INSTALLATION HANDBOOK
Remote Control Information
Epson PowerLite 410W
1
Using the Remote Control
The remote control lets you access your projector’s features from
anywhere in the room—up to 20 feet (6 m) away. For example, you
can turn the projector on and o, freeze the presentation, zoom in on
a portion of your image, and accessthe menu system. (The projector
menus let you adjust many projector settings; see Chapter 4.)
When using the remote control, stand within 20 feet (6 m) of the
projector. Point the remote control either at the front or back of the
projector or at the screen (the projector’s front sensor can detect
signals bounced o the screen). Press the button for the function you
want to use.
This chapter covers the following information:
Controlling the picture and sound
Replacing the remote control batteries
Controlling the Picture and Sound
You can use the remote control to select your source, adjust the colors,
temporarily turn o the picture and sound, freeze the action, or zoom
in on the picture. Make sure you have set up your projector and
connected any equipment asdescribed in Chapter 1.
Switching Between Picture Sources
If you’ve connected your projector to more than one computer and/or
video source, you can use the Source Search button on the projector
or remote control to switch between the dierent sources.
After you select a source, the screen goes dark for a moment before the
image appears. The name of the selected source (such as Computer1
or S-Video)appears briey on the screen.
Source Search
button

INSTALLATION HANDBOOK
Remote Control Information
Epson PowerLite 410W
2
Adjusting the Color Mode
You may want to adjust the color mode to select a dierent setting
that isappropriate for the image you’re projecting and the
environment in which you’re projecting it. Press the Color Mode
button on the remote control.
If you’re projecting computer or RGB video images, the default color
mode is Presentation, which is appropriate for full-color
presentations in bright rooms.
The following table lists the color modes available.
You can also use the projector menu system to change the color mode
in the Image menu
Color mode Description
Dynamic Use for projecting the brightest picture.
Presentation Use when you’re projecting a full-color presentation in
a bright room.
Theatre Use when projecting movies in a dark room.
Photo Best for projecting still images with vivid color in a
bright room (computer input only).
Sports Best for projecting TV programs in a bright room
(component, composite, or S-Video input only).
sRGB Use when projecting computer images conforming to
the sRGB color standard.
Blackboard Choose thisfixed color mode when you need to
project against a green blackboard.
Whiteboard Choose this fixed color mode when you need to
project against a whiteboard.
Color
Mode
button
Turning Off the Picture and Sound
Press the A/V Mute button on the remote control to turn o the
image and sound and darken your screen. This is useful if you want to
temporarily re-direct your audience’s attention without the distraction
of a bright screen.
To turn o the picture and sound, press the A/V Mute button. The
screen goes dark.
To turn the image and sound back on, press the button again.
You can create an image, such as a company logo or a picture, to
display on the screen whenever you press the A/V Mutebutton.
A/V Mute
button

INSTALLATION HANDBOOK
Remote Control Information
Epson PowerLite 410W
3
Stopping Action
Press the Freezebutton to stop the action in your video or computer
image and keep the current image on the screen. The sound will
continue, however. Also, because the source continues to transmit
signals, you won’t resume the action from the point you paused it.
To restart the action, press the Freezebutton again. Freeze
button
Zooming Your Image
Follow these steps to zoom in on a portion of the image:
1. Press the E-Zoom + button on the remote control.
You see a crosshair indicating the center of the zoom-in area.
2. Use the four “arrow” buttons on the remote control to position
the crosshair in the area you want to enlarge.
3. Continue pressing the E-Zoom + button to enlarge the selected
area up to4 times.
4. While the image is enlarged, you can:
Use the arrow buttons to pan about.
Press the E-Zoom – button to zoom out.
5. When you’re done, press the ESC button to return to the original
size.
Changing the Image’s Aspect Ratio
You can use the Aspect button on the remote control to change the
aspect (width to height) ratio, depending on the input signal.
Auto (video images only)
Automatically sets the aspect ratio according to the input signal.
4:3 ratio images display at 4:3, squeeze-recorded signals display at
16:9, andletterbox signals display at Zoomratio (described
below).
Normal
Displays images using the full projection area and maintains the
aspect ratio of the image. 4:3 ratio images project with black
bands on the sides, 16:9 images project with black bands on the
top and bottom, and 16:10 images use the entire projection area.
16:9
Converts the aspect ratio of the image to 16:9. 4:3 ratio images
are elongated horizontally to t.
E-Zoom
buttons
Arrow
buttons
Aspect
button

INSTALLATION HANDBOOK
Remote Control Information
Epson PowerLite 410W
4
Zoom
Displays images using the full width of the projection area and
maintains the aspect ratio of the image. 4:3 ratio images are cut
o on the top and bottom.
Full
Displays images using the full width of the projection area, but
does not retain the aspect ratio. 4:3 ratio images are elongated
horizontally.
Through
Displays images as is (aspect ratio and resolution are maintained).
Black bands appear if the resolution is 1280 × 800 or less; images
are cut o if the resolution is over 1280 × 800.
Press the Aspect button repeatedly tocycle through the available
options.
You can also change the aspect ratio using the projector’s Signal
menu.

INSTALLATION HANDBOOK
Remote Control Information
Epson PowerLite 410W
5
Replacing the Batteries
The remote control uses two AA alkaline batteries. Follow these steps
when you need to replace them:
1. Press in the tab to remove the battery cover.
2. Remove the old batteries, then insert the new ones as shown.
3. Replace the battery cover. (It should click into place.)
caution
When replacing batteries,
take the following
precautions:
Replace the batteries as
soon as they run out. If a
battery leaks, wipe away
battery uid with a soft
cloth. If uid gets on your
hands, wash them
immediately.
Do not expose batteries to
heat or ame.
Dispose of used batteries
according to local
regulations.
Remove the batteries if
you won’t be using the
remote control for a long
period of time.
note
The remote control
automatically shuts o when
it detects a button being
pressed more than
30 seconds. This conserves
battery life. It can be
helpful, for example, when
the remote is in a carrying
case and the PPower
button is accidentally
pushed.
