Epson 1810p - PowerLite XGA LCD Projector User manual

PowerLite®1810p
Multimedia Projector
User’sGuide

2
Important Safety Information
WARNING: Never look into the projector lens when the lamp is turned on; the bright light can damage your eyes.
Never let children look into the lens when it is on. Never open any cover on the projector, except the lamp and
filter covers. Dangerous electrical voltages inside the projector can severely injure you. Except as specifically
explained in this User’s Guide, do not attempt to service this product yourself. Refer all servicing to qualified service
personnel.
WARNING: The projector and its accessories come packaged in plastic bags. Keep plastic bags away from small
children to avoid any risk of suffocation.
Caution: When you replace the lamp, never touch the new lamp with your bare hands; the invisible residue left by
the oil on your hands may shorten the lamp life. Use a cloth or glove to handle the new lamp.
Copyright Notice
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in
any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior
written permission of Seiko Epson Corporation. The information contained herein is designed only for use with
this Epson product. Epson is not responsible for any use of this information as applied to other products.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for
damages, losses, costs, or expenses incurred by purchaser or third parties as a result of: accident, misuse, or abuse of
this product or unauthorized modifications, repairs, or alterations to this product, or (excluding the U.S.) failure to
strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or
any consumable products other than those designated as Original Epson Products or Epson Approved Products by
Seiko Epson Corporation.
Trademarks
Epson, Quick Corner, and Instant Off are registered trademarks, and Exceed Your Vision and EasyMP are
trademarks, of Seiko Epson Corporation.
PrivateLine, Presenters Club, and PowerLite are registered trademarks; SizeWise is a trademark; and Epson Store
and Epson Extra Care are service marks of Epson America, Inc.
Pixelworks, DNX, and the DNX logo are trademarks of Pixelworks, Inc.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of
their respective owners. Epson disclaims any and all rights in those marks.
© 2007 Epson America, Inc. 1/07

3
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using Your Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Getting More Information . . . . . . . . . . . . . . . . . . . . . . . . 8
Registration and Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Unpacking the Projector. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Additional Components. . . . . . . . . . . . . . . . . . . . . . . . . 10
Optional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Displaying and Adjusting the Image . . . . . . . . 13
Positioning the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Turning On and Off the Projector . . . . . . . . . . . . . . . . . . . . 15
Using the Direct Power On Function . . . . . . . . . . . . . . 17
Shutting Down the Projector . . . . . . . . . . . . . . . . . . . . . 18
Displaying an Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting Display Problems. . . . . . . . . . . . . . . . . . . . 19
You Can’t Project an Image . . . . . . . . . . . . . . . . . . . . . . 19
The Projector and Notebook Don’t Display
the Same Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Adjusting the Height of the Image . . . . . . . . . . . . . . . . . 21
Focusing and Zooming the Image . . . . . . . . . . . . . . . . . 22
Adjusting the Image Shape. . . . . . . . . . . . . . . . . . . . . . . 22
Selecting the Color Mode . . . . . . . . . . . . . . . . . . . . . . . 25
Resizing Video Images . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Presenting with the Remote Control. . . . . . . . . 27
Using the Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Controlling the Picture and Sound. . . . . . . . . . . . . . . . . . . . 28
Switching Between Picture Sources . . . . . . . . . . . . . . . . 28

4
Turning Off the Picture and Sound. . . . . . . . . . . . . . . . 29
Stopping Action. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Zooming Part of Your Image . . . . . . . . . . . . . . . . . . . . . 30
Controlling the Volume. . . . . . . . . . . . . . . . . . . . . . . . . 31
Highlighting Your Presentation . . . . . . . . . . . . . . . . . . . . . . 31
Using the Pointer Tool . . . . . . . . . . . . . . . . . . . . . . . . . 31
Customizing the Pointer Tool . . . . . . . . . . . . . . . . . . . . 32
Operating Your Computer with the Remote Control . . . . . . 32
Operating Two or More Projectors with the
Remote Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Setting the Projector ID. . . . . . . . . . . . . . . . . . . . . . . . . 33
Setting the Remote Control ID . . . . . . . . . . . . . . . . . . . 34
Connecting to Computers and
Other Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Connecting to a Computer. . . . . . . . . . . . . . . . . . . . . . . . . . 36
Connecting to the Computer Port . . . . . . . . . . . . . . . . . 36
Connecting the Cable for Remote Mouse Control . . . . 37
Connecting to Video Equipment . . . . . . . . . . . . . . . . . . . . . 38
Connecting a Composite Video Source . . . . . . . . . . . . . 39
Connecting an S-Video Source . . . . . . . . . . . . . . . . . . . 40
Connecting a Component Video Source . . . . . . . . . . . . 41
Connecting an RGB Video Source. . . . . . . . . . . . . . . . . 42
Connecting an External Monitor . . . . . . . . . . . . . . . . . . . . . 43
Playing Sound Through the Projector . . . . . . . . . . . . . . . . . 44
Connecting External Speakers . . . . . . . . . . . . . . . . . . . . 45
Fine-Tuning the Projector. . . . . . . . . . . . . . . . . . . 47
Using the Menu System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Restoring the Default Settings . . . . . . . . . . . . . . . . . . . . 49
Adjusting the Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Six-Axis Color Adjustment. . . . . . . . . . . . . . . . . . . . . . . 51
Adjusting Signal Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Customizing Projector Features . . . . . . . . . . . . . . . . . . . . . . 54
Using the Projector Security Features . . . . . . . . . . . . . . . . . . 55
Enabling Password Protection . . . . . . . . . . . . . . . . . . . . 55
Creating Your Own Startup Screen . . . . . . . . . . . . . . . . 57

5
Disabling the Projector’s Buttons. . . . . . . . . . . . . . . . . . 59
Customizing Power and Operation. . . . . . . . . . . . . . . . . . . . 60
Multi-screen Color Adjustment . . . . . . . . . . . . . . . . . . . . . . 62
Maintaining the Projector. . . . . . . . . . . . . . . . . . . 63
Cleaning the Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Cleaning the Projector Case . . . . . . . . . . . . . . . . . . . . . . . . . 64
Cleaning the Air Filter and Vent. . . . . . . . . . . . . . . . . . . . . . 65
Replacing the Lamp and Air Filter . . . . . . . . . . . . . . . . . . . . 66
Resetting the Lamp Timer . . . . . . . . . . . . . . . . . . . . . . . 69
Checking Lamp Usage . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Replacing the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Transporting the Projector . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Using On-Screen Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Checking Projector Status. . . . . . . . . . . . . . . . . . . . . . . . . . . 75
What To Do When the Lights Flash . . . . . . . . . . . . . . . 75
Solving Projector Operation Problems . . . . . . . . . . . . . . . . . 77
Solving Problems with the Image or Sound . . . . . . . . . . . . . 77
Solving Problems with the Remote Control . . . . . . . . . . . . . 83
Where To Get Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Speak to a Support Representative . . . . . . . . . . . . . . . . . 84
Projector Installation . . . . . . . . . . . . . . . . . . . . . . . . 87
Technical Specifications . . . . . . . . . . . . . . . . . . . . . 89
Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . 95
FCC Compliance Statement. . . . . . . . . . . . . . . . . . . . . . . . . 97
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

6

7
-
Welcome
The PowerLite®1810p is an easy-to-use projector that weighs less
than 7 pounds. The projector offers up to 3500 lumens of brightness.
You can connect it to a wide range of computers and video sources.
Easy setup, control, and security:
■5-second startup time and Instant Off ®feature for fast setup and
shut down
■Automatic digital keystone correction
■1.6x optical zoom lens for flexible placement and positioning
■Security features include password, user’s logo, and the ability to
lock the projector buttons
■A/V mute slide (lens cover) to block the lens and save lamp life
when you want to temporarily stop projecting

8Welcome
Using Your Documentation
This book contains all the information you need to set up and use
your projector. Please follow these guidelines as you read through it:
■Warnings must be followed carefully to avoid bodily injury.
■Cautions must be observed to avoid damage to your equipment.
■Notes contain important information about your projector.
■Tips contain additional projection hints.
Getting More Information
Need tips on giving presentations? Quick steps for setting up your
projector? Here’s where you can look for help:
■Quick Setup sheet
Gives you the instructions you need to get your projector up and
running if you are connecting to a notebook, MacBook,TM
PowerBook,
®
or iBook®computer.
■Projector kit
Includes this User’s Guide, your Quick Setup sheet, warranty
brochures, and Epson PrivateLine®Support card. Keep the kit
with your projector at all times.
■Built-in help system
Provides assistance for common problems. Available from the
Help button on the projector or the remote control. See page 74
for details.
■epson.com/support
Download FAQs and e-mail your questions to Epson support.
■If you still need help after checking this User’s Guide and the
sources listed above, you can use the Epson PrivateLine Support
service to get help fast. Call [phone] and enter the PIN on
the PrivateLine card. Or take advantage of Epson’s automated
support services 24 hours a day. See page 83 for more
information.

Welcome 9
■presentersonline.com
Includes a library of articles covering presentation tips, tricks, and
technology. The site provides templates, clip art and sound clips,
as well as Presenters Services to use on the road. Even more
resources and services are available if you register to join the
Presenters Club®—and it’s free.
Registration and Warranty
Your projector comes with a basic carry-in 2-year and 90-day lamp
warranty as well as an international warranty that let you project with
confidence anywhere in the world. For details, see the warranty
brochures included with your projector.
In addition, for customers who register their projector, Epson offers
free Extra CareSM Road Service. In the unlikely event of an equipment
failure, you won’t have to wait for your unit to be repaired. Instead,
Epson will ship you a replacement unit anywhere in the United States
or Canada, usually via overnight delivery. See the brochure included
with your projector for details.
To register, simply fill out the registration card and mail it to Epson.
Or you can register online at epson.com/webreg. Registering also lets
you receive special updates on new accessories, products, and service.

10 Welcome
Unpacking the Projector
After unpacking the projector, make sure you have all these parts:
Save all packaging in case you need to ship the projector. Always use
the original packaging (or the equivalent) when you need to send the
projector to another location. If you are moving the projector by
hand, use the carrying case. See page 11 for ordering information, and
page 71 for transportation instructions.
Additional Components
Depending on how you plan to use the projector, you may need
additional components:
■To receive an S-video signal, you’ll need an S-video cable.
■To receive a component video signal from a VCR or other video
device, you’ll need an HD15 to component video cable.
You can purchase these items from Epson. See “Optional Accessories”
on page 11.
Projector
Remote control and
2 AAA batteries
Power cable VGA computer cable
Carrying case
PDF manual and
registration CD-ROM

Welcome 11
Optional Accessories
To enhance your use of the projector, Epson provides the following
optional accessories:
You can purchase screens or other accessories from an Epson
authorized reseller. To find the nearest reseller, call 800-GO-EPSON
(800-463-7766). Or you can purchase online at www.epsonstore.com
(U.S. sales) or www.epson.ca (Canadian sales).
Product Part number
Replacement lamp V13H010L40
Air filter replacement set (2 filters) V13H134A08
Universal ceiling mount
False ceiling plate
Security bracket/cabling for gyro lock mounts
Adjustable ceiling channel
Suspension adapter
ELPMBUNI
ELPMBFCP
ELPMBSEC
ELPMBACC
ELPMBAPL
Kensington®security lock ELPSL01
50-inch portable screen (4:3 aspect ratio)
60-inch portable pop-up screen (4:3 aspect ratio)
80-inch portable pop-up screen (4:3 aspect ratio)
83.6-inch hanging pull-down screen (4:3 aspect ratio)
DUET Portable Projector Screen (4:3/16:9 combination)
ELPSC06
ELPSC07
ELPSC08
ELPSC09
ELPSC80
HD-15 to component video cable
S-video cable
ELPKC19
ELPSV01
Distribution amplifier ELPDA01
Image presentation camera (ELPDC05) V12H162020

12 Welcome

13
1
Displaying and Adjusting
the Image
Whether you’re presenting from a computer or video equipment,
you need to follow some basic steps to display your image on the
screen.
Follow the guidelines in this chapter for:
■Positioning the projector
■Turning on and off the projector
■Displaying an image
■Troubleshooting display problems
■Adjusting the image

14 Displaying and Adjusting the Image
Positioning the Projector
If the projector isn’t already installed in the room you’re using, you’ll
probably want to place it on a table in front of the screen, as shown.
This lets you stand in the front of the room, face the audience, and
remain close enough to the equipment to be able to control it. Try to
leave as much space as possible between the projector and the screen to
get a good-size image.
Use the figure below to help you determine placement. Image size
increases with distance, but can vary depending on how you position
the zoom ring and whether you’ve adjusted the image with other
settings.
Also keep these considerations in mind:
■Place the projector on a sturdy, level surface.
■Make sure there is plenty of space for ventilation around and
under the projector. Do not set the projector on top of anything
that could block the vents under the projector.
■Make sure the projector is within 10 feet of a grounded electrical
outlet or extension cord.
note
You can mount the projector
on the ceiling, or place it
behind a translucent screen
for rear projection. See
page 87 for details.
2.7 to 4.6 ft5.7 to 9.4 ft29.7 to 48.2 ft Distance from screen
TBD

Displaying and Adjusting the Image 15
Ideally, you should place the projector directly in front of the center of
the screen, facing it toward the screen squarely. The base of the lens
should be at about the level of the bottom of the screen.
If you place the projector below screen level, you’ll have to tilt it up by
extending the front adjustable foot. This causes the image to become
“keystone” shaped, but you can correct the distortion (see page 22).
For instructions on installing the projector in a permanent location,
such as a theater or conference room, see page 87.
Turning On and Off the Projector
Turn on any connected computer or video equipment before starting
the projector so it can automatically detect and display the image
source. If you turn on the projector first, or have multiple pieces of
connected equipment, you may have to select the image source
manually (see page 18).
note
After positioning the
projector, you may want to
connect a Kensington
MicroSaver®anti-theft
device to the lock port on the
projector. You can purchase
this from Epson; see
page 11.
Screen
Projector

16 Displaying and Adjusting the Image
Follow these steps to turn on the projector:
1. Open the A/V mute slide (lens cover).
2. Plug one end of the power cable into the projector, and the other
end into an electrical outlet.
The Power light turns orange.
note
You can set the projector to
automatically turn off the
projector lamp and enter
“sleep mode” when it has
not received any signals for
30 minutes. This conserves
electricity, cools the
projector, and extends the
life of the lamp. If you want
to start projecting again,
press the PPower button.
If you are done using the
projector, unplug the power
cord. To enable sleep mode,
see page 60.
Power light

Displaying and Adjusting the Image 17
3. Press the PPower button on the remote control or on top of the
projector.
The projector beeps once and the Power light flashes green as the
projector warms up, then an image begins to appear. When the
Power light stops flashing and remains green, the projector is
ready for use.
4. If you are prompted to enter a password, see page 57.
Using the Direct Power On Function
The Direct Power On function enables faster setup. The projector
starts up automatically when you plug it in or turn it on with a wall
switch. You don’t have to press the PPower button.
Follow these steps to enable Direct Power On:
1. Press the Menu button on the remote control or projector and
select the Extended menu.
2. Choose Operation and press Enter.
3. Choose Direct Power On and press Enter.
4. Highlight On and press Enter.
5. Press Menu to exit. The setting will take effect the next time you
plug in the projector.
warning
Never look into the lens
when the lamp is on. This
can damage your eyes, and is
especially dangerous for
children.
note
If a power outage occurs
when Direct Power On is
enabled and the projector is
plugged in, the projector will
start when the power is
restored.

18 Displaying and Adjusting the Image
Shutting Down the Projector
This projector incorporates Instant Off technology. To turn it off, you
can press its PPower button as described below, unplug it, or turn
off a power switch that supplies power to the projector. You don’t
have to wait for the projector to cool off first.
1. To turn off the projector, press the PPower button on the
remote control or projector.
You see a confirmation message.
(If you don’t want to turn it off,
press any other button.)
2. Press the PPower button again. The
projection lamp turns off and you can unplug the power cord.
If you want to turn the projector on again, make sure the orange
Power light is not flashing, then press the PPower button.
Displaying an Image
You may need to select the image source if you have multiple video
sources connected to the projector (such as a computer or DVD
player). Selecting the image source lets you switch between images
input from different pieces of connected equipment.
If you don’t see the image you want, press the Search button on the
remote control or the Source Search button on the projector until
you see the image you want to project.
You can also use the Source buttons on the remote control to switch
between devices connected to the ports identified on each button. The
PowerLite 1810p does not support EasyMP.
TM
note
Lamp life results will vary
depending on mode selected,
environmental conditions,
and usage.
Turn off this product when
not in use to prolong the life
of the projector.

Displaying and Adjusting the Image 19
Troubleshooting Display Problems
Follow these guidelines if you’re having trouble displaying an image.
You Can’t Project an Image
If you don’t see the image you are trying to project, try the following:
■Make sure the cables are connected correctly, as described
beginning on page 35.
■Make sure the Power light is green and not flashing and the A/V
mute slide (lens cover) is open.
■If you’ve connected more than one computer and/or video source,
you may need to press the Source Search button on the
projector’s control panel or Search button on the remote control
to select the correct source. (Allow a few seconds for the projector
to sync up after pressing the button.)
■If you’re using a PC notebook, press the function key on your
keyboard that lets you display on an external monitor. It may be
labeled CRT/LCD or have an icon such as . You may have to
hold down the Fn key while pressing it. Allow a few seconds for
the projector to sync up after changing the setting.
The Projector and Notebook Don’t Display the
Same Image
If you’re projecting from a notebook, and you can’t see your image on
the projection screen and on your computer at the same time, follow
these guidelines.
If you’re using a PC notebook:
■On most systems, there’s a function key that lets you toggle
between the LCD screen and the projector, or display on both at
the same time. It may be labeled CRT/LCD or have an icon such as
. You may have to hold down the Fn key while pressing it.
Allow a few seconds for the projector to sync up after changing
the setting.

20 Displaying and Adjusting the Image
■If the function key doesn’t permit you to display simultaneously
on both screens, you should check your monitor settings to make
sure both the LCD screen and the external monitor port are
enabled.
From the Control Panel, open the Display utility. In the Display
Properties dialog box, click the Settings tab, then click
Advanced. The method for adjusting the settings varies by
brand; you may need to click a Monitor tab, then make sure the
external Monitor port is set as your primary display and/or
enabled. See your computer’s documentation or online help for
details.
If you’re using Mac OS X:
You may need to set up your system to display on the projector screen
as well as the LCD screen. Follow these steps:
1. From the Apple®menu, select System Preferences, then select
Displays.
2. Make sure the VGA Display or Color LCD dialog box is selected.
3. Click the Arrangement (or Arrange) tab.
4. Make sure the Mirror Displays checkbox is selected.
Make sure
Mirror Displays
is checked
