEFT 1
732 1040659 ROLLER ASSY., LD, RIGHT 1
733 1040597 COVER, ROLLER, LD, LEFT 1
734 1040598 COVER, ROLLER, LD, RIGHT 1
735 1036868 COMPRESSION SPRING, 1.961 2
736 1038211 LEVER, FASTEN, EDGEGUIDE; B 2
737 1030959 EXTENSION SPRING, 0.088 2
738 1040601 SHAFT, ROLLER, LD 1
739 1042067 LEVER, HOPPER, RELEASE 2
740 1040607 WHEEL, DETECT 1
741 1030951 LEVER, BRAKE 1
742 1030970 PAD, BRAKE 1
743 1030966 TORSION SPRING, 41.2 1
744 1030456 BUSHING, FASTEN, SHAFT 1
745 1040599 SHEET, PAPER FEED 2
746 1040600 HOLDER, SHEET, PAPER FEED 2
747 1005416 SHAFT, MOUNT, CR 1
748 1032300 C.P.S-TITE(P4), 3X6, F/ZN 1
750 1040588 SPUR GEAR, 34 1
751 1030419 PAPER GUIDE, LOWER 1
752 1030372 POROUS PAD, INK EJECT, LARGE 2
753 1030374 TRAY, POROUS PAD 1
754 1040873 SPACER, TRAY 1

A
STYLUS COLOR 640
Page 3
REF. PART NO. DESCRIPTION QTY
527 1031164 C-RING 3
528 1030967 PLAIN WASHER, 12.2X0.5X15 2
529 1040586 ROLLER, ASSY., PAPER EJECT 1
530 1030422 BUSHING, 6 2
531 B150300711 RETAINING RING 1
532 1030424 SPUR GEAR, 36 1
533 1040576 SPUR GEAR, 11 1
534 1030971 PLAIN WASHER, 4.1X0.5X6.5 2
535 1040585 PAPER GUIDE, FRONT 1
536 1042582 GROUNDING WIRE, EJ 1
538 1040574 FRAME, PAPER EJECT 1
539 1042338 HOLDER, STAR WHEEL, RIGHT 1
540 1042339 HOLDER, STAR WHEEL, LEFT 1
541 1032723 HOLDER, STARWHEEL, FRONT 1
542 1030415 STAR WHEEL ASSY., 8 (NATURAL) 20
543 1033652 STAR WHEEL, 8; B 1
544 1032244 ROD SPRING, STAR WHEEL 14
545 1030408 PAPER GUIDE, UPPER 5
546 1032646 PAPER GUIDE, RIGHT 1
547 1030414 PAPER GUIDE, LEFT 1
548 1030968 SHAFT, PAPER GUIDE, UPPER 6
549 1030969 SHAFT, ROLLER, DRIVEN 6
550 1038961 ROLLER, DRIVEN; D 12
551 1030956 TORSION SPRING, 117.6 6
552 2022329 CIRCUIT ASSY, PE 1
553 1030411 HOLDER, PE 1
554 1030410 LEVER, PE 1
555 1030958 TORSION SPRING, 0.22 1
556 1042648 SHEET, GUIDE PLATE, CABLE 1
557 1040575 GUIDE PLATE, CABLE 1
558 1032719 SHEET, CABLE 1
559 2021854 DETECTOR, HP 1
560 1032426 CARRIAGE ASSY. 1
561 1030380 LEVER, ADJUST 1
562 1030381 GROUNDING PLATE, HEAD 1
563 1030382 OIL PAD 1
564 1030387 SLIDER, CR 1
565 1041884 TIMING BELT 1
566 1030391 SHAFT, CR, GUIDE 1
567 1031313 PULLEY ASSY., DRIVEN 1
568 1030389 HOLDER, PULLEY, DRIVEN 1
569 1030955 COMPRESSION SPRING, 19.6 1
570 1037577 LEVER, PG 1
571 1030395 LEVER, PG, SUPPORT 1
572 1032240 TORSION SPRING, 63.7 1
573 1040653 COMBINATION GEAR 6, 34.4 1
574 1040652 COMBINATION GEAR 8, 30 1
576 1034669 POROUS PAD, SLIDER, CAP 1
577 1040644 BUSHING, FASTEN, COMBINATION GEAR 1
578 1023219 PUSHING NUT, 2 1
579 2028816 HARNESS, HP 1
580 2028815 HARNESS, PE 1
581 2028817 HARNESS, ASF 1
586 1015240 C.C.S.SCREW 2
587 B300204211 C.B.S. SCREW 19
588 1032300 C.P.S-TITE(P4), 3X6, F/ZN 2

A
STYLUS COLOR 640
Page 2
REF. PART NO. DESCRIPTION QTY
D4 2014230 DIODE 1
F1 X502036070 FUSE 1
IC1 2023322 MICRO CONTROLLER, TMP95C061BF 1
IC10 2024977 TIMER IC 1
IC11 2014681 EEPROM, AT93C46-10SC 1
IC14 2017973 HIC 1
IC2 2026760 GATE ARRAY 1
IC3 X630114030 IC SOCKET 1
IC5 2023181 D-RAM 1
IC7 2026633 HIC, H8D2813E 1
IC9 2024507 RESET IC, M62030FP 1
Q1 2019965 TRANSISTOR 1
Q7 1040157 HEAT SINK 1
Q7 2024208 TRANSISTOR 1
Q8 1040157 HEAT SINK 1
Q9 1040157 HEAT SINK 1
Q9 2024209 TRANSISTOR 1
R166 2006289 CHIP RESISTOR 1
R167 2006289 CHIP RESISTOR 1
R22 X193211012 CHIP RESISTOR 1
R53 X193211012 CHIP RESISTOR 1
R84 2024308 METAL FILM RESISTOR 1
R93 2024307 METAL FILM RESISTOR 1
300 2025775 BOARD ASSY., POWER SUPPLY 1
330 2023343 WIRE HARNESS 1
400 2006741 POWER CABLE, BS31303SA-SR-10A 1
401 2018028 HARNESS 1
450 2023066 BOARD ASSY., PANEL 1
500 2028550 PRINTER MECHANISM(ASP) M4L10-100 1
501 1040655 FRAME ASSY., LEFT 1
502 2028086 MOTOR ASSY., PF 1
503 1039368 SPUR GEAR, 23.2 1
504 1030453 COMBINATIONGEAR, 16, 40.8 1
505 1030343 FRAME, RIGHT 1
506 1040571 FRAME, TOP 1
507 1031323 MOTOR ASSY, CR 1
508 1040515 PUMP ASSY. 1
509 1042881 CAP ASSY. 1
510 1030345 FRAME, BOTTOM 1
511 1032969 SHEET, PROTECTION, HEAD 1
512 1030344 FRAME, FRONT 1
513 1030392 BUSHING, PARALLELISM ADJUST, LEFT 1
514 1030393 BUSHING, PARALLELISM ADJUST, RIGHT 1
515 1030417 PAPER GUIDE, REAR 1
516 1041663 ROLLER, PF 1
517 1030957 COMPRESSION SPRING, 5.85 1
518 1037093 BUSHING, 12, LEFT 1
519 1030454 LEVER, CHANGE 1
520 1030452 SPUR GEAR, 26.4 1
521 1030975 SPACER, C-RING 2
522 1032301 SCALLOP SPRING PIN-AW, 2X16, F/B 1
523 1030965 COMPRESSION SPRING, 0.9 1
524 1030402 SPUR GEAR, 67.2 1
525 1037094 SPACER, FASTEN, ROLLER, PF 1
526 1037095 SPACER, FASTEN, ROLLER, PF; B 1

A
STYLUS COLOR 640
(INCLUDES DETAILS OF NEWLY-AVAILABLE PRINT-HEAD KITS)
Page 1
SHADED ROWS IINDICATE MAJOR ITEMS
REF. PART NO. DESCRIPTION QTY
100 1039820 HOUSING; B 1
101 1039830 COVER, PRINTER; B 1
102 1040615 PAPER SUPPORT; B 1
103 1039828 STACKER ASSY.; B 1
104 1039829 PANEL ASSY., RIGHT; B 1
105 1030603 SHIELD PLATE, PANEL 1
106 1039827 HOUSING, PANEL, LEFT; B 1
107 1037312 BUTTON, P/S; B 1
108 1030669 GROUNDING PLATE 2
109 1030609 COVER, SHIELD PLATE, M/B, RIGHT 3
110 1030610 COVER, SHIELD PLATE, M/B, LEFT 1
111 1030608 COVER, CABLE 2
112 1037313 COVER, INLET, UPPER; B 1
113 1037314 COVER, INLET, LOWER; B 1
114 1032587 SHIELD PLATE, M/B; C 1
115 1041678 LOGO PLATE 1
116 1038233 HOUSING, SUPPORT, RIGHT; B 1
117 1038234 HOUSING, SUPPORT, LEFT; B 1
119 1033230 FOOT 5
121 B010103311 C.P.SCREW 2
122 B300204211 C.B.S. SCREW 23
123 1032538 C.B.(O) SCREW, 4X5, F/ZG 1
124 B300204411 C.B.S. SCREW 4
125 1005019 C.B.P-TITE SCREW, 3X8, F/ZN 3
126 1012350 C.B.P-TITE, 3X10, F/ZN 2
128 1031165 MINI CLAMP 1
180 1041680 LABEL CAUTION 1; B 1
183 1037833 LABEL LEVER CART. BLACK 1
184 1037835 LABEL LEVER CART. COLOUR 1
200 2027863 BOARD ASSY., MAIN 1
IC3 2029011 EP-ROM, TDZ00 1
BAT1 2027639 BATTERY HOLDER 1
BAT1 X505000700 LITHIUM BATTERY 1
BAT1 Y502002001 SPONGE TAPE 1
C15 2004332 ELECTROLYTIC CAPACITOR 1
C16 2023447 ALUMINIUM ELECTROLYTIC CAPACITOR 1
C27 2023050 ALUMINIUM ELECTROLYTIC CAPACITOR 1
C42 2023447 ALUMINIUM ELECTROLYTIC CAPACITOR 1
C59 2023447 ALUMINIUM ELECTROLYTIC CAPACITOR 1
C65 2004332 ELECTROLYTIC CAPACITOR 1
C66 2004332 ELECTROLYTIC CAPACITOR 1
CN1 2013284 CONNECTOR 57RE-40360-830B(D7B) 1
CN10 2005704 CONNECTOR 1
CN11 2007079 PHOTO MICROSENSOR 1
CN3 2023034 CONNECTOR 1
CN4 2022864 CONNECTOR 1
CN5 X600440310 CONNECTOR 1
CN6 2017936 CONNECTOR 1
CN7 2017936 CONNECTOR 1
CN8 2023336 CONNECTOR 1
CR1 2021879 CERAMIC OSCILLATOR 1
CR2 2023326 CERAMIC OSCILLATOR 1
CR3 2023154 QUARTZ OSCILLATOR 1
D1 2002872 DIODE 1
D2 2014230 DIODE 1

REV. 04 10002
103
400
123
400 for EAI
400 for ETT
100
124
101
115
126
751
752
752
753
500
126
125
125
105
450
107
122
122
106
124
180
182
for LATIN
124
124
401
EXPLODED DIAGRAM FOR EPSON STYLUS COLOR 640 (1/3)
for EUR,S.E.ASIA,OCEANIA,EKL,RUSSIA
102 for USA
102 for EUR.,S.E.ASIA,OCEANIA
EKL,RUSSIA
104
181
for LATIN
185
for CHINA
769

B
B
C
A
C
A
D
586
501
502
587
503
750
587
504
725
724
732
734
733
731
724
745
746
746
742
741 720 729
723
736
737 738
735
739
728
718
726 727 709
764
712 711
707
713 708
714 703
703
710
736
739
748
737
744
740
747
763
721
720
735
722 723
719
718
716
717
565
506
587
558
587
556
587
557
758
756
757
559 587
505 122
116
108
108
114
121
112
122
110
122
579
580
581
330
510
128
511
122
122
122
200
122
122
122
122
587
122
300
111
111
113
121
587
569
568
721
755
743
730
534
530
587
532
574
578
573
590
EXPLODED DIAGRAM FOR EPSON STYLUS COLOR 640 (2/3) REV. 03 10002
577
122
567
766 without 747,748
with 581
