Epson U925 - TM B/W Dot-matrix Printer User manual

THERMAL LINE PRINTERS
Extremely fast, quiet output and exceptionally clear characters are just some of the advantages of thermal printers.
There's no need to change the ribbon because printing is performed directly onto the paper.
Paper loading is easy due to a simplified paper path.
And printing is possible on a ide range of media, including polypropylene and clear labels.
Outstanding Performance & Versatility
Prints everything from slips and receipts to journals.
Ultra-fast output of up to 88 columns on A4-size paper
ith bi-directional, logic-seeking printing.
Reliability & Convenience
The reliability is there. Plus a ide range of handy
features including automatic paper cutting
and easy paper loading and ribbon changing.
Fast & Super Quiet
Throughput is fast thanks to bi-directional minimum
distance printing.
Quieter than other impact dot matrix printers of its class.
Handy Features
ASB (Automatic Status Back) function automatically
transmits changes in printer status.
Also offers the convenience of t o- ay paper loading.
TM-U675
9-pin, serial dot
TM-U950/U925
9-pin, serial dot
Versatile Printer For Large POS Systems
High-Performance, Multi-Purpose Printer
atrix
3 cps
.0,
0.36)
rs
s
ble)
ss B
15
N),
ss B
Print method 9-pin serial impact dot matrix
Print font Font 5 x 9 / 7 x 9
Column capacity (columns) Receipt: 37 / 50, Slip / Validation: 45 / 60
Character size (mm) 1.56 (W) x 3.1 (H) / 1.24 (W) x 3.1 (H)
Character set 95 Alphanumeric, 37 International,
128 x 12 Graphic
Characters per inch 13.3 cpi / 17.8 cpi
Interfaces
RS-232, Bi-directional parallel,
Dealer option: RS-485, USB, 10 Base-T I/F
Data buffer 4 KB or 45 bytes
Print speed Approx. 5.14 lps (at 40 columns, 17.8 cpi)
Paper Dimensions (mm) Roll paper: 82.5 ±0.5 (W) x dia. 83.0
Slip: 70 (W) x 150 (L) to 148 (W) x 297 (L)
Validation: 148 (W) x 70 (L) to 150 (W) x 210 (L)
Thickness (mm) Roll paper: 0.06 to 0.085 / sheet
Slip: 0.09 to 0.2 (total thickness: 0.09 to 0.31)
Copy capability One original and two copies
Inked ribbon ERC-32 (Purple, Black)
Ribbon life Purple: 6 x 106 characters , Black: 4 x 106 characters
Power 24 VDC ±10%
Power consumption Approx.1.8 A (mean)
D.K.D.function 2 drivers
Reliability MTBF: 18 x 104hours MCBF: 37 x 106lines
Overall dimensions (mm) 186 (W) x 298 (D) x 195 (H)
Mass (Approx.) 5.8 kg
EMI standards
VCCI class A, FCC class A, CE marking, AS / NZS 3548 class B
Power supply PS-170 (option)
Factory options MICR device, Autocutter
Safety standards UL / CSA / TÜV (EN60950)
Print method 9-pin, serial impact dot matrix
Print font Font 7 x 9 / 9 x 9
Column capacity (columns) Receipt (Journal): 40 / 30, Slip: 88 / 66 (TM-U950)
Receipt: 40 / 30, Slip: 88 / 66 (TM-U925)
Character size (mm) 1.3 (W) x 3.1 (H) / 1.6 (W) x 3.1 (H)
Character set 95 Alphanumeric, 32 International,
128 x 8 Graphic
Characters per inch 16.7 cpi / 12.5 cpi
Interfaces RS-232, Bi-directional parallel (TM-U950)
RS-232 (TM-U925)
Data buffer 2 KB or 32 bytes
Print speed 311 / 233 cps
Paper Dimensions (mm)
Receipt (Journal): Roll paper: 69.5 ±0.5 (W) x dia. 83.0
Slip: 70 (W) x 70 (L) to 210 (W) x 297 (L) (TM-U950)
Receipt: Roll paper: 69.5 ±0.5 (W) x dia. 83.0
Slip: 70 (W) x 70 (L) to 210 (W) x 297 (L) (TM-U925)
Thickness (mm)
Receipt (Journal): 0.06 to 0.09, Slip: 0.09 to 0.36 (TM-U950)
Receipt: 0.06 to 0.09, Slip: 0.09 to 0.36 (TM-U925)
Copy capability One original and four copies (for slip)
Inked ribbon ERC-31 (Purple, Black)
Ribbon life
Purple: 7 x 106 characters, Black: 4.5 x 106 characters
Power 24 VDC ±10%
Power consumption Approx. 1.8 A (mean)
D.K.D.function 2 drivers
Reliability MTBF: 18 x 104hours
MCBF: 18 x 106lines
Overall dimensions (mm)
251 (W) x 298 (D) x 194.5 (H) (TM-U950), 251 (W) x 298 (D) x 193.7 (H) (TM-U925)
Mass (Approx.) 5.6 kg
EMC standards
VCCI class A, FCC class A, CE marking, AS / NZS 3548 class B
Power supply PS-170 (option)
Factory options MICR device
Safety standards UL / CSA / TÜV (EN60950)
