Epson 410W - PowerLite WXGA LCD Projector User manual

• Large, engaging presentations, even in small spaces—
 ultra-shortthrowdistancesavesspace;projecta60-inch,
 16:10imagefromjust2feetaway
• Reduced shadows and glare—idealforusewith
 interactivewhiteboards
• Giant widescreen images from your computer or video
source—nativeWXGA(1280x800)resolutionand16:10
 performance
• Super bright and colorful images—2000lumenscolor
 lightoutput,2000lumenswhitelightoutput*
Take your presentations to the next level with incredible short-throw distance and amazing widescreen performance.
PowerLite®
410W
Short-throwProjector
• Powerful sound and communication features, no added
cost—built-in10Wspeaker,closedcaptioningdecoder
• Energy-efficient E-TORL®lamp—lastsupto4000hours**
• Simple and cost-effective installation —optionalwall
 mountforinstallationexibilityandstability
• Easy network monitoring and control—RJ-45
 LAN(withincludedsoftware)andRS-232connectivity
• Rich, vibrant color and reliable performance—3LCD,
 3-chipopticalengine

Epson America, Inc.
3840KilroyAirportWay,LongBeach,CA90806
Specicationsandtermsaresubjecttochangewithoutnotice.EpsonandE-TORLareregisteredtrademarks,EpsonExceedYourVisionisaregisteredlogomarkandBetterProductsforaBetterFutureisatrademarkof
SeikoEpsonCorporation.PowerLiteandPrivateLineareregisteredtrademarks,DuetisatrademarkandEpsonConnectionisaservicemarkofEpsonAmerica,Inc.Allotherproductandbrandnamesaretrademarksand/or
registeredtrademarksoftheirrespectivecompanies.Epsondisclaimsanyandallrightsinthesemarks.Copyright2009EpsonAmerica,Inc.CPD-30279R14/0910K
Epson Canada, Ltd.
3771VictoriaParkAvenue,Toronto,OntarioM1W3Z5
ORDERING INFORMATION
Product Name Product Code UPC
PowerLite410W V11H330020  010343873407
ReplacementLamp V13H010L42  010343864115
ReplacementAirFilter V13H134A13  010343864122
Short-throwProjectorWallMount(ELPMB24) V12H003B24  010343873513
Short-throwProjectorWallMount(ELPMSTPW) ELPMSTPW  010343868380
SPECIFICATIONS
Projection System
Epson3LCD,3-chipopticalengine
Projection Method
Front/rear/wall/ceilingmount
Driving Method
EpsonPoly-siliconTFTActiveMatrix
Pixel Number
1,024,000dots(1280x800)x3
White Light Output*
2000lumens(ISO21118Standard)
Color Light Output*
2000lumens
Aspect Ratio
16:10
Native Resolution
1280x800(WXGA)
Resize
640x480(VGA),800x600(SVGA),
1024x768(XGA),1152x864(SXGA),
1440x900(WXGA+),1400x1050(SXGA+),
1680x1050(WSXGA+),1600x1200(UXGA)
Lamp Type
E-TORL170WUHE
Lamp Life**
Upto4000hours(LowLightOutputMode)
Upto3000hours(HighLightOutputMode)
Throw Ratio Range
0.48'–
 0.66'(16:10)
0.59'–
 0.80'(4:3)
Size
50"–116"
Keystone Correction
Vertical:± 15degrees
Contrast Ratio
Upto500:1
Color Reproduction
16.77millioncolors
PROJECTION LENS
Type
Manualfocus
F-number
1.80
Focal Length
6.48mm
Zoom Ratio
Digital1.0–
 1.35x
OTHER
Display Performance
NTSC:560lines
PAL:560lines(dependsonobservation
ofthemulti-burstpattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/
PAL60/SECAM
Interfaces
Computer/componentvideo:
D-sub15pinx2
S-video:MiniDINx1
Compositevideo:RCAx1
Audioinx3(RCA(L&R)x1,ministereox2)
Variableaudioout:ministereox1
LANnetworking:RJ-45x1
Serial:RS-232cx1
Monitorout:D-sub15pinx1
Speaker
10Wmonaural
Operating Temperature
41˚to95˚F(5˚to35˚C)
Power Supply Voltage
100–240V±10%,50/60HzAC
Power Consumption
251W
Networkon:4.9Wstandby,
Networkoff:4.2Wstandby
Fan Noise
35dB(HighLightOutputMode)
28dB(LowLightOutputMode)
Security
Kensington®-stylelockprovision,
securityanchorbar,
passwordprotectionfunction
WEIGHT AND DIMENSIONS (W x D x H)
Includingfeet:12.9"x10.7"x6.2"
Excludingfeet:12.9"x10.2"x3.7"
Weight:7.9lb/3.6kg
REMOTE CONTROL
Features
Sourcesearch,power,aspect,colormode,
volume,e-zoom,A/Vmute,freeze,menu,
help,auto,enter,esc
Operating Angle
Upper/lower:front:0to+60degrees
Right/left:±30degrees
Rear:-30to+30degrees
Operating Distance
19.7ft(6m)
SUPPORT — THE EPSON CONNECTIONSM
Pre-sales Support
U.S.andCanada 800-463-7766
Internetwebsie www.epson.com
Service Programs
Two-yearprojectorlimitedwarranty,90-day
lamplimitedwarranty,EpsonRoadService
program,EpsonPrivateLine®dedicatedtoll-
freesupport
What's In The Box
Powercord,computercable(VGA),
projectorremotecontrol,batteries,user
manualCD,EMPMonitorCD,QuickSetup
Sheet,PrivateLinesupportcard,registration
cardandpasswordprotectionsticker
ACCESSORY PART NUMBERS
Replacementremote 1456641
Presentationremotecontrol V12H007TOB
Universalprojectorceilingmount ELPMBPJF
Advancedprojectorceiling
mountwithprecisiongear ELPMBPRG
HighSecurityprojectorceiling
mount ELPMBATA
Adjustablesuspendedceiling
channelkit ELPMBP01
Falseceilingplatekit ELPMBP02
StructuralRoundceilingplate ELPMBP03
AdjustableExtensioncolumn
(pipe)8"–11" ELPMBC01
Distributionamplier ELPDA01
Component-to-VGAvideocableELPKC19
S-videocable ELPSV01
SwissGearbackpack ELPKS63
Softshouldercaseforprojector
andlaptop ELPKS61
Moldedhardshellcase ELPKS58
50"portablescreen ELPSC06
60"portablepop-upscreen ELPSC07
80"portablepop-upscreen ELPSC08
Duet™screen ELPSC80
ImagePresentationCamera
(ELPDC05) V12H162020
EpsonDC-10sdocumentcamera ELPDC10S
EpsonDC-06documentcamera
(ELPDC06) V12H321001
Kensingtonsecuritylock ELPSL01
PACKAGING SPECIFICATIONS
PowerLite 410W
Dimensions19.1"x14.1"x11.3"(WxDxH)
Weight13.6lb
Short-throw ProjectorWall Mount (ELPMB24)
Dimensions9.6"x38.4"x15.4"(WxDxH)
Weight28.71lb
Short-throw ProjectorWall Mount (ELPMSTPW)
Dimensions13"x15.5"x54"(WxDxH)
Weight31lb
Replacement Lamp
Dimensions 6.3"x5.6"x5.6"(WxDxH)
Weight0.7lb
MasterCarton
Dimensions28.4"x13.1"x6.8"(WxDxH)
Weight8.8lb
UnitsPerMasterCarton10
Replacement Air Filter
Dimensions 3.9"x1.2"x4.9"(WxDxH)
Weight0.1lb
MasterCarton
Dimensions 12.8"x5.3"x4.7"(WxDxH)
Weight1.2lb
UnitsPerMasterCarton10
*Lightoutputvariesdependingonmodes(colorandwhitelightoutput).WhitelightouputmeasuredusingISO21118standard.
** Lamplifewillvarydependinguponmodeselected,environmentalconditionsandusage.Lampbrightnessdecreasesovertime.
BACK PANEL
S-video
Power
RS-232c
Audio 1
Audio 2
Monitor Out
Speaker
PowerLite410W
Short-throwProjector
Computer 1/Component 1
Computer 2/Component 2
Audio R
Audio L
LAN
FormoreinformationonEpson'senvironmentalprograms,goto
www.epson.com/environment
Audio Out
Composite Video
Audio Out
