Epson Stylus®Pro GS6000
REDEFINING THE FUTURE OF PRINTING
64"
Introducing the all-new Epson Stylus Pro GS6000 | The world’s most advanced 64-inch wide, solvent-based printer.
Epson Stylus Pro GS6000 Print Engine Specifications
Base Printing Technology
Dual-Array MicroPiezo AMC Print Head
with Ink-repelling Coating Technology
8-channel, drop-on-demand, ink jet
8 cartridges (C, M, Y, K, Lc, Lm, Orange and Green)
Epson UltraChrome GS ink
Professional-level solvent-based ink technology
Printer Nozzle Configuration
Color and Monochrome 360 nozzles x 8
Smallest droplet size 3.7 picoliters
Printer Resolutions
1440 x 1440 dpi; 1440 x 720 dpi; 720 x 720 dpi;
540 x 720 dpi; 720 x 360 dpi
Print Engine SpeedsA
1440 x 1440 dpi, 16-pass 32 SFPH
1440 x 720 dpi, 8-pass 71 SFPH
720 x 720 dpi, 8-pass 91 SFPH
540 x 720 dpi, 6-pass 122 SFPH
720 x 720 dpi, 4-pass 180 SFPH
720 x 360 dpi, 2-pass 340 SFPH
Typical Print Engine SpeedsA
Fine Art Reproduction 71 SFPH
Decorative Fine Art Reproduction 91 SFPH
Photo Quality Vehicle Wraps 91 SFPH
Everyday Sigange Production 180 SFPH
Typical Outdoor Banners 340 SFPH
Acoustic Noise Level
Approximately 70 dB(A) according to ISO 7779
Front-End RIP Workflow by ColorBurst
Standard PANTONE licensed PostScript Language Level 3
Compatible RIP by ColorBurst. Includes full workflow
software with layout, nesting, tiling, custom spot color
management and custom media support with full ICC
profiling software included.
The Epson Stylus Pro GS6000 is also supported by most
leading third-party RIPs and workflows.
ColorBurst RIP Requirements
Server Workstation: Windows Vista®or XP (32-bit)
2.8 GHz Intel®Core 2 Duo or better
4GB memory recommended
Client Workstation(s): Macintosh®10.5.x or higher
Windows Vista or XP (32 or 64-bit)
Printer Interfaces
Includes as standard one Hi-Speed USB 2.0 (1.1 compatible)
and one Gigabit Ethernet port (10/100/1000Base-T)
Dimensions
106"(W) x 50"(D) x 41"(H)
Printer weight: 445 lb
Dimensions and weight include printer stand and take-up reel
Limited Warranty and Service
Standard one-year, on-site, usually next business day service
with toll-free phone support Monday through Friday
Optional one-and two-year extended Epson Preferred PlusSM
service programs available for purchase
Printable Area
Maximum media width 64"
Left and right margins 0.20" (0.40" total)
Maximum printable width 63.60"
Maximum printable length Limited by software application,
OS, media length, and driver/RIP
Media Handling
Media input Single roll-to-roll up to 64" wide
Cut-sheet size 17" x 22" up to 64" wide
Media core compatibility Handles 3"cored media
Max. roll media diameter Up to 6.7" and 66 lb
Weight 12 lb bond up to 1.3 mm thick
posterboard
Manual head height 1.5 or 2.5 mm
Platen tension settings Normal and high
Roll media take-up reel Fully automatic with tension bar
Roll media output weight Up to 150 lb
Media Heating System
Pre-heater Off or 86˚ to 122 ˚F (off or 30˚ to 50 ˚C)
Platen-heater Off or 86˚ to 122 ˚F (off or 30˚ to 50 ˚C)
Post-heater Off or 86˚ to 122 ˚F (off or 30˚ to 50 ˚C)
Independently controlled via front control panel or front-end RIP
Epson Intelligent Ink CartridgesB
Cartridge fill volume 950 ml each color x 8 colors total
Ink cartridge shelf life 2 years from printed production
(recommended) date or 6 months after open
Hot-swappable buffer time Approx. 3 minutes
Image Permanence Ratings
Epson UltraChrome GS Ink Outdoor permanence ratings
are provided by 3M and Avery.
Please visit their websites for
more information.
Environmental Characteristics
Temperature
Operating 50˚ to 95 ˚F (10˚ to 35 ˚C)
Storage -4˚ to 104 ˚F (-20˚ to 40 ˚C)
Relative humidity 20 to 85%
Operating 40 to 50%
Recommended storage 5 to 85% (no condensation)
Installation requirements Virtually any location with a
typical air conditioning or other
air ventilation system.
No forced ventilation or air
purification systems required.
Safety Standards and EMI
UL (MET), FCC (Class A), CSA, TSCA, OSHA, CE, and EMC
Electrical Requirements
Voltage AC 100 – 120 V, AC 200 – 240 V
Frequency 50 – 60 Hz
Current 11A at AC 110 –120 V or
6A at AC 200 – 240 V
Power consumption
Operating Approx. 680 W or less
Standby Less than 48 W or less
Power Off Less than 3 W or less
Product/Accessories Part Numbers
Epson Stylus Pro GS6000 Production Edition SPGS6000PE
(includes ColorBurst RIP, stand, and take-up reel)
Additional One-year Epson Preferred Plus Service EPPGS6KB1
Additional Two-year Epson Preferred Plus Service EPPGS6KB2
Print Head Cleaning Kit
(for periodic print head cleaning) C890621
Additional Printer Maintenance Kit
(same kit that comes with a new printer) C890611
Additional Cleaning Cartridges (set of eight)
(for periodic print head washing) T623900
Waste Ink Bottle (set of 6) CBOTTLE
Additional 64-inch Wide Media Take-up Core C64CORE
Epson UltraChrome GS Ink (950 ml)
Black Ink Cartridge T624100
Cyan Ink Cartridge T624200
Magenta Ink Cartridge T624300
Yellow Ink Cartridge T624400
Light Cyan Ink Cartridge T624500
Light Magenta Ink Cartridge T624600
Green Ink Cartridge T624700
Orange Ink Cartridge T624800
Epson America, Inc.: 3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.: 3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Internet website: www.proimaging.epson.com
Specifications and terms are subject to change without notice. Epson, Epson Stylus, MicroPiezo and Epson UltraChrome
are registered trademarks and Epson Exceed Your Vision is a registered logomark of Seiko Epson Corporation. AMC is
a trademark and Epson Preferred and myepsonprinter.com are service marks of Epson America, Inc. All other product
and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and
all rights in these marks.
Copyright 2008, Epson America, Inc. CPD 25390 8/08
©2008 Mark Laita
A Based upon print engine speed only. Total throughput times depend upon front-end
RIP, file size, printer resolution, ink coverage, networking, etc. All print speeds are
based upon bi-directional printing.
B Cartridge yields vary considerably based on images printed, print settings, paper type,
frequency of use and temperature. For print quality, a variable amount of ink remains
in the cartridge after the "Replace cartridge" indicator comes on. The printer ships with
a full set of cartridges and part of the ink from the first cartridges is used for priming
the printer. Printer ships with 350 ml cartridges.
See www.epson.com/cartridgeinfo for more information about cartridges.
